Craftex CX series User manual

MODEL CX512
6”×9” BELT DISC SANDER

2
TABLE OF CONTENTS
General Safety Instructions..................................................................................... 3
CX512 Manual ........................................................................................................ 4
Safety Precautions and Specification...................................................................... 5
Assembly................................................................................................................. 5
Installing Sanding Belt Fences................................................................................ 6
Installing the Disc Table.......................................................................................... 6
PSA Sandpaper Disc Install.................................................................................... 7
Adjusting Disc Table Angle..................................................................................... 8
Adjusting the Belt Assembly.................................................................................... 9
Grounding Instructions............................................................................................10
Extension Cord Length............................................................................................11
ON/OFF Switch.......................................................................................................12
Replacing the Sanding Belt.....................................................................................13
Belt Tracking Adjustment........................................................................................14
Trouble Shooting Guide for CX512.........................................................................16
Diagram for CX512 .................................................................................................18
Parts List for CX512................................................................................................19
Parts List for CX512-2.............................................................................................20
Parts List for CX512-3.............................................................................................21
Parts List for CX512-4.............................................................................................22
Parts List for CX512-5.............................................................................................23
Warranty..................................................................................................................24

3
GENERAL SAFETY INSTRUCTIONS
Extreme caution should be used when operating all power tools. Know your power tool, be
familiar with its operation, read through the owner’s manual and practice safe usage procedures
at all times.
ALWAYS read and understand the user
manual before operating the machine.
CONNECT your machine ONLY to the
matched and specific power source.
ALWAYS wear safety glasses respirators,
hearing protection and safety shoes,
when operating your machine.
DO NOT wear loose clothing or jewelry
when operating your machine.
A SAFE ENVIRONMENT is important.
Keep the area free of dust, dirt and other
debris in the immediate vicinity of your
machine.
BE ALERT! DO NOT use prescription or
other drugs that may affect your ability or
judgment to safely use your machine.
DISCONNECT the power source when
changing drill bits, hollow chisels, router
bits, shaper heads, blades, knives or
making other adjustments or repairs.
NEVER leave a tool unattended while it is
in operation.
NEVER reach over the table when the tool
is in operation.
ALWAYS keep blades, knives and bits
sharpened and properly aligned.
ALL OPERATIONS MUST BE performed
with the guards in place to ensure safety.
ALWAYS use push sticks and feather
boards to safely feed your work through
the machine.
ALWAYS make sure that any tools used
for adjustments are removed before
operating the machine.
ALWAYS keep the bystanders safely away
while the machine is in operation

4
CX512 MANUAL
GETTING STARTED
WARNING
Be careful not to touch overhead power
lines, piping, lighting, etc. if lifting
equipment is used. Sander weighs
approximately 88 lbs, proper tools,
equipment and qualified personnel should
be employed in all phases of unpacking
and installation.
Cartons should be handled with care to
avoid damage from dropping, bumping, etc.
Store and unpack cartons with correct side
up. After unpacking the Sander, inspect
carefully for any damage that may have
occurred during transit. Check for loose,
missing or damaged parts. If any damage or
loss has occurred, claim must be filed with
the carrier immediately. Check for
completeness. Immediately report any
missing parts to the dealer.
The sander is shipped partially assembled.
The end user will need to assemble loose
parts to the machine.
IMPORTANT: The tool has been coated with
a protective coating. In order to ensure
proper fit and operation, the coating must
be removed. Remove coating with mild
solvents such as mineral spirits and a soft
cloth. Non-flammable solvents are
recommended. After cleaning, cover all
exposed metal surfaces with a light coating
of oil.
CAUTION
Never use highly volatile solvents. Avoid
getting cleaning solutions on paint as it
may tend to deteriorate these finishes. Use
soap and water on all painted components.
Contents
Sander (1)
Miter gauge assembly (1)
Support rod assembly (1)
Table assembly (1)
Hardware bag (1)
Rubber foot (4)
Hex Wrench S+4x120 (1)
Operating instructions and parts
manual (1)
Unpacking:
Carefully unpack the sander from
the carton. Do not discard packing
materials until after machine has
been inspected for damage and
completeness. Locate loose parts
and set aside.
Pre-inspection
After unpacking the unit, carefully
inspect for any damage that may
have occurred during transit. Check

