CORNING MA2000 QX User manual

MA2000 QX Remote
User Manual

Corning Optical Communications User Manual I CMA-255-AEN I Page 2
Warranties
Hardware
Corning Optical Communications, LLC (“Corning”) warrants to (“Customer”) that for the duration of the warranty period, one
(1) year, commencing on the date of shipment of the Hardware, unless otherwise agreed in writing by Corning (the “Hardware
Warranty Period”), the Hardware furnished by Corning shall be free in all material respects from defects in material and
workmanship, and shall conform to the applicable portions of the Specifications, as defined below (the “Hardware Warranty”).
If notified by Customer of any such defects in material or workmanship or nonconformity with applicable portions of the
Specifications within the Hardware Warranty Period, Corning shall promptly, at its own election and expense, repair or
replace any such Hardware proven to be defective under the terms of this Hardware Warranty. Such repair or replacement
shall be Customer’s sole remedy and Corning’s sole obligation in the event this Hardware Warranty is invoked. If any
components comprising a part of the Hardware are replaced or repaired during the Hardware Warranty Period, the Hardware
Warranty Period for such repaired or replaced components shall extend to the longer of (i) the balance of the Hardware
Warranty Period or (ii) three (3) months from the date of repair or replacement. For purposes of this Warranty,
“Specifications” shall mean the specifications and performance standards of the Products as set forth in documents published
by Corning and delivered to Customer which contain technical specifications or performance standards for the Products.
If Customer invokes this Hardware Warranty, it shall notify Corning promptly of the claimed defect. Customer will allow
Corning to inspect the Hardware at Customer’s location, or to return the Hardware to Corning’s closest repair facility. For
Hardware returned to Corning’s repair facility, Customer shall be responsible for payment of all transportation and freight
costs (including insurance) to Corning’s repair facility, and Corning shall be responsible
for all transportation and freight costs (including insurance) incurred in connection with the shipment of such Hardware to
other repair facilities of Corning and/or its return to Customer.
Notwithstanding the foregoing, in no event will Corning be liable for damage to Products resulting from improper handling
during or after shipment, misuse, neglect, improper installation, operation or repair (other than by authorized Corning
personnel), alteration, accident, or for any other cause not attributable to defects in materials or workmanship on the part of
Corning. Corning shall not reimburse or make any allowance to Customer for any labor charges incurred by Customer for
replacement or repair of any goods unless such charges are authorized in advance in writing by Corning.
Software Warranty
Corning warrants to the original purchaser (“Customer”) that for the duration of the warranty period, one (1) year,
commencing on the date of shipment of the Software, unless otherwise agreed in writing by Corning (the “Software Warranty
Period”), the Software shall conform with, and perform the functions set forth in the Specifications, and shall be free from
defects in material or workmanship (the “Software Warranty”). In the event the Software is proven to be defective under the
terms of this Software Warranty, Corning shall correct such defects or failure and ensure that the Software conforms with,
and performs the functions set forth in, the Specifications. Customer will allow Corning Optical Communications to inspect the
Software at Customer’s location or to return it to Corning Optical Communications’ closest repair facility.
Notwithstanding the foregoing, Corning shall have no obligation under the Software Warranty if the Software is modified or
used with hardware or software not supplied or approved by Corning Optical Communications or if the Software is subject to
abuse, improper installation or application, accident, electrical or environmental over-stress, negligence in use, storage,
transportation or handling.
Third-party software distributed with the Software may carry certain warranties which, to the maximum extent allowed by law,
Corning hereby assigns, transfers and otherwise conveys to Customer, provided, however, that Corning itself provides no
warranty of any kind, express, implied, statutory or otherwise, for any third-party software provided hereunder.
Corning does not warrant any hardware, software or services not provided by Corning
THIS WARRANTY IS THE ONLY WARRANTY MADE BY CORNING OPTICAL COMMUNICATIONS AND IS IN

