Cosmo GRP Series User manual

Rev.23.06
COS-GRP486G
GAS RANGE
COS-GRP304
COS-GRP366
INSTALLATION INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
PLEASE LEAVE THESE INSTRUCTIONS WITH THIS UNIT FOR
THE OWNER.
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
IMPORTANT:
INSTALLER:
OWNER:
GRP SERIES SLIDE-IN RANGE

2
THANK YOU FOR YOUR PURCHASE
Thank you for your purchase. We know that you have many brands and
products to choose from and we are honored to know that you have decided
to take one of our products into your home and hope that you enjoy it.
COSMO Appliances are designed according to the strictest safety and
performance standard for the North American market. We follow the most
advanced manufacturing philosophy. Each appliance leaves the factory after
thorough quality inspection and testing. Our distributors and our service
partners are ready to answer any questions you may have regarding how to
install, use and care for your products. We hope that this manual will help you
learn to use the product in the safest and most effective manner.
Before using this product, please read through this manual carefully.
Keep
this user manual in a safe place for future reference. Please ensure that other
persons using this product are familiar with these instructions as well.
If you have any questions or concerns, please contact the dealer from whom you
purchased the product, or contact our Customer Support at:
1-888-784-3108
Reach us online at:
www.cosmoappliances.com

3
TABLE OF CONTENTS
RANGE SAFETY.................................................................................................... 4
Anti-tip Device ........................................................................................................... 6
INSTALLATION REQUIREMENTS ........................................................................ 7
Tools and Parts .......................................................................................................... 7
Location Requirements ............................................................................................ 9
Product Dimensions ..................................................................................................11
Clearances.................................................................................................................14
Venting Requirements.............................................................................................16
Electrical Requirements........................................................................................... 17
Gas Supply Requirements ......................................................................................19
INSTALLATION INSTRUCTIONS........................................................................ 23
Remove Old Appliance .......................................................................................... 23
Unpack Range ......................................................................................................... 25
Install Anti-tip Device ............................................................................................. 26
Install/Remove Oven Door Handle...................................................................... 29
Install/Remove Control Knobs ...............................................................................31
Gas Connection....................................................................................................... 33
Complete Installation............................................................................................. 37
Electrical Supply Connection............................................................................ 37
Placement and Leveling Range ....................................................................... 38
Verify Anti-tip Bracket Engagement............................................................... 39
Removing/Assembling Oven Door...................................................................41
Assembling the Surface Burners and Grates ................................................ 43
Checking Operation of the Surface Burners .................................................45
Adjust Flame Height .......................................................................................... 47
Checking Operation of the Oven ....................................................................49
GAS CONVERSION............................................................................................50
Convert Gas Pressure Regulator.......................................................................51
Convert Surface Burners ...................................................................................54
Convert Oven Burners ....................................................................................... 58
Complete Gas Conversion ............................................................................... 60

4
RANGE SAFETY
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on
your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards
that can kill or hurt you and others.
All safety messages will follow the safety alert
symbol and either the word "WARNING" or
"CAUTION." These words mean:
You can be killed or seriously injured if you
don't follow instructions.
A potentially hazardous situation which, if not
avoided, could result in minor or moderate
injury.
All safety messages will tell you what the potential hazard is, tell you how
to reduce the chance of injury, and tell you what can happen if the
instructions are not followed.
In the State of Massachusetts, the following installation instructions apply:
•Installations and repairs must be performed by a qualified or licensed
contractor, plumber, or gasfitter qualified or licensed by the State of
Massachusetts.
•If using a ball valve, it shall be a T-handle type.
•A flexible gas connector, when used, must not exceed 3 feet.
California Proposition 65 Warning
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
WARNING
CAUTION

5
FIRE AND EXPLOSION HAZARD
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or death.
-Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
-WHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance.
•Do not touch any electrical switch.
•Do not use any phone in your building.
•Clear the room, building, or area of all occupants.
•Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fire department.
-Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
Never Operate the Top Surface Cooking Section of this Appliance
Unattended.
•Failure to follow this warning statement could result in fire, explosion,
or burn hazard that could cause property damage, personal injury, or
death.
•If a fire should occur, keep away from the appliance and immediately
call your fire department.
DO NOT ATTEMPT TO EXTINGUISH AN OIL/GREASE FIRE WITH WATER.
WARNING
WARNING