5
for loose, missing or damaged parts.
Shipping claims must be filed with
the carrier.
All tools should be visually inspected
before use, in addition to regular
periodic maintenance inspections.
Be sure that the voltage label on the
unit matches your power supply.
See General safety Instructions,
Cautions and Warnings as shown.
SAFETY PRECAUTIONS
Personal Safety
Do not wear loose clothing, gloves,
neckties, rings, bracelets or other
jewelry which may get caught in the
moving parts of the machine.
Wear protective hair covering to
contain long hair.
Wear safety shoes with non slip
soles.
Wear safety glasses.
Wear a face mask or dust mask if
operation is dusty.
Be alert and think clearly. Never
operate power tools when tired,
intoxicated or when taking
medications that cause drowsiness.
Work Area Preparation
Keep work area clean. Cluttered
work areas invite accidents
Do not use power tools in dangerous
environments. Do not use power
tools in wet locations. Do not expose
power tools to rain.
Work area should be properly
illuminated.
Proper electrical receptacle should
be available for the sander. Use a
three prong only plugged into a
grounded receptacle.
Check for damaged parts and ensure
all guards are in place and
undamaged. Repair before use.
SPECIFICATIONS
Belt size 6 x 48”
Belt platen area 6 x 14-1/2”
Belt drum dimensions 2-7/8 x 6-1/8”
Table Area 6 x 11-1/2”
Table angle range 0 to 45 Deg.
Dust chute diameter 2”
Belt speed 1836 SFPM
Disc diameter 9”
Disc speed 2510 RPM
Base dimensions 12 x 18-1/8”
Switch SP, Locking
rocker
Motor 1 HP, 120 V,
8.0 Amps
Weight 72 lbs
Ship weight 76 lbs
ASSEMBLY
Installing the Foot Pads
Four rubber foot pads are supplied with the
machine to protect your work surface and
to reduce any vibration that may develop
during the sanding operation. The foot pads
are easily installed as per Figure 1. No
hardware is required.

6
Figure 1 – Install Foot Pads
Installing the Sanding Belt Fences
The sander includes two fences for use with
the sanding belt. The small fence/platen
attaches directly to the sanding belt frame,
and is used for supporting small items being
sanded.
The larger fence/platen attaches to the
small fence. It gives a larger support surface
for sanding larger work pieces
NOTE: These parts may be pre-assembled at
the time of delivery. If not, follow the
following parts assembly:
1. Install the small fence onto the
sanding belt frame with the four hex
screws and washers. See Figure 2.
Figure 2 – Install the small fence
2. Insert two Phillips head screws
through the countersunk holes in
the large fence and install the knobs
on their threaded ends. (Washers
shown in Figure 3 are optional, not
included with the sander).
3. Slide the large fence’s two screws
with knobs over the two slots in the
small fence and fasten it in place.
Depending upon the material being
sanded, the fence can easily be
removed by loosening the two
knobs and sliding it off the small
fence, See Figure 3.
Figure - 3 Install fence knobs
Installing the Disc Table
Refer to figures 4 and 5.
The larger work Table is used with the sanding
disc. It should be used to support workpieces in
all sanding operations except inside
applications.
1. Place the worktable on to the sander
frame, aligning the semicircle slot with
the threaded hole.
2. Place a washer on the threaded shaft of
each worktable handle, insert through
the semicircular slot and tighten into
the threaded hole. Repeat on the
other side.