Corning Optical Communications User Manual I CMA-255-AEN I Page 3
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. CORNING OPTICAL
COMMUNICATIONSS SHALL NOT BE LIABLE FOR ANY OTHER DAMAGE INCLUDING, BUT
NOT LIMITED TO, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR
IN CONNECTION WITH FURNISHING OF GOODS, PARTS AND SERVICE HEREUNDER, OR THE
PERFORMANCE, USE OF, OR INABILITY TO USE THE GOODS, PARTS AND SERVICE.
CORNING OPTICAL COMMUNICATIONS SALES AGENTS OR REPRESENTATIVES ARE NOT AUTHORIZED TO
MAKE COMMITMENTS ON WARRANTY RETURNS.
Returns
In the event that it is necessary to return any product against above warranty, the following procedure shall be followed:
1. Return authorization is to be received from Corning Optical Communications prior to returning any unit. Advise Corning
Optical Communications of the model, Serial number, and discrepancy. The unit may then be forwarded to Corning
Optical Communications, transportation prepaid. Devices returned collect or without authorization may not be accepted.
2. Prior to repair, Corning Optical Communications will advise the customer of our test results and any charges for repairing
customer-caused problems or out-of-warranty conditions etc.
3. Repaired products are warranted for the balance of the original warranty period, or at least 90 days from date of shipment.
Limitations of Liabilities
Cornings’ liability on any claim, of any kind, including negligence for any loss or damage arising from, connected with, or
resulting from the purchase order, contract, quotation, or from the performance or breach thereof, or from the design,
manufacture, sale, delivery, installation, inspection, operation or use of any equipment covered by or furnished under this
contact, shall in no case exceed the purchase price of the device which gives rise to the claim.
Except as expressly provided herein, Corning Optical Communications makes no warranty, expressed or implied, with
respect to any goods, parts and services provided in connection with this agreement including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose. Corning shall not be liable for any other damage including,
but not limited to, indirect, special or consequential damages arising out of or in connection with furnishing of goods, parts
and service hereunder, or the performance, use of, or inability to use the goods, parts and service.
Reporting Defects
Note: Keep all packing material until you have completed the inspection.
The units were inspected before shipment and found to be free of mechanical and electrical defects. Examine the units for
any damage that may have been caused in transit. If damage is discovered, file a claim with the freight carrier immediately.
Notify Corning as soon as possible in writing.

Corning Optical Communications User Manual I CMA-255-AEN I Page 4
Warnings and Admonishments
There may be situations, particularly for workplace environments near high-powered RF sources, where recommended limits
for safe exposure of human beings to RF energy could be exceeded. In such cases, restrictive measures or actions may be
necessary to ensure the safe use of RF energy.
The equipment has been designed and constructed to prevent, as far as reasonably, practicable danger. Any work activity on
or near equipment involving installation, operation or maintenance must be, as far as reasonably, free from danger.
Where there is a risk of damage to electrical systems involving adverse weather, extreme temperatures, wet, corrosive or
dirty conditions, flammable or explosive atmospheres, the system must be suitably installed to prevent danger.
Equipment provided for the purpose of protecting individuals from electrical risk must be suitable for the purpose and properly
maintained and used. This covers a range of activities including lifting, lowering, pushing, pulling, carrying, moving, holding or
restraining an object, animal or person from the equipment. It also covers activities that require the use of force or effort, such
as pulling a lever, or operating power tools.
Where some of the abovementioned activities are required, the equipment must be handled with care to avoid being
damaged.
Observe standard precautions for handling ESD-sensitive devices. Assume that all solid-state electronic devices are ESD-
sensitive. Ensure the use of a grounded wrist strap or equivalent while working with ESD-sensitive devices. Transport, store,
and handle ESD-sensitive devices in static-safe environments.
RF Safety
WARNING!To comply with FCC RF exposure compliance requirements, each individual antenna used for this product must
be fixed mounted in indoor permanent structures, providing a separation distance greater than 75 cm or more from all
persons during normal operation and must not be co-located with any other antenna for meeting RF exposure requirements.
The design of the antenna installation needs to be implemented in such a way so as to ensure RF radiation safety levels and
non-environmental pollution during operation.
WARNING! Antenna gain should not exceed 12.5 dBi.
WARNING! The design of the antenna installation needs to be implemented in such a way so as to ensure RF radiation
safety levels and non-environmental pollution during operation.
Compliance with RF safety requirements:
•Corning Optical Communications products have no inherent significant RF radiation.
•The RF level on the downlink is very low at the downlink ports. Therefore, there is no dangerous RF radiation when the
antenna is not connected.
Power requirements for DC Inputs
WARNING! Only use a special DC supply cable with four connectors
WARNING! Always keep DC IN connectors connected during the product operation
WARNING! Disconnect all power from the equipment by means of an external circuit breaker before connecting or
disconnecting the DC IN connectors.

