CosmoPro LM917135 User manual

Installation Guide
PRODUCT #:
LM917135
ITEM:
Biarritz Pedi Pipeless Spa from
Cosmopro
Cosmopro
SOURCE FOR PURCHASE:
SpaEquip, Inc.
211 Wappo Ave.,
Calistoga, CA 94515
p: 707.737.1100
f: 707.737.1150
www.spaequip.net
LIST PRICE (USD):
FEATURES:
Treat your clients to the Biarritz, featuring plush comfort, Italian design, and a noiseless water pump. For comfort, the
adjustable seat reclines and swivels. For pedicures, the acrylic spa has 2 SaniJet pipeless water jet assemblies plus an
adjustable footrest and hand sprayer. For manicures, hand baths and manicure rests are included. Patented adjustable
headrest. (shown with Limoge stool, see below) The SaniJet water jet assemblies are completely removable for
maximum hygiene, and so quiet the sound of flowing water is barely audible. Since the water pump is included in each
assembly there is no internal piping to allow stagnant water or bacteria buildup. Marine grade vinyl fabric (shown in
Teak) is available in wide range of colors. 110V AC. 60" long (71" with seat fully reclined) x 37" wide x 54" high. Requires
3/4" Hot and Cold water supply and 1 1/2" drain connection. 1 Year parts and labor (excluding fabric), 2 Year shell. UL,
CE and CSA Certified. Oversized item - ships by Truck.
SPECIFICATIONS:
Dimensions: Upright 56" L x 36.5" W x 54" H; Reclined up to 73" L x 36.5" W x 50" H
Electrical: 115V AC - North America; 200-240V AC, 15 Amps - International; 50/60 Hz, GFCI
Suggested Outlet: Hard wired, GFI
Plumbing: 3/4" hot & cold, 1 1/2" (38mm) PVC floor drain for waste
Notes: See detailed specifications
Warranty: CO: 1 Year parts and labor (excluding fabric), 2 Year shell
Certifications: UL, CSA, CE
Country of Origin: United States
Installed By: Client's Contractor
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150 Page 1 of 18

General Overview
3 - Biarritz™ Installation Manual v.1.3
Photo #1
11
10
6
8
7
3
4
9
5
2
12
12
1
13
14
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150 Page 2 of 18

Biarritz™ Installation Manual v.1.3 - 4
General Overview
Item Descriptions
(See Photo #1)
1) Tub Fill Port
2) Hand Shower
3) Hand Shower Flow Control
4) Basin Fill Valve
5) Footrest Height Adjusting Hand Screw
6) Footrest Receiver
7) Thermostatic Control Valve
8) Jet Pump On/Off Control
9) Removable Lower Skirt Assembly
10) Seat Horizontal Adjustment
11) Seat Reclining Back Adjustment
12) Removable Manicure Soaking Bowls
13) Main Power
14) On/Off Indicator Light
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150 Page 3 of 18

5 - Biarritz™ Installation Manual v.1.3
Installation Requirements
LOCATION:
IMPORTANT NOTE: This system has been designed to be installed as a free standing
unit and should be located on a suitable, structurally sound and stable floor of
concrete or similar non-combustible material. The entire system containing water at
normal operating level, without the client, weighs approximately 282 lbs (128 kg). It
is recommended that a structural engineer be consulted prior to locating the system
in a facility, to ensure the floor support is suitable.
THE MAXIMUM ALLOWANCE INDIVIDUAL WEIGHT IS 300 (136 kg)LBS.
PLUMBING CONNECTIONS:
All connections to water supply and waste line should be made by a licensed plumber in
accordance with local and national plumbing codes.
Hot and cold supply connections are made by means of 3/4 inch (19 mm) compression
fittings provided. Incoming supply connections should be made in accordance with local
and national plumbing code requirements (See Photo #2 below).
IMPORTANT: Before connecting the hot and cold water to the FACILITY’S WATER
SUPPLY system, first purge the supply water to ensure all grit and waste is purged
from the inbound plumbing.
FAUCET/SALT WATER PRECAUTIONS
It is not recommended to run salt water through the system’s faucet (tapware) set. If the faucet
is connected directly to a salt water supply, it is essential that a fresh water flushing system
is also provided. This will ensure that the internal components of the faucet are flushed with
fresh water after being exposed to salt water (for further details, contact your distributor).
HOT
(red tape) COLD
(blue tape)
Photo #2
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150 Page 4 of 18

