Weidmüller Premium Line IE-SW-PL10M Series Manual

Managed Fast/Gigabit Ethernet
Switches Premium Line
IE-SW-PL10M Series (from product Rev. 2.0.0)
Hardware Installation Guide
Sixth Edition, August 2018
1243400000/05/08.18
Important note:
This document, the detailed user manual, additional product
information, configuration tool and latest firmware can be
downloaded using following link:
http://www.weidmueller.com
►Select Product Catalogue
Select „Active Industrial Ethernet“
Select „PremiumLine managed Switches“
Select Product model
Click and expand section „Downloads“
Download needed software or documentation
Copyright Notice
Copyright 2018 Weidmüller Interface GmbH & Co. KG
All rights reserved.
Reproduction without permission is prohibited.

2
Package Checklist
Your Ethernet switch is shipped with the following items. If any of these
items is missing or damaged, please contact your Weidmüller customer
service for assistance.
1 Ethernet Switch of IE-SW-PL10M series
Hardware Installation Guide (printed)
RJ45 to DB9 console port cable
Protective caps for unused ports
Regarding further documentation like the manual please download it
from the Weidmüller product catalouge as described on page 1.
Optional Accessories (must be ordered separately)
IE-SFP-1GSXLC Art.No.: 1241490000
(SFP transceiver with 1000BaseSX, LC, 0.5km, 0 to 60°C)
IE-SFP-1GSXLC-T Art.No.: 1286700000
(SFP transceiver with 1000BaseSX, LC, 0.5km, -40 to 85°C)
IE-SFP-1GLSXLC Art.No.: 1241500000
(SFP transceiver with 1000BaseLSX, LC, 2km, 0 to 60°C)
IE-SFP-1GLSXLC-T Art.No.: 1286710000
(SFP transceiver with 1000BaseLSX, LC, 2km, -40 to 85°C)
IE-SFP-1GLXLC Art.No.: 1241510000
(SFP transceiver with 1000BaseLX, LC, 10km, 0 to 60°C)
IE-SFP-1GLXLC-T Art.No.: 1286720000
(SFP transceiver with 1000BaseLX, LC, 10km, -40 to 85°C)
IE-SFP-1GLHXLC Art.No.: 1241520000
(SFP transceiver with 1000BaseLHX, LC, 40km, 0 to 60°C)
IE-SFP-1GLHXLC-T Art.No.: 1286730000
(SFP transceiver with 1000BaseLHX, LC, 40km, -40 to 85°C)
EBR-MODULE RS232 Art.No.: 1241430000
(External module for backing up and restoring the configuration via
Switch´s RS-232 Console Port)
RM-KIT Art.No.: 1241440000
(Kit for 19"-rack mounting)
IE-WALLMOUNT-KIT-46MM Art.No.: 1504440000
(Kit for wall mounting)

3
Brief Information for quick access to the
Web interface
The Web interface of the managed Switch can be accessed
via IP address 192.168.1.110 and subnet mask
255.255.255.0 (Factory default value).
Connect the PC to any port of the managed Switch and set
the PC’s IP address to a free one of range 192.168.1.0 /
255.255.255.0
Start a web browser and enter the IP address of the
connected Switch into the browser’s address line.
http://192.168.1.110
After the appearance of the login prompt, please enter
following login data (factory settings):
User name:
admin
Password:
Detmold
Note: The Web interface uses Java Runtime applets for
displaying some Switch parameters. For this reason your
PC must have installed the Java Runtime Engine to be able
to configure the Switch without any limitations.
For general settings of the Switch parameters please
refer to the manual.