Corning Optical Communications User Manual I CMA-255-AEN I Page 5
Laser Safety
Fiber optic ports of the MA2000 system elements emit invisible laser radiation at the 1310/1550 nm wavelength window.
The laser apertures /outputs are the green SC APC Bulkhead adapters located on the front panel of the equipment.
The product is Class 1/Hazard level 1
External optical power is less than 10 mW, Internal optical power is less than 500 mW.
To avoid eye injury never look directly into the optical ports, patchcords or optical cables. Do not stare into beam or view
directly with optical instruments. Always assume that optical outputs are on.
Only technicians familiar with fiber optic safety practices and procedures should perform optical fiber connections and
disconnections of MA2K devices and the associated cables.
MA2000 QX has been tested and certified as a Class 1 Laser product to IEC/EN 60825-1 (2007). It also meets the
requirements for a Hazard Level 1 laser product to IEC/EN 60825-2: 2004 to the same degree.
MA2000 system complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice NO. 50 (2007).
Care of Fiber Optic Connectors
Do not remove the protective covers on the fiber optic connectors until a connection is ready to be made. Do not leave
connectors uncovered when not connected.
The tip of the fiber optic connector should not come into contact with any object or dust.
Refer to the cleaning procedure for information on the cleaning of the fiber tip.
CAUTION!
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE
Regulatory Compliance Information
WARNINGS!
•This is NOT a CONSUMER device. It is designed for installation by FCC LICENCEES and QUALIFIED INSTALLERS.
You MUST have an FCC LICENSE or express consent of an FCC Licensee to operate this device. Unauthorized use
may result in significant forfeiture penalties, including penalties in excess of $100,000 for each continuing violation.
•ANTENNAS: Use only authorized and approved antennas, cables and/or coupling devices! The use of unapproved
antennas, cables or coupling devices could cause damage and may be of violation of FCC regulations. The use of
unapproved antennas, cables and/or coupling devices is illegal under FCC regulations and may subject the user to fines.

Corning Optical Communications User Manual I CMA-255-AEN I Page 6
Standards and Certifications
Corning Optical Communications products have met the approvals of the following certifying organizations:
Company Certification
ISO 9001: 2000 and ISO 13485: 2003
Product Certification
US
Radio Equipment and Systems
•FCC 47 CFR part 22 – for CELL Frequency Band
•FCC 47 CFR part 24 – for PCS Frequency Band
•FCC 47 CFR part 27 – for LTE and AWS Frequency Bands
•FCC CFR part 15 Subpart B
•FCC CFR part 90
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Warning!
Changes or modifications to this equipment not expressly approved by Corning Mobile Access could void the
user’s authority to operate the equipment.
Europe
Radio Equipment and Systems
•EN 301502 – for GSM/EGSM Frequency Bands
•EN 300609 – for DCS Frequency Bands
•EN 301908 – for UMTS Frequency Band
EMC
EN 301 489
NTRL Safety
UL 60950-1
Laser Safety
IEC 60825-1, IEC 60825-2
TRA
TRA type approval for UAE
Licensee Contact Information
Industrial boosters may only be used by FCC licensees or those given express (individualized) consent of license. Corning
Corning Optical Communications certifies all of the VARs listed as licensed installers for Corning. For the list of licensed
VARs, please contact the Corning Tech Support Hotline: (US) 410-553-2086 or 800-787-1266.

