Costway Hw65716 User manual

HW65716

Install 4 pcs dowels (A) and 4 pcs cam pins (B) to End panel (2)

Part A x 4 Part B x 4 Part 2 x 1

Install 8 pcs dowels (A) to Between panel (4)

Part A x 8 Part 4 x 2

Install 8 pcs dowels (A) and 4 pcs cam pins (B) to Middle panel (6)

Part A x 8 Part B x 4 Part 6 x 1

Install 4 pcs cam pins (B) to 2 Brace panels (5)

Part B x 4 Part 5 x 2

Install 4 pcs dowels (A) and 4 pcs cam pins (B) to Bottom panel (7)

Part A x 4 Part B x 4 Part 7 x 1

Install 4 pcs dowels (A) and 4 pcs cam pins (B) to End panel (3)

Part A x 4 Part B x 4 Part 3 x 1

Install 4 pcs dowels (A) to 2 Solid Panels (8)

Part A x 4 Part 8 x 2

Install 10 pcs cam pins (B) to 2 Legs (9)

Part B x 10 Part 9 x 2

Install 8 pcs cam pins (B) to 2 Legs (10)

Part B x 10 Part 10 x 2

Install one Front Leg (9) and one Rear Leg (10) to End panel (3)

and lock with 4 pcs Cam locks (C)

Part C x 4

Install lever (11) to End panel (2) with 8 pcs Screws (E4)

Part E4 x 8

Part 11 x 1

Install one Front Leg (9) and one Rear Leg (10) to End panel (2)

and lock with 4 pcs Cam locks (C)

Part C x 4

x2

x2 x2

x2

x2

BOTTOM

(C)

(C)

(C)

(C)

(C)

(C)

(C)

(C)

Install lever (12) to End panel (3) with 8 pcs Screws (E4)

Part E4 x 8 Part 1 2 x 1

Install 2 Support panels (8) to Bottom panel (7) with 16 pcs Screws (E4)

and reinforce with 4 sets of Corner brackets (S1) (S1 has equipped

with self-tapping screws with no drilling holes)

Part E4 x 16 Part S1 x 4

Attach 2 Brace panels (5) to Middle panel (6) and lock with

4 pcs Cam locks (C)

Part C x 4

Install 2 Between panels (4) to the middle of Solid panel (6)

and Solid panel (7), then lock with 8 pcs Cam locks (C)

Part C x 8

Integrate End panel (2), (3) and the table legs with the main body,

then secure with 20 pcs Cam locks (C)

Part C x 20

16

17

18

19 TIPS

1

2

3

4

Stick 40 pcs Cam covers (P) on

Cam locks (C) and stick 6 pcs

(M1) to the corresponding places

shown in the figure.

Part M1 x 6

Part P x 40

Installation of

cam pin and

cam lock

Install the Top panel (1) to the lifters (11), (12) with 12 pcs

Screws (E4)

Part 1x 1 Part E4 x 12

(C)

(C)

(C)

(C)

(C)

(C) (C)

(C)

(C)(C)

(C)

(C) (C)

(C) (C)

(C)

(C)

(C)
