Cosmo COS-ERC305WKTD User manual

Rev.23.11
ELECTRIC RANGE
COS-ERC305WKTD
USER MANUAL
IMPORTANT:
INSTALLER:
OWNER:
30" SLIDE-IN RANGE
READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
PLEASE LEAVE THESE INSTRUCTIONS WITH THIS UNIT FOR
THE OWNER.
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE.

2
THANK YOU FOR YOUR PURCHASE
Thank you for your purchase. We know that you have many brands and
products to choose from and we are honored to know that you have decided
to take one of our products into your home and hope that you enjoy it.
COSMO Appliances are designed according to the strictest safety and
performance standard for the North American market. We follow the most
advanced manufacturing philosophy. Each appliance leaves the factory after
thorough quality inspection and testing. Our distributors and our service
partners are ready to answer any questions you may have regarding how to
install, use and care for your products. We hope that this manual will help you
learn to use the product in the safest and most effective manner.
Before using this product, please read through this manual carefully. Keep
this user manual in a safe place for future reference. Please ensure that other
persons using this product are familiar with these instructions as well.
If you have any questions or concerns, please contact the dealer from whom you
purchased the product, or contact our Customer Support at:
1-888-784-3108
Reach us online at:
www.cosmoappliances.com

3
TABLE OF CONTENTS
RANGE SAFETY.................................................................................................... 5
Anti-tip Device........................................................................................................... 6
Important Safety Instructions ................................................................................. 7
OVERVIEW..........................................................................................................12
Range Layout............................................................................................................ 12
Control Panel ............................................................................................................13
FEATURES ...........................................................................................................15
Clock ........................................................................................................................... 15
Timer...........................................................................................................................16
Settings ...................................................................................................................... 17
Oven Light ................................................................................................................20
Lock............................................................................................................................20
OPERATION........................................................................................................21
Cooktop ..................................................................................................................... 21
Before Using the Cooktop..................................................................................21
Cooking Areas..................................................................................................... 23
Warming Zone.................................................................................................... 24
Hot Surface Indicator ........................................................................................24
Using the Cooktop Elements ............................................................................ 25
Using the Proper Cookware..............................................................................26
Oven .......................................................................................................................... 28
Before Using the Oven ...................................................................................... 28
Before Using the Oven for the First Time ....................................................... 28
Oven Vent ............................................................................................................ 29
Oven Door............................................................................................................ 29
Using Oven Racks ...............................................................................................29
Preheating ...........................................................................................................30
Cooking Modes....................................................................................................31
Pizza...................................................................................................................... 32
Air Fry.................................................................................................................... 32
Bake ...................................................................................................................... 33

4
Broil ....................................................................................................................... 34
Convect Roast ..................................................................................................... 35
Convect Bake ...................................................................................................... 36
Proof...................................................................................................................... 37
Keep Warm.......................................................................................................... 37
Cook Time ............................................................................................................ 38
Delay.....................................................................................................................39
Using the Sabbath Mode...................................................................................41
Tips and Techniques ..........................................................................................43
RANGE CARE AND MAINTENANCE..................................................................50
Manual Cleaning ....................................................................................................50
Self/Steam Clean .................................................................................................... 55
Steam Clean........................................................................................................ 55
Self Clean............................................................................................................. 57
TROUBLESHOOTING......................................................................................... 59
Cooktop Problems...................................................................................................59
Oven Problems .........................................................................................................61
LIMITED WARRANTY ........................................................................................64

5
RANGE SAFETY
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on
your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards
that can kill or hurt you and others.
All safety messages will follow the safety alert
symbol and either the word "WARNING" or
"CAUTION." These words mean:
You can be killed or seriously injured if you
don't follow instructions.
A potentially hazardous situation which, if not
avoided, could result in minor or moderate
injury.
All safety messages will tell you what the potential hazard is, tell you how
to reduce the chance of injury, and tell you what can happen if the
instructions are not followed.
WARNING
CAUTION
California Proposition 65 Warning
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

