Coway P-07FR User manual

Water Filtration Device
• Thisproductcannotbeusedifthevoltageisdierentfrom
thatmentionedintheratingplate.
• Foryoursafetyandproperuseoftheproduct,pleasereadthis
User’sManualbeforeuse.
• WarrantycardisincludedinthisUser’s
Manual.
P-07FR/FRV/FU/FUV
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

1
FEATURES
1. Undersink type
Usercangetthelteredwaterbyjustopeningthefaucet.
2. Self lter check
Theelectriclterchangeindicatorremindsuserwhentochange
thelter.
3. Auto ushing (Only P-07FR/FRV)
Ifthesystemisinuseforunextendedperiodoftime,theltercan
beprotectedbyautoushingfeature.
4. Innovative tankless water ltration system
Cowayinventedatanklesswaterltrationsystemwhichisvery
space-ecient.
5. Safer structure
Theriskofwaterleakageisdiminishedbyusinganelectronic
valve.
6. Preventing secondary pollution
Duetothetanklesssystem,secondary-sourcepollution,which
sometimesoccursinsideoftanks,iseliminated.
7. Ultra violet lamp lter (Only P-07FRV/FUV)
Theultravioletlampcirculatesthetreatedwater.
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

2
Coway FEATURES / CONTENTS
DEAR CUSTOMERS
CONTENTS
- Please keep the User’s Manual where it can be readily reached or found -
ThankyouforusingourCoway Water Filtration Device.
PleasereadthisUsers’Manualtouseandmaintaintheproductcorrectly.Ifyouencountera
problemwhileusingtheproduct,youmaysolvetheproblemreferringtotheUser’sManual.
Asthismanualcontainstheproductwarrantycard,pleasekeepitinasafeplace.
Thissystem(P-07FR/FRV/FU/FUV)conformstoNSF/ANSI42foraestheticchlorinereductionand
NSF/ANSI53forVOCreductionasveriedandsubstantiatedbytestdata.
Thissystem(P-07FR/FRV)conformstoNSF/ANSI58forthereductionofPentavalentArsenic,
Barium,Cadmium,Selenium,Radium226/228,Trivalentchromium,Hexavalentchromium,Lead,
Mercuryasveriedandsubstantiatedbytestdata.
Thissystem(P-07FR/FRV)registeredinCalifornia.
Seeperformancedatasheetforindividualcontaminantsandreductionperformance.
FOR INFORMATION
SAFETY INFORMATION. . . . . . . . . . . . . . . . . . . 3
Electricitysafety....................... 3
Installationsafety. . . . . . . . . . . . . . . . . . . . . . 4
Operationsafety....................... 5
Others................................. 6
PARTSNAME ............................7
WATER FILTRATION PROCESS. . . . . . . . . . . . . 8
HOW TO USE
INSTALLATION PRECAUTIONS . . . . . . . . . . .12
HOWTOUSE............................15
Todrinktheroomwater . . . . . . . . . . . . . . 15
Toextractcontinuously. . . . . . . . . . . . . . . 15
Tousetherestart. . . . . . . . . . . . . . . . . . . . . 15
MAINTENANCE
INSTALLATION..........................16
FILTER REPLACEMENT. . . . . . . . . . . . . . . . . . . 17
FILTER REPLACEMENT METHOD . . . . . . . . .18
OTHERS
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . 20
SPECIFICATION.........................21
WATER FLOW DIAGRAM . . . . . . . . . . . . . . . . . 22
PERFORMANCE DATA SHEET . . . . . . . . . . . .23
WARRANTYCARD.......................33
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

