CORNING RAU5 User manual

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 1
Analog Low Power Remote Unit
(RAU5x)
User Manual

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 2

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 3
Warranties
Hardware Warranty
Corning Optical Communications LLC (“Corning”) warrants to the original purchaser (“Customer”) that for the duration of
the warranty period, one (1) year, commencing on the date of shipment of the Hardware, unless otherwise agreed in writing
by Corning (the “Hardware Warranty Period”), the Hardware furnished by Corning shall be free in all material respects from
defects in material and workmanship, and shall conform to the applicable portions of the Specifications, as defined below
(the “Hardware Warranty”). If notified by Customer of any such defects in material or workmanship or nonconformity with
applicable portions of the Specifications within the Hardware Warranty Period, Corning shall promptly, at its own election
and expense, repair or replace any such Hardware proven to be defective under the terms of this Hardware Warranty. Such
repair or replacement shall be Customer’s sole remedy and Corning’s sole obligation in the event this Hardware Warranty is
invoked. If any components comprising a part of the Hardware are replaced or repaired during the Hardware Warranty
Period,
the Hardware Warranty Period for such repaired or replaced components shall extend to the longer of (i) the balance of the
Hardware Warranty Period or (ii) three (3) months from the date of repair or replacement. For purposes of this Warranty,
“Specifications”shall mean the specifications and performance standards of the Products as set forth in documents published
by Corning and delivered to Customer which contain technical specifications or performance standards for the Products.
If Customer invokes this Hardware Warranty, it shall notify Corning promptly of the claimed defect. Customer will allow
Corning to inspect the Hardware at Customer’s location, or to return the Hardware to Corning closest repair facility. For
Hardware returned to Corning repair facility, Customer shall be responsible for payment of all transportation and freight costs
(including insurance) to Corning’ repair facility, and Corning shall be responsible for all transportation and freight costs
(including insurance) incurred in connection with the shipment of such Hardware to other repair facilities of Corning and/or its
return to Customer.
Notwithstanding the foregoing, in no event will Corning be liable for damage to Products resulting from improper handling
during or after shipment, misuse, neglect, improper installation, operation or repair (other than by authorized Corning
personnel), alteration, accident, or for any other cause not attributable to defects in materials or workmanship on the part of
Corning. Corning shall not reimburse or make any allowance to Customer for any labor charges incurred by Customer for
replacement or repair of any goods unless such charges are authorized in advance in writing by Corning.
Software Warranty
Corning Optical Communications LLC (“Corning”) warrants to the original purchaser (“Customer”) that for the duration of the
warranty period, one (1) year, commencing on the date of shipment of the Software, unless otherwise agreed in writing by
Corning (the “Software Warranty Period”), the Software shall conform with, and perform the functions set forth in the
Specifications, and shall be free from defects in material or workmanship (the “Software Warranty”). In the event the Software
is proven to be defective under the terms of this Software Warranty, Corning shall correct such defects or failure and ensure
that the Software conforms with, and performs the functions set forth in, the Specifications. Customer will allow Corning to
inspect the Software at Customer’s location or to return it to Corning’s closest repair facility.
Notwithstanding the foregoing, Corning shall have no obligation under the Software Warranty if the Software is modified or
used with hardware or software not supplied or approved by Corning or if the Software is subject to abuse, improper
installation or application, accident, electrical or environmental over-stress, negligence in use, storage, transportation or
handling.