6
WARNING: Gas leaks cannot always be detected by smell.
Gas suppliers recommend that you use a gas detector approved by UL or
CSA. For more information, contact your gas supplier.
WARNING: Do not install a ventilation system that blows air downward
toward this cooking appliance. This type of ventilation system may cause
ignition and combustion problems with this cooking appliance resulting in
personal injury or unintended operation.
WARNING: This appliance is intended for normal residential use. It is not
approved for commercial use, outdoor installation, or any other application
not specifically allowed by this manual.
Making sure the anti-tip bracket is installed:
•Slide range forward.
•Safely tilt the front of the range upward
slightly and slide range back.
•Making sure the pin slides under the anti-tip
bracket.
•A child or adult can tip the range and be killed.
•Install anti-tip bracket to wall per installation instructions.
•Slide range back so rear range pin is under the anti-tip bracket.
•Re-engage the anti-tip bracket if range is moved.
•Do not operate the range without anti-tip bracket installed and
engaged.
•Failure to follow these instructions can result in death or serious burns to
children and adults.
WARNING
TIP OVER HAZARD

7
INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the required tools and parts before starting installation. Read and
follow the instructions provided with any tools listed here.
Tools Needed
•Tape measure
•Phillips screwdriver
•Level
•Drill and drill bit (for anti-tip
bracket installation)
•Adjustable wrench or pliers
•Pipe wrench
•Pipe-joint compound resistant to
Propane gas
•Noncorrosive leak-detection
solution
•Marker or pencil
For Propane/Natural Gas
Conversions
•Combination wrench
•Nut drive
Parts Needed
New flexible gas supply line
(3/4" or 1/2" NPT x 1/2" ID)
New Flare Union Adapter
(3/4" or 1/2" NPT x 1/2" ID)
New Flare Union Adapter
(1/2" NPT x 1/2" ID)
Gas line shut-off valve

8
Parts Supplied
Surface burner grates
30" Model: COS-GRP304 (3)
36" Model: COS-GRP366 (3)
48" Model: COS-GRP486G (4)
Surface burners and caps
30" Model: COS-GRP304 (4)
36" Model: COS-GRP366 (6)
48" Model: COS-GRP486G (8)
Control knobs
30" Model: COS-GRP304 (5)
36" Model: COS-GRP366 (7)
48" Model: COS-GRP486G (10)
Handle end caps with set screw
30" Model: COS-GRP304 (2)
36" Model: COS-GRP366 (2)
48" Model: COS-GRP486G (4)
Oven door handle
30" Model: COS-GRP304 (1)
36" Model: COS-GRP366 (1)
48" Model: COS-GRP486G (2)
Griddle
48" Model: COS-GRP486G
Gas pressure regulator
(pre-installed)
Anti-tip bracket with screw pin and
mounting screws

9
LOCATION REQUIREMENTS
IMPORTANT: Observe all governing codes and ordinances. Do not obstruct
flow of combustion and ventilation air.
•It is the installer's responsibility to comply with installation clearances
specified on the model/serial/rating plate. The model/serial/rating plate
is located on the back panel of the range.
•The range should be located for convenient use in the kitchen.
•Recessed installations must provide complete enclosure of the sides and
rear of the range.
•Do not install a ventilation system that blows air downward toward the
range.
•Do not locate the range where it may be subject to strong drafts.
•All openings in the wall or floor where range is to be installed must be
sealed.
•Do not seal the range to the side cabinets.
•Cabinet opening dimensions that are shown must be used.
•The anti-tip bracket must be installed.
•Grounded electrical supply is required. See "Electrical Requirements"
section.
•Proper gas supply connection must be available. See "Gas Supply
Requirements" section.
•Stylish color handle & knob kits
•LP conversion kits
Optional Parts
To purchase these or any other accessories or replacement parts, please visit
www.cosmoappliances.com or reference the contact information at the end
of this manual.
Scan to find
available LP kits
Scan to find
available
handle & knob
kits