7
Adjust worktable to level or any angle in
between 0 degrees and 45 degrees for
sanding.
NOTE:
Always check to make sure the handles are
tight before beginning any sanding
operation.
Figure 4
Figure 5
PSA Sandpaper Disc Install
NOTE: The 6” x 9” Belt Disc Sander only
uses 9” diameter abrasive sanding discs
with Pressure Sensitive Adhesive (PSA)
backing. To apply the sandpaper:
1. The metal disc plate is preinstalled
on the machine. Locate the 9” PSA
sandpaper disc and peel the
protective backing off.
2. Center the sandpaper over the
metal disc plate, Then press the
sandpaper firmly in place. See Figure
6.
See page 9 for instructions on changing the
sandpaper sisc.
Figure 6 – Mount sandpaper disc.
INSTALLATION
Mounting the Sander
NOTE
Although compact, the sander is heavy. At
least two people are required to lift it from
the carton.
Choose a suitable location to mount the
sander. The sander must be installed in a
place with a place with ample lighting and
have the correct power supply.

8
Make sure there is plenty of room for
moving the workpiece. There must be
enough room that neither operators nor
bystanders will have to stand in line with
the wood while using the tool. Allow room
so that the belt assembly can be positioned
horizontally.
Figure 7 shows the base dimensions,
mounting holes and the required space to
allow for table assembly in the horizontal
position.
Figure 7 – Base dimension and required
space.
The sander must be bolter to a firm, level
surface. The sander can be installed on a
workbench or a tool stand using bolts, lock
washers and hex nuts. (Not Supplied).
Adjusting Disc Table Angle
Ensure the sander is disconnected from the
power source prior to commencing work.
1. To check the trueness of the 90 Deg.
Angle of the disc sanding table,
place a square or other measuring
device on the table with the other
end against the sanding disc. See
Figure 8.
Figure 8 – Checking the disc trueness.
2. Loosen the disc table adjustment
handle, and adjust the table angle to
90 Deg.
3. Re-tighten the disc table adjustment
handle.
4. Adjust the angle scale pointer to
Zero Deg.
5. To adjust the table angle to another
angle, loosen the disc table
adjustment handle.
6. Set the table at the desired angle
using the angle scale pointer.
7. Re-tighten the disc table adjustment
handle.
WARNING
To avoid jamming the workpiece or fingers
between the table and sanding surface, the

9
table edge should be set to a maximum of
1/16 inches away from the sanding
surface. See Figure 9.
Figure 9.
Adjusting the Belt Assembly
The sanding frame can be adjusted easily
between a vertical and horizontal position,
or any other position to assist your sanding
operation.
1. Loosen the hex screw that pulls the
split casting together. This will allow
the sanding belt frame to be moved
to the desired work angle. See
Figure 10.
Figure 10
2. Once the sanding belt frame is at
the desired angle, re-tighten the hex
screw to secure it in place.
3. In the horizontal position, there are
two vertical padded set screws that
support the sanding belt frame.
These should be checked and
adjusted, if necessary, to make sure
they both touch the sanding belt
frame supports. These screws will
help relieve pressure on the casting
during work. See Figure 11.
Figure 11
Power Source
WARNING
All electrical connections must be
performed by an electrician.
Connect the sander to a supply circuit
protected breaker or time delay fuse.
The motor is designed for operation on the
voltage and frequency specified. Normal
loads will be handled safely not more than
10% above or below the specified voltage.
Running the unit on voltages not within the
range may cause overheating and burn-out.
Heavy loads require that the voltage at
motor terminals be no less than the voltage
specified. Power supply to the motor is
controlled by a single pole locking rocker