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 4
Third-party software distributed with the Software may carry certain warranties which, to the maximum extent allowed by law,
Corning hereby assigns, transfers and otherwise conveys to Customer, provided, however, that Corning itself provides no
warranty of any kind, express, implied, statutory or otherwise, for any third-party software provided hereunder.
Corning does not warrant any hardware, software or services not provided by Corning.
THIS WARRANTY IS THE ONLY WARRANTY MADE BY CORNING AND IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. CORNING SHALL NOT BE LIABLE FOR ANY OTHER DAMAGE INCLUDING,
BUT NOT LIMITED TO, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR
IN CONNECTION WITH FURNISHING OF GOODS, PARTS AND SERVICE HEREUNDER, OR THE PERFORMANCE,
USE OF, OR INABILITY TO USE THE GOODS, PARTS AND SERVICE.
CORNING SALES AGENTS OR REPRESENTATIVES ARE NOT AUTHORIZED TO MAKE COMMITMENTS ON
WARRANTY RETURNS.
Returns
In the event that it is necessary to return any product against above warranty, the following procedure shall be followed:
1. Return authorization is to be received from Corning prior to returning any unit. Advise Corning of the model, Serial
number, and discrepancy. The unit may then be forwarded to Corning, transportation prepaid. Devices returned collect or
without authorization may not be accepted.
2. Prior to repair, Corning will advise the customer of our test results and any charges for repairing customer-caused
problems or out-of-warranty conditions etc.
3. Repaired products are warranted for the balance of the original warranty period, or at least 90 days from date of shipment.
Limitations of Liabilities
Corning’s liability on any claim, of any kind, including negligence for any loss or damage arising from, connected with, or
resulting from the purchase order, contract, quotation, or from the performance or breach thereof, or from the design,
manufacture, sale, delivery, installation, inspection, operation or use of any equipment covered by or furnished under this
contact, shall in no case exceed the purchase price of the device which gives rise to the claim.
Except as expressly provided herein, Corning makes no warranty, expressed or implied, with respect to any goods, parts and
services provided in connection with this agreement including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose. Corning shall not be liable for any other damage including, but not limited to, indirect, special
or consequential damages arising out of or in connection with furnishing of goods, parts and service hereunder, or the
performance, use of, or inability to use the goods, parts and service.
Reporting Defects
The units were inspected before shipment and found to be free of mechanical and electrical defects. Examine the units for
any damage that may have been caused in transit. If damage is discovered, file a claim with the freight carrier immediately.
Notify Corning as soon as possible in writing.
Note: Keep all packing material until you have completed the inspection.

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 5
Warnings and Admonishments
There may be situations, particularly for workplace environments near high-powered RF sources, where recommended limits
for safe exposure of human beings to RF energy could be exceeded. In such cases, restrictive measures or actions may be
necessary to ensure the safe use of RF energy.
The equipment has been designed and constructed to prevent, as far as reasonably, practicable danger. Any work activity on
or near equipment involving installation, operation or maintenance must be, as far as reasonably, free from danger.
Where there is a risk of damage to electrical systems involving adverse weather, extreme temperatures, wet, corrosive or
dirty conditions, flammable or explosive atmospheres, the system must be suitably installed to prevent danger.
Equipment provided for the purpose of protecting individuals from electrical risk must be suitable for the purpose and properly
maintained and used. This covers a range of activities including lifting, lowering, pushing, pulling, carrying, moving, holding or
restraining an object, animal or person from the equipment. It also covers activities that require the use of force or effort, such
as pulling a lever, or operating power tools.
Where some of the above-mentioned activities are required, the equipment must be handled with care to avoid being
damaged.
Observe standard precautions for handling ESD-sensitive devices. Assume that all solid-state electronic devices are ESD-
sensitive. Ensure the use of a grounded wrist strap or equivalent while working with ESD-sensitive devices. Transport, store,
and handle ESD-sensitive devices in static-safe environments.
Regulatory Compliance Information
WARNINGS!
•This is NOT a CONSUMER device. It is designed for installation by FCC LICENCEES and QUALIFIED INSTALLERS.
You MUST have an FCC LICENSE or express consent of an FCC Licensee to operate this device. Unauthorized use may
result in significant forfeiture penalties, including penalties in excess of $100,000 for each continuing violation.
•ANTENNAS: Use only authorized and approved antennas, cables and/or coupling devices! The use of unapproved
antennas, cables or coupling devices could cause damage and may be of violation of FCC regulations. The use of
unapproved antennas, cables and/or coupling devices is illegal under FCC regulations and may subject the user to fines.
See section 3.6 of this document.
•RxU67: Part 90 and Part 20 Signal Booster. THIS IS A 90.219 CLASS B DEVICE WARNING. This is NOT a
CONSUMER device. It is designed for installation by FCC LICENSEES and QUALIFIED INSTALLERS. You MUST have
an FCC LICENSE or express consent of an FCC Licensee to operate this device. You MUST register PART 90 Class B
signal boosters (as defined in 47 CFR 90.219) online at www.fcc.gov/signal-boosters/registration. Unauthorized use may
result in a significant forfeiture penalties, including penalties in excess of $100,000 for each continuing violation. Patent:
http://www.corning.com/worldwide/en/patent-notices.html