10
IMPORTANT: To avoid damage to your cabinets, check with your builder or
cabinet supplier to make sure that the materials used will not discolor,
delaminate, or sustain other damage.
Mobile Home - Additional Installation Requirements
•The installation of this range must conform to the Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part 3280 (formerly the
Federal Standard for Mobile Home Construction and Safety, Title 24, HUD
Part 280). When such standard is not applicable, use the Standard for
Manufactured Home Installations, ANSI A225.1/NFPA 501A or with local
codes.
In Canada, the installation of this range must conform with the current
standards CAN/CSA-A240-latest edition, or with local codes.
Mobile Home Installations Require:
•When this range is installed in a mobile home, it must be secured to the
floor during transit. Any method of securing the range is adequate as
long as it conforms to the standards listed above.
•Four-wire power supply cord or cable must be used in a mobile home
installation. The appliance wiring will need to be revised. See "Electrical
Connection" section.

11
PRODUCT DIMENSIONS
Your model may appear different from the models depicted. Dimensions
given are maximum dimensions across all models.
COS-GRP304 (30”)
30 ¹⁄₁₆ in
(76.3 cm)
Min. 39 ³⁄₈ in
(100.0 cm)
30 ¹⁄₁₆ in
(76.3 cm)
39 ³⁄₈ - 40 ¹⁄₁₆ in
(100.0 - 101.7 cm)
37 ¹³⁄₁₆ - 38 ⁷⁄₁₆ in
(96.0 - 97.7 cm)
To cooktop
26 in
(66.0 cm)
44 ¹⁄₄ in
(112.4 cm)
Door fully open
27 ⁵⁄₁₆ in
(69.4 cm)
29 ¹⁄₁₆ in
(73.9 cm)
24 ⁵⁄₁₆ in
(61.8 cm)
34 ¹³⁄₁₆ in
(88.5 cm)
36 ⁷⁄₁₆ in
(92.5 cm)

12
36 in
(91.5 cm)
Min. 39 ³⁄₈ in
(100.0 cm)
COS-GRP366 (36")
26 in
(66.0 cm)
39 ³⁄₈ - 40 ¹⁄₁₆ in
(100.0 - 101.7 cm)
37 ¹³⁄₁₆ - 38 ⁷⁄₁₆ in
(96.0 - 97.7 cm)
To cooktop
36 in
(91.5 cm)
44 ¹⁄₄ in
(112.4 cm)
Door fully open
27 ⁵⁄₁₆ in
(69.4 cm)
29 ¹⁄₁₆ in
(73.9 cm)
24 ⁵⁄₁₆ in
(61.8 cm)
34 ¹³⁄₁₆ in
(88.5 cm)
36 ⁷⁄₁₆ in
(92.5 cm)

13
27 ⁵⁄₁₆ in
(69.4 cm)
29 ¹⁄₁₆ in
(73.9 cm)
24 ⁵⁄₁₆ in
(61.8 cm)
34 ¹³⁄₁₆ in
(88.5 cm)
36 ⁷⁄₁₆ in
(92.5 cm)
47 ⁷⁄₈ in
(121.7 cm)
Min. 39 ³⁄₈ in
(100.0 cm)
COS-GRP486G (48")
47 ⁷⁄₈ in
(121.7 cm)
39 ³⁄₈ - 40 ¹⁄₁₆ in
(100.0 - 101.7 cm)
37 ¹³⁄₁₆ - 38 ⁷⁄₁₆ in
(96.0 - 97.7 cm)
To cooktop
44 ¹⁄₄ in
(112.4 cm)
Door fully open
26 in
(66.0 cm)