10
switch. Remove the key to prevent
unauthorized use.
Grounding Instructions
WARNING
Improper connection of equipment
grounding conductor can result in the risk
of electrical shock. Equipment should be
grounded while in use to protect the
operator from electric shock.
Check with a qualified electrician if
grounding instructions are not understood
or if in doubt if the tool is properly
grounded.
The tool is equipped with an approved 3-
conductor cord rated at 300V and a 3-prong
grounding type plug (See Figure 15) for your
protection against shock hazards.
Grounding plug should be plugged directly
in to a properly installed and grounded 3-
prong grounding-type receptacle, as shown
(Figure 12).
Figure 12 – 3-prong receptacle
Do not remove or alter the grounding prong
in any manner. In the event of malfunction
or breakdown, grounding provides a path of
least resistance for electrical shock.
WARNING
Do not permit fingers to touch the
terminals of the plug when installing or
removing from the outlet.
The plug must be plugged into a matching
outlet that is properly installed and
grounded in accordance with local codes
and ordinances. Do not modify the plug
provided. If it will not fit in the outlet, have
the proper outlet installed by an electrician.
Inspect the tool cords periodically, and if
damaged, have them repaired by an
authorized service facility.
Green (or green and yellow) conductor in
the cord is the grounding wire. If repair or
replacement of the electrical cord or plug is
necessary, do not connect the Green (or
green and yellow) wire to a live terminal.
Where a 2-prong wall receptacle is
encountered, it must be replaced with a
properly grounded 3-prong receptacle
installed in accordance with national
Electric Code and local codes and
ordinances.
Extension Cords
The use of any extension cord will
cause some drop of voltage and loss
of power.

11
Wires of the extension cord must be
of sufficient size to carry the current
and maintain adequate voltage.
Use the table to determine the
minimum wire size (A.W.G.)
extension cord
Use only 3-wire extension cords
having 3-prong grounding type plugs
and 3-pole receptacles which accept
the tool plug.
If the extension cord is worn, cut or
damaged in any way, replace it
immediately.
Extension Cord Length
Length Wire Size A.W.G
Up to 25 ft 18
25-50 ft 16
NOTE
Using extension cords over 50 ft long is not
recommended.
OPERATION
WARNING
Operation can result in foreign objects
being thrown into your eye which can
result in severe eye damage. Always wear
safety goggles before commencing power
tool operation.
CAUTION
Always observe the following safety
precautions:
Whenever adjusting or replacing any
parts on the tool, Turn switch off
and remove plug from the power
source.
Recheck table handles and bolt.
They must be tightened securely.
Make sure all guards are properly
attached and securely fastened.
Make sure all moving parts are free
and clear of any interference.
Make sure all fasteners are tight and
have not vibrated loose.
With power disconnected, test
operation by hand to verify
clearance and adjust if necessary.
Always wear eye protection or face-
shield.
Make sure abrasive belt tracks
properly. Correct tracking gives
optimum performance.
After turning switch on, always
allow the belt to come to full speed
before sanding or grinding.
Be sure disc runs counter-clockwise.
Abrasive belt must travel downward.
Keep your hands clear of abrasive
belt, disc and all moving parts.
For optimum performance, do not
stall motor or reduce speed. Do not
force the work into the abrasive belt
or disc.
Always support work piece with
table or work stop when sanding

12
with the belt and with table when
sanding with disc.
Never push a sharp corner of the
workpiece against belt or disc.
Abrasive backing may tear.
Replace the abrasive belt or disc
when they become loaded (glazed)
or frayed.
WARNING
Review all safety precautions, before
turning on the machine, making sure that
you fully understand the features,
adjustments and capabilities of the
machine outlined in this manual.
ON/OFF Switch
The ON/OFF switch needs to have the
safety switch key inserted before the switch
can be used. This feature prevents
unauthorized use of the sander. See Figure
14.
Figure 14 – Remove safety key to prevent
sander use.
Abrasive Belt Sanding
Finishing flat surfaces: Hold
workpiece firmly with both hands;
keep fingers away from abrasive
belt.
Use table to position and secure
work being sanded. Keep the end
butted against the table and move
work evenly across the abrasive belt
Finishing long pieces: Use belt in
horizontal position with the work
stop. Apply only enough pressure to
allow the abrasive belt to remove
material.
Use work stop to position and
secure work being sanded. Keep the
end butted against the table and
move work evenly across the
abrasive belt. Use extra caution
when sanding very thin pieces.
Finishing curved edges: Finish
outside curves on flat portion of
abrasive belt. Finish inside curves on
the idler drum portion of the
abrasive belt.
Finishing end grain: It is more
convenient to finish the end of long
workpieces with the abrasive belt in
the vertical position.
Position the table on belt side of
sander. Move work evenly across
abrasive belt. For accuracy, use the
miter gauge. Table may be tilted for
beveled work.
Disc Sanding
Abrasive disc sanding is well suited
for finishing small flat surfaces and
convex edges.