4
Panel Layout of IE-SW-PL10M-series
1) 1 to 7 10/100BaseT(X) ports
2) G1 10/100/1000BaseT(X) port
3) G2 IE-SW-PL10M(T)-3GT-7TX =
10/100/1000BaseT(X) port,
IE-SW-PL10M(T)-1GT-2GS-7TX =
1000BaseSFP port
) G3 IE-SW-PL10M(T)-3GT-7TX =
10/100/1000BaseT(X) port,
IE-SW-PL10M(T)-1GT-2GS-7TX =
1000BaseSFP port
5) G1, G2, G3: LED indicators for 1000 Mbps
ports
6) PWR1: LED for power input 1
7) PWR2: LED for power input 2
8) FAULT: LED indicator
9) MSTR/HEAD: LED indicator
10) CPLR/TAIL: LED indicator
11) 100M: LED indicator for TP port
12) 10M: LED indicator for TP port
13) Article Number

5
Mounting Dimensions
Units: mm (inch)
DIN-Rail Mounting
The aluminum DIN-Rail clip should already be fixed to the back panel of
the Ethernet Switch when you take it out of the box. If you need to
reattach the DIN-Rail clip, make sure the stiff metal spring is situated
towards the top, as shown in the following figures.
STEP 1:
Insert the top of the DIN-Rail into
the slot just below the stiff metal
spring.
STEP 2:
The DIN-Rail attachment unit will
snap into place as shown below.
To remove the device from the DIN-Rail, simply reverse Steps 1 and 2.

6
Wall Mounting (optional)
For some applications, you will find it convenient to mount the Ethernet
switch on the wall, as shown in the following figures.
STEP 1: Remove the
aluminum DIN-Rail
attachment plate from the
switch rear panel, and then
attach the wall mount
plates as shown in the
diagram at the right.
STEP 2:
Mounting the switch on the wall requires 4 screws.
Use the switch, with wall mount plates attached, as a
guide to mark the correct locations of the 4 screws.
The heads of the screws should be less than 6.0 mm
in diameter, and the shafts should be less than 3.5
mm in diameter, as shown in the figure at the right.
NOTE Before tightening the screws into the wall, make sure the screw
head and shank size are suitable by inserting the screw into
one of the keyhole-shaped apertures of the wall mounting
plates.
Do not screw the screws in completely—leave about 2 mm to
allow room for sliding the wall mount panel between the wall
and the screws
STEP 3:
Once the screws are fixed on the wall, insert the four screw
heads through the large parts of the keyhole-shaped
apertures, and then slide the switch downwards, as indicated.
Tighten the four screws for added stability.
ATEX Information
1. Certificate number DEMKO 11 ATEX 150190X
2. Ambient range: -40°C ≤Tamb ≤75°C
3. Certification string: Ex nA nC IIC T4 Gc
4. Standards covered:
EN 60079-0:2012+A11:2013, EN 60079-15:2010
5. The conditions of safe usage:
 These products must be mounted in an IP54 enclosure
 Install in an area of pollution degree 2 or less
 Use a conductor wire of size 0.2 mm
2
or greater
 PROVISIONS SHOULD BE MADE, EXTERNAL TO THE
APPARATUS, TO PREVENT THE RATED VOLTAGE FROM
BEING EXCEEDED BY TRANSIENT DISTURBANCES OF
MORE THAN 40 %.
6.0 mm
3.5 mm

7
Wiring Requirements
WARNING
Do not disconnect modules or wires unless the power supply
has been switched off or the area is known to be non-
hazardous. The devices may only be connected to the supply
voltage shown on the type plate.
The devices are designed for operation with a Safety Extra-
Low Voltage. Thus, they may only be connected to the
supply voltage connections and to the signal contact with
the Safety Extra-Low Voltages (SELV) in compliance with
IEC950/ EN60950/ VDE0805.
WARNING
This unit is a built-in type. When the unit is installed in
another piece of equipment, the equipment enclosing
the unit must comply with fire enclosure regulation IEC
60950/EN60950 (or similar regulation).
WARNING
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring the Ethernet Switch.
Calculate the maximum possible current in each power wire
and common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring
could overheat, causing serious damage to your equipment.
Please read and follow the guidelines:
Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring
in the same wire conduit. To avoid interference, wires with different
signal characteristics should be routed separately.
You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb is
that wiring with similar electrical characteristics can be bundled
together.
Keep input wiring and output wiring separated.
It is strongly advised that you label wiring for all devices in the
system when necessary.