Corning Optical Communications User Manual I CMA-255-AEN I Page 7
About this Guide
This user guide describes how to perform the physical installation of the MA2000 systems. The installation procedures of
other units (e.g. RIU, SC-450) relevant to the system are detailed in their user manuals (see Additional Relevant
Documentation below).
Additional Relevant Documents
The following documents are required if the corresponding units are included in your system.
Document Name
RIU Installation and Configuration Guide
Base Unit Quick Start Guide
System Controller (SC-450) User Manual
MA2000 QX Specification Sheet
MA Software Version Update Tool
List of Acronyms
AO
Add-On module
BDA
Bi-Directional Amplifier
BTS
Base Transceiver Station
BTSC
Base Transceiver Station Conditioner
BU
Base Unit
DL
Downlink
RHM
Remote Hub Module
RIU
Radio Interface Unit
UL
Uplink

Table of Contents
Warranties ..................................................................................................................................2
Hardware....................................................................................................................................................... 2
Software Warranty ........................................................................................................................................ 2
Returns.......................................................................................................................................................... 3
Limitations of Liabilities................................................................................................................................. 3
Reporting Defects ......................................................................................................................................... 3
Warnings and Admonishments ...................................................................................................4
RF Safety....................................................................................................................................4
Compliance with RF safety requirements:.................................................................................................... 4
Power requirements for DC Inputs..............................................................................................4
Laser Safety................................................................................................................................5
Care of Fiber Optic Connectors.................................................................................................................... 5
Regulatory Compliance Information............................................................................................5
Standards and Certifications.......................................................................................................6
Company Certification................................................................................................................................... 6
Product Certification...................................................................................................................................... 6
Licensee Contact Information......................................................................................................6
About this Guide .........................................................................................................................7
Additional Relevant Documents..................................................................................................7
List of Acronyms .........................................................................................................................7
Table of Contents........................................................................................................................8
1Introduction........................................................................................................................11
1.1 Key Features and Capabilities ............................................................................................................11
1.2 System Architecture............................................................................................................................12
1.3 QX Interfaces and Internal Modules.................................................................................................... 14
1.3.1 QX Interfaces............................................................................................................................14
1.3.2 QX Main Internal Modules ........................................................................................................16
1.4 SCU-F Interfaces.................................................................................................................................17
2Installation Guidelines........................................................................................................18
2.1 Infrastructure Preparation ................................................................................................................... 18
2.2 Installation Requirements.................................................................................................................... 18
2.3 Coaxial Cable Connections................................................................................................................. 18
2.3.1 General Cable Installation Procedures.....................................................................................18

Corning Optical Communications User Manual I CMA-255-AEN I Page 9
2.3.2 RF Rules...................................................................................................................................19
2.3.3 Coax Cable Lengths and Losses..............................................................................................19
2.4 Fiber Optic Rules................................................................................................................................. 20
2.5 Power Consumption, Connections and Power Supplies ....................................................................21
2.5.1 Power Safety Instructions .........................................................................................................21
2.5.2 Types of Power Supplies..........................................................................................................21
2.6 Installation Conventions......................................................................................................................21
3System Installation.............................................................................................................22
3.1 Overview of Physical Installation......................................................................................................... 22
3.2 Unpacking and Inspection...................................................................................................................23
3.3 Inserting an RHM/AO Module in to QX Chassis ................................................................................. 24
3.4 Mounting..............................................................................................................................................26
3.4.1 Rack Mount Installations........................................................................................................... 26
3.4.1.1 Plan the rack installation..............................................................................................26
3.4.1.2 Rack Installation Safety Instructions............................................................................27
3.4.1.3 Mounting QX Unit in 19-in Rack ..................................................................................27
3.4.1.4 Mounting SCU-F Unit...................................................................................................28
3.4.2 Wall Mount Installation..............................................................................................................29
3.4.2.1 QX Horizontal Wall Mount Installation......................................................................... 30
3.4.2.2 QX Vertical Wall Mount Installation ............................................................................. 32
3.5 Connections ........................................................................................................................................35
3.5.1 Internal Power Feed to AO Connections..................................................................................35
3.5.2 QX Fiber Optic Connections..................................................................................................... 36
3.5.2.1 MIMO Configurations...................................................................................................37
3.5.3 RF Connections ........................................................................................................................38
3.5.3.1 QX RF Connections to SCU-F..................................................................................... 38
3.5.3.2 RF MIMO Connections to SCU-F................................................................................ 39
3.5.3.3 QX Antenna Monitoring Unit (AMU) Connections ....................................................... 40
3.5.3.4 SCU-F to Broadband Antenna Connections................................................................41
3.5.4 Grounding the QX Unit..............................................................................................................41
3.5.5 External Power Connections..................................................................................................... 42
3.6 Verifying Normal Operation.................................................................................................................43
4Maintenance ......................................................................................................................45
4.1 Replacing an RHM/AO Module........................................................................................................... 45
4.2 Replacing Fan Module ........................................................................................................................ 47
5Appendix A: System Specifications....................................................................................49
5.1 Supported Services............................................................................................................................. 49
5.2 RF Parameters.................................................................................................................................... 50
RF Parameters per Service at Antenna Port of Service Combiner Unit (SCU-F)...............................50
5.3 Absolute Maximum Rating.................................................................................................................. 51
5.4 Optical Specifications.......................................................................................................................... 51
5.5 Environmental Specifications..............................................................................................................51
5.6 Standards and Approvals.................................................................................................................... 52
5.7 System Component Specifications ..................................................................................................... 53
5.7.1 Quad-Service Package (QX) .................................................................................................... 53