13
Move workpiece across downside
(left) of the abrasive disc. Hold
workpiece firmly with both hands;
keep fingers away from abrasive
disc.
Abrasive disc moves fastest and
removes more material at the outer
edge.
For accuracy, use the miter gauge.
Replacing the Sanding Belt
1. Remove the plastic side cover from
the frame by unscrewing the knob.
See Figure 15
Figure 15
2. Remove the small fence. See page 3
for instructions on installing this
part.
3. Slide tension lever to the right to
release the belt tension. See Figure
16.
NOTE
Above the tension lever, there is a direction
arrow. The sanding belt must run in the
direction of this arrow so that the splice does
not come apart. See Figures 16 and 17.
4. Remove the old belt by sliding it off
to the left of the frame. Place the
new sanding belt over the drums
with the direction arrow pointing in
the proper direction. See Figure 17.
Make sure the belt is centered on
both drums.
5. Slide the tension lever to the left to
apply tension to the belt. See Figure
16.
6. Re-install the small fence and slide
cover onto frame (removed in Step 1
& 2).
7. Plug in the power cord. Turn the
switch to “ON” and note if the belt
tends to move to the right or left on
the drums. The belt should be
running on the center of the drive
drums. If it is not the belt tracking
needs adjustment. See instructions
on sanding belt tracking.
Figure 16
Figure 17

14
Belt Tracking Adjustment
Refer to Figure 18.
1. Belt tracking on the center of the
drive wheels is pre-set at the
factory. If an adjustment needs to
be made, the sander must be turned
on.
a) If the sanding belt moves toward
the disc, slowly turn the tracking
knob clockwise ¼ turn.
b) If the sanding belt moves away
from the disc, slowly turn the
tracking knob counter-clockwise
¼ turn.
2. Slowly turn the belt tracking knob
noting the belt movement. Re-adjust
the tracking knob, as necessary,
until the belt runs true in the center
of the drums.
Figure 18
Sanding Disc Installation
Refer to Figure 19.
The sandpaper disc can be removed with
the table installed, or with the table
removed to give more working access to
the disc, if needed.
1. Peel the abrasive disc from the
metal disc plate. A putty knife may
help in this process.
2. Make sure the disc plate is clean of
any residue. Mineral spirits will
soften the PSA adhesives for its
removal. Rotate the disc by hand to
access all of the disc surface.
3. Peel the protective backing from the
new PSA 9” abrasive sanding disc,
then center and press the sanding
disc firmly onto the metal disc plate.
4. Replace the sanding table if it was
removed.
Figure 19
MAINTENANCE
WARNING
Make certain that the unit is disconnected
from the power source before attempting
to service or remove any component.
Cleaning
Keep the machine and workshop
clean. Do not allow sawdust to
accumulate on the tool.

15
Keep the drums clean. Dirt on the
drums will cause poor tracking and
belt slippage.
Operate the tool with a dust
collector to keep dust from
accumulating.
Be certain the motor is kept clean
and is frequently vacuumed free of
dust.
Use soap and water to clean painted
parts, rubber parts and plastic parts.
Lubrication
The shielded ball bearings on the tool are
permanently lubricated at the factory. They
require no further lubrication.
When operation seems stiff, a light
coat of paste wax applied to the belt
and disc tables will make it easier to
feed the work while finishing.
Do not apply wax to the belt platen.
Belt could pick up wax and deposit it
on the drums causing the belt to
slip.
Tool Upkeep
If the power cord is worn, cut or
damaged in any way, have it
replaced immediately.
Replace worn abrasives when
needed.
Replace any damaged or missing
parts. Use parts list to order parts.
Any attempt to repair the motor
may create a hazard unless the
repair is done by a qualified
technician.