8
Grounding the Ethernet Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well-grounded
mounting surface,
such as a metal panel.
Wiring the Relay Contact
The Ethernet Switch has two sets of relay outputs—relay 1 and relay 2.
Each relay contact uses two contacts of the terminal block on the
Switch´s top panel. Refer to the next section for detailed instructions on
how to connect the wires to the terminal block connector and how to
attach the terminal block connector to the terminal block receptor. In
this section, we illustrate the meaning of the two contacts used to
connect the relay contact.
FAULT:
The two sets of relay contacts of
the 6-pin terminal block connector
are used to detect user-configured
events. The two wires attached to
the fault contacts form an open
circuit when a user-configured
event is triggered. If a user-
configured event does not occur,
the fault circuit remains closed.
Wiring the Redundant Power Inputs
The Ethernet Switch has two sets of power inputs—power input 1 and
power input 2. The top two contacts and the bottom two contacts of the
6-pin terminal block connectors on the Switch´s top panel are used for
the two power inputs. Input Terminal Block is rated 300 V/15 A, is
soldered on the board, can mate with a plug-half connector suitable for
28-12 AWG wire size, and has a torque value of 4.5-5.0 lb-in. The plug-
half connection has latching mechanism. The top and front views of one
of the terminal block connectors are shown here.
STEP 1:
Insert the negative/positive
DC wires into the V-/V+ terminals,
respectively.
STEP 2:
To keep the DC wires from
pulling loose, use a small flat-blade
screwdriver to tighten the wire-
clamp screws on the front of the
terminal block connector.
STEP 3: Insert the plastic terminal
block connector prongs into the
terminal block receptor, which is
located on the
Switch´s
top panel.

9
Wiring the Digital Inputs
The Ethernet Switch has two sets of digital inputs, DI 1 and DI 2. Each
DI consists of two contacts of the 6-pin terminal block connector on the
Switch´s top panel. The top and front views of one of the terminal block
connectors are shown here.
STEP 1: Insert the negative
(ground)/positive DI wires into the
┴/I1 terminals, respectively.
STEP 2: To keep the DI wires from
pulling loose, use a small flat-blade
screwdriver to tighten the wire-
clamp screws on the front of the
terminal block connector.
STEP 3: Insert the plastic terminal
block connector prongs into the
terminal block receptor, which is
located on the
Switch´s
top panel.
Communication Connections
Each switch of IE-SW-PL10M series has 3 types of communication
ports:
1 RJ45 console port (RS-232 interface)
7 10/100BaseTX Ethernet ports
3 Gigabit Ethernet ports:
3 10/100/1000BaseTX ports, or 1 10/100/1000BaseTX and
2 1000BaseSFP (mini-GBIC) ports

In this section, we present two types of diagrams—Pinout Diagrams
and Cable Wiring Diagrams—that convey information about the ports
and the cables used to connect the Ethernet Switch to other devices:
Pinouts: The “Pinouts” diagrams display the type of signal passing
through each of the port’s pins.
Cable Wiring: The “Cable Wiring” diagrams present standard cable
wiring schemes for cables used to connect the Switch´s ports to other
devices. These diagrams display three pieces of information:
1. When building your own cable, refer to the “pin-to-pin” cable
wiring information displayed between the two vertical dashed lines
to see which pin of the connector on the left should be connected
to which pin of the connector on the right.
2. The information to the left of the left vertical dashed lines gives the
pinouts of the relevant Ethernet Switch port.
3. The information to the right of the right vertical dashed line gives
the pinouts of the opposing device’s port.