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 6
RF Safety
To comply with FCC RF exposure compliance requirement, adhere to the following warnings:
Warning! Antennas used for this product must be fixed mounted on indoor permanent structures, providing a separation
distance of at least 50 cm from all persons during normal operation.
Warning! Each individual antenna used for this transmitter must be installed to provide a minimum separation distance of 50
cm or more from all persons and must not be co-located with any other antenna for meeting RF exposure requirements.
Warning! Antenna gain should not exceed 12.5 dBi.
Warning! The design of the antenna installation needs to be implemented in such a way so as to ensure RF radiation safety
levels and non-environmental pollution during operation.
ATTENTION!
Compliance with RF safety requirements:
•Corning products have no inherent significant RF radiation
•The RF level on the downlink is very low at the downlink ports. Therefore, there is no dangerous RF radiation when the
antenna is not connected.
CAUTION!
Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous
radiation exposure.
Laser Safety
•Fiber optic ports of the Corning optical network evolution (ONE™) solution elements emit invisible laser radiation at the
1310/1550 nm wavelength window.
•External optical power is less than 10 mW, Internal optical power is less than 500 mW.
•To avoid eye injury never look directly into the optical ports, patchcords or optical cables. Do not stare into beam or view
directly with optical instruments. Always assume that optical outputs are on.
•Only technicians familiar with fiber optic safety practices and procedures should perform optical fiber connections and
disconnections of the devices and the associated cables.
•CoringONE has been tested and certified as a Class 1 Laser product to IEC/EN 60825-1 (2007). It also meets the
requirements for a Hazard Level 1 laser product to IEC/EN 60825-2: 2004 to the same degree.
•Corning ONE complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to laser notice no. 50 (2007).

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 7
Care of Fiber Optic Connectors
•Do not remove the protective covers on the fiber optic connectors until a connection is ready to be made. Do not leave
connectors uncovered when not connected.
•The tip of the fiber optic connector should not come into contact with any object or dust.
Company Certification
ISO 9001: 2000 and ISO 13485: 2003
Licensee Contact Information
Industrial Boosters may only be used by FCC licensees or those given express (individualized) consent of license. Corning
Optical Communications Wireless certifies all of the VARs listed as licensed installers for Corning. For the list of licensed
VARs, please contact the Tech Support Hotline: (US) 410-553-2086 or 800-787-1266.
FCC at (https://signalboosters.fcc.gov/signal-boosters/) for Class B devices. FRN contact: Isaac Nissan, FRN# 0027544261

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 8
Additional Relevant Documents
The following documents are required if the corresponding units are included in your system (these can be downloaded from
the Corning partner portal).
Document Name
Part Number
Five- band remote access unit datasheet
CE0009001 Rev A00 and higher
Corning optical network evolution (ONE™) system installation
709C011801 REV A01
Headend Control Module (HCM) and Web Management GUI
User Manual
709C014205 Rev. A00 and higher
About This Manual
This user guide provides all the information necessary to understand the architecture and general installation procedures and
requirements of the Corning optical network evolution (ONE) solutions convergence infrastructure five-band remote access
unit (RAU5x) and plug-in add-on modules, optionally assembled in the RAU enclosure (hot pluggable):
•RxU2325 (supports two additional bands: 2300 MHz WCS and 2500 MHz TDD)
•RXU67 (supports two additional bands: 600MHz and FirstNet 700MHz)
•GEM (Gigabit Ethernet module)
Notes:
1. The monitoring, management capabilities, and configuration options of the remote access units are described in the
Corning ONE Web Management user manual.
2. RAU5, and RAU5x (extended bands) models have identical look and connectors, where both can optionally include
an external antenna connector.
3. GEM can't be installed together with RxU67.