Plumbing Connections
PLUMBING CONNECTIONS:
Drain connection (waste line) is by means of the 1 1/2 inch (38 mm) PVC drain assembly
(See Photo #3). Connect to drain in accordance with local and national plumbing code
requirements.
IMPORTANT NOTE: We recommend the use of anti-slip graded tiles on surrounding
floor surfaces. This important recommendation will ensure a safe environment for
therapists and clients alike.
Biarritz™ Installation Manual v.1.3 - 6
1 1/2” (38mm) Sanitary Drain
Connection (to Floor Drain)
Photo #3
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150 Page 5 of 18

7 - Biarritz™ Installation Manual v.1.3
Electrical Connections
To 3 prong
male plug
Electrical
Box #1
Earth Ground
Grnd.
N
L1
Green
Black
WH
Photo #4A
ELECTRICAL CONNECTIONS:
WARNING: RISK OF ELECTRIC SHOCK
THIS SYSTEM MUST BE CONNECTED TO A SUITABLE ELECTRICAL
SUPPLY SOURCE IN ACCORDANCE WITH LOCAL AND NATIONAL
ELECTRICAL CODES.
The branch circuit supplying this system must be provided with a main disconnect in the
fixed wiring.
NOTE: Outside of North America, a GFCI may be referred to as an earth leakage circuit
breaker.
VERY IMPORTANT!!
This unit is to be connected to main power outlet supplied with 115v AC 60Hz power
using the attached 3 wired plug.
NOTE: Not Suitable for field installed heater
Photo #4B
Photo #4C
Alternate GFCI
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150 Page 6 of 18

ELECTRICAL CONNECTIONS
(see Photo # 4A-C)
IMPORTANT NOTE:
THERE ARE NO USER SERVICEABLE PARTS ON OR INSIDE THIS SYSTEM. DO
NOT ATTEMPT TO REMOVE ANY COVER FROM ANY COMPONENT. THE ENTIRE
SYSTEM OR ANY OF ITS COMPONENTS MUST BE SERVICED BY QUALIFIED
PERSONNEL. CONTACT THE MANUFACTURER OR SUPPLIER FOR FURTHER
SERVICING INSTRUCTIONS.
To assist you in case of any technical problems, the supplier will make available, upon request,
circuit diagrams, component parts lists, descriptions, calibration instructions or other information
which will assist the user’s technical personnel to repair those parts of the equipment which are
designed by the manufacturer as repairable.
Electrical Connections
VOLTAGE
CURRENT
FREQUENCY
PHASES
110V-115V
6 AMPS
60 Hz
1 / 3 Wire
Risk of electric
shock.
Disconnect power
prior to servicing.
DANGER
Biarritz™ Installation Manual v.1.3 - 8
N. American
VOLTAGE
CURRENT
FREQUENCY
PHASES
200V-230V
3 AMPS
50 Hz
1 / 2 Wire
European
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150 Page 7 of 18

9 - Biarritz™ Installation Manual v.1.3
Seat Installation
Photo #5
CHAIR INSTALLATION:
1. Position chair assembly as shown in Photo #5.
2. Align attaching bolts of chair base with pre-drilled holes in base assembly shell.
3. Using supplied nuts and washers (4 each), install from the underside and
secure/tighten using a 1/2” (13mm) deep well socket and ratchet assembly.
Note: 8 mm hardware nuts are included within your packaging.
Photo #6
4. Electrical connection for the chair massage is
located on back of unit between the chair and
base and is accomplished by connecting plugs
as shown.
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150 Page 8 of 18

