LONG-JOIN JL-403C User manual

JL-403 WIDE VOLTAGE ELECTRONIC COIN-TYPE PHOTOELECTRIC SWITCH
1.Product SummAry
The photoelectric switch JL-403 is applicable to control the street lighting, passage
lighting and doorway lighting automatically in accordance with the ambient lighting level.
This product is designed with electronic circuits. Its quicker response with time delay of 3-
10 seconds offers easy-to-test feature. Especially, model JL-403C provides a wide
voltage range for customer applications under almost power supplies.
Further, a preset 3-10 seconds time-delay might avoid mis-operation due to spotlight or
lightning during the night time
This product has been listed by UL Inc and is comply with the Standard for Non-industrial
Photoelectric Switches for Lighting Control UL773A.
2.Ordering Information
*JL-403C **07 ***L ****M *****N
*: Model Number;
**: Lead Length in inches
***: 2nd Lock-Nut needed
****: cULus Holographic Label applied
*****: Flat Gasket replaces O-ring Gasket
3.TechnicAl DAtA
Model No.
JL-403C
Rated Voltage
120-277VAC
Rated Frequency
50/60Hz
Rated Loading
500W Tungsten,
850VA Ballast
5A E-Ballast
Power consumption
2W
Operate Level
10~20Lx On
30~80Lx Off
Ambient Temperature
-40℃~ +70℃
Related Humidity
99%RH
Overall Dimensions
54.5(L) x 29(W) x 44(H)mm
Leads Length
180mm or Customer request (AWG#18)
4.InstAllAtion & OperAtionAl Instructions
Disconnect power; wire the color coded receptacle according to the diagram below.

Push the photocontroller on and twist it clockwise to lock it into the receptacle.
Install the photocontroller with the Photocell facing the NORTH direction as
indicated on the top of the photocontroller.
Adjust the receptacle position if necessary.
It is normal for the SWITCH to take several minutes to turn off when first installed.
To test “turn on” during daytime, cover its eye with sliding the metal strip mounted.
Do not cover with finger because light traveling through fingers may be great enough to
keep the switch open.
Test will take approximately 2 minutes.