6
TIP OVER HAZARD
Making sure the anti-tip bracket is installed:
•Slide range forward.
•Look for the anti-tip bracket securely attached
to floor and wall.
•Slide range back so rear range foot is under
anti-tip bracket.
This appliance is intended for normal residential use. It is not approved for
commercial use, outdoor installation, or any other application not
specifically allowed by this manual.
This appliance requires connection to a 3-prong or 4-prong, 240VAC
single-phase (split-phase), 60Hz grounded electrical source. When
installed, appliance must be electrically grounded in accordance with local
codes or, in the absence of local codes, with the National Electrical Code,
NFPA 70 or the Canadian Electric Code, CSA C22.1-02.
Proper installation is the responsibility of the installer. Any adjustment and
service should be performed only by qualified range installers or service
technicians.
Product failure due to improper installation is not covered under warranty.
Anti-Tip
Bracket
Leveling
Leg
WARNING
•A child or adult can tip the range and be killed.
•Install anti-tip bracket to floor or wall per installation instructions.
•Slide range back so rear range foot is engaged in the slot of the anti-tip
bracket.
•Re-engage the anti-tip bracket if range is moved.
•Do not operate the range without anti-tip bracket installed and
engaged.
•Failure to follow these instructions can result in death or serious burns to
children and adults.
WARNING

7
IMPORTANT SAFETY
INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical shock, injury to persons, or
damage when using the range, follow basic precautions, including the
following:
•WARNING: TO REDUCE THE
RISK OF TIPPING OF THE RANGE,
THE RANGE MUST BE SECURED
BY PROPERLY INSTALLED ANTI-
TIP DEVICES. TO CHECK IF THE
DEVICES ARE INSTALLED
PROPERLY, SLIDE RANGE
COMPLETELY FORWARD, LOOK
FOR ANTI-TIP BRACKET
SECURELY ATTACHED TO THE
FLOOR OR WALL, AND SLIDE
RANGE BACK SO THE REAR
RANGE FOOT IS UNDER ANTI-
TIP BRACKET.
•CAUTION: Do not store items of
interest to children in cabinets
above a range or on the back
guard of a range – children
climbing on the range to reach
items could be seriously injured.
•Do Not Leave Children Alone –
Children should not be left alone
or unattended in area where
range is in use. They should
never be allowed to sit or stand
on any part of the appliance.
•Never use your appliance for
warming or heating the room.
•Use this appliance only for its
intended purpose as described
in this manual.
•Proper Installation – The
appliance, when installed, must
be electrically grounded in
accordance with local codes, or
in the absence of local codes,
with the National Electrical
Code, ANSI/NFPA 70 or the
Canadian Electrical Code, CSA
C22.1-02. In Canada, the
appliance must be electrically
grounded in accordance with
Canadian Electrical Code. Be
sure your appliance is properly
installed and grounded by a
qualified technician.
•User Servicing – Do not repair or
replace any part of the range
unless specifically recommended
in the manual. All other servicing
should be referred to a qualified
technician.
•Before performing any service,
unplug the range or disconnect
the power supply at the
household distribution panel by
removing the fuse or switching
off the circuit breaker.
•Do Not Use Water on Grease
Fires – Smother fire or flame or
use dry chemical or foam-type
extinguisher.
READ AND SAVE THESE INSTRUCTIONS

8
IMPORTANT SAFETY
INSTRUCTIONS
•If there is a fire in the oven
during baking, smother the fire
by closing the oven door and
turning the oven off or by using
a multi-purpose dry chemical or
foam-type fire extinguisher.
•Do not use any type of foil or
liner to cover the oven bottom or
anywhere in the oven, except as
described in this manual. Oven
liners can trap heat or melt,
resulting in damage to the
product and risk of shock, smoke
or fire.
•Use Only Dry Potholders – Moist
or damp potholders on hot
surfaces may result in burns
from steam. Do not let potholder
touch hot heating elements. Do
not use a towel or other bulky
cloth.
•DO NOT TOUCH SURFACE UNITS
OR AREAS NEAR UNITS – Surface
units may be hot even though
they are dark in color. Areas
near surface units may become
hot enough to cause burns.
During and after use, do not
touch, or let clothing or other
flammable materials contact
surface units or areas near units
until they have had sufficient
time to cool. Among these areas
are the coil elements, the
cooktop, and surfaces facing the
cooktop.
•DO NOT TOUCH HEATING
ELEMENTS OR INTERIOR
SURFACES OF OVEN – Heating
elements may be hot even
though they are dark in color.
Interior surfaces of an oven
become hot enough to cause
burns. During and after use, do
not touch, or let clothing or other
flammable materials contact
heating elements or interior
surfaces of oven until they have
had sufficient time to cool. Other
surfaces of the appliance may
become hot enough to cause
burns – among these surfaces
are oven vent openings and
surfaces near these openings,
oven doors, and windows of
oven doors.
•Do Not Cook on Broken Cooktop
–If cooktop should break,
cleaning solutions and spillovers
may penetrate the broken
cooktop and create a risk of
electric shock. Contact a
qualified technician
immediately.
•Avoid scratching or impacting
glass doors, cooktops, or control
panels. The cooktop can be
scratched with items such as
knives, sharp instruments, rings
or other jewelry, and rivets on
clothing. Doing so may lead to
glass breakage.
READ AND SAVE THESE INSTRUCTIONS

