USER’S MANUAL
HANDHELD VACUUM CLEANER
GX10005US-WH

Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: [e-mail]
UK: [e-mail]
Before You StartBefore You Start
Please read all instructions carefully.
Retain instructions for future reference.
Separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from
babies and children as they potentially pose a serious choking hazard.
02

PLEASE READ THIS MANUAL BEFORE USING THIS PRODUCT.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
MADE IN CHINA
03

Congratulations on the purchase of this high-quality product. Please read this
operating instruction attentively before you take the appliance in operation. It gives
important notes for security, the use and maintenance of the appliance. If you have
further questions, please contact our customer service.
Appliance figure:
K-908
Standard accessories (refer to the figure)
1.Handle
2.Switch
3.Indicator light
4.Machine body
5.Combined brush
6.Dust bin
7.Metal mesh cover
8.HEPA filter
9.Charger
SAFETY GUIDELINES - DEFINITIONS
It is important for you to read and understand this manual. The information it
contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS.
The symbols below are used to help you recognize this information.
DANGER: Indicates an imminent hazardous situation, which, if not avoided,
could result in death or serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
NOTICE: Used without the safety alert symbol indicates potentially hazardous
situation, which, if not avoided, may result in property damage.
!
!
!
!
04

IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliances, basic precautions should always be followed,
including the following: READ ALL INSTRUCTIONS BEFORE USING THE
APPLIANCE.
WARNING: Read all safety warnings and all instructions.
Failure to follow the warnings and instructions listed below may result in electric
shock, fire and / or serious injury.
WARNING: Some household dust contains chemicals known to the State of
California to cause cancer, birth defects or other reproductive harm such as asbestos
and lead in lead based paint.
WARNING: To reduce the risk of fire, electric shock or injury:
● Close supervision is necessary when any appliance is used by or near children. Do
not allow to be used as a toy.
● Do not use without dust bag and/or filters in place.
● Do not charge the unit outdoors.
● Shock Hazard. To protect against risk of electric shock, do not put unit or charging
base in water or other liquid.
● Do not use dry handheld vacuum cleaner to pick up liquids, toxic substances,
flammable or combustible liquids such as gasoline or use in areas where they may
be present.
● Do not use wet/dry handheld vacuum cleaner to pick up toxic substances,
flammable or combustible liquids such as gasoline or use in areas where they may
be present.
● Do not operate in the presence of explosives and/or flammable fumes or liquids.
● Shock Hazard. Do not operate any appliance with a damaged cord or charger or
after the appliance malfunctions, is left outdoors, dropped into water or is damaged
in any manner. Return the appliance to any authorized service facility.
● Do not use dry handheld vacuum cleaner outdoors or on wet surfaces.
● Do not abuse the cord. Never carry the charger or base by the cord or yank to
disconnect from an outlet; instead grasp the charger and pull to disconnect. Keep
cord away from heated surfaces. Do not pull cord around sharp edges or corners.
● Do not allow the cord to hang over the edge of a table or counter or touch hot
surfaces. The unit should be placed or mounted away from sinks and hot surfaces.
● Do not use an extension cord. Plug the charger directly into an electrical outlet.
!
!
!
05

● Use the charger only in a standard electrical outlet (100-240V/50-60Hz).
● Do not attempt to use the charger with any other product; do not attempt to charge
this product with any other charger. Use only the charger supplied by the
manufacturer to recharge.
● Keep hair, loose clothing, and all parts of body away from openings and moving
parts.
● Do not insert accessories when unit is running.
● Shock Hazard. Do not handle plug or appliance with wet hands.
● Do not put any object into unit openings. Do not use with any openings blocked;
keep free of dust, lint, hair, and anything that may reduce air flow.
● Fire Hazard. Do not vacuum burning or smoking materials, such as lit cigarette
butts, matches or hot aches.
● Do not use on or near hot surfaces.
● Use extra caution when cleaning on stairs.
● This appliance is intended for household use only and not for commercial or
industrial use.
● Use only as described in this manual. Only use attachments recommended by the
manufacturer.
● Unplug the charger from outlet before any routine cleaning or maintenance.
● This product includes rechargeable Lithium ion batteries. Do not incinerate
batteries as they will explode at high temperatures.
● If battery contents come into contact with the skin immediately wash the area with
mild soap and water. If battery liquid gets into the eye, rinse water over the open eye
for 15 minutes or until irritation ceases. If medical attention is needed, the battery
electrolyte for Lithium ion batteries is composed of a mixture of liquid organic
carbonates and lithium salts.
WARNING: Do not look into the air vents when the unit is switched on, as
sometimes there is a possibility of small debris being discharged from the air vents,
especially after cleaning/replacement of the filters as debris inside the unit can be
disturbed.
● The charger supplied with this product is intended to be plugged in such that it is
correctly oriented in a vertical or floor mount position.
!
06

