Craftsman 919.167243 User manual

Owner's Manuam
PermanentJy Lubricated
Tank Mounted
AIR COMPRESSOR
ModeJ No.
o
o
o
o
o
o
o
Safety Guidelines
Assembly
Operation
Maintenance
Service and Adjustments
Repair Parts
CALIT|ON: Read the Safety Guidelines
and All instructions CarefulIy Before
Operating.
Sears, Roebuck and Co., Hoffman Estates, mL(}0179 U.S.A.
Visit our Craftsman website: www, sears,com/craftsman
A09706 R_v,0 1/s/0._

WARRANTY ................................................ 2
SPECiFiCATiON CHART ..................................... 3
SAFETY GUiDELiNES ...................................... 3-8
GLOSSARY ................................................ 9
ACCESSORIES ............................................ 9
DUTY CYCLE .............................................. 9
ASSEMBLY ............................................... 10
iNSTALLATiON ......................................... 11-12
OPERATION ........................................... 13-15
MAINTENANCE ............................................ 16
SERVICE AND ADJUSTMENTS ............................ 17-18
STORAGE ................................................ 18
TROUBLESHOOTING GUIDE ............................. 19-21
REPAIR PARTS ......................................... 22-25
ESPANOL .............................................. 26-46
REPAIR PROTECTION AGREEMENTS ......................... 47
HOW TO ORDER REPAIR PARTS ...................... back cover
FULL ONE YEAR WARRANTY AiR COMPRESSOR
If this CRAFTSMAN Air Compressor fails due to a defect in material or
workmanship within one year from the date of purchase, Sears will at
its option repair or replace it free of charge. Contact your nearest Sears
Service Center (1-800-4-MY-HOME O) to arrange for repair, or return the Air
Compressor to the place of purchase for replacement.
If this Air Compressor is used for commercial or rental purposes, this warranty
applies for only ninety days from the date of purchase.
This warranty gives you specific legal rights and you may have other rights
which vary from state to state.
Sears, Roebuck and Co., Dept. 817WA, Hoffman Estates, IL 60179
A09706 2= ENG

ModeB Ne. 919-167243
Running HP 1.5
Sore 1.875"
Stroke 1.25"
Voltage-Single Phase 120V
Minimum Branch Circuit Requirement 15 amps
Fuse Type Time Delay
Air Tank Capacity 15
Approx. Cut-In 120
Approx. Cut-out 150
SCFM @ 40 psig 4.9
SCFM @ 90 psig 3.5
Refer to Glossary for abbreviations.
This manual contains information that is important for you to know and
understand. This information relates to protecting YOUR SAFETY and
PREVENTING EQUIPMENT PROBLEMS. To help you recognize this
information, we use the symbois below. Please read the manual and pay
attention to these symbols.
situation which, if not avoided, will result
in death or serious injury.
_ Indicates a potentially
' hazardous s tuat on
which, if not avoided, could result in
death or serious in'_
_ Indicates a potentially
hazardous situation
which, if not avoided, _ result in minor
or moderate injury..
_Used without the
safety alert symbol
indicates a potentially hazardous situation
which, if not avoided, may result in
re err dama e.
7
Some dust created by power sanding, sawing, grinding,
drilling, and other construction activities contains
chemicals known (to the State of California) to cause cancer, birth defects
or other reproductive harm. Some exampme of these chemicals are:
lead from lead-based paints
crystalline silica from bricks and cement and other masonry products
arsenic and chromium from chemically-treated Bumber
Your risk from these exposures varies, depending on how often you do
this type of work. To reduce your exposure to these chemicals: work in
a wen ventilated area, and work with approved safety equipment, always
wear MSNA/NIOSN approved, proper_y fitting face mask or respirator when
using such teems.
When using air teems, basic safety precautions shoumd always be followed
to reduce the risk of of personal injury.
3-ENG A09706