Corning Optical Communications User Manual I CMA-255-AEN I Page 10
5.7.2 Remote Hub Module (RHM) .....................................................................................................54
5.7.3 Add-On (AO) Module................................................................................................................54
5.7.4 Termination Module ..................................................................................................................54
5.7.5 Antenna Monitoring Unit (AMU)................................................................................................55
5.7.6 Service Combiner Unit (SCU-F)................................................................................................ 55
6Appendix B: Ordering information ......................................................................................56
6.1 QX Chassis and Modules....................................................................................................................56
6.2 QX Accessory Kits...............................................................................................................................57

Corning Optical Communications User Manual I CMA-255-AEN I Page
11
1Introduction
MA200 QX remote is a compact, modular, cellular indoor coverage remote solution for the MA2000 distributed antenna
systems (DAS).
It is a fiber fed, compact and scalable multi-service platform designed to complement the MA1000 and MA2000 supporting up
to four services (CELL, PCS, and AWS1/3).
All services are received from the headend, over an optic fiber pair, converted back to RF and distributed over a common
DAS antenna infrastructure.
Service support can be quickly added as needed by inserting card like modules into the chassis without any downtime or
additional cabling. In addition, two QX units can be cascaded to provide various combinations of SISO and MIMO services.
MA2000 QX remotes share a common equipment headend and element management system (EMS) with other remotes on
the MA1000/MA2000 platform. Management and configuration options are provided for each QX service module (i.e., RHM
and AO) and for the QX chassis fans via a web session to the SC-450 controller.
MA2000 QX
Figure 1-1
1.1 Key Features and Capabilities
The following benefits are achieved with the QX platform:
•Multiservice platform - supports up to four services: CELL850, PCS1900 and AWS3 services in various configurations.
•Multi-operator optimized platform - services from a number of operators can be supported by the same chassis or by
different units and distributed over a common DAS antenna infrastructure.
•Optic fiber savings - all services routed to an QX unit are routed over a single optic fiber
•Modular design - seamless service upgrades – simply insert a module in the MA2000 QX and configure
•Scalable MIMO upgrades - upgrade any or all services from SISO to MIMO by cascading another QX unit
•Small footprint - 3 U height rack; 4 U height rack including SCU-F unit
•Simple maintenance - All connections and status LEDs located on front panel; Modular, hot-swap, field replaceable
service modules, including fan modules
•Web management - web management via the SC-450 controller

