Owner's Manual
JCRaFT MRM I
Portable Air Tank
Model No. 15200/15201 /
FULL ONE YEAR WARRANTY ON CRAFTSMAN PORTABLE AIR TANK
If this Craftsman Portable Air Tank fails due to manufacturer's defects in material or workmanship within one year
from the date of purchase, return it to your nearest Sears store in the United States and it will be replaced free of
charge.
If this Portable Air Tank is used for commercial or rental purposes, this warranty applies for only 90 days from the
date of purchase. This warranty gives you specific legal rights and you may also have other rights which vary from
state to state.
Sears, Roebuck and Co., Dept. 817WA, Hoffman Estates, IL 60179
Important Safety Instructions and Guidelines
The information listed below should be read and understood by the operator. This information is
given to protect the user while operating and storing the portable air tank. We use the symbols
below to allow the reader to recognize important safety information. Improper operation or maintenance of this product
could result in serious injury and/or property damage. Read and understand all of the warnings and safety instruc-
tions provided before using this equipment.
Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
Risk to Breathing
Keep children, pets, and others
out of the area of operation.
This portable air tank does not
provide breathable air for
anyone or any auxiliary
breathing device.
Risk of Bursting
If the tank develops a leak, then
replace the portable air tank.
Never attempt to repair a tank by
welding!
NOTE: This tank is stamped with a
"DISCARD AFTER" date. Discard
the empty tank and DO NOT use
after this date has passed.
Risk of Personal Injury
Compressed air can be
hazardous. The air stream can
cause injury to soft tissue areas
such as eyes, ears, etc. Particles
or objects propelled by the air
stream can cause injury.
www.sears.com/craftsman
12/30/2002
Part No. E100174

Operating Procedures
Filling the Portable Air Tank
Take your portable air tank to any source of clean dry
compressed air. A full service gas station or truck stop is
preferable. Modern convenience mart type filling stations
do not have sufficient air pressure available to allow you
to get the most from your air tank. It is recommended
that you fill your tank with air until the pressure gauge
reads between 95 to 135 psi. The air tank is filled like a
car tire by pressing the chuck from the source to the filler
valve. PLEASE NOTE: Tank can be filled and the
pressure gauge can be read with the RED ON/OFF
KNOB in the OFF position.
Using the Portable Air Tank
Turn the RED ON/OFF KNOB counter-clockwise to the
open position to allow air to flow from the tank into the
hose. To prevent air from leaking out of the tank between
uses, turn the RED ON/OFF KNOB clockwise to the
closed position.
Storage
STORING YOUR PORTABLE AIR TANK
Turn the RED ON/OFF KNOB CLOCKWISE to the OFF
position when storing your air tank.
Failure to remove condensation will cause the tank to
rust prematurely.
Always drain the tank of all air after the last use for the day
and before repairing or removing any component parts.
Point the safety pressure relief valve AWAY FROM YOUR
BODY when releasing air. Use the pull ring on the safety
relief valve to vent any pressure inside the tank before
attempting to service the tank. Safety goggles must be
worn at all times for eye protection.To disperse any
accumulated condensation inside the tank, begin by
reducing the air pressure inside the tank by pulling out on
the safety valve and holding until the tank gauge reaches
25 psi. Invert the tank with the manifold facing downward
and pull the ring on the safety relief valve. We as the
manufacturer and you as the consumer have no control
over the moisture content of air coming from any fill
source. Premature rusting caused by condensation inside
the tank is the primary reason for the suggested
replacement date stamped on the tank.
Never attempt to remove any components while tank is
pressurized.
Never remove or deface the information sticker on tank.
•Never attempt to fill the tank if any air leak is detected
in the tank body. Discontinue use of the air tank immediately.
Warranty is void if any attempt is made to alter or
change the design of the tank.
Parts List
O Carry Handle
Pressure Gauge
Indicates internal air pressure of tank.
@ On/Off Valve
Prevents air from leaking out of the air hose and/or
tire chuck, when in the off position.
O Filler Valve
Fill tank with compressed air through this point.
@Safety Pressure Relief Valve
Prevents tank from being over-pressurized.
O Air Hose
Delivers compressed air from the tank.
OSteel Legs
Support tank in an upright stable position.
@Tire Chuck
Used to inflate tires and other items.
Manifold Enlargement
0
Replacement Parts
Item No(s). Part No. Description
2 E100179 Pressure Gauge
3, 4, & 5 E100177 Manifold Assembly
6 & 8 E100178 Air Hose w/Chuck
1
1
1
For replacement parts call
1-800-4-MY-HOME ® (1-800-469-4663)
