Costway HW67660 User manual

Multifunctional Chair
HW67660

Please read all instructions carefully and keep it for future reference.
General Security Warning
Caution: The Product is not suitable for the children under 3 years
Danger: Keep all small parts and packaging materials for this product away from babies and
children, otherwise they may pose a choking hazard.
Danger: Lack of attachment may cause a risk of tipping.
Warning for Assembly
Construction only by adults
Remove all Packaging, separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the area in which
they will be placed in use, to avoid moving the product unnecessarily once assembled.
Ensure a secure surface during construction, and place the product always on a flat,
steady and stable surface.
WARNING:
CHOKING HAZARD-Small parts.
Not for children under 3 years.
02

123
5
6
8910 x2 11
12 x2
4
7
03

F×5
Hx1 Gx1
Kx1
Jx2
Ix1 Lx1
Mx4
04

1
2
Assembly Instruction
STEP 1:
Assemble part I to No.3 panel
with screws M. Assemble part
G to No.4 panel with screws F.
Insert nuts B to No.3 and No.4
panels.
STEP 2:
Assemble parts J to No.6 panel with screws C.
05
4
G
3MM
I
6
JJ

3
4
STEP 3:
Assemble No.1 panel to No.3 and No.4 panels with screws A.
STEP 4:
06
4
13
5
2
Insert No.5 panel to No.3 and No.4 panels.
Then assemble No.2 panel to No.3 and
No.4 panels with screws

5
6
STEP 5:
Insert nuts B to No.1 and No.2 panels, then assemble No.6 to No.1,
No.2 and No.4 panels with screws A.
STEP 6:
Assemble part H to No.7 panel with screws F, then assemble No.7
panel to No.6 panel with screws C.
07
6
7H

7
8
STEP 7:
Assemble part K to parts H and G. Assemble the part L to No.7
panel with screws M.
08
K
L
M
M
10
10
STEP 8:
Assemble No.10 panel to No.1 and No.2 panels with screws E.

9
10
STEP 9:
Insert nuts B to No.10, No.8 and No.9 panels, then assemble
No.8 and No.9 panels to No.10 panel with screws D.
09
8
9
11
STEP 10:
Assemble No.11 panel to No.8 and No.9 panels with screws A.

11
STEP 11:
Assemble the part No.12 to No.10 panel.
10
12
12