Biarritz™ Installation Manual v.1.3 - 10
Ventilation
VENTILATION
This system is designed to be normally operated and cooled by the designed ventilation
means, allowing normal air flow beneath and around electrical and jet pump assemblies.
Additionally, each adjustable foot may be used to level the entire unit during installation.
Leveling feet also are designed to elevate the system and provide an adequate
ventilation area by providing an air gap between the bottom of the covering or skirt and
the floor (See Photo #7).
IMPORTANT NOTE:
DO NOT OBSTRUCT THE AIR GAP BETWEEN THE BOTTOM OF THE
SYSTEM AND THE FLOOR IN ANY WAY. TO DO SO MAY CAUSE
COMPONENT OVERHEATING AND DAMAGE TO YOUR EQUIPMENT.
Photo #7
1” (2.54 cm)
minimum
air gap
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150 Page 9 of 18

11-Biarritz™ Installation Manual v.1.3
Rough-In
Install in accordance with local and
national code requirements.
Biarritz™ Whisper-Soft
Hydrotherapy Foot Spa System
Overhead View
Side View
56”
142.2
cm
37”
94 cm
Plumbing codes vary from location
to location and may require
backflow prevention systems above
the included standard equipment
on the hot and cold supply lines.
Sanitary drain connections may
also require backflow prevention
that is not included with this
system. Please arrange with a
licensed plumbing contractor to
install the appropriate devices as
required to meet local codes.
34”
86.4 cm
FRONT
Plumbing and Electrical Layout
73”
185.4 cm
(In the reclined
position)
Electrical: 115V N. America
60Hz. 1P (6 Amp)
Install on dedicated line
with disconnect, all pole.
See Biarritz™ Installation and
User Guide for details.
Updated 10.06.05
This information is provided as a guide only. Cosmopro, Inc., as supplier, reserves the right to amend specifications without prior notice.
23”
58.4 cm
BACK
26”
66 cm
This area for inbound
Hot & Cold Supply
& 11/2”(3.8 cm)
Floor Drain
14”
35.6 cm
14”
35.6 cm
10”
25.4 cm Electrical Box
Connection
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150
Page 10 of 18

Biarritz™ Installation Manual v.1.3 - 12
Installation and Testing Procedures
• Remove all packaging material and inspect system thoroughly to ensure that no damage has
occurred during handling/transportation. In the event of damage due to shipping,
immediately notify the freight carrier so that an appropriate claim may be filed with the carrier.
• Select installation location in accordance with the instructions stated in the “Location”
section of this manual (Page 5). When selecting location, consideration must be given to
the proximity of the electrical and plumbing connections.
• Electrical and plumbing connections can now be made in accordance with location
plumbing and electrical codes. Refer to “Electrical Rating”, “Electrical and Plumbing
Connection” sections contained in this manual for technical support information
(See Pages 5 - 8)
Plumbing codes vary from location to location and may require the installation of check
valves (back-flow prevention valves) on incoming hot and cold water supply lines and/or
sanitary drain connections. Due to the variations in plumbing codes, this system is not
supplied with these valves. Please arrange for your plumbing contractor to install the
appropriate devices as required to meet your local codes.
NOTE: ANY METAL PLUMBING PROVIDED DURING INSTALLATION MUST BE
BONDED WITH A #8 AWG WIRE TO THE SAME BONDING GRID AS THE SANIJET®
MOTORS.
• Once the electrical and plumbing connections are made, the system should be filled
with water and tested so that all plumbing and fitting can be inspected prior to fitting
the enclosure skirt.
WARNING: WHEN WATER TESTING THE SYSTEM, AND BEFORE FILLING THE
SYSTEM WITH WATER, ALL ELECTRICAL ENCLOSURE BOXES MUST BE CLOSED
AND COVERS SECURED, TO PREVENT WATER INFILTRATION SHOULD LEAKS
OCCUR.
• Before filling the Biarritz™ with water, ensure the basin is clean and that no debris or other
foreign matter is inside the basin that could cause blockage of jets when the system is
operated, damage to the hydro-jets system, or scratches to the basin’s acrylic surface.
• Test the system by filling the basin until water reaches approximately 1” (25 mm) higher
than the highest jets. This will avoid water being expelled from the Biarritz™ when
system is activated (See Photo #8 below). NOTE: The basin drain (See Photos #23-24,
Pg.22) must be in the closed position prior to filling.
Fill Level
Fill Jet
Photo #8
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150
Page 11 of 18

