Costway EP24399 User manual

www.costway.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Visit us: www.costway.com
Follow Costway
Please give us a chance to make it right and do better！
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP!
USER’S MANUAL
EP24399
EN
Dual Speed Juicer Extractor

2
www.costway.com
3
www.costway.com
Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: [e-mail]
UK: [e-mail]
Before You StartBefore You Start
Please read all instructions carefully.
Retain instructions for future reference.
Seperate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from
babies and children as they potentially pose a serious choking hazard.
Diagram of name and position of main components
1. Pushing bar
2.Transparent cover
3. Juicing net
4. Middle ring
6. Residue barrel
7. Main machine
8
5. Handle
. Juicer jug
1
2
3
4
5
8
7
6

4
www.costway.com www.costway.com
5
1.
2.Design is fine, simple, and beautiful, with combined structure,
easy to operate and clean.
3.High speed electric motor with overheating protection is adopted,
high efficiency, time saving, energy saving, high service life of
the motor.
4.Safety lock unit for switching is specially designed, in order to
make sure safety and reliability in use.
5. Design with anti-drip function juice mouth.
For the juicer with large diameter, entire apple or pear can be put
in for juicing, no cutting apart needed, easy and quick.
Performances
Attention before using
1.This machine is set with safety unit, whenthe handle does not
fasten the cover or the cutter seat is not fastened, the motor
cannot turn, so as to ensure safety for the user.
2. When disassembling or assembling the juicer, press the upper
of feed port of the cover with your hand, then force the handle
to slide in or out of cover slot.
3.When disassembling juicing net, first remove the cover and
residue barrel, then turn the middle ring up to 30 degrees by
holding juicing nozzle with your hand, and take up, the juicing
net will automatically leave the rotor.
4. In order to avoid damage, before using, first check power
supply for compliance with rated voltage.
5. Clean all parts able to disassemble (refer to the section of
"maintenance and cleaning").
6. When assembling, please carefully read the diagram of "name
and position of main components".
7. Please carefully read the "attentions" before using.
1. Before using, please confirm the button switch of the main
machine in stop state, in this way, in case assembly is not
completed, starting the main machine can be avoided, so
unnecessary damagefor persons or property avoided.
2. Before juicing, first confirm juicing net and rotor clutched in
position, and no hard contact between juicing net cutter and
transparent cover. Put the transparent cover on, put the handle
into the cover slot, then turn on the machine.
3. Before using, please make sure to put the juice mouth to drip
position, and after turning off the machine, put the juice mouth
to anti-drip position to avoid juice come out without juice cup
and make the table dirty.
4. For using, assemble according to the diagram of "name and
position of main components". Turn on power supply, press
switch to let the machine run no-load for 5 sec. Put prepared
vegetable or fruit into feed port of the juicer, press with the
pushing bar, evenly, hard and slowly, juice of the vegetable or
fruit can be found, original, fresh, goodfor health.
5. Note: when pressing food with the pushing bar, force shall be
even or indirect, pressing force shall not be more than 1 kg, no
too sudden force, otherwise, juicing effect will be reduced.
Operating time
This machine is designed with button switches of O grading, I
grading, II grading (O for stop, I for weak grading,II for strong
grading). For juicing, select strong grading,for operating time,
after operating for 1min, stop for 1min, then use again. After the
above operation is performed for three times, stop for 15 min, do
not operate until the motor is cooled, in this way, service life of
Juicing

www.costway.com
6
www.costway.com
7
Attentions
1. This machine is unavailable for the weakness, unresponsive or
psychopathic person (including children), unless under the
direction or help from the person who have the responsibility
for security. Children should be overseen, so it can be testified
thatthey are not playing with it.
2. Before using, putthis machine on a stable and even table
board; operate according to the above methods.
3. Before juicing, first confirm juicing net and rotor clutched in
position, and no hard contact between juicing net cutter and
transparent cover. Put the transparent cover on, fasten tightthe
handle, thenturn on the machine.
4. Before being used, the motor works in running-in phase, there
may be slight peculiar smell and spark, this is normal, after the
motor works for some period, the above phenomenon will
disappear.
5. During juicing, make sure there is nottoo full juice and residue
in the middle seat and residue cup, if too full, please cut off
power supply, clean up, and then use again.
6. During using, do not openthe cup cover. In case power supply
is on, do not put hand or any ware into the mixing cup or feed
port, otherwise, harmful accident may occur or this machine
may be damaged.
7. In order to prolong service life of this machine, over-
temperature protective device is mounted in the motor. If the
motor works for a longtime or overloaded, when over warning
temperature, power supply will automatically cut off. After the
Operating time
this machine will be prolonged; the machine will serve you more
efficiently. motor stops, pull out plug of power supply, wait for the motor to
cool (aboutfor 30 min), use again.
8. Please make sure to put down the spout before do the
extraction,only after the operation,consumers can put up the
spout,then it can avoid the rest of source drop down onto the
table
9. During operating, please do not leave, never let children
operate this machine.
10. After operation, do not pour the food out until pull out the plug
of power supply.
11. Cutters are very sharp, in order to avoid danger, when
cleaning a cutter, please put the cutter under water tap for
washing, do not wash it with hand.
12. This machine must not be used for others beyond regulated
purposes.
13. In case of damaged power supply cord, in order to avoid
danger, replacement must be performed by the manufacturer
or its service department or similar professional persons.
.
Maintenance and cleaning
Attentions
1.This machine shall be often used, so as to keep the motor dry
and clean.
2.If not using for a long time, please store this machine at a dry
and well-ventilated place so as to prevent the motor from being
damped and going moldy.
3.No washing the main machine. When cleaning, only wipe with
wet cloth. Other components may be washed directly with
water, such as pushing bar, cover, middle seat, residue cup,
juice nozzle cover.