10
10/100BaseT(X) Ethernet Port Connection
The 10/100BaseT(X) ports located on the Switch´s front panel are used
to connect to Ethernet-enabled devices. Most users configure these
ports for Auto MDI/MDI-X mode, in which case the port’s pinouts are
adjusted automatically depending on the type of Ethernet cable used
(straight-through or cross-over), and the type of device (NIC-type or
HUB/Switch-type) connected to the port.
In what follows, we give pinouts for both MDI (NIC-type) ports and MDI-
X (HUB/Switch-type) ports. We also give cable wiring diagrams for
straight-through and cross-over Ethernet cables.
10/100Base T(x) RJ45 Pinouts
MDI Port Pinouts MDI-X Port Pinouts 8-pin RJ45
Pin
Signal
1
Tx+
2
Tx
-
3
Rx+
6
Rx
-
Pin
Signal
1
Rx+
2
Rx
-
3
Tx+
6
Tx
-
RJ45 (8-pin) to RJ45 (8-pin) Straight-through Cable Wiring
RJ45 (8-pin) to RJ45 (8-pin) Cross-over Cable Wiring

11
1000BaseT Ethernet Port Connection
1000BaseT data is transmitted on differential TRD+/- signal pairs over
copper wires.
MDI/MDI-X Port Pinouts
Pin
Signal
1
TRD(0)+
2
TRD(0)
-
3
TRD(1)+
4
TRD(2)+
5
TRD(2)
-
6
TRD(1)
-
7
TRD(3)+
8
TRD(3)
-
1000BaseSFP (mini-GBIC) Fiber Port
The Fiber optic ports on the IE-SW-PL10M(T)-1GT-2GS-7TX are SFP
type slots, which require 1000BaseSFP mini-GBIC fiber transceivers to
work properly. Weidmüller provides transceiver models for various
distance requirements.
The concept behind the LC port and cable is quite straightforward.
Suppose that you are connecting devices I and II; contrary to electrical
signals, optical signals do not require a circuit in order to transmit data.
Consequently, one of the optical lines is used to transmit data from
device I to device II, and the other optical line is used transmit data from
device II to device I, for full-duplex transmission.
Remember to connect the Tx (transmit) port of device I to the Rx
(receive) port of device II, and the Rx (receive) port of device I to the Tx
(transmit) port of device II. If you make your own cable, we suggest
labeling the two sides of the same line with the same letter (A-to-A and
B-to-B, as shown below, or A1-to-A2 and B1-to-B2).
LC
-
Port Pinouts
LC
-
Port to
LC
-
Port Cable Wiring
ATTENTION
This is a Class 1 Laser/LED product. To avoid causing
serious damage to your eyes, do not stare directly into the
Laser Beam.

12
Turbo Ring DIP Switch Settings
Switches of IE-SW-PL10M series are managed Ethernet switches that
offer redundancy. The proprietary Turbo Ring protocol provides better
network reliability and faster recovery time. Turbo Ring’s recovery time
is less than 300 ms (Turbo Ring) or 20 ms (Turbo Ring V2) -
compared to a 3- to 5-minute recovery time for commercial switches -
decreasing the possible loss caused by network failures in an industrial
setting.
There are 4 Hardware DIP Switches for Turbo Ring on the top panel of
the Switch that can help setup the Turbo Ring easily within seconds. If
you do not want to use a hardware DIP switch to setup the Turbo Ring,
you can use a web browser, telnet, or console to disable this function.
NOTE Please refer to the Turbo Ring DIP Switch section and
Using Communication Redundancy section in User’s
Manual for more detailed information about the settings and
usage of Turbo Ring and Turbo Ring V2.
IE
-
SW
-
PL10M
s
eries D
IP Switches
The default setting for each DIP Switch is OFF.
The following table explains the effect of setting
the DIP Switch to the ON position.
“Turbo Ring” DIP Switch Settings
DIP 1
DIP 2
DIP 3
DIP 4
Reserved for
future use.
ON: Enables
this Ethernet
Switch as the
Ring Master.
ON: Enables the
default “Ring
Coupling” ports.
ON: Activates
DIP switches 1,
2, 3 to configure
“Turbo Ring”
settings.
OFF: This
Ethernet Switch
will not be the
Ring Master.
OFF: Do not use
this Ethernet
Switch as the
ring coupler.
OFF: DIP
switches 1, 2, 3
will be disabled.
“Turbo Ring V2” DIP Switch Settings
DIP 1
DIP 2
DIP 3
DIP 4
ON: Enables
the default
“Ring Coupling
(backup)” port.
ON: Enables
this Ethernet
Switch as the
Ring Master.
ON: Enables
the default
“Ring Coupling”
port.
ON: Activates
DIP switches 1,
2, 3 to configure
“Turbo Ring V2”
settings.
OFF: Enables
the default
“Ring Coupling
(primary)” port.
OFF: This
Ethernet Switch
will not be the
Ring Master.
OFF: Do not
use this
Ethernet Switch
as a ring
coupler.
OFF: DIP
switches 1, 2, 3
will be disabled.