• Press the pump on /off speed control button (See Photo #9) to allow the system to operate
for approximately fifteen (15) minutes, while thoroughly inspecting the system’s plumbing for
leaks that may have been caused as a result of mishandling during transportation. If leaks
are detected, turn the system off by depressing the pump on/off control button. Empty the
water from the system and disconnect the electrical supply to the system. In the event of
leaks, ensure that all fittings are tight. (See Photo #10 for skirt removal/ installation for
inspection and service). If necessary, contact the manufacturer or supplier to arrange for
any repair or replacement parts that may be needed.
• Upon completion of water testing the system, install the enclosure skirt (See Photo #10).
WARNING:
APART FROM THE ABOVE REFERENCED TESTING PROCEDURE, THE SYSTEM
MUST NEVER BE OPERATED UNLESS THE ELECTRICAL BOX ENCLOSURE
PANELS AND THE ENCLOSURE SKIRT ARE FIXED TO THE SYSTEM. THE SYSTEM
MUST NOT BE OPERATED IF ANY DAMAGE TO THE ENCLOSURE PANELS HAVE
OCCURRED.
13 - Biarritz™ Installation Manual v.1.3
Installation and Testing Procedures
Jet
On/Off
Control Button
Installing the Enclosure Skirt
Photo #10
Photo #9
Main
Power
On/Off
Indicator
Light
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150
Page 12 of 18

Biarritz™ Installation Manual v.1.3 - 14
Important Safety Instructions
WARNING :When using this unit, basic precautions should always be followed,
including the following:
1. CAREFULLY AND THOROUGHLY READ AND FOLLOW ALL
INSTRUCTIONS
2.WARNING: This hydrotherapy pedicure spa is designed for your safety, comfort, and
relaxation. Should you experience any pain or discomfort during the use of this
hydrotherapy device, advise your pedicure technician, immediately discontinue
use, and if necessary, consult your physician.
As a safety precaution, this equipment is not recommended for individuals who are
diabetic, who have open cuts or wounds on the legs or feet, or who have swelling and
inflammation in the lower legs or feet.
Should you have any swelling, fracture, persistent pain, or fungal infection, you should
not use this equipment until you have consulted a physician.
3. DANGER: This system is not designed for use by or for children.
4. Use this unit only for its intended use as described in this manual. Do not use
attachments or products not recommended by the manufacturer.
5. Never drop or insert any object into any opening.
6. For the protection of you and your customer from being exposed to an electrical fault,
this unit is equipped with a GFCI (Ground Fault Circuit Interrupter). The GFCI is located
underneath and to the rear of the Spa shell. The GFCI is mounted in the
electrical control box and can be accessed by lifting the outer skirt around the Spa. To
test the GFCI, push the test button. The GFCI should interrupt power. Push the reset
button to restore power. If the GFCI fails to operate in this manner, an unsafe electrical
condition may exist. DO NOT USE THE UNIT. Disconnect the unit and have the problem
corrected by a qualified electrical service representative before using.
7. The Biarritz may be provided for electrical installation in the USA and North America
with a standard 110/115 volt 60 Hz. A green with yellow wire marked by the grounded
(earthing) symbol is provided within the Electrical Box #1 (See Photos #4a,4b & 4c
Pg #7). To reduce the risk of electric shock, connect this terminal or connector to the
grounding terminal of your electric service or supply panel with a conductor equivalent in
size to the circuit conductors supplying the equipment.
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150
Page 13 of 18