3
SAFETY INFORMATION
Ifnotobserved,
seriousinjuryor
evendeathcould
occur.
Ifnotobserved,
seriousinjuryor
propertydamage
couldoccur.
Ifnotobserved,slight
injuryorproperty
damagecouldoccur.
Danger Warning Caution
Electricity safety
Do not use a damaged
power cord or plug, and
loose outlet.
Otherwise,electricshockor
remayoccurasaresult.
Do not pull the power
cord.
Otherwise,electricshockor
remayoccurasaresult.
Do not carry the unit by
its power cord.
Otherwise,electricshockor
remayoccurasaresult.
Do not touch the power
plug with a wet hand.
Otherwise,electricshockor
remayoccurasaresult.
Do not forcefully bend
the power cord or put
it under a heavy object
to prevent it from being
damaged or deformed.
Otherwise,electricshockor
remayoccurasaresult.
Do not connect and
pull out the power plug
repeatedly.
Otherwise,electricshockor
remayoccurasaresult.
If the electric outlet is
wet, carefully unplug the
unit and let the electric
outlet completely dry
before subsequent use.
Otherwise,electricshockor
remayoccurasaresult.
Unplug the product
before repair, inspection,
or parts replacement.
Otherwise,electricshockor
remayoccurasaresult.
Be careful to keep this safety information.
Pleasereadthisinformationtopreventpropertylossandensureyoursafety.
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

4
For Information
Remove any dust or
water o in the pin and
contacts of the power
plug.
Otherwise,electricshockor
remayoccurasaresult.
Do not plug into an
outlet that is being
used by several other
appliances.
Use an electrical outlet
dedicated.
Otherwise,remayoccuras
aresult.
When you don’t use for a
long time, close the main
water supply valve and
unplug.
Otherwise,electricshockor
remayoccurasaresult.
Do not attempt to repair
or modify the power cord
at your discretion.
Otherwise,electricshockor
remayoccurasaresult.
In the case the power
cord is damaged, do
not replace the cord
yourself. Call Coway
Service Center to have it
replaced.
Otherwise,electricshockor
remayoccurasaresult.
Installation safety
Do not install near a
heating device.
Otherwise,remayoccuras
aresult.
Do not install the
product on a sloped
oor.
Injurytotheuserordamage
totheunitmayresult.
Do not press the product
by constraint or impact.
Injurytodamagetotheunit
mayresult.
The ltration device installation shall
comply with applicable state and local
regulations.
SAFETY INFORMATION |Electricity safety |Installation safety
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

5
SAFETY INFORMATION
Ifnotobserved,
seriousinjuryor
evendeathcould
occur.
Ifnotobserved,
seriousinjuryor
propertydamage
couldoccur.
Ifnotobserved,slight
injuryorproperty
damagecouldoccur.
Danger Warning Caution
Operation safety
When the water is
coming inside of the
product or there is a
puddle on the product,
call Service Center after
closing the supplying
valve and unplugging.
Otherwise,electricshockmay
occurasaresult.
If our product produces a
strange noise or odd
smell, immediately
unplug from the
electrical outlet and call
our Service Center.
Otherwise,electricshockor
remayoccurasaresult.
Do not put the candle, a
light for cigarette on the
products.
Otherwise,remayoccuras
aresult.
Do not place any
containers with water,
medicine, food, small
metallic objects, or any
ammable material on
the top of the product.
Inthecaseforeignmaterial
getsinsidetheproduct,
electricshock,re,product
damagemayoccurasaresult.
To drink the ltered,
change the lter
according to the lter
replacement cycle.
Ifyouusetheexpiredlter,
thelterperformanceis
lowered.
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

6
For Information SAFETY INFORMATION |Operation safety |Others
Danger Warning Caution
Others
Clean after unplugging.
Otherwise,electricshockor
remayoccurasaresult.
Do not clean by spraying
the water directly or
don’t wipe the product
using the benzene and
thinner.
Otherwise,electricshockor
remayoccurasaresult.
Do not repair,
disassemble, or modify.
Otherwise,electricshockor
productdamagemayoccur
asaresult.
Do not use ltered water
for the water exchange
of an aquarium or a
shbowl.
Theroomwaterthroughthe
membraneisn’tsuitablefor
thesh’slifeenvironmentas
itremovedtheionicmaterial.
Insomecases,shesmight
evendie.
Do not use with water
that is microbiologically
unsafe or of unknown
quality without adequate
disinfection before or
after the system.
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

7
PARTS NAME
Front
Rear
Restart button
Indication part
Power cord
Waste water (Blue color) 1/4 inch
Inlet (Orange color) 3/8 inch
Extraction (Orange color) 1/4 inch
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

