Coxo DB-685 Super User manual

DB-685 SuperDB-685 Super

Thanks for applying the curing light For the sake of safety
and efficient use of the product please read this user s guide first
.
,'.
Content
Ⅰ
Ⅱ
Ⅲ
Ⅳ
Ⅴ
Ⅵ
Ⅶ
Ⅷ
. INTRODUCTION
. SAFETY INFORMATION
. INSTALLATION
.
.
. MAINTENANCE
. TROUBLESHOOTING
.
.
CONFIGURATION AND FUNCTION
USAGE INSTRUCTION
TECHNICAL INDEX
. Guarantee
SYMBOLS AND DEFINITION
Ⅸ
Ⅹ
1
2
3
7
8
10
11
4
6
9

Introduction
1
This user s guide describes the normal properties of this curing
light and introduces the principle of the safety issues installation
usage and maintenance
Before the first using, please check the accessories and make sure
they are all in good condition.
'
,,,
.
Handle
The base of the charger
Charger
Light guide rod
Eye protection unit
User s guide'
Packing List
DB-685 Super

CAUTION: please read the following information completely
before use this product. Our warranty is applicable only if
these instructions concerning the operation and the safety
of the unit have been properly applied.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
This device must be used in strict accordance with the instructions co-
ntained in this user s guide The manufacturer will not take any respo-
nsibility for damage caused by improper use
Before connecting the base of the charger to the main power, make sure
that the power voltage is accord with the charger voltage range
Improper voltage would damage the device and cause the danger to the
patient and/or the operator.
Don t see the light with your eyes without protection it s harmful to your
eyes. In order to avoid the eyes getting in touch with the light directly
please assemble the eye protector.
Before using, let the device reach the room temperature Especially, the
device has been removed from a cold place to a warm place
Never use any other battery except the original battery otherwise it will
result in severe damage And remove the battery from the device body
for long-term storage so that it does not discharge slowly and risk damage.
Don t put the device near the flammable items and don t touch the fla-
mmable liquid with this light.
To avoid the electric shock, don t insert any other parts into the device it
may cause electric shock or damage
Please use our LED accessories, such as light guide rod charger and
battery We won t take the responsibility to any problem or damage bec-
ause of using other parts which not supplied by us.
Avoid the detergent go into the device in case that causes the short
circuit or problem
It s not allowed to modify the device at any condition Any disasse-
mbling or modification will cause the invalidation of the guarantee
Unstable voltage and if it s in electromagnetic environment will interfere
the normal operation.
Don t use the device to the patient who has heart pacemaker with him
Don t expose the battery in lower than 5 or higher than 30 and don t
expose out of the humidity rang: 10%-80%.
'.
.
';'
,
.
.
;
.
''
';
.
:,,
.'
,
,
'.
.
'
' .
' ℃ ℃, '
.
Safety InformationSafety Information
2

1. Before using, please sterilize the light guide
rod
2. Screw the battery into the handle and insert
the light guide rod into the handle As the light
guide rod is in the proper position it will
emit a slight kata sound.
3. Insert the eye protector on to the light guide rod
4. Put the charge base on a stable place and
connect the charger to the suitable power
5. Put the handle into the charger base the
indicator on the charger base will indicate
the status of the battery If the indicator is
red, that means the battery is being charged,
when it s green, it shows it has finished the
charging, a complete charging is about 3
hours.
.
,
.
,
“”
.
,
.
,
.
'
Installation
3
kata
135°C
3 hours

The following description will help you to use this unit swiftly
and correctly:
Configuration and FunctionConfiguration and Function
4