Biarritz™ Installation Manual v.1.3 - 26
Warranty
1 Year on Components
Parts manufacturing defects. Manufacturer reserves the right to repair or replace
defective parts.
*PLEASE NOTE: All parts subject to warranty must be returned to the address below for
proper credit to your account. Unused non-warrantied parts that are returned and in
original containers may be subject to restocking fees.
Cosmopro, Inc.
280 Fentress Blvd.
Daytona Beach, FL 32114
Tel: [phone]
Email: [email protected]
Fax: [phone]
Techno-Spa
Manufacturing, Inc.
280 Fentress Blvd.
Daytona Beach, FL 32114
Made in the U.S.A.
BSJ
110V-115V
6
60HZ
370
IPX4
1 / 3 Wire
Duty Cycle 20 min. on /20 min. off. Connect only
to a circuit that is protected by a ground fault
Circuit-Interrupter (GFCI)
MODEL
SERIAL NUMBER
MFG DATE
VOLTS
AMPERAGE
FREQUENCY
POWER
IP NUMBERS
PHASES
The Biarritz™ design is protected by a patent
and manufactured exclusively for the
Biarritz™Whisper-Soft Hydrotherapy Foot
Spa System. The Biarritz™ is manufactured
by Techno-Spa Manufacturing, Inc., using first
quality nationally and internationally
manufactured parts and sub assemblies.
Calling For Assistance
*Please note: When calling for
assistance or information
regarding your system
please have all information
found on the MFG Data Plate
(as seen here) ready. You will
find this data affixed to the
shell of your Biarritz™. This
will enable us to assist you
promptly.
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150
Page 14 of 18

Technical Specifications
EQUIPMENT, MATERIALS
& CONTROLS
2 SANIJET®Assemblies:
Pump/Motor:
• 2 each 1/10 HP AC Industrial Duty
Material:
• Shell: White Acrylic
• Base: ABS Plastic
• Frame: Galvanized Steel
• Chair: Marine Grade Vinyl Upholstery
Chair Assembly:
• Cushioned, 3-Way adjustable
multi position and reclining back
*seat capacity 250lbs/114kg
Colors:
• White
• Black
• Grey / Blue
• Taupe/ Ivory
• Aqua / Dark Blue
Controls:
• Thermostatic Control
• Fill / Flush Control
• Hydro-Pump Speed Control
• Hand Shower Flow Control
Plumbing:
• Drain: 1 1/2" (38 mm) PVC
• Water Supply: 3/4" Hot & Cold
Ingress Protection:
• IPX4
DIMENSIONS, CAPACITIES
& WARRANTIES
Dimensions:
• (Upright) 56" (144 cm) L x
42" (108 cm) W x
57" (146 cm) H
• (Reclined) Up to 78" (200 cm) L x
42" (108 cm) W x
37" (95 cm) H
Individual Dimensions:
•Chair: 30"(77 cm) (Upright)
46" (118 cm) (Reclined) L x
42"(108 cm) W x
51"(131 cm) H
•Base: 56"(144 cm) L x
37"(95 cm) W x
16"(46 cm) H
Total Weight:
206 lbs (93 kg) (empty)
Water capacity:
• Between 8 and 9 US gallons (34 L)
Operating Requirements:
• Electrical Ratings
N. America -110-115 Volts Ac
6 amp
60 Hz - GFCI protected
European -230 Volts Ac
3 amp
50Hz - GFCI protected
Duty Cycle:
• Hydro-pump motor -
Continuous Duty
Warranty:
• One Year Motors /Jet Pumps
• Two Years Shell and Hardware
(See manufacturer’s limited warranty
for detailed coverage).
27 - Biarritz™ Installation Manual v.1.3
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150
Page 15 of 18