Gave these instructions
Improper operation or maintenance of this product could result in serious injury and
property damage. Read and understand all warnings and operation instructions before
using this equipment.
WARNING: Risk of explosion or fire _,i
What Could Happen How To Prevent It
mtis normal for electrical contacts within Always operate the compressor in a
the motor and pressure switch to spark, well ventilated area free of combustible
materiame, gasoline, or somvent vapors.
mfelectrical sparks from compressor if spraying flammable materials, locate
come into contact with flammable compressor at least 20 feet away from
vapors, they may ignite, causing fire or spray area. An additional length of hose
e×plosion, may be required.
Store flammable materials in a secure
location away from compressor.
Restricting any of the compressor
ventilation openings will cause serious
overheating and could cause fire.
Unattended operation of this product
couM resumt in personal injury or
property damage. To reduce the risk
of fire, do not anew the compressor to
operate unattended.
Never place objects against or on top
of compressor. Operate compressor in
an open area at least 12 inches away
from any wan or obstruction that would
restrict the flow of fresh air to the
ventilation openings.
Operate compressor in a clean, dry well
ventilated area. Do not operate unit
indoors or in any confined area.
Always remain in attendance with the
product when it is operating.
ABways disconnect eRectrical power by
moving pressure switch lever to the off
position and drain tank daily or after
each use,
A09706 4= ENG

WARNING: Risk of Bursting "_1
Air Tank: The following conditions could lead to a weakening of the tank, and result
in a violent tank explosion and could cause property damage or serious injury.
What Could Happen How To Prevent it
FaiRure to properly drain condensed Drain tank daily or after each use, If tank
water from tank, causing rust and develops a leak, replace it immediately
thinning of the steeB tank. with a new tank or replace the entire
corn presser
Modifications or attempted repairs to
the tank.
Unauthorized modifications to the
unRoader valve, safety valve, or any
other components which control tank
pressure,
Excessive vibration can weaken the
air tank and cause rupture or
explosion
ATTACHMENTS &ACCESSORIES:
Exceeding the pressure rating of air
tools, spray guns, air operated
accessories, tires, and other inflatables
can cause them to explode or fly apart,
and could result in serious injury.
Never drill into, weld, or make any
modifications to the tank or its
attachments.
The tank is designed to withstand specific
operating pressures. Never make
adjustments or parts substitutions to
alter the factory set operating
pressures,
For essential control of air pressure, you
must install a pressure regulator and
pressure gauge to the air outlet (if not
equipped} of your compressor. Follow the
equipment manufacturers recommendation
and never exceed the maximum allowable
pressure rating of attachments. Never use
compressor to inflate small low
pressure objects such as children's
toys, footbaHs, basketbaHs, etc.
i D iii_,
WARNING: Risk from FrayingObjects
What Coumd Happen How To Prevent It
The compressed air stream can cause
soft tissue damage to exposed skin and
can propel dirt, chips, loose particles,
and small objects at high speed,
resulting in property damage or personal
injury.
Always wear ANSI Z87.1 approved
safety glasses with side shieRds when
using the compressor.
Never point any nozzle or sprayer
toward any part of the body or at other
peopBe or animals.
Always turn the compressor oft and
bleed pressure from the air hose and tank
before attempting maintenance, attaching
tools or accessories.
5= ENG A09706