9
IMPORTANT SAFETY
INSTRUCTIONS
•Never Leave Surface Units
Unattended at High Heat
Settings – Boilover causes
smoking and greasy spillovers
that may ignite.
•Do Not Heat Unopened Food
Containers – Build-up of
pressure may cause container to
burst and result in injury.
•Wear Proper Apparel – Loose-
fitting or hanging garments
should never be worn while
using the appliance.
•Use Proper Pan Size – This
appliance is equipped with one
or more surface units of different
size. Select utensils having flat
bottoms large enough to cover
the surface unit heating
element. The use of undersized
utensils will expose a portion of
the heating element to direct
contact and may result in
ignition of clothing. Proper
relationship of utensil to heating
element will also improve
efficiency.
•Glazed Cooking Utensils – Only
certain types of glass,
glass/ceramic, ceramic,
earthenware, or other glazed
utensils are suitable for range-
top service without breaking due
to the sudden change in
temperature.
•Utensil Handles Should Be
Turned Inward and Not Extend
Over Adjacent Surface Units – To
reduce the risk of burns, ignition
of flammable materials, and
spillage due to unintentional
contact with the utensil, the
handle of a utensil should be
positioned so that it is turned
inward, and does not extend
over adjacent surface units.
•If power is lost to an electric
cooktop with knob surface unit
controls while a surface unit is
ON, the surface unit will turn
back on as soon as power is
restored. In the event of power
loss, failure to turn all surface
unit knobs to the OFF position
may result in ignition of items on
or near the cooktop, leading to
serious injury or death.
•Do not place or store items that
can melt or catch fire on the
glass cooktop, even when it is
not being used. If the cooktop is
inadvertently turned on, they
may ignite. Heat from the
cooktop or oven vent after it is
turned off may cause them to
ignite also.
•Use Care When Opening Door –
Let hot air or steam escape
before removing or replacing
food.
READ AND SAVE THESE INSTRUCTIONS

10
IMPORTANT SAFETY
INSTRUCTIONS
•Never broil with door open.
Open-door broiling is not
permitted due to overheating of
control knobs.
•Care must be taken to prevent
aluminum foil and meat probes
from contacting heating
elements.
•Placement of Oven Racks –
Always place oven racks in
desired location while oven is
cool. If rack must be moved
while oven is hot, do not let
potholder contact hot heating
element in oven.
•Injuries may result from misuse
of appliance doors or drawers
such as stepping, leaning, or
sitting on the doors or drawers.
•Storage in or on Appliance –
Flammable materials should not
be stored in an oven or near
surface units.
•This appliance is not intended
for storage.
•Maintenance – Keep range area
clear and free from combustible
materials, gasoline, and other
flammable vapors and liquids.
•Do not let cooking grease or
other flammable materials
accumulate in or near the range.
Grease in the oven or on the
cooktop may ignite.
•Keep Oven Vent Ducts
Unobstructed.
•Clean Cooktop With Caution – If
a wet sponge or cloth is used to
wipe spills on a hot cooking
area, be careful to avoid steam
burn. Some cleaners can
produce noxious fumes if
applied to a hot surface.
•Use care when touching the
cooktop. The glass surface of the
cooktop will retain heat after the
controls have been turned off.
•Do Not Soak Removable
Heating Elements – Heating
elements should never be
immersed in water.
•Do Not Clean Door Gasket – The
door gasket is essential for a
good seal. Care should be taken
not to rub, damage, or move the
gasket.
•Do Not Use Oven Cleaners – No
commercial oven cleaner or
oven liner protective coating of
any kind should be used in or
around any part of the oven.
•Clean Only Parts Listed in
Manual.
•Do not use replacement parts
that have not been
recommended by the
manufacturer (e.g. parts made
at home using a 3D printer).
READ AND SAVE THESE INSTRUCTIONS

