Coyote C1PB User manual

www.coyoteoutdoor.com
DIMENSIONAL RENDERINGS
Model No. Gas Supply BTU's Regulator WC Pressure Max PSI Electrical Requirements
C1PBLP Propane 60,000
1/2" Female Pipe
11" .5 PSI No Electrical Connections Required
C1PBNG Natural Gas 60,000
20 lb Tank Regulator
4" .5 PSI No Electrical Connections Required
Model No. Height Width Depth
Model No. Height Width Depth
C1PB
C1PB
Cutout Dimensions for Island
Overall Product Dimensions
13" 21"
24" 21"
10 1/4"
C1PB INSTALL GUIDE
24 1/4"
Important Note to Installer: This file is not intended to replace your Owners' Manual which contains specific safety requirements
and consumer guidelines. Please refer to your Owners' Manual prior to installing or operating your built-in side burner.

www.coyoteoutdoor.com
FRONT VIEW
Combustible material can not be within 24" of the grills frame
This applies to all directions - horizontal & vertical
Shaded area above on "TOP VIEW" illustrates the 24" minimum requirement (not to scale for rendering purposes)
The grill is designed to hang from the counter top with no support underneath
Ventilation Requirements:
Regardless if you are using a combustible or non-combustible building material, you must include at least two vents within the island.
These vents must be at least 20 sq. in. each and allow fresh air to move from the grill cabinet to the exterior environment.
For a propane setup, the vents should be installed lower as propane is heavier than air.
For a natural gas setup, the vents should be located higher in the island, as natural gas is lighter than air.
Do not locate the two vents on the same wall of the island. Cross ventilation is key to allow any excess heat or trapped gas to dissipate.
C1PB INSTALL GUIDE
OPENING
HEIGHT
TOP VIEW
24"
24"
COUNTERTOP
OVERHANG
SIDE
BURNER
OPENING
24"
3/4"
21"
21"
10 1/4"
INCLUDING
COUNTERTOP
DOORS / DRAWERS
OPENING WIDTH
OPENING
HEIGHT
1 1/2" MIN
Important Note to Installer: This file is not intended to replace your Owners' Manual which contains specific safety requirements
and consumer guidelines. Please refer to your Owners' Manual prior to installing or operating your built-in side burner.
Install Notes:
21"
CUTOUT WIDTH
CUTOUT WIDTH
NON-COMBUSTIBLE CONSTRUCTION ONLY
Insulated Jacket NOT Required
4"
4"
4"
