CORNING OptiTect Gen III Series User manual

p/n 003-979-AEN, Issue 1
STANDARD RECOMMENDED PROCEDURE 003-979-AEN | ISSUE 1 | APRIL 2014 | PAGE 1 OF 5
OptiTect®Local Convergence
Cabinet, Gen III Series,
Splitter Box Kit
related literature |
003-735 Instruction, OptiTect®Gen III Local Convergence Cabinet
1. General
This document describes installation of a splitter box kit into the Corning Optical Communications
OptiTect®local convergence cabinet, Gen III series (Figure 1) to provide additional capacity.
Figure 1
2. Carton Contents
• Splitter box kit (Figure 2) (p/n FDH-G3-
SPLTRBX-KITVZ), consisting of
• (1) Splitter box
• (1) Splitter box plate
• (3) #6-32 x .50 stainless steel panhead
screws
• (1) Standard recommended procedure
(SRP) 003-979-AEN
Figure 2
Screw (x3)
Splitter box (x1)
Top view
Plate (x1)
Underside
view
TPA-4652

STANDARD RECOMMENDED PROCEDURE 003-979-AEN | ISSUE 1 | APRIL 2014 | PAGE 2 OF 5
3. Tools and Materials Required
• Phillips screwdriver
• 216B tool or a 7/16-in nutdriver (for entry into the interior of the cabinet)
• Dry-process connector cleaning supplies
4. Precautions
WARNING: Never look directly into the end of a ber that may be carrying laser light.
Laser light can be invisible and can damage your eyes. Viewing it directly does not cause pain.
The iris of the eye will not close involuntarily as when viewing a bright light. Consequently,
serious damage to the retina of the eye is possible. Should accidental eye exposure to laser
light be suspected, arrange for an eye examination immediately.
5. Installation
5.1 Into a 288- or 432-ber Cabinet
Step 1: Use the 216B tool or 7/16-in nutdriver to open the cabinet door (Figure 3).
Step 2: Open the main adapter panel and remove three screws from the top.
Figure 3
TPA-4653

STANDARD RECOMMENDED PROCEDURE 003-979-AEN | ISSUE 1 | APRIL 2014 | PAGE 3 OF 5
Step 3: Align the holes on the plate with the screw holes on the panel and secure the plate
with the three screws provided in the kit.
Figure 4
Step 4: Install four splitters inside the splitter box (Figure 5) and secure them to the box with
the captive fasteners.
Figure 5
Step 5: Slide the splitter box into the tracks on the underside of the plate (Figure 6). Secure
the box by pushing in the plungers.
Figure 6
TPA-4654
TPA-4655
TPA-4656

STANDARD RECOMMENDED PROCEDURE 003-979-AEN | ISSUE 1 | APRIL 2014 | PAGE 4 OF 5
Step 6: Store the connectors in the connector parking eld on the cabinet door. To properly
close the door without pinching bers:
• Use elds C and D when installing up to 288 bers.
• Use elds C, D, and E when installing up to 432 bers
Figure 7
Step 7: When ready to install the connectors, remove them from the parking clip.
Step 8: Clean the connectors and adapters using a dry process; then mate the connectors
into the correct port or connector adapter.
Step 9: Route the cable slack through the guide at the bottom of the cabinet, then through
the retaining guides and slack storage guides.
TPA-4658

STANDARD RECOMMENDED PROCEDURE 003-979-AEN | ISSUE 1 | APRIL 2014 | PAGE 5 OF 5
Corning Optical Communications LLC • PO Box 489 • Hickory, NC 28603-0489 USA
800-743-2675 • FAX [phone] • International [phone] • www.corning.com/opcomm
Corning Optical Communications reserves the right to improve, enhance, and modify the features and specications of Corning Optical Communications products
without prior notication. A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks. All other
trademarks are the properties of their respective owners. Corning Optical Communications is ISO 9001 certied. © 2014 Corning Optical Communications. All
rights reserved. Published in Mexico.
5.2 Into a 144-ber Cabinet
Step 1: Use the 216B tool or 7/16-in nutdriver to open the cabinet door (Figure 3).
Step 2: Remove the plastic door and brackets as shown in Figure 8.
Figure 8
Step 3: Follow Steps 2 through 9 of Section 5.1 to install the plate, splitter box and splitters
into the 144-ber cabinet.
NOTE: In the 144-ber cabinet, additional splitters must have a leg length of 30 in.
TPA-4647
From back of cabinet,
open door. Remove the
two nuts shown.
From front of cabinet,
remove the brackets
shown.
From front of cabinet,
remove the screw
holding the plastic door.
Loosen captive
fastener and remove
door from the brackets.
1
2
3