WARNING: Risk of Electticam Shock
What CouBd Happen
Your air compressor is powered by
eRectricity, Like any other electrically
powered device, If it is not used
property it may cause eRectric shock.
Repairs attempted by unqualified
personneB can result in serious injury
or death by electrocution.
Electrical Grounding: Failure to provide
adequate grounding to this product
could result in serious injury or death
from electrocution.
See grounding instructions.
Now To Prevent it
Never operate the compressor outdoors
when it is raining or in wet conditions.
Never operate compressor with
protective covers removed or damaged.
Any electricam wiring or repairs required
on this product should be performed by
authorized service center personnel in
accordance with national and local
electrical codes.
Make certain that the electrical circuit
to which the compressor is connected
provides proper eBectrical grounding,
correct voltage and adequate fuse
protection.
WARNING: Risk to Breathing
What Could
The compressed air directly from your
compressor is not safe for breathing.
The air stream may contain carbon
monoxide, toxic vapors, or solid
particles from the tank. Breathing these
contaminants can cause serious injury
or death.
Sprayed materials such as paint, paint
solvents, paint remover, insecticides,
weed killers, may contain harmful
vapors and poisons.
Now To Prevent It
Air obtained directly from the compressor
shouM never be used to supply air for
human consumption. In order to use air
produced by this compressor for
breathing, suitable filters and in-line
safety equipment must be property
installed. In-line filters and safety
equipment used in conjunction with the
compressor must be capabBe of treating
air to aH appBicable local and federam
codes prior to human consumption.
Work in an area with good cross
ventilation. Read and follow the safety
instructions provided on the label or
safety data sheets for the materiaBs
you are spraying. Use a NmOSH/MSHA
approved respirator designed for use
with your specific application.
A09706 6-ENG

WARNING: Risk of Burns
What Could Happen How To Prevent it
Touching exposed metal such as the
compressor head or outlet tubes, can
result in serious burns.
Never touch any exposed metal parts
on compressor during or immediately
after operation. Compressor win remain
hot for several minutes after operation.
Do not reach around protective shrouds
or attempt maintenance until unit has
been allowed to cool
WARNING: Risk from Moving Parts _
What Could Happen New To Prevent mt
Moving parts such as the pulley, Never operate the compressor with
flywheel, and belt can cause serious guards or covers which are damaged or
injury if they come into contact with you removed.
or your clothing.
Attempting to operate compressor with Any repairs required on this product
damaged or missing parts or should be performed by authorized
attempting to repair compressor with service center personnel
protective shrouds removed can expose
you to moving parts and can result in
serious injury.
WARNING: Risk of Falling
What Could Happen
A portable compressor can fan from
a table, workbench, or roof causing
damage to the compressor and could
result in serious injury or death to the
operator.
Now To Prevent It
Always operate compressor in a stable
secure position to prevent accidental
movement of the unit. Never operate
compressor on a roof or other elevated
position. Use additionaB air hose to
reach high locations.
7-ENG A09706

B,_ i,ll
WARNING: Risk of Serious Injury or Property DamageWhen Transporting Compressor
(Fire, Inhalation, Damage to Vehicle Surfaces)
What Could Happen
Oil can leak or spill and could result in
fire or breathing hazard; serious injury or
death can result, oil leaks will damage
carpet, paint or other surfaces in vehicles
or trailers.
How To Prevent it
Always place COMPRESSOR on a
protective mat when transporting to
protect against damage to vehicle from
leaks. Remove COMPRESSOR from
vehicle immediately upon arrival at your
destination.
iiiiiiiii_.... B'_ i'l
WARNING: Risk of Unsafe Operation
How To Prevent it
What Could Happen
Unsafe operation of your air compressor
could lead to serious injury or death to
you or others.
Review and understand all instructions
and warnings in this manual.
Become familiar with the operation and
controls of the air compressor.
Keep operating area clear of all persons,
pets, and obstacles.
Keep children away from the air
compressor at aH times.
Do not operate the product when
fatigued or under the influence of
alcohol or drugs. Stay alert at all times.
Never defeat the safety features of this
product.
Equip area of operation with a fire
extinguisher.
Be not operate machine with missing,
broken, or unauthorized parts.
SAVE THESE INSTRUCTIONS
A09706 8-ENG

