CORNFIELD ELECTRONICS ArduTouch User manual

ArduTouch MusicSynthesizer
AssemblyInstructions
revC
27-Feb-2019

LearnToSolder
downloadforfreeat:
http://mightyohm.com/soldercomic
The following photos will
show you how to solder.
But feel free to download
the “Soldering Is Easy” comic book
for free!

LearnToSolder
downloadforfreeat:
http://mightyohm.com/soldercomic

LearnToSolder
Downloadinthelanguageofyourchoiceforfreeat:
http://mightyohm.com/soldercomic

LearnToSolder
Downloadinthelanguageofyourchoiceforfreeat:
http://mightyohm.com/soldercomic

LearnToSolder
Downloadinthelanguageofyourchoiceforfreeat:
http://mightyohm.com/soldercomic

LearnToSolder
Downloadinthelanguageofyourchoiceforfreeat:
http://mightyohm.com/soldercomic

All of the parts
Some parts are inside
of this battery pack

The board we’ll solder the parts to

The tools you’ll need:
• soldering Iron (35W or less)
• solder (60/40 Sn/Pb, rosin core, 0.031” diameter or less)
• soldering iron stand
• cellulose kitchen sponge (not plastic!)
•small wire cutter

R1 – this is where it goes

R1: Brown, Black, Orange
(not Brown, Black, Red)

R1

wires coming out
from parts are
called “leads” –
they lead to the
part

R1 – this is how it will look before
inserting it into the board

these are pads

R1 – inserted into the board

Howtoholdasoldering
iron
(Likeapencil– heldfromunderneath)
