Cornelius CTP-20 Setup guide

IMICORNELIUSINC.
OneCorneliusPlace
Anoka,MN.55303--6234
Telephone[phone]
Facsimile1-800-258-0255
www.cornelius.com
ILLUSTRATEDPARTSLIST
CTP-20 PRE-MIXDISPENSER
MODELNO.
ManualPartNo.569030057
10-15-2001
ãIMICorneliusCo., 2001
CTP-20 1 of3

IMICORNELIUSINC.
OneCorneliusPlace
Anoka,MN.55303--6234
Telephone[phone]
Facsimile1-800-258-0255
www.cornelius.com
ILLUSTRATEDPARTSLIST
CTP-20 PRE-MIXDISPENSER
FIGURE1. GENERALASSEMBLY
ManualPartNo.569030057
10-15-2001
ãIMICorneliusCo., 2001 CTP-20
2 of3

IMICORNELIUSINC.
OneCorneliusPlace
Anoka,MN.55303--6234
Telephone[phone]
Facsimile1-800-258-0255
www.cornelius.com
ILLUSTRATEDPARTSLIST
CTP-20 PRE-MIXDISPENSER
Item
No.PartNo.Name
1 230395 GrilleHood (No LongerAvailable)
2 550136 DecalCocaColaBack
3 550195 GrommetStrip
4 400284 Screw No.6PHB20
5 400288 ScrewMA6-32 X1/4TAPR
6 230082 BrktLH CondenserSupport
(No LongerAvailable)
7 230083 BrktRH CondenserSupport
8 550088 Cond Coil
9 230509 Shroud Fan Small
10 350017 Blade Fan
11 350095 MotorFan 120V60HZ
350096 MotorFan 230V50/60HZ
12 230113 BrktMtrFan
13 320389000 Bushing Snap
14 230280 BoxOnlyElec
15 260151 Evap Coil Assy
16 230233 CoverElecBox
17 186074001 ControlIceBank
18 350137 ReceptacleSingle
19 186564000 StrainRelief
20 350126 CordPwr
21 260969 KitComp 1/3HP120V60HZ
260967 KitComp 1/3HP230V50HZ
26972 Comp 1/3HP240V60HZ
350148 Relay1/3HP120V60HZ
350151 Relay1/3HP230V50HZ
350152 Relay1/3HP240V60HZ
350108 Overld 1/3HP120V60HZ
350106 Overld 1/3HP230V50HZ
350107 Overld 1/3HP240V60HZ
22 398034400 PinHitch
23 20223010 WasherFt .489 I.D.
24 189723000 GrommetCmpr
25 350158 SleeveCompressor
26 550135 DecalCocaColaSide
27 400285 ScrewYokeBecker
(No LongerAvailable)
700204 ValYkShnk
151202039 ValHdPre-MixSelfClosing
Item
No.PartNo.Name
28 FlavorTab (SpecifyFlavorand
Valve)
29 700196 Knob Asy
30 700202 ValPrmx7/16-20 Becker
31 230283 FrontValve 4-Fl
(No LongerAvailable)
230703 FrontValve 5-Fl
(No LongerAvailable)
230707 FrontValve 6-Fl
(No LongerAvailable)
32 550173 Cup Rest
33 550172 DripTray
34 230586 TraySkirt
35 650036 Tubg Drain
36 230041 BrktMtrAgit
37 230304 HeatShrink
38 350082 MotorAgit5W120V60HZ
350083 MotorAgit25W230V50HZ
39 400411 Gasket
40 350007 Blade Agitator120V60HZ
350008 Blade Agitator230V50HZ
41 186610000 PinSprg
42 400244 NutPack 7/16-20
43 31525002 O-Ring .176 I.D.
44 ItemNotUsed
45 77080101 FitgBarb 1/4x7/16-20
46 318858000 Clamp
47 650054 Tube Poly.156 I.D.(Sold bythe
Foot)
48 260261 Coil Setof5(No LongerAvailable)
260262 Coil Setof6(No LongerAvailable)
49 230150 HolderCntlTemp
50 260066 Cabinet
51 230484 PanelAirStop (No Longer
Available)
52 550035 Bushing
53 500134 Leg
CompressorAss’yinclude:Compressor,
Relay,Overload,Grommetsand Sleeves.
ManualPartNo.569030057
10-15-2001
ãIMICorneliusCo., 2001
CTP-20 3 of3