8
For Information PARTS NAME / WATER FILTRATION PROCESS
WATER FILTRATION PROCESS
The 4-step water ltering system (P-07FR)
Step 1, 2 : NEO-SENSE FILTER
Thisneo-senselterhasthefunctiontoreduceaestheticchlorine,odor,volatileorganic
compounds(VOC’s).
Step 3 : RO MEMBRANE FILTER
ROmembranelterhasthefunctiontoreducewatercontaminantssuchaspentavalentarsenic,
barium,cadmium,mercury,selenium,radium226/228,trivalentchromium,hexavalentchromium,
lead.
Step 4 : INNO SENSE FILTER
Thisinno-senselterhasthefunctionstoreducesmellinductionmaterialandtoimprovetasteof
water.Italsohasthefunctiontoreduceaestheticchlorine,volatileorganiccompounds(VOC’s).
Thelteristhecoretechnologyoftheltrationsystem.
Ifyoudon’tusequalifyinglterorifyouuseanoldlterthathasexpired,
thesystemperformancemaydegrade.
Uses of disposed water
- Therejectwatershouldbeusedforcleaningtherestroom,thehouse,clothes,or
purposesotherthandrinking.
- Neverusetherejectwaterforadrinkingwateroracook.
Tips
Reject
Water
Outlet
NEO-SENSE
FILTER
ROMEMBRANE
FILTER
INNO-SENSE
FILTER
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

9
WATER FILTRATION PROCESS
The 5-step water ltering system (P-07FRV)
Step 1, 2 : NEO-SENSE FILTER
Thisneo-senselterhasthefunctiontoreduceaestheticchlorine,odor,volatileorganic
compounds(VOC’s).
Step 3 : RO MEMBRANE FILTER
ROmembranelterhasthefunctiontoreducewatercontaminantssuchaspentavalentarsenic,
barium,cadmium,mercury,selenium,radium226/228,trivalentchromium,hexavalentchromium,
lead.
Step 4 : INNO SENSE FILTER
Thisinno-senselterhasthefunctionstoreducesmellinductionmaterialandtoimprovetasteof
water.Italsohasthefunctiontoreduceaestheticchlorine,volatileorganiccompounds(VOC’s).
Step 5 : ULTRA VIOLET LAMP
Thisultravioletlampcirculatesthetreatedwater.
Reject
Water
Outlet
NEO-SENSE
FILTER
ROMEMBRANE
FILTER
INNO-SENSE
FILTER
ULTRAVIOLET
LAMP
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

10
For Information WATER FILTRATION PROCESS
The 4-step water ltering system (P-07FU)
Step 1 : PLUS SEDIMENT FILTER
Thisplussedimentlterhasthefunctionstoreduceinfusibleparticlesfromfeedwaterandto
protectmembraneandpre-carbonlterfrombeingplugged.
Step 2 : PRE-CARBON FILTER
Thispre-carbonlterhasthefunctiontoreduceaestheticchlorine,odor,volatileorganic
compounds(VOC’s).
Step 3 : POST CARBON FILTER or INNO-SENSE FILTER
Thispost-carbonlterhasthefunctionstoreducesmellinductionmaterialandtoimprovetasteof
water.Italsohasthefunctiontoreduceaestheticchlorine,volatileorganiccompounds(VOC’s).
Thisinno-senselterhasthefunctionstoreducesmellinductionmaterialandtoimprovetasteof
water.Italsohasthefunctiontoreduceaestheticchlorine,volatileorganiccompounds(VOC’s).
Step 4 : UF MEMBRANE FILTER
PLUSSEDIMENT
FILTER
PRE-CARBON
FILTER
POSTCARBON
FILTER
UFMEMBRANE
FILTER
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

11
WATER FILTRATION PROCESS
The 5-step water ltering system (P-07FUV)
Step 1, 2 : NEO-SENSE FILTER
Thisneo-senselterhasthefunctiontoreduceaestheticchlorine,odor,volatileorganic
compounds(VOC’s).
Step 3 : POST CARBON FILTER or INNO-SENSE FILTER
Thispost-carbonlterhasthefunctionstoreducesmellinductionmaterialandtoimprovetasteof
water.Italsohasthefunctiontoreduceaestheticchlorine,volatileorganiccompounds(VOC’s).
Thisinno-senselterhasthefunctionstoreducesmellinductionmaterialandtoimprovetasteof
water.Italsohasthefunctiontoreduceaestheticchlorine,volatileorganiccompounds(VOC’s).
Step 4 : UF MEMBRANE FILTER
Step 5 : ULTRA VIOLET LAMP
Thisultravioletlampcirculatesthetreatedwater.
NEO-SENSE
FILTER
POSTCARBON
FILTER
UFMEMBRANE
FILTER
ULTRAVIOLET
LAMP
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