Corning Optical Communications User Manual I CMA-255-AEN I Page 12
1.2 System Architecture
MA2000 QX compliments the MA2000 DAS solution and coexists alongside other MA1K and MA2K remotes, sharing a
common headend. The QX remote unit provides coverage for up to four RF services over a common fiber/coax antenna
infrastructure. The QX is installed at the remote end on floor level and operates in conjunction with the service combiner unit
(SCU-F) which combines the service signals and distributes them to up to four broadband antennas.
Headend:
At the headend MA2000 elements provide interface to the wireless service provider’s network, condition the signals and
convert them to optical signals for transportation over fiber optics towards the remote ends.
•Radio Interface Unit (RIU) - the RIU conditions and custom tunes the RF downlink signals from an operator’s signal
source (BTS or BDA) to ensure a constant RF level. In the uplink, the signal (at the required level) is routed back to the
operator’s signal source.
•Base Unit (BU) – RF-to-optic converter unit – The BU is a wideband unit that convert the RF downlink signals from the
RIU into optical signals for routing over single or multi-mode fiber optic cabling (SM/MM) to/from the QX units located at
the remote locations up to 2 km away.
•System Controller (SC-450) - the system controller enables centralized remote management and control of MA2000
elements. This unit connects directly to the RIU and BU and allows management of these as well as their hosted
elements (e.g. QX) via a controller web session.
Remote End:
At the remote end, the optical signal is reconverted to RF, filtered, amplified to the appropriate level, combined with other
signals and distributed over the broadband antenna infrastructure. The QX unit is installed, along with the SCU-F. The QX
system remote end consists of the following elements:
•MA2000 QX - each QX unit provides coverage for four RF services (e.g. CELL, PCS, LTE 700 MHz, and AWS3) via two
types of service dedicated internal modules (RHM and AO). Each of these modules is monitored via the controller as an
independent unit:
•Remote Hub Module (RHM): The RHM is a service-specific module, supporting two services, that performs optical to
RF conversion of signals received from the BU. Signals are automatically filtered and amplified for transport over
broadband coax cable to a passive antenna. Uplink signals from the antennas are then converted to optical signals
before being transmitted back to the BU.
•Add-On Module (AO): The AO is a single service module coupled with an RHM to deliver an additional service at a
lower incremental cost. The AO receives RF signal from the RHM and amplifies it to transport across the broadband
coax.
•Service Combiner Unit (SCU-F): The SCU-F is a passive unit that can combine service signals from up to two fully
loaded QX units and distributes the combined signals over broadband antennas.
Note: The QX can be used with any flavor of SCU (i.e. SCU-F, SCU-FT, SCU-4, SCU-8).

Corning Optical Communications User Manual I CMA-255-AEN I Page 13
Figure 1-2 sows an example of an MA2000 QX deployment including two QX remote units (quad-band and tri-band). The QX
receives RF over optic service signals from the headend, reconverts the signals to RF over copper, adjusts them to the
required level and outputs each service to dedicated interfaces. The signals are combined by the SCU-F (along with services
from other QX units) and distributed over a common distributed antenna system infrastructure.
In the uplink, cellular service signals received at the DAS are separated by the SCU-F and routed to their dedicated QX ports.
The signals are then converted to optic and forwarded to the head-end for reconversion to RF and distribution to the relevant
BTS or BDA systems.
Note: Third party equipment is sold separately (i.e., cabling, antennas).
QX Architecture Diagram
Figure 1-2

Corning Optical Communications User Manual I CMA-255-AEN I Page 14
1.3 QX Interfaces and Internal Modules
1.3.1 QX Interfaces
This section provides a full, detailed description of the QX unit and relevant interface connections (Table 1-1) and LED
indicators (Table
1-2).
MA2000 QX Front Panel
Figure 1-3
Interface
Description
DB-15 AMU (Antenna Monitoring Unit) port. Connect to parallel port on SCU-F.
Note that only one QX unit port can be connected to the parallel SCU-F port. For
installations with more than one QX, cascade QX AMU ports using IN/OUT ports.
IN/OUT AMU cascading ports. Use in case there are more than one QX units connected to
the SCU-F.
DB-9 RS232 serial connection (D-Type 9); Serves as AMU console port for service
personnel
Console Connect to network for AMU SW upgrade – for tech support personnel only
Service specific
QMA connectors Used for connecting to corresponding SCU-F High band and Low Band QMA
connectors.
Optic Port Slot Slot used to guide the optic fiber to the RHM module fiber optic SC/APC port inside
the chassis.
AC In Local AC power connection: 100 - 240 VAC (Integrated AC/DC converter)
DC In Remote DC power connection: 25 to 48 VDC
Table
1-1. QX Front Panel Interfaces