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page
9
TABLE OF CONTENTS
1Introduction.............................................................................................. 13
1.1 Key Features and Capabilities ....................................................................................................................13
1.2 Architecture.................................................................................................................................................14
1.3 Web Management Application ....................................................................................................................15
2Interfaces................................................................................................. 16
2.1 RAU5x........................................................................................................................................................16
2.2 RxU2325.....................................................................................................................................................19
2.3 RxU67.........................................................................................................................................................20
2.4 GEM ...........................................................................................................................................................21
3Installation Guidelines.............................................................................. 23
3.1 Infrastructure Preparation ...........................................................................................................................23
3.2Installation Location Requirements.............................................................................................................23
3.3 Safety Guidelines........................................................................................................................................23
3.4 Power Requirements ..................................................................................................................................24
3.4.1 Power Input and Consumption.........................................................................................................24
3.4.2 Cable Gauge Requirements............................................................................................................24
3.4.3 Power, Heat and Rack Specifications..............................................................................................25
3.4.4 Remote End Distance and Power Draw Matrix................................................................................25
3.4.5 Power Safety Instructions................................................................................................................27
3.4.6 Circuit Breakers...............................................................................................................................27
3.5 RF Coaxial Cable Guidelines......................................................................................................................27
3.5.1 General Cable Installation Procedures ............................................................................................27
3.5.2 RF Rules .........................................................................................................................................27
3.5.3 Coax Cable Lengths and Losses.....................................................................................................28
3.6 Antenna Specifications and Guidelines.......................................................................................................29
3.6.1 Authorized Antennas and Required Specifications ..........................................................................29
3.6.2 General Installation Guidelines........................................................................................................29
3.7 Fiber Optic Requirements...........................................................................................................................29
3.7.1 Authorized Optic Cables..................................................................................................................29
3.7.2 Fiber Optic Rules.............................................................................................................................29

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page
10
3.8 Power Safety Instructions ...........................................................................................................................30
4Installation................................................................................................ 31
4.1 Verify Package Contents.............................................................................................................................32
4.1.1 RAU5x Package..............................................................................................................................32
4.2 Assemble Relevant Add-ons.......................................................................................................................32
4.3 Mount the RAU5x........................................................................................................................................33
4.3.1 Standard Standoff Mount Installation...............................................................................................34
4.3.1.1 Mount the standoff mount.........................................................................................................34
4.3.1.2 For green-field installation with RxU67......................................................................................35
4.3.1.3 Mount the RAU5x onto the standoff mount...............................................................................36
4.3.2 Top Bracket (Mid-Mount Installation)...............................................................................................38
4.3.2.1 Package Contents...................................................................................................................38
4.3.2.2 Installing Bracket Assembly and Mounting RAU5x....................................................................39
4.3.2.3 Top Bracket Cap Assembly ......................................................................................................44
4.3.3 Wall Bracket Mount .........................................................................................................................47
4.3.3.1 Package Contents ....................................................................................................................47
4.3.3.2 Installing Wall Mount Bracket and Mounting RAU5x .................................................................48
4.4 Connect the Cables ....................................................................................................................................52
4.4.1 Locate Required Connection Cables ...............................................................................................52
4.4.2 Connect the Cables.........................................................................................................................53
4.4.2.1 Grounding Connection..............................................................................................................53
4.4.2.2 Optical Fiber Connection ..........................................................................................................54
4.4.2.3 Main Power Connections..........................................................................................................54
4.4.2.4 RF Connections........................................................................................................................56
4.4.2.5 Antenna Connections ...............................................................................................................59
4.5 Verify Normal Operation..............................................................................................................................59
5RAU5x/RxU2325 Cavity Filter Installation............................................... 61
5.1.1 Package Contents...........................................................................................................................62

