CP TECHNOLOGIES GES-2451 User manual

GES-1651 / GES-2451
16 GE With 2 Shared SFP Web Smart Switch
24 GE With 4 Shared SFP Web Smart Switch
Quick Installation Guide

Hardware Installation Figures
Rack Mounting
Flat Surface Installation
Power Regulation
Input : AC 100-240V; 50/60Hz

Installation
LED Indicator
Connecting Equipment
Step1. Inspect the Power Adapter carefully, and make sure
that it is properly connected to a power source.
Step2. Plug-in the Power Adapter to the Switch.
Step3. Connect your network devices with the switch by
using Ethernet cable. (e.g. Cat-5e)
LED Indicator
Status
Meaning
Power
On
Power is on.
Off
Power is off.
Link/Act
On
Port is connected
Blinking
Transmitting / Receiving data
Off
Port is not connected
SFP
Power
Link/Act