16
Trouble Shooting Guide for CX512
Problem Possible Cause Solution
Motor will not start 1. Faulty or defective switch
2. Faulty or blown capacitor
3. Blown fuse or tripped circuit
breaker
4. Low line voltage
1. Replace switch
2. Replace the capacitor
3. If fuse is blown replace it with
required size. If breaker is
tripped, reset it
4. Check power supply for voltage
and correct as needed
Motor will not start due to
blown fuse or tripped breaker in
service panel
1. Faulty or defective plug
2. Faulty or defective switch
3. Defective or damaged power
cord
4. Faulty or incorrect Internal
wiring
5. Overloading due to binding or
jamming of machine
1. Have the plug replaced
2. Have the switch replaced
3. Have the power cord replaced
if damaged
4. Contact Busy Bee Tools
Customer service.
5. Clean debris from around
wheels and shaft or replace
bearings if seized.
Motor overheats 1. Motor is overloaded 6. Reduce load on motor
Motor fails to develop full
power. (power output decreases
rapidly with drop in voltage to
motor terminals)
1. Wires gauge is undersized or
circuit is too long
2. Circuit is overloaded the
lights, appliances, or other
motors
3. General overloading of
power.
1. Increase the wire gauge and
short the run length of the
circuit
2. Reduce load on circuit or try
using another circuit.
3. Request a voltage check from
your power company
Abrasive belt runs off top wheel 1. Not tracking properly 1. See the Adjusting sanding belt
section on page 6

17
Machine slows down during
operation
1. Applying to much pressure to
workpiece
2. V-belt (drive belt is slipping
1. Ease up on pressure and let the
machine do the work
2. Adjust and increase the V-belt
tension
Motor stalls (resulting in a
tripped breaker or blown fuse)
1. Low voltage
2. Wrong size fuse or breaker
for circuit load
3. Loose connection or short
circuit in motor connections
4. Motor overloaded
1. Correct the low line voltage
conditions.
2. Install the appropriate size
breaker or fuse
3. Inspect motor for loose
connections, worn, or damage
wires. Replace if required.
4. Reduce the load on the motor

18

19
Parts List For CX512
Part Number Description Quantity
1 Phillipsscrew+flatwasherM4x6 4
2 Phillipsscrew+springwasher+flatwasherM4x8 4
3 BasePlate 1
4 PhillipsscrewM5x8 4
5 Lockhandle 2
6 Powercord 1
7 Dusthose 1
8 V‐beltA580 1
9 HexscrewM6x8 5
10 Cordclip6P4 1
11 KeyA5X15 2
12 Motor 1
13 NutM8 2
14 Drivingpulley 1
15 Dustcover 1
16 Hexscrew+springwasher+flatwasherM5x10 10
17 FlatwasherD8 2
18 HexscrewM8x55 2
19 Hexnut,ItypeM8 5
20 Bearingcap 1
21 Ballbearing6201 3
22 HexscrewM8X12 3
23 Drivingdrum 1

20
24 Drivingshaft 1
25 Supportingplate 1
26 Hexscrew+springwasher+flatwasherM8X30 2
27 HexscrewM8X16 4
28 Base 1
29 Rubberfoot 4
30 PhillipsscrewM5X12 1
31 Capacitorbracket 1
32 Hexnut,ItypeM5 3
33 PhillipsscrewM4X10 11
34 Hexscrew+springwasher+flatwasherM6x12 4
35 Capacitor20UF/120V 1
36 Capacitor20UF/300V 1
37 Capacitorbracket 1
38 Hexscrew+springwasher+flatwasherM5x18 2
39 Beltcover 1
40 Disctable 1
41 Dustport 1
42 Phillipsscrew+springwasherM5x25 3
43 Phillipsscrew+springwasher+flatwasherM5x12 9
44 Idlerpulley 1
45 Fixingring 1
46 Beltframeassemblybase 1
47 BearingCap 1
48 Ballbearing6202 2