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page
11
5.1.2 (Concrete) Ceiling Mounting Option.................................................................................................62
5.1.3 Acoustic Ceiling Mount Installation ..................................................................................................63
5.1.4 Wall Mount Installation.....................................................................................................................63
5.1.5 Filter Connections............................................................................................................................65
6Appendix A: Bracket Dimensions ............................................................ 66
Top Bracket .........................................................................................................................................................67
Wall- Mountable Bracket......................................................................................................................................68
7Appendix B: Upgrades............................................................................. 70
7.1 Package Contents.......................................................................................................................................70
7.1.1 RxU67 Package...............................................................................................................................70
7.1.2 RxU2325 Package...........................................................................................................................71
7.1.3 GEM Package.................................................................................................................................71
7.2 Installing the Plug-in Module in the RAU5x .................................................................................................71
7.2.1 Connect RxU2325 and/or GEM to the RAU5x.................................................................................73
7.2.2 Connect an RxU67 to the RAU5x ....................................................................................................74
7.2.2.1 Connect the RxU67 unit to the RAU5x......................................................................................74
7.2.2.2 Assemble the Cavity filter .........................................................................................................75
8Appendix C: Specifications...................................................................... 78
System Level RF Parameters per Service............................................................................................................78
Optical .................................................................................................................................................................79
Environmental Specifications...............................................................................................................................79
Standards and Approvals.....................................................................................................................................79
Component Specifications ...................................................................................................................................79
Remote Expansion Unit (RxU67) ................................................................................................................81
2300 MHz/2500 MHz Remote Expansion Unit (RxU2325)..........................................................................81
Cavity Duplexer for LTE 700 MHz...............................................................................................................81
Cavity Duplexer for 800 MHz ......................................................................................................................82
Gigabit Ethernet Module (GEM)..................................................................................................................83

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page
12
9Appendix D: Ordering Information........................................................... 84
Accessories .........................................................................................................................................................84

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 13
1INTRODUCTION
The five-band remote access unit (RAU5x) is a fiber fed, multi-service indoor coverage remote solution for Corning® optical
network evolution (ONE™) solutions. It enables multiple wireless technologies and operator services to be distributed over a
single broadband infrastructure. The RAU5x supports up to five SISO services (model dependent) in various combinations in
addition to two MIMO services via an expansion module. The RF services are routed from the headend according to user
defined service groups over single-mode fiber and converted for distribution by the specified remotes via an external
broadband antenna
Note: RAU5x can be ordered with a preassembled Corning external antenna or can be connected to external omni directional
or directional antennas complying with the requirements specified in Section 3.6.1.
The remote unit can host the following additional modules:
•RxU67 (Remote expansion unit 67) –provides 600MHz and FirstNet 700 support
•RxU2325 (Remote expansion unit 2325) —provides support for two additional bands: 2300 MHz WCS and 2500 MHz
TDD
•GEM (Gigabit Ethernet module) –provides Gigabit Ethernet support, enabling offload, expansion and effective use of Wi-
Fi resources. Ethernet services from the corporate LAN (received via Ethernet switch) are routed towards the GEM. The
optical traffic is then converted to 1GbE by the GEM and distributed to two third party equipment such as access points,
Ethernet switch, etc.
Note: RxU67 and GEM cannot be added together.
The RAU5x can be deployed alongside other Corning ONE remotes (e.g., mid-power remote unit –MRU), sharing a common
headend and element management system. Management and configuration options are provided for each remote access unit
service via a web session to the headend control module (HCM).
1.1 Key Features and Capabilities
•Multi-frequency/ multi-service platform: supports five services: ESMR 800/CELL 850, LTE 700, AWS1/3 1700, and PCS 1900
•Expansion of RAU5x services via RxU2325 plug-in module which supports 2300 MHz and 2500 MHz TDD —support for
seven services per coverage area over the same footprint.
•Multi-operator optimized platform —services from a number of operators can be distributed by the same unit
•Operator grade performance —advanced signal handling, RF filtering and management ensures operator grade
performance
•Optic fiber savings —all services are routed over a single optic fiber pair
•Expansion module RxU67 providing expansion of two additional bands:600MHz and FirstNet 700.
•Ethernet support —supports “plug in” GEM providing support for connected IP devices (Wi-Fi APs, IP Phones, etc.) with
Ethernet pass through and PoE
•Simple installation and maintenance —provided with easy-to-install mounting bracket; all interfaces located on front panel
•Array of mounting options —various accessory kits available to accommodate different mounting options: wall/ceiling
mount, back-to-back wall mount, acoustic ceiling installations
•Management and control —alarm forward to NOC or standard EMS via SNMP, software-controlled output power and optical
link auto gain control

