INSTALLATION INSTRUCTIONS
CONDENSER FAN MOTOR ASS’Y REPLACEMENT KIT
(P/N 569000321 and 569000322)
on
UN 750 PRE–MIX DISPENSER
Read and understand these instructions thoroughly before installing this kit. Retain these instructions as part of
your equipment manual.
NOTE: Only qualified personnel should install this Kit.
Table 1. Loose-Shipped Parts
Item
No. Part No. Name Qty.
1 569000321
569000322 Condenser Fan Motor Ass’y Kit (120 VAC, 60 Hz, 16 Watts, 1400 RPM) Condenser Fan Motor Ass’y Kit (230 VAC, 50/60 Hz, 16 Watts, 1200 RPM 1 1
2 569000320 Installation Instructions 1
3 690945000 WireTie 1
WARNING: To avoid possible fatal electrical shock or serious injury to Installer, make sure
Dispenser is disconnected from power source before attempting to install this kit.
1. Disconnect electrical power from the Unit.
2. Remove screw securing back and right side grills on the Dispenser, then remove grills.
3. Disconnect condenser fan motor assembly power cord connector from the Dispenser wiring harness con-
nector.
4. Remove four screws securing the condenser fan motor assembly to the refrigeration deck. Remove old
condenser fan motor assembly from the Dispenser.
5. Remove bolt securing the condenser fan blade to the old condenser fan motor shaft, then remove the fan
blade. Discard the old condenser fan motor assembly.
6. Install the condenser fan on the new CONDENSER FAN MOTOR ASS’Y (item 1) shaft and secure with
screw and washer provided with the new condenser fan motor assembly.
7. Install the new condenser fan motor assembly on the Dispenser and secure with four screws.
8. Connect new condenser fan motor assembly power cord connector to mating electrical connector on the
Dispenser wiring harness where the old condenser fan motor assembly was disconnected in step 3.

2569000320
9. Using the WIRE TIE (item 3) provided, secure wiring harness so it does not interfere with the condenser
fan motor blades.
10. Install grills on the on Dispenser and secure screws.
11. Connect electrical power to the Dispenser, then check Dispenser for proper operation.
RETAINING
SCREW (4)
MOUNTING SCREW (3)
(850000283)
FAN MOTOR BRACKET
FAN MOTOR
REFRIGERATION DECK
FAN BLADE
