COX Homelife Smart LED Light Bulb User manual

Watch Installation Video
Before you begin, watch the Smart LED Light Bulb installation
video at cox.com/diyhomelife on your mobile device, tablet or computer.
Install Smart Bulb
You may install your Smart Bulb in any indoor light fixture, such a lamp
or ceiling light, with an E26 standard (medium) base socket.
1. Start with the light turned off
2. Replace the old light bulb with the new Smart Bulb
3. Turn on the light
The light bulb will begin to pulse, indicating it is ready to pair with your
Homelife system. You will have 3 minutes to complete the pairing
process.
TROUBLESHOOTING TIP
If the bulb does not pulse immediately, or if it has timed out, you can
reset it by pressing and holding the bulb’s power button located on
the side of the bulb, while installed and the light turned on. Press the
button for 20 seconds, then release. The bulb will blink five times
and then begin to pulse, indicating it is ready to pair.
Pair Smart Bulb with Touchscreen
1. On your Touchscreen Control Panel, press the Settings app.
2. Enter your 4-digit master keypad code.
3. From the Settings menu, select Home Devices > Lighting > Add
Lights.
4. The Locating Lighting Devices screen will appear. Press Next to
begin the pairing process. Once the Smart Bulb is found by the
Touchscreen, the light will become solid.
(Note: Do not press Done during the pairing process.)
5. When the “Dimmable Light” icon appears, pairing is
complete. Press Done. Then press Next to configure your Smart Bulb.
Smart LED Light Bulb
Installation & Pairing Instructions
With the Smart LED Light Bulb from Homelife, you can easily switch out old bulbs,
for new efficient, dimmable LED bulbs that have a life expectancy of up to 22 years!
Plus, you can control your lights remotely using the Cox Homelife mobile app or
online Subscriber Portal, and set up Rules that automate when they turn on or off.
Follow these steps to install and pair your new Smart Bulb with the Homelife system.
Expected Installation Time: 5 minutes
Power
button
1
2
3
INSTALLATION TIP
Pair the bulb using a lamp located
near your Touchscreen. You can
move the bulb to any location
after pairing is complete.
Continued on next page…
Step 5: Press Done after pairing is complete
cox.com/diyhomelife
START HERE

Configure Smart Bulb
1. On the Configure Lighting Devices screen, press the
“Dimmable Light” icon to configure it.
2. Tap the ‘Dimmable Light Name’ field to display a keyboard.
Delete the default name and enter the desired name for
your Smart Bulb or light fixture (example: Living Room Lamp).
Press Done to close the keyboard.
3. Toggle the ‘Dimmable’ field to Yes to allow the bulb’s
brightness to be controlled by the Homelife system.
4. Press Next to complete configuration. Press the
Touchscreen’s home button to return to the home
screen.
You can now control your Smart LED Light Bulb using the Lights app on your Touchscreen, Homelife mobile
app or online Subscriber Portal.
Congratulations, the installation and pairing process is now complete!
To learn how to set up Rules and find other helpful information, visit
us online at cox.com/diyhomelife
For Homelife technical support, call 1-877-404-2568
4
Smart LED Light Bulb
Installation & Pairing Instructions
Step 2: Change Light Name
IMPORTANT: The light switch for your light fixture must remain in the ON position in
order to control the bulb remotely.