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 14
1.2 Architecture
The remote access units distribute the wireless and Ethernet services received over the fiber-optic infrastructure from the
Corning® optical network evolution (ONE™) solutions headend.
The RAU5x is a service-specific module supporting five SISO services that performs the optical to RF conversion of signals
received from the optical interface unit (OIU) at the headend. Signals are automatically filtered, amplified and distributed via
external antennas. Uplink signals are then converted to optical signals before being transmitted back to the OIU.
Figure 1-1. Example of Corning Optical Network Evolution (ONE) Solutions Deployment
Acronyms
AP = Access point
GEM = Gigabit Ethernet Module
HCM = Headend control module
HEU = Headend unit
RAU5x = Five-band remote access unit
RxU67, RxU2325 = RF expansion modules
ICU = Interconnect unit
OIU = Optical interface unit
Table 1-1. Acronyms in System Architecture

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 15
1.3 Web Management Application
The Corning Optical Network Evolution (ONE™) Solution headend control module (HCM) enables centralized, system-level
element management and provides c omprehensive end-to-end, single source setup and management of the active RF system
components after their physical installation . Management capabilities are provided for both the RAU5x and installed RF
expansion module.
Note: Refer to the Corning ONE™HCM and management GUI user manual for a complete description of the web
management application.
Figure 1-2. Example of RAU5x Device Management Window
The RAU5x device management tabs include the following:
Tab
Description
Device Alarms
Module specific alarms used for fault sourcing
Module Info
Provides device version and identification definition
Alarms
Service level alarms
RF Parameters
Includes configurable RF parameters such as output power and service
on/off option.
Comments
Used to enter any information relevant to the selected device
Table 1-2. RAU5x Device Management Tabs Descriptions

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 16
2INTERFACES
2.1 RAU5x
Note the following:
•The RAU5x can host additional expansions:
•RxU67 –expansion module providing expansion of two additional bands:600MHz and FirstNet 700.
•RxU2325 —expansion module providing support for two additional bands: 2300 WCS and 2500 TDD bands
•GEM –provides digital coverage.
•GEM and RxU67 may not be installed together.
•Specific RAU5x models are available with provided external antenna enclosure.
Figure 2-1. RAU5x: Interfaces
GND Bolt

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 17
Figure 2-2. RAU5x with GEM: Interfaces
Interface
Description
MGMT
RJ-45 local management connection
MAIN POWER
Main DC input; Input range: 37 –57 VDC; DC power fed from composite cable; Refer to
section 3.4.1 for power consumption
SECONDARY POWER
Secondary DC input required for use in addition to “‘MAIN POWER” with PoE clients
(installations including GEM module); Refer to section 3.4.1 for power input per PoE port
and consumption
LIST. MODE
N/A
EXTERNAL ANTENNA
QMA connector for external broadband antenna connection
CELL/LTE FILTER
Two QMA RF connectors (In/Out) per external cavity filter type (i.e. LTE and CELL)
OPTIC
LC APC SM connector for UL and DL fiber optic connection
GROUNDING BOLT
8-32 x 3/8 grounding screw used for connecting RAU5x to earth ground

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 18
Table 2-1. Connection Interface Descriptions
LED
Description
POWER
Steady green —power input detected by remote unit
Off - no power supplied to remote unit
LINK
Steady green —Optical link power to/from the remote unit is normal
Blinking green —Optical power from remote is lower than required
Off —no optical link is detected
RUN
Blinking green blinking —software initializing
Steady green —boot up sequence complete and module software up and running
Off —no power supplied to unit
Table 2-2. LED Descriptions

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 19
2.2 RxU2325
The RxU2325 is an add-on module which plugs into the RAU5x and enables support for two additional bands: 2.3 GHz WCS
and 2.5 GHz LTE (TDD).
Figure 2-3. RxU2325 Interfaces
Module
Description
To RAU
QMA RF connector; Connects to RAU5x
ANT.
QMA RF connector; Connects to external antenna
UL/DL External
QMA RF ports for external cavity filter use (if required by site planner). For
CELL and LTE filters.
Table 2-3. RxU2325 Interface Connections

Corning Restricted
Corning Optical Communications User Manual I CMA-482-AEN I Page 20
2.3 RxU67
The RxU67 is an add-on module which plugs into the RAU5x and enables support for two additional bands: 600MHz and
FirstNet 700.
Figure 2-4. RxU67 and Filter Interfaces
Module
Description
External RF Filters
DL600 UL600 DL700 UL700
PWR LED
Indicates power ON.
Table 2-4. RxU67 Front Panel Interface Connections