12
For Information WATER FILTRATION PROCESS / INSTALLATION PRECAUTIONS
INSTALLATION PRECAUTIONS
P-07FR/FRV
1. Wind the teon tape on the adapter and t it to the
pipe.
2. Connect orange tubing with the connector on the
adapter.
3. Make a hole on the drain pipe and install the drain
clamp on the hole.
4. Connect the extraction tting to the faucet with a
tube.
5. Connect the orange colored inlet tubing for the feed
water with the cold water pipe.
Extend the blue color outlet tubing to where the drain
is.
6. Connect it to voltage rating that matches it on the
rating plate. Then, open the feed valve to supply
water to the ltration system.
7. The nished image.
Shall install the adapter with connector on the cold water
pipe.
Drain water for more than 8 minutes before use.
After ushing 8 minutes, the ltered water will be
suitable for consumption.
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

13
INSTALLATION PRECAUTIONS
P-07FU/FUV
1. Wind the teon tape on the adapter and t it to the
pipe.
2. Connect orange tubing with the connector on the
adapter.
3. Connect the extraction tting to the faucet with a
tube.
4. Connect the orange colored inlet tubing for the feed
water with the cold water pipe. Extend the blue color
outlet tubing to where the drain is.
5. Connect it to voltage rating that matches it on the
rating plate. Then, open the feed valve to supply
water to the ltration system.
6. The nished image.
Shall install the adapter with connector on the cold water
pipe.
Flush water through each lter at least 10 minutes before
drinking.
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

14
How to Use INSTALLATION PRECAUTIONS
Please check before use!
• Openthemainwatersupplyvalve.
Themainwatermustbesuppliedtooperatethewaterltrationdevicenormally.
• Regularlylterreplacement
Itisimportanttoreplacethelterregularlytodrinkthelteredwater.Ifthelterisoverused
beyonditsservicelife,theperformanceofthewaterltrationdevicedeteriorate,Donotmissthe
lterreplacementcycle.
This product is for 120 V~ 60 Hz only
Pleaseconnectthepowerplugtoadedicatedgroundedelectrical
outletfor120V~60Hz.Thewaterltrationdeviceworksnormally
onlywhentheelectricityisconnected.
Whenyoudon’tuseforalongtime,closethemainwatersupplyvalveandunplug.
Tips
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

15
HOW TO USE
To drink the room water
1. Puttheextractionpipeinthedesiredpositionandplacethe
cupundertheextractionfaucettocollectthewater.
2. Turnthefaucetonandodependingondesireduseof
lteredwater.
To extract continuously
Waterextractionautomaticallystopsaftereightminutesto
preventtoomuchuseofwateroroverowingaroundthe
productcausedbyuser’scarelessness.Afterrepeatingforfour
cycles,thisdevicewillautoushandthenshuto.
(OnlyP-07FR/FRV)
To use the restart
Ifthesystemdoesnotworkwhenthefaucetisopened,pushthe
restartbuttonforonesecondstorestartextraction.
(OnlyP-07FR/FRV)
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