Corning Optical Communications User Manual I CMA-255-AEN I Page 15
The QX front panel supports three groups of LEDs: QX Chassis (system level), RHM and Add-On unit LEDs.
MA2000 QX Front Panel
Figure 1-4
Table
1-2: LEDs Descriptions
Module
LED
Description
QX Chassis
(System Level) Power Steady Green: Required power is supplied to AMU module of
QX chassis
Off: No power supplied to AMU module of QX chassis
Run Steady Green: AMU module software initialized
Blinking Green: AMU module software is initializing (blinks for the
duration of approximately one minute)
Fan Steady Green: Fan status normal
Blinking Green: Faulty fan, alarm triggered
RHM Power Steady Green: Power input detected for RHM
Off: No power detected for RHM
Comm Blinking Green: Active communication detected - connected and
discovered by the BU
Steady Slow Blink: Faulty communication link - no external
communication is received
Link Steady Green: Normal optical link level from BU
Blinking Green: Low optical link level from BU
Off: No optical link is present
AO1/AO2 Power Steady Green: Power input detected for first/second Add-On unit
Off: No power detected for first/second Add-On unit
Run Blinking Green: Indicates that the Add-On module is in normal
operating mode.

Corning Optical Communications User Manual I CMA-255-AEN I Page 16
1.3.2 QX Main Internal Modules
The QX main components consist of the following internal modules:
•Remote Hub Module (RHM) – service specific module, supports two voice services, converts the optical signals received
from the BU to RF signals (and vice versa) and routes them to the coax antenna infrastructure (via the Four Port Service
Combiner Unit – SCU-F).
•Add-On (AO) – adds an additional voice service to the host RHM (QX includes two AO modules hosted by the RHM)
Note: The voice services are combined by the connected Service Combiner Unit (SCU).
•Antenna Monitoring Unit (AMU) – digital unit that enables antenna monitoring and relay messaging of the following
information:
•Antenna status
•Fans status
•Fans control
•AMU/QX alarms.
The AMU is connected to the SCU. The AMU modules of a number of QX units can be daisy chained to a single SCU-F
(see section 3.5.3.1).
•Fan Module – two extractable fans, simple to maintain and replace (see section 4.2).
MA2000 QX Internal Modules
Figure 1-5

Corning Optical Communications User Manual I CMA-255-AEN I Page 17
1.4 SCU-F Interfaces
The SCU-F is a passive unit which interfaces to the QX RF service ports and internal AMU module and to the DAS
infrastructure. All of the interfaces are located on the front panel (shown in Figure 1-6).
SCU-F Front Panel
Figure 1-6
Interface
Description
DB-15 DB-15 port used to connect the SCU-F to the QX DB-15 port (internal AMU
module port)
Antenna Ports N-Type RF antenna ports used to connect
to the broadband antenna
infrastructure
QMA Ports (Low/High) QMA type RF ports used to connect to the QX service ports:
Low: Ports 1-4 support low band service connections from the QX
High: Ports 5-8 support high band service connections from the QX
Table 1-3. SCU-F Front Panel Interfaces

Corning Optical Communications User Manual I CMA-255-AEN I Page
18
2Installation Guidelines
2.1 Infrastructure Preparation
This following installation rules are based on the assumption that site survey and installation planning (including power
requirements) have been completed.
2.2 Installation Requirements
The infrastructure preparation consists of two main phases:
Floor Planning: Planning the distribution of the antennas on each floor to provide the required coverage.
Telecom Closet Planning: Planning the layout of the devices and cables in the telecom closet or shaft.
2.3 Coaxial Cable Connections
2.3.1 General Cable Installation Procedures
Observe the general cable installation procedures that meet with the building codes in your area. The building code requires
that all cabling be installed above ceiling level (where applicable). The length of cable from the risers to each antenna must
be concealed above the ceiling.
The cable must be properly supported and maintained straight using tie-wraps, cable trays and clamps or hangers every 10
feet (where practical above ceiling level). Where this is not practical, the following should be observed:
•The minimum bending radius of 7-in is required for the supplied ½-in coax cable.
•Cable that is kinked or has a bending radius smaller than 7-in must be replaced.
•Cable runs that span less than two floors should be secured to suitably located mechanical structures.
•The cables should be supported only from the building structure.