Biarritz™ Installation Manual v.1.3 - 28
Limited Warranty
1. Equipment manufactured by Techno-Spa, Inc. (Techno-Spa) is warranted to the original
purchaser, to be free in defects in material and workmanship for a period of one (1) year from
the date of sale. For a period of ninety (90) days from the date of purchase, Techno-Spa will
warranty both parts and labor to the original purchaser at the purchaser’s facility as may be
determined at the sole option of Techno-Spa. During the first ninety (90) days after purchase,
equipment not approved for repair at the purchaser’s facility and authorized for return to Techno-
Spa’s facilities must be returned freight prepaid and will be replaced or repaired at no charge
and returned to the customer prepaid by Techno-Spa. After ninety (90) days, Techno-Spa’s
liability under this warranty shall be limited to repairing or providing replacement parts, at
Cosmopro’s option, without charge to the original purchaser, F.O.B. Techno-Spa’s facilities.
Techno-Spa will not be liable for any costs of removal, installation, transportation, or other
charges that may arise in connection with a warranty claim. Techno-Spa will not be liable for
damage or wear to products caused by abnormal operating conditions, accident, abuse,
misuse, unauthorized alteration or repair, or if the product was not installed in accordance with
Techno-Spa’s printed installation and operation instructions.
2. To obtain service under this warranty, contact Techno-Spa for detailed instructions for
the repair or replacement of parts needed. Any defective product or part to be
returned for replacement or repair after the initial ninety (90) day period must be sent
freight prepaid along with documentation supporting the warranty claim and with the
Return Authorization provided by Techno-Spa. Parts or equipment returned without a
return authorization will not be accepted.
3. TECHNO-SPA WILL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES, LOSSES, DAMAGES OR LOSSES OCCURRING DURING TRANSPORT-
ATION, OR EXPENSES ARISING FROM INSTALLATION, USE, OR ANY OTHER
CAUSES. THERE ARE NO EXPRESS OR IMPLIED WARRANTIES, INCLUDING
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WHICH EXTEND
BEYOND THOSE WARRANTIES DESCRIBED OR REFERRED TO ABOVE.
4. Some jurisdictions do not allow the exclusions or limitation of incidental or consequential
damages and some jurisdictions do not allow limitations on how long implied warranties may
last. Therefore, the above limitations or exclusions may not apply to you. This warranty gives
you specific legal rights and you may also have other rights that may vary from one
jurisdiction to another.
Limited Warranty
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150
Page 16 of 18

Troubleshooting Guide
Important
U.S. Version
This System is supplied with a 3 connector Plug and must be connected to a 115 volt, 60 Hz,
standard power outlet.
Problem Solution
No Power to Biarritz Check in house breaker panel,
make sure breaker is on.
Check GFCI on Biarritz for default
condition. Reset if required.
Green Power Indicator on Check GFCI for default.
Biarritz does not illuminate condition. Reset GFCI.
Check and/or replace F1 fuse
on Main Control Box.
Chair does not operate Check all above.
Make certain connector to
chair is securely made.
Check to see that remote
Control is “ON”.
Chair Turns “OFF” after 15 or 30 minutes Check Timing Mode on Remote
Control and set accordingly.
Jets Do Not Operate Check all Power Connections
to Biarritz.
Push Air Button Switch for
Jets firmly.
Make sure Power is applied
and Green Light is “ON”.
Biarritz™ Installation Manual v.1.3 - 29
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150
Page 17 of 18

Jets make Noise when in Operation Make sure Pump Impellers
are installed correctly.
Make sure water level is
above impeller housings.
No Hot Water in Biarritz Basin Check for Hot water on
feed pipe to Biarritz.
Make sure Main Valve on
Biarritz is fully open.
Make sure Hot Water feed from
Main Supply is connected to
Hot Water input on Biarritz.
Make sure Thermostatic
valve is fully clockwise.
No Cold Water in Biarritz Basin Check for Cold water on
feed pipe to Biarritz.
Make sure Main Valve on
Biarritz is fully open.
Make sure Cold Water feed from
Main Supply is connected to
Cold Water input on Biarritz.
Make sure Thermostatic valve is
fully counter- clockwise.
Valves make “squealing” Noise Check water pressure
from Main Lines.
Nominal Water Pressure
Should be 40-60 PSI.
IMPORTANT NOTE:
All of the above in this Troubleshooting Guide applies to the European Model
Also. The only difference is the applied Primary Power. That Power is 230 volts
AC, 50 Hz.
Troubleshooting Guide
Biarritz™ Installation Manual v.1.3 - 30
Product Code: LM917135
www.spaequip.com P: 707.737.1100 F: 707.737.1150
Page 18 of 18