13
NOTE You must enable the Turbo Ring function first (DIP 4) before
using the DIP switches to activate the Master and Coupler
functions.
NOTE If you do not enable any of the IE-SW-PL10M switches to be
the Ring Master, the Turbo Ring protocol will automatically
choose the switch with the smallest MAC address to be the
Ring Master. If you accidentally enable more than one IE-
SW-PL-10M switch to be the Ring Master, these switches
will
auto-negotiate to determine which one will be the Ring
Master.
LED Indicators
There are several LEDs on the Ethernet Switches front panel. The
function of each LED is described in the following table.
LED
Color
State
Description
PWR1 AMBER
On Power is being supplied to power input
PWR1.
Off Power is not being supplied to power
input PWR1.
PWR2 AMBER
On Power is being supplied to power input
PWR2.
Off Power is not being supplied to power
input PWR2.
FAULT RED
On
When (1) a relay warning event is
triggered, (2) the switch is the Master of
this Turbo Ring, and the Turbo Ring is
broken, or (3) start
-
up failure.
Off When a relay warning event is not
triggered.
MSTR/
HEAD GREEN
On
When the switch is set as the Master of
the Turbo Ring, or as the Head of the
Turbo Chain.
Blinking
The switch has become the Ring Master
of the Turbo Ring, or the Head of the
Turbo Chain, after the Turbo Ring or the
Turbo Chain is down.
Off
When the switch is not the Master of this
Turbo Ring or is set as the Member of
the Turbo Chain.

14
CPLR/
TAIL GREEN
On
When the switch coupling function is
enabled to form a back-up path, or when
it's set as the Tail of the Turbo Chain.
Blinking
When the Turbo Chain is down.
Off
When the switch disables the coupling
function, or is set as the Member of the
Turbo Chain.
10M
(TP) GREEN
On
TP port’s 10 Mbps link is active.
Blinking
Data is being transmitted at 10 Mbps.
Off
TP Port’s 10 Mbps link is inactive.
100M
(TP) GREEN
On
TP
port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100 Mbps.
Off
TP Port’s 100 Mbps link is inactive.
1000M
(TP/SFP)
GREEN
On
TP/SFP
port’s 100
0
Mbps is active.
Blinking
Data is being transmitted at 100
0
Mbps.
Off TP/SFP port’s 1000 Mbps link is
inactive.
Specifications
Technology
Standards IEEE802.3, 802.3u, 802.3x, 802.1D-2004, 802.1Q,
802.1w, 802.1p
,
802.1X, 802.3ad, 802.3z
Protocols
IGMPv1/v2, GMRP, GVRP, SNMPv1/v2c/v3, DHCP
Server/Client, BootP, TFTP, SNTP, SMTP, RARP,
RMON, HTTP, HTTPS, Telnet, Syslog, DHCP Option
66/67/82, SSH, SNMP Inform, LLDP, IEEE 1588
PTP, IPv6
, Modbus/TCP,
Ethernet/IP, PROFINET
RT
MIB MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, RMON
MIB Group 1, 2, 3, 9, Bridge MIB, RSTP
MIB
Interface
RJ45 Ports 10/100/1000BaseT(X) auto negotiation speed, F/H
duplex mode, and auto MDI/MDI
-
X connection
Fiber Ports
optional
1000BaseSX/LSX/
/LX/LHX
(LC connector)
Console
RS
-
232 (
10
-
pin
RJ45)
LED Indicators PWR1, PWR2, FAULT, 10/100M (TP-port),
100
0
M (
TP/SFP
-
port), CPLR/TAIL,
MSTR/HEAD
Relay Contact Two relay outputs
with current carrying capacity of 1A
@ 24 VDC
Digital Input
Two inputs with the same ground, but electrically
isolated from the electronics
• For state “1”: +13 to +30V
• For state “0”: -30 to +3V
• Max. input current: 8 mA
DIP Switches
Master, Coupler, Turbo Ring, Reserve