Corning Optical Communications User Manual I CMA-255-AEN I Page 19
2.3.2 RF Rules
•When using the MA2000 system in an environment in which other indoor coverage systems are installed, it is
recommended (where possible) that the antennas are placed at least two meters apart
•When bending coax cables, verify that the bending radius does not exceed the coax specifications.
•Use wideband antennas supporting a range of 800 MHz to 2500 MHz
•Use a VSWR meter (i.e. Site Master or equivalent) for checking coax cables, including the antennas. (< 2). The VSWR
must be measured prior to terminating the RUs in the remote communication rooms
•Terminate all unused SCU ports with a 50 ohm load
2.3.3 Coax Cable Lengths and Losses
Use coax ½”, 50 ohm, male-to-male QMA type, for connecting to SCU broadband antenna ports.
Note: The required distance between the antennas (installed in the ceiling) depends on the infrastructure and calculated path-
loss. For example, if there is free space-loss between the antennas, a minimum distance of 100 ft is required; if there are
partitions (loss) between the antennas, a distance of less than 100 ft between them is allowed.
Coax Length
Coax Loss (900Mhz)
Connector Loss
Total Loss
30 0.7 1.5 2.2
40 0.9 1.5 2.4
50 1.1 1.5 2.6
60 1.3 1.5 2.8
70 1.5 1.5 3
80 1.7 1.5 3.2
90 1.9 1.5 3.4
100 2.1 1.5 3.6
110 2.3 1.5 3.8
120 2.5 1.5 4
130 2.7 1.5 4.2
140 2.9 1.5 4.4
150 3.1 1.5 4.6
160 3.3 1.5 4.8
170 3.5 1.5 5
180 3.7 1.5 5.2
190 3.9 1.5 5.4
200 4.1 1.5 5.6

Corning Optical Communications User Manual I CMA-255-AEN I Page 20
2.4 Fiber Optic Rules
•Either single mode or multimode fiber can be used with QX products.
•Only Multimode fiber, 50/125 or 62.5/125um complying with ANSI/TIA/EIA-568-B series, EN50173-1 or ISO/IEC 11801
can be used. The fiber length can be up to 300 meters assuming the following qualifications:
•All fiber in a given length of fiber must be of the same core diameter.
•All Bulkhead adapters must be Single mode SC APC (Green) adapters.
•All terminations cross connections or patches must be direct fusion splice or the specified patch cords listed below.
900 microns patchcord for splicing, 2 Meters, 2xSC/APC
Diamond p/n ENC/1045341 Beige boots, 62.5/125/900 MA# 500001057
Diamond p/n ENC/1045340 Black boots, 50/125/900 MA# 500001058
Zipcord patchcord, 4xSC/APC, 50/125/900/2000/4500 micron
Diamond p/n ENC/1045342 Black/Brown boots, 1 Meter MA# 50000105
Diamond p/n ENC/1045343 Black/Brown boots, 3 Meter MA# 500001060
Zipcord patchcord, 4xSC/APC, 62.5/125/900/2000/4500 micron
Diamond p/n ENC/1045344 Beige/Brown boots, 1 Meter MA# 500001061
Diamond p/n ENC/1045345 Beige/Brown boots, 3 Meter MA# 500001062
•Use only 8-degree SC APC connectors (green color).
•Use only fusion splice for connecting two fibers.
•Use minimum splicing/connectors to achieve minimum losses on the fibers (<0.5 dB).
•Use precaution while installing, bending, or connecting fiber optic cables:
•Fiber optic cable is sensitive to excessive pulling, bending and crushing forces. Consult the cable specification sheet
for the cable you are installing.
•Do not bend cable more sharply than the minimum recommended bend radius.
•Do not apply more pulling force to the cable than specified.
•Do not crush the cable or allow it to kink. Doing so may cause damage that can alter the transmission characteristics
of the cable. The cable may have to be replaced.
•Use an optical power meter and light source for checking the fiber optic cables.
•Make sure the environment is clean while connecting/splicing fiber optic cables.
•All fiber optic connectors should be cleaned prior to connecting to the system
•Fiber connector protective caps should be installed on all non-terminated fibers and removed just before they are
terminated.
•Check the Fiber Optic connections.
•Pay special attention while connecting the SC APC connectors - ensure that you hear a “click”, indicating a secure
connection
•Never look directly into the end of a fiber that may be carrying laser light. Laser light can be invisible and can damage
your eyes.