11
IMPORTANT SAFETY
INSTRUCTIONS
•Proper Disposal of Your
Appliance – Dispose of or recycle
your appliance in accordance
with Federal and Local
Regulations. Contact your local
authorities for the
environmentally safe disposal or
recycling of your appliance.
For units with ventilating hood –
•Clean Ventilating Hoods
Frequently – Grease should not
be allowed to accumulate on
hood or filter.
•When flaming foods under the
vent hood, turn the fan on.
For self-cleaning ranges –
•Before Self-Cleaning the Oven –
Remove broiler pan and other
utensils. Wipe off all excessive
spillage before initiating the
cleaning cycle.
•Wait for the oven to cool before
removing contents and cleaning
the oven.
•In the event of ignition inside the
oven during self-clean, turn off
the oven and wait for the fire to
extinguish. DO NOT FORCE THE
DOOR OPEN. Introduction of
fresh air at Self Clean
temperatures may lead to a
burst of flame from the oven.
•If the self-cleaning mode
malfunctions, keep door closed,
turn off the appliance,
disconnect the circuit at the
circuit breaker box, and contact
a qualified service provider for
repairs.
•Some birds are extremely
sensitive to the fumes produced
during a self-clean cycle. Move
birds to another well-ventilated
room.
READ AND SAVE THESE INSTRUCTIONS

12
RANGE LAYOUT
The range you have purchased may have some or all of the items listed. The
locations and appearances of the features shown here may not match those
of your model.
1. Oven Vent
2. Cooktop
3. Oven Control
4. Cooktop Control
Knobs
5. Broil Heating
Element
6. Rack Positions
7. Bake Heating
Element Cover
8. Oven Door Handle
9. Cooling Vent
10. Door Lock
11. Oven Light
12. Door Gasket
13. Convection Fan
14. Door Hinge
15. Storage Drawer
16. Leveling Legs
OVERVIEW

13
WHAT'S INCLUDED
Oven racks (2)
NOTE:
•To purchase replacement parts or any other accessories, please visit
www.cosmoappliances.com or reference the contact information at
the end of this manual.
CONTROL PANEL
COOKTOP
Stronger heating elements are placed towards the front for higher
temperature or shorter duration cooking, such as boiling, searing, and pan
frying. Weaker heating elements are placed towards the rear for lower
temperature or longer duration cooking, such as simmer or melting chocolate.
Warming zone is also placed towards the rear center for keeping hot and
cooked food at serving temperature.
Warming
zone
Cooktop
control knobs

14
OVEN
Read the instructions for each feature and cooking mode in this owner's
manual carefully before using the oven.
# Name Description
1 PIZZA To select the Pizza mode.
2 AIR FRY To select the Air Fry mode.
3 BAKE To select the Bake mode.
4 BROIL To select the Broil mode.
5 Display To provide oven status.
6 TIMER To set or cancel the timer.
7 CLOCK
8 WARM ZONE To turn the warming zone on and off.
9 SETTINGS To access and adjust oven settings.
10 CONVECT ROAST To select the Convect Roast mode.
11 CLEAN To select the Self Clean / Steam Clean modes.
12 CONVECT BAKE To select the Convect Bake mode.
13 PROOF To select the Proof / Keep Warm modes.
14 Number Pads To enter temperature and all times.
To set or adjust the clock.

15
# Name Description
15 START/ENTER To start all oven functions or accept input.
16 CLEAR/OFF To stop oven operations or clear input.
17 COOK TIME To set the length of the cooking time.
18 DELAY To set delay start time of the cooking.
19 OVEN LIGHT To turn the oven lights on and off.
20 LOCK
FEATURES
CLOCK
IMPORTANT: The 12-hour clock must be set to the correct time of day for the
automatic oven timing functions to work properly. The time of day cannot be
changed during a timed cooking, timer cycle, or Self/Steam Clean cycle.
Setting the Clock
1. Press CLOCK, the time in the display will begin to flash.
2. Press the numbers to enter the correct time of day. For example, to set
12:34, press the numbers 1, 2, 3, and 4.
3. Press CLOCK to toggle and select AM or PM.
4. Press START/ENTER to confirm the time entered.
NOTE:
To deactivate and activate oven control.
•In the event of a power failure, the clock time set will be lost. When the
power returns, "12:00" will flash in the display and clock must be set
again.

16
TIMER
The Timer will beep when the set time has run out, and can be used during
any of the other oven control functions. It does not start or stop cooking.
Setting the Timer (Up to 12 Hours)
1. Press TIMER once. "00:00" will show in the display.
2. Press the numbers to enter the length of time. For example, to set a 30-
minute timer, press the numbers 3 and 0.
NOTE:
3. Press START/ENTER to start the timer.
NOTE:
•The set time counting down is shown in the display.
•For remaining time less than an hour, the display shows MM:SS
(minutes : seconds); for remaining time over an hour, the display
shows HH:MM (hours : minutes).
4. Press TIMER to cancel the current timer at any time. When the set time
has run out and the remaining time "00:00" shows in the display, the
alarm rings until any key is pressed.
NOTE:
•Pressing CLEAR/OFF will not cancel the current timer, but will
cancel any oven cooking modes in progress.
•If no numbers are entered, the timer returns to the time of day.