15
Power
Input Voltage
24 VDC (12 to 45
VDC),
2 redundant inputs
Input Current
(@24V)
IE-SW-PL10M(T)-3GT-7TX: 0.48 A
IE
-
SW
-
PL10M(T)
-
1GT
-
2GS
-
7TX: 0.
38 A
Connection
Two
removable 6
-
pin terminal block
s
Overload Current
Protection
Present
Reverse Polarity
Protection
Present
Mechanical
Housing
Metal, IP30 protected
Dimensions
(W ×H ×D) 80.5 ×135 ×105 mm
Weight
1170 g
Installation
DIN
-
Rail, Wall Mounting
(optional kit)
Environment
Operating
Temperature
Standard models: -10 to 60°C (14 to 140°F)
Wide temp. models:
-
40 to 75°C (
-
40 to 167°F)
Storage
Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5% to 95% (non-condensing)
Regulatory
Approvals
Safety UL 508, CSA C22.2 No. 60950-1, UL 60950-1,
EN60950
-
1
Hazardous
Location
UL/cUL Class I, Division 2, Groups A, B, C, and D
ATEX
Zone 2: Ex nA nC IIC T4 Gc
EMC
EN 55032 Class A
CISPR 32, FCC Part 15B Class A
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80MHz to 1GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10V
IEC 61000
-
4
-
8
Shock
IEC60068
-
2
-
27
Freefall
IEC60068
-
2
-
31
Vibration
IEC60068
-
2
-
6
MTBF
(meantime between failures)
Time
977,099
hrs
Database
Telcordia (Bellcore), GB 25°C
WARRANTY
Time Period
5 years

16
WARNING This equipment is intended to be used in a
restricted access location.
HOT SURFACE!! Before touching it, special
attention or protection is required.
Weidmüller gives a 5-year warranty on this product in accordance with
the warranty terms as described in the general conditions of sale of the
Weidmüller company which has sold the products to you. Weidmüller
warrants to you that such products the defects of which have already
existed at the time when the risk passed will be repaired by Weidmüller
free of charge or that Weidmüller will provide a new, functionally
equivalent product to replace the defective one. Safe where expressly
described otherwise in writing in this catalogue/product description,
Weidmüller gives no warranty or guarantee as to the interoperability in
specific systems or as to the fitness for any particular purpose. To the
extent permitted by law, any claims for damages and reimbursement of
expenses, based on whatever legal reason, including contract or tort,
shall be excluded. Where not expressly stated otherwise in this
warranty, the general conditions of purchase and the expressive liability
commitments therein of the respective Weidmüller company which has
sold the products to you shall be applicable.
Contact Information
Weidmüller Interface GmbH & Co. KG
Postfach 3030
32760 Detmold
Klingenbergstraße 16
32758 Detmold
Germany
Phone [phone]
Fax [phone]
E-Mail [e-mail]
Internet www.weidmueller.com
