LevelOne
User Manual
FSW-0511 / FSW-0811
5/8-Port Fast Ethernet Switch
V1.0.0-0803

Package Contents
•FSW-0511 or FSW-0811
•Power Adapter
•User Manual
•Wall-Mounting Kit
Installation
1. Please inspect the Power Adapter carefully, and make
sure that it is properly connected to a power source.
2. Power on. It will be automatically initialized and the LED
indicators should respond as follows:
a. All of the Link/Act LED indicators will flash
momentarily, which represent a resetting of the
system.
b. The Power LED indicators will light up.

Features & Specifications
y5/8 auto-negotiation 10/100 Mbps Ethernet ports
yAuto MDI/MDI-X at each port
ySupports IEEE802.3x flow control for Full Duplex mode and
backpressure for Half Duplex mode
yData filtering and forwarding at full wire speed
yStore-and-Forward switching technology
Standards IEEE802.3 10Base-T, IEEE802.3u 100Base-TX
Data Transfer
Rate 10Mbps (Half Duplex), 20Mbps (Full Duplex)
100Mbps (Half Duplex), 200Mbps (Full Duplex)
Network
Media
(Cable)
10BASE-T: UTP category 3, 4, 5 cable (maximum
100m) EIA/TIA-568 STP (maximum 100m)
100BASE-Tx: UTP category 5, 5e cable (maximum
100m) EIA/TIA-568 STP (maximum 100m)
Interface 5/8 10/100MbpsAuto-Negotiation ports
Power
Supply FSW-0511 AC 12V~ 0.35A/ DC 12V 0.35A
FSW-0811 AC 9V~ 0.8A/ DC 12V 1A
Temperature Operating Temperature: 0℃~40℃
Storage Temperature: -10℃~70℃
Humidity Operating Humidity: 10%~90% non-condensing
Storage humidity: 5%~95% non-condensing

LED Definition
FSW-0511/FSW-0811 Front Panel
PWR This indicator will light up when the Switch powers up
Link/Act One LED indicator will light green when a device is
connected to the corresponding port. It flashes when
data is being transmitted or received on the connection.
Rear Panel
The rear panel of the FSW-0511/FSW-0811 consists of 5/8
10/100Mbps RJ45 Ports. All ports can work as the Uplink port.