16
How to Use HOW TO USE |Room water |Extract continuously |Restart / INSTALLATION
INSTALLATION
Be cautious!
Water ltration device installation place 1
Pleaseinstallthewaterltrationsystemnotataroughplace,adamp
place,aplacewheretheunitisexposedtothedirectsunlight,a
placewheredustispresent,oraplacethatthewaterdrops.
Water ltration device installation place 2
Pleaseinstallattheplacewhereitis10cmormoreofromthewall
andthebottomisatandrm.
Cold water plumbing
Pleaseconnecttothecoldwaterpipenecessarily.(Ifyouconnectto
thewarmwaterpipe,theltercanbedamaged.)
Movement and installation
Whenthepositionismoved,connectthepowercordwhen30
minutespassesafterinstalling.
$IWHU
PLQXWHV
+RW
:DWHU
Tomaintainoptimalproductperformance,consultaCowayengineerforthedetailed
installationmethods.
Theremaybesomewaterremaininginsideofthelterwhichwasusedtotestthe
productduringinspectionprocessatthefactory.
Pleasefeelateasyanduseasitisn’ttheusedproduct.
Don’treusethemainwatersupplyvalveandhosethatwaspreviously
usedwhenyouinstalltheproduct.
Tips
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

17
FILTER REPLACEMENT
Filter
Thelifeofthewaterltrationsystemisthelter.Itisn’tthelegitimatedlter
oryouusetoolongevenifitisthelegitimatedlter,thelterperformance
canbelowered.
Pleasechangetothelegitimatedlteraccordingtothereplacementcycle.
Filter replacement cycle
Ifthelterisnotregularlyreplaced,itmaydegradethewaterqualityfromthe
product.Thelterreplacementcycledependingonthemainwaterquality
canbeshortenedraterthantheexpectedreplacementcycle.
P-07FR
Part No. Names of Filter Usable Period
WJNF12 Neo-senselter 6months
WJMF12-700 Membranelter 24months
WJIF12 Inno-senselter 12months
P-07FRV
Part No. Names of Filter Usable Period
WJNF12 Neo-senselter 6months
WJMF12-700 Membranelter 24months
WJIF12 Inno-senselter 12months
WJUVF-4W-BALLAST Ultravioletlamp 16months
P-07FU
Part No. Names of Filter Usable Period
WJSF11-PLUS Plussedimentlter 6months
WJCF11-PRE Precarbonlter 12months
WJCF11S-POST-D/WJIF11 PostcarbonorInnosenselter 12months/18months
WJMF11-UF UFMembranelter 12months
P-07FUV
Part No. Names of Filter Usable Period
WJNF11 Neo-senselter 6months
WJCF11S-POST-D/WJIF11 PostcarbonorInnosenselter 12months/18months
WJMF11-UF UFMembranelter 12months
WJUVF-4W-BALLAST Ultravioletlamp 16months
About lter replacement cycle
Thelterreplacementcycledescribedaboveisnotthelterquality
warrantyperiodbuttheexpectedcycle(life)thattheltershowsitsoriginal
performance.
Therefore,thelterreplacementcyclemaybereducedfortheareawiththe
poorwaterqualityormoreapplication.
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

18
Maintenance FILTER REPLACEMENT / FILTER REPLACEMENT METHOD
FILTER REPLACEMENT METHOD
1. Close water lead-in valve and pull out plug.
2. Unfasten screws. Then, hold both side covers at the bottom and force them
upwards as if pushing up to remove them from the main body.
3. Remove tting from lter as shown in diagram. Replace lters as required.
Take caution for safety at all times.
Don’tpullthecup-touchleverwiththeexcesspower.
Otherwise,theproductmaybreak.
Tips
FilterreplacementtimeisindicatedwhenthecorrespondingLEDoflterickersinwindow
display.
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011

19
FILTER REPLACEMENT METHOD
4. Initialize lter setting by pressing the corresponding button (for 3 sec) of
lter among the lter reset buttons located at the back of the front panel.
5. Insert both side covers and fasten screws and plug the power cord into
outlet.
Check for normal operation of lter replacement parts in window display.
Pleasebesuretousethenewlteraftercleansing.
- Neo-senselter:PleaseassembleaftercleansingwithNeo-senselterforabout
30seconds.
- Plussedimentlter:Pleasemountitaftercleaningwiththemainwaterforabout
3minutes.
- Pre-carbon/Postcarbonblock/Inno-senselter:
Pleasemountaftercleansingwiththewaterpassedtheplussedimentlterfor
about3minutes.
- Membranelter(RO):Pleasemountaftercleansingwiththewaterpassedthe
plus-sedimentlterandthepre-carbonlterforabout3
minutes.
Tips
WQA Approved NSF/ANSI 42/53/58 MH 01/24/2011