17
SETTINGS
The oven has a variety of settings which can be accessed and adjusted using
the SETTINGS button. These settings can only be adjusted or activated while
no oven operation is in progress. They remain in the control's memory after a
power failure or until changed.
Settings Description Default
VOL Volume
•Adjust the tone volume.
2 (MAX)
DISP Display Brightness
•Adjust the brightness of the display.
3 (MAX)
HOLD Keep Warm When Done Mode
•Turn Keep Warm When Done on or off to
automatically turn on "Keep Warm" or turn off
oven at the end of a timed cook.
Off
SABB Sabbath Mode
•Turn Sabbath mode on or off.
Off
DEG Temperature Scale
•Switch the temperature scale between
Fahrenheit and Celsius.
°F
CAL Oven Temperature Calibration
•Adjust the oven offset temperature.
00°F
SALE Demo Mode
•Turn Demo mode on or off.
Off
SETTING TONE VOLUME
1. Press SETTINGS.
2. Press START/ENTER to enter "VOL" setting.
3. Press +or –to toggle and select 0, 1, or 2 (MAX), and press START/ENTER.
4. Press CLEAR/OFF or SETTINGS to exit oven settings.

18
SETTING DISPLAY BRIGHTNESS
1. Press SETTINGS.
2. Press +or –repeatedly to select "DISP", and press START/ENTER.
3. Press +or –to toggle and select 1, 2, or 3 (MAX), and press START/ENTER.
4. Press CLEAR/OFF or SETTINGS to exit oven settings.
TURNING ON/OFF KEEP WARM WHEN DONE MODE
Keep Warm When Done mode turns on "Keep Warm" automatically to
maintain oven temperature of 150°F at the end of a timed cook to keep food
warm. This feature only works with cooking modes mentioned in "Cook Time"
section.
1. Press SETTINGS.
2. Press +or –repeatedly to select "HOLD", and press START/ENTER.
3. Press +or –to toggle and select On or Off, and press START/ENTER.
•On: Turn on "Keep Warm" at the end of a timed cooking.
•Off: Turn off oven at the end of a timed cooking.
4. Press CLEAR/OFF or SETTINGS to exit oven settings.
TURNING ON/OFF SABBATH MODE
Sabbath mode is designed for those whose religious observances require
disabling certain oven features. By turning on Sabbath Mode, the oven will
conform to Star-K Jewish Sabbath requirements.
To Turn On/Off Sabbath Mode:
1. Press SETTINGS.
2. Press +or –repeatedly to select "SABB", and press START/ENTER.
3. Press +or –to toggle and select On or Off, and press START/ENTER. A
single bracket "]" will appear in the display indicating that the Sabbath
mode is active.
4. Press CLEAR/OFF or SETTINGS to exit oven settings.

19
SETTING TEMPERATURE SCALE
1. Press SETTINGS.
2. Press +or –repeatedly to select "DEG", and press START/ENTER.
3. Press +or –to toggle and select F or C, and press START/ENTER.
•F: Fahrenheit
•C: Celsius
4. Press CLEAR/OFF or SETTINGS to exit oven settings.
SETTING TEMPERATURE CALIBRATION
This oven may cook differently than the one it replaced. Use the oven for a
few weeks to become more familiar with it before adjusting the thermostat
settings. Do not use thermometers, such as those found in grocery stores, to
check the temperature setting of your oven. These thermometers may vary
20–40 degrees.
1. Press SETTINGS.
2. Press +or –repeatedly to select "CAL", and press START/ENTER.
3. Press +or –to toggle and select between -25°F and 25°F, and press
START/ENTER.
4. Press CLEAR/OFF or SETTINGS to exit oven settings.
TURNING ON/OFF DEMO MODE
Demo Mode allows user to explore various features and options on the oven
user interface without turning on all the functionality (i.e. turning on the
heating elements).
1. Press SETTINGS.
2. Press +or –repeatedly to select "SALE", and press START/ENTER.
3. Press +or –to toggle and select On or Off, and press START/ENTER.
4. Press CLEAR/OFF or SETTINGS to exit oven settings.

20
OVEN LIGHT
The oven lights automatically turn on when the door is opened and turn off
when the door is closed.
•Press OVEN LIGHT to manually turn the oven lights on or off.
NOTE:
•The oven lights cannot be turned on if the Self Clean feature is active.
LOCK
The Lock feature locks most oven controls to avoid unintended use of the
oven.
•Press and hold LOCK for 3 seconds to activate or deactivate the oven
controls.