14
Model
A
Horizontal Clearance
COS-GRP304 (30") 30" (76.2 cm)
COS-GRP366 (36") 36" (91.5 cm)
COS-GRP486G (48") 48" (121.9 cm)
CLEARANCES
IMPORTANT: Some cabinet and building materials are not designed to
withstand the heat produced by the oven for baking and self-cleaning. Check
with your builder or cabinet supplier to make sure that the materials used will
not discolor, delaminate or sustain other damage.
GIVEN DIMENSIONS ARE MINIMUM CLEARANCES.
13 in
(33 cm)
Overhead
Cabinet
Depth
36 in
(91.4 cm)
18 in
(45.7 cm)
30 in
(76.2 cm)
A
6 in
(15.2 cm)
to right
wall
6 in
(15.2 cm)
to left
wall
24 in
(61 cm)
Lower
Cabinet
Depth

15
NOTE:
•30" (76.2 cm) minimum clearance between cooking surface and bottom
of the overhead cabinet.
•18" (45.7 cm) minimum clearance from upper cabinet to countertop on
either side of unit.
•Island Installations: Maintain 6" (15.2 cm) minimum clearance from
cutout to back and side edges of countertop.
Power Supply Location
IMPORTANT: An electrical outlet in the floor, may be either recessed or
surface mounted, but an electrical outlet in the wall must be recessed to make
the connection.
4"
4"
A7"
2"
Electric
supply
area
Model
A
Cutout Width
COS-GRP304 (30") 30" (76.2 cm)
COS-GRP366 (36") 36" (91.5 cm)
COS-GRP486G (48") 48" (121.9 cm)

16
VENTING REQUIREMENTS
IMPORTANT: This range must be exhausted outdoors unless you are using
ductless venting. Observe all governing codes and ordinances. Do not
obstruct flow of combustion and ventilation air.
•Do not terminate the vent system in an attic or other enclosed area.
•Use an approved vent cap for proper performance. If an alternate wall or
roof cap is used, be certain the cap size is not reduced and that it has a
backdraft damper.
•Vent system must terminate to the outside unless you are using a ductless
vent kit.
•Rigid metal vent is recommended. For best performance, do not use
plastic or metal foil vent.
•If a joist or stud must be cut, then a supporting frame must be
constructed.
•The size of the vent should be uniform.
•The vent system must have a damper.
•Seal all joints in the vent system.
•Use caulking to seal exterior wall or roof opening around the cap.
•Determine which venting method is best for your application.
Makeup Air
Local building codes may require the use of makeup air systems when using
ventilation systems greater than specified CFM of air movement. The specified
CFM varies from locale to locale. Consult your HVAC professional for specific
requirements in your area.

17
ELECTRICAL REQUIREMENTS
U.S.A. ONLY
Be sure that the electrical connection and wire size are adequate and in
conformance with the National Electrical Code, ANSI/NFPA No. 70 - latest
edition and all local codes and ordinances.
A copy of the above code standards can be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02169
CANADA ONLY
Be sure that the electrical connection and wire size are adequate and in
conformance with the CSA Standard C22.1, Canadian Electrical Code, Part 1 -
latest edition and all local codes and ordinances.
A copy of the above code standards can be obtained from:
Canadian Standards Association
178 Rexdale Blvd.
Toronto, ON M9W 1R3 CANADA
WARNING
ELECTRICAL SHOCK HAZARD
ELECTRICAL GROUNDING INSTRUCTIONS
•Electrically ground range.
•Failure to do so can result in death, fire or electrical shock.
•The power cord of this appliance is equipped with a three-prong
(grounding) plug which plugs into a standard three-prong grounding
wall receptacle to minimize the possibility of electric shock hazard from
this appliance.
•DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE (THIRD)
GROUNDING PRONG FROM THE PLUG.