SAFETY WARNINGS AND INSTRUCTIONS: BATTERIES
● Do not disassemble or open, drop (mechanical abuse), crush, bend or deform,
puncture, or shred.
● Do not modify or remanufacture, attempt to insert foreign objects into the battery,
immerse or expose to water or other liquids, or expose to fire, excessive heat
including soldering irons, or put in microwave oven.
● Only use the battery/tool with a charging system specified by the
manufacturer/supplier.
● Do not short-circuit a battery or allow metallic or conductive objects to contact
both battery terminals simultaneously.
● Dispose of used batteries promptly according to the manufacturer/supplier's
instructions.
● Improper battery use may result in a fire, explosion, or other hazard.
● Battery/tool usage by children should be supervised.
SAFETY WARNINGS AND INSTRUCTIONS:CHARGING
1.This manual contains important safety and operating instructions.
2.Before using battery charger, read all instructions and cautionary warnings on the
battery charger and the product that uses the battery. CAUTION: To reduce the risk
of injury, use this charger only with this product. Batteries in other products may
burst causing personal injury or damage.
3.Do not expose charger to rain or snow.
4.Use of an attachment not recommended by the manufacturer may result in a risk of
fire, electric shock, or injury to persons.
5.To reduce risk of damage to electric plug and cord, pull the plug instead of the
power cord when disconnecting the charger.
6.Make sure cord is located so that it will not be stepped on, tripped over, or
otherwise subject to damage or stress.
7.An extension cord should not be used unless absolutely necessary. Use of
improper extension cord could result in a risk of fire, electric shock or electrocution.
8.Use only the supplied charger when charging your tool. The use of any other
charger could damage the tool or create a hazardous condition.
9.Use only one charger when charging.
10.Do not attempt to open the charger. There are no customer serviceable parts inside.
11.Do not incinerate the tool or batteries even if they are severely damaged or
07

completely worn out. The batteries can explode in a fire. Toxic fumes and materials
are created when lithium ion battery packs are burned.
12.Do not charge or use battery in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Inserting or removing the battery from the charger
may ignite the dust or fumes.
13.If battery contents come into contact with the skin, immediately wash the area
with mild soap and water. If battery liquid gets into the eye, rinse water over the
open eye for three minutes or until irritation ceases. If medical attention is needed,
the battery electrolyte is composed of a mixture of liquid organic carbonates and
lithium salts.
WARNING: Burn hazard. Battery liquid may be flammable if exposed to spark
or flame.
!
08

Check the HEPA filter
On-off and power adjustment
Press the switch for seconds to start with low
gear.
Press the switch again to adjust to the high gear.
Press the switch a third time to turn off the
machine.
Charging
1.Insert the charger to the hole of charging
station
-Three blue lights will light up when charging.
-When fully charged, all three lights will be
blue, and will go out after 10 minutes of fully
charged.
- It takes 4-5 hours to fully charge.
If the battery temperature is too high or too low, the
indicator light will flash red. After the temperature
returns to normal, it can be charged normally.
Product usage
Accessories usage
Combined brush usage
Insert the brush into the dust cup, fix it to
start using,flip the brush head to replace
it.
1. The flat nozzle can be used on tables,
counters, sofas, etc.
2. The brush can be used for curtains,
computer keys, ceilings, etc.
09

Take down the dust cup
Hold the machine and dust cup, turning
them apart to unlock status when it is off.
Disassemble the HEPA filter
Lift the HEPA filter, empty the dust cup,
turn and remove the HEPA filter from the
metal cover.
Clean the HEPA filter
Clean and dry the filter set and dust cup
before use (do not expose it to the sun).
Install the HEPA filter
Follow the steps in reverse to the above to
install the filter set, align the dust cup with
machine body, and turn it to the right until
you hear the lock sound.
Maintenance
10

Fault handling
Fault
No working
Weak suction
Possibilities Method
•No power
•Overheat protector
•Failure switch
•Full dust cup
•Full dust on the filter
set
•Block in the brush or
tube
•Shortage of charging
time
•Aging battery
Short using
time after
charging
•Charge the machine
•Restart the machine after cooling
•After-sales repair
•Empty the dust cup
•Clean or change the filter set
•Clean the dust in the brush
•Fully charge the machine
according to the instructions
•Battery is quick-worn part,
please buy a new one for
replacement
Specifications
Rated voltage
Rated power
Battery capacity
Rated voltage for the charger
Output of the charger
Dust cup capacity
Charging time
Working time
11.1V
100W
2000mAh
100-240V~ 50/60Hz
14V, 500mA
0.5 L
4~5h
13~25min
