Coway BA08 Product information sheet

BA08 - Simple to Use
Easy Guide to your Bidet Remote Control
Rear cleansing
and bottom wash
Front cleansing/
ladies wash
Nozzle position indicator
Battery status indicator
Nozzle position button
Water temperature
adjustment button
Seat temperature
adjustment button
Power on/o (Do not turn o
as remote will go automatically
turn itself o)
Auto cleansing
function selection
button
Stop button
Change spray from
narrow to wide
Air dryer function
selection button
Seat temperature
adjustment indicator
Wide function indicator
Air+ function
selection indicator
Water pressure/air dryer
temperature indicator
Warm water temperature
adjustment indicator
Water pressure/air
dryer temperature
adjustment button
Move function
selection button
Air+ function
selection button
If you are not getting an adequate clean
please check your LCD screen, it should show:
WIDE FUNCTION INDICATOR SET TO 1 OR 3 SPRAYS
AIR+ FUNCTION SELECTION INDICATOR
WATER PRESSURE 3 BARS
1800 243 387
FREECALL
www.thebidetshop.com.au

Once your Bidet is set to your preferred
temperatures, you only need to press 2 buttons.
Then press the ‘Dry’ button and the Bidet will provide a stream
of air set at your preferred temperature. If it doesn’t dry you
immediately, just press the ‘Dry’ button again or you could
soak up the large drops with a large piece of toilet paper.
Function Buttons Explained - What they can do for you
First press the ‘Rear Cleansing’ or ‘Front Cleansing’ button,
the machine will then provide your chosen wash for one minute.
BA08 - Remote Control Functions
Stop ceases all or any functions.
Press this button for bottom wash. Cleansing will run for 1 minute.
Changes the width of the spray pattern from a single line point to a wider fan spray.
Activates Air Dryer. Dryer will run for 2 minutes. See below regarding adjusting
temperature.
Press this button for ladies/front wash. Cleansing will run for 1 minute.
Press arrow up to increase water pressure. Press down arrow to decrease water
pressure. Indication is shown by left horizontal bars on the bottom left screen.
To adjust the air temperature, press the up and down buttons while the dryer
is running.
Pressing arrow up moves the nozzle further forward. Pressing the down arrow will move the nozzle back.
5 positions of these are shown on the right hand side of the screen.
Press the ‘Move’function during rear or front cleansing to make the nozzle move forwards and
backwards providing a better clean.
Adjusts the water temperature to 3 heating settings or o. Shown on the screen as a thermometer, empty
thermometer indicates o. 1bar=Mild 2bars=Medium 3bars=Warmest
Adjusts the seat temperature to 3 heating settings or o. Shown on the screen as a toilet seat, empty seat
indicates o. 1bar=Mild 2bars=Medium 3bars=Warmest
An additional pressure setting, adding air to the water stream creating a gentler feel with increased cleansing
power. This is indicated by a fourth bar on the pressure setting Air+.
Press this button and the bidet will provide a bottom wash for 1 minute and an air dryer for 2 minutes
automatically.
This function is rarely used. Please do not touch as when the remote is not in use, it goes into sleep mode
(power saving mode) and the screen goes blank. Remote can be ‘woken’ by pressing any button you require.