18
WARNING: Improper connection of the equipment-grounding conductor can
result in a risk of electric shock. Check with a qualified electrician or service
technician if you are in doubt as to whether the appliance is properly
grounded. Do not modify the power supply cord plug. If it will not fit the
outlet, have a proper outlet installed by a qualified electrician.
ELECTRICAL CONNECTION
•The receptacle of this range is to be connected to a properly grounded
dedicated circuit providing 120 VAC/60 Hz power and protected by a 15-
or 20-Amp circuit breaker or slow blow fuse. It is recommended that a
separate circuit serving only this range be provided.
•Where a standard two-prong wall receptacle is encountered, contact a
qualified electrician to have it replaced with a properly grounded three-
prong wall receptacle.
•This range is equipped with an electronic ignition system that will not
operate properly if plugged into an outlet that is not correctly polarized.
•Electronic ignition systems operate within wide voltage limits, but proper
grounding and polarity are necessary. Check that the outlet provides 120-
volt power and is correctly grounded.
•Do not use an extension cord or an adapter plug.
•Check local codes and consult gas supplier. Check existing electrical
supply and gas supply. It is recommended that all electrical connections
be made by a licensed, qualified electrical installer.
•Range must be connected to the proper electrical voltage and frequency
as specified on the model/serial/rating plate. The plate is located on the
back panel of the range.
•It is the personal responsibility of the range owner to provide the correct
electrical service for this range.
•This gas range is not required or recommended to be plugged into a GFCI
(Ground-Fault Circuit Interrupter) outlet. It is recommended that you not
plug an electric spark ignition gas range or any other major appliance
into a GFCI wall outlet as it may cause the GFCI to trip during normal
cycling.
•Performance of this range will not be affected if operated on a GFCI-
protected circuit. However, occasional nuisance tripping of the GFCI
breaker is possible due to the normal operating nature of electronic gas
ranges.
•The wiring diagram is located on the back of the range.

19
GAS SUPPLY REQUIREMENTS
IMPORTANT:
•Observe all governing codes and ordinances.
•This installation must conform with all local codes and ordinances. In the
absence of local codes, installation must conform with American National
Standard, National Fuel Gas Code ANSI Z223.1/NFPA 54 - latest edition,
or in Canada, the Natural Gas and Propane Installation Code, CAN 1-1.1-
M81 - latest edition.
•Leak testing of the range must be conducted according to the
manufacturer's instructions. Do not use a flame to check for leaks.
WARNING
FIRE AND EXPLOSION HAZARD
•Use a new CSA International approved gas supply line.
•Install a shut-off valve.
•Securely tighten all gas connections.
•If connected to LP, have a qualified person make sure gas pressure does
not exceed the maximum pressure listed in this section.
•Examples of a qualified person include:
-licensed heating personnel
-authorized gas company personnel
-authorized service personnel
•Failure to do so can result in death, explosion or fire.

20
TYPE OF GAS
This range is design-certified by CSA International for use with natural gas or,
after proper conversion, for use with Liquid Propane (LP) gas.
Natural Gas
This range is factory-set for use with Natural gas. The model/serial/rating
plate located on the back panel of the range has information on the types of
gas that can be used. If the types of gas listed do not include the type of gas
available, check with the local gas supplier.
LP Gas Conversion
The LP conversion kit is sold separately. Conversion must be performed by a
qualified service technician. The qualified agency performing this work
assumes the gas conversion responsibility. No attempt shall be made to
convert the appliance from the gas specified on the model/serial/rating plate
for use with a different gas without consulting the serving gas supplier.
GAS SUPPLY LINE
Provide a gas supply line of 3/4" (1.9 cm) rigid pipe to the range location. A
smaller size pipe on longer runs may result in insufficient gas supply. Pipe-joint
compounds that resist the action of LP gas must be used. With LP gas, piping
or tubing size can be 1/2" (1.3 cm) minimum. Usually, LP gas suppliers
determine the size and materials used in the system.
Flexible Metal Appliance Connector
•If local codes permit, a new CSA design-certified, 4 - 5 ft (122 - 152.4 cm)
long, 1/2" (1.3 cm) or 3/4" (1.9 cm) I.D., flexible metal appliance connector
may be used for connecting range to the gas supply line. In Canada,
flexible connectors must be single wall metal connectors less than 6 feet
(182.9 cm) in length.
•A 1/2" (1.3 cm) male pipe thread is needed for connection to the female
pipe threads of the inlet to the appliance pressure regulator.
•Do not kink or damage the flexible metal tubing when moving the range.