Configuration and FunctionConfiguration and Function
5
DB-685

press
1-2mm
1. Please select the desired mode .
Strong mode is default. (picture 1)
2. After selecting the mode turn on the
power The unit is ready to operate.
3 During operation you can shut down
the unit at any time by pressing the
power button.
4 After one session you can press the
power button immediately for the
next session (only if the handle is
not too hot). Otherwise the unit
needs to cool down before using it
for the next session.
5
6. Do not use the DB-685 Super, before
the light is covered by the transparent
material.
.
.
.
.
(picture 2)
(picture 3)
(picture 4)
Put the light guide rod close to the
material surface, the distance from
the light guide rod to the material
should be 1-2mm otherwise it
will affect the result seriously
(picture 5)
;,
Usage InstructionUsage Instruction
6
press
mode select
Picture 1
Picture 2
Picture 3
Picture 4
Picture 5
press
shut down
too hot to use

1. We suggest the unit should be cleaned and sterilized before the first
using
2. Avoid to use detergent or material which contains flammable ingre-
dient, if yes, make sure it s complete evaporated, then start the ope-
ration.
3. When sterilize the handle and the battery, the handle and the base
must be separate completely. When it s used for next patient, the
light guide rod must be cleaned and sterilized.
4. The main body and the accessories can be cleaned with alcohol or
neutral detergent it s not allowed to use caustic or rubbing deterg-
ent, and no ultrasonic cleaning.
5. In case of scratching, don t make the light guide rod touch any hard
items, after using, please check if there is any material on the termin-
al, if yes, clean it with plastic tool, don t use metal instrument. If
light guide rod is damaged, it has to be replaced.
6. The light guide rod can be sterilized with alcohol, or can be sterilized
for 18 minutes in the condition: 134 C 200kPa
7. There should be no dirt on the gilt surface of the printed circuit board
of both side of battery, and no dirt on the connection chip either, you
can clean with alcohol.
8. Please put the handle on the base if cease working for a short time,
but if long time, please take the light guide rod out, and separate the
handle and battery, save it in a good condition.
.
'
'
;'
'
'
.
°
Maintenance
7

If the unit works out of order, before calling our service center,
please check according with the below table.
Our service center can offer technical assistance to you.
Troubleshooting
8

1.
2.
3.
4.
5.
6.
7.
8.
9.
Power adaptor
Lithiumbattery
LEDsource
Lightguiderod
Temperatures
Humidity
Atmosphericpressure
Protectiontypeagainstelectricalshock:
Protectionagainstelectricalshock:
.
:
Input: 100-240Vac 50/60Hz
Output: DC 5V/1 5A
Voltage: DC 3.7V
Capacity: 2000mAh
perating
Storage:
Operating: 30% 75%
Storage: 10% 100% including condensation
perating: 70 106KPa
Storage: 50 106KPa
classII(adaptor)
type B
Power max 6W
Wavelength: 440-480nm
Lightpower >1200mW/cm
8 angle:60
()：
:2
Φmm
O +10˚C +40
-20 +70
~˚C
˚C~ ˚C
~
~
O~
~
Technical IndexTechnical Index
9

part warranty periodwarranty period
Handle
The base of
the charger
Charger
Light guide rod
Eye protection
unit
Battery
no warraty
no warraty
24 months
6months
6months
24 months
.DB-685 super is guaranteed from the date of purchase
The accessories are covered by warranty as follow:
The guarantee is valid for normal usage conditions. Any modification or
accidental damage will render the guarantee void.
We will repair or replace, at its option, a defective unit. This warranty is in
lieu of all warranties of merchantability, fitness for purpose or other
warranties express or implied. We do not accept liability for any loss or
damage, direct, consequential or otherwise, arising out of the use of or the
inability to use the product herein described.
Guarantee
10

Direct current
Type B equipment
Caution! Please read the instruction
Used indoor only
CE marked product
Class II equipment(Adaptor)
11
Symbols and DefinitionSymbols and Definition

Ver1.0
Foshan COXO Medical Instrument Co. Ltd
Address: 21 Wufeng Si Road, Foshan, Guangdong China
,
，
Wellkang Ltd.
Address: Suite B, 29 Harley Street London W1G QR
United Kingdom