Become familiar with these terms
before operating the unit.
Ot=M: Cubic feet per minute.
Set=M: Standard cubic feet per
minute; a unit of measure of air
delivery.
PSlG: Pounds per square inch
gauge; a unit of measure of pressure.
Code Certification: Products that
bear one or more of the following
marks: UL, CUL, ETL, CETL, have
been evaluated by OSHA certified
independent safety laboratories and
meet the applicable Underwriters
Laboratories Standards for Safety.
Cut-In Pressure: While the motor
is off, air tank pressure drops as
you continue to use your accessory.
When the tank pressure drops to a
certain Iow level the motor wilI restart
automatically. The low pressure
at which the motor automatically
restarts is called "cut-in" pressure.
Cut-Out Pressure: When an air
compressor is turned on and begins
to run, air pressure in the air tank
begins to build. It builds to a certain
high pressure before the motor
automatically shuts off, protecting
your air tank from pressure higher
than its capacity. The high pressure
at which the motor shuts off is called
"cut-out" pressure.
Branch Circuit: Circuit carrying
electricity from electrical panel to
outlet.
This unit is capable of powering the following Accessories. The accessories are
available through the current Power and Hand Tool Catalog or full-line Sears
stores.
Accessories
® In Line Filter
+ Tire Air Chuck
® Quick Connector Sets
(various sizes)
+ Air Pressure Regulators
+ Oil Fog Lubricators
+ Air Hose: 1/4", 3/8" OR 1/2" LD. in
various lengths
Refer to the selection chart located
on the unit to select the tools this unit
is capable of powering.
This air compressor pump is
capable of running continuously.
However, to prolong the life of your
air compressor, it is recommended
that a 50%-75% average duty
cycle be maintained; that is, the air
compressor pump should not run
more than 30-45 minutes in any given
hour.
9+ ENG A09706

Contents of Carton
1 - Air Compressor
2- Wheels
2 - Shoulder Bolts, 3/8-16
2 - Hex Nuts, 3/8-16
2 - Molded Foot Bumpers
2 - Screws, 1/4 x 1.50
1- Handle
1 - Handle Grip
2 - Screws, #10-16 x 1.00
Tools Required for
1 - 9/16" socket or open end
wrench
1 - 3/8" socket
installing Handles,
Wheels, and Molded Foot
The wheems
and handme do
not provide adequate cmearance,
stability or support for pulling the
unit up and down stairs or steps,
The unit must be lifted, or pushed
up a ramp.
1. Submerge handle grip into warm
soapy water to make installation
easier. Remove handle grip from
soapy water and slide onto
handle.
2. Slide handle through holes in
compressor saddle onto tabs.
Secure with screws, one on each
side.
Compressor Saddme
HandRe Screw
It wHmbe necessary
to brace or
support one side of the unit when
installing the wheems because the
compressor will have a tendency
to tip,
3. InstalI one shoulder bolt
and one nut for each wheel.
Tighten securely. The outfit
wilI sit leve! if the wheels are
properly installed.
Wheel
4. Clean and dry underside of
air tank Ieg opposite wheels.
Remove the protective strip from
the adhesive backed molded
foot bumpers. Attach the foot
bumpers to the bottom of Ieg
on each end. Press firmly into
place.
Molded Foot
A09706 10-ENG

HOW TO SET UP YOUR UNIT IMPORTANT: The outlet being used
Location of the Air Compressor
Locate the air compressor in a
clean, dry and we[! ventilated area.
The air compressor should be
located at least 12" away from the
wall or other obstructions that will
interfere with the flow of air. The
air compressor pump and shroud
are designed to allow for proper
cooling. The ventilation openings
on the compressor are necessary
to maintain proper operating
temperature. Do not place rags or
other containers on or near these
openings.
GROUNDING INSTRUCTIONS
SHOCK, in the event of a short
circuit, grounding reduces the risk
of shock by providing an escape
wire for the electric current, This
air compressor must be propermy
grounded,
The portable air compressor is
equipped with a cord having a
grounding wire with an appropriate
grounding plug (see following
illustrations). The plug must be used
with an outlet that has been installed
and grounded in accordance with all
local codes and ordinances.
1. The cord set and plug with this
unit contains a grounding pin.
This plug MUST be used with a
grounded outlet.
must be installed and grounded in
accordance with all local codes and
ordinances.
Make sure the outlet being used
has the same configuration
as the grounded plug. DO
NOT USE AN ADAPTER, See
illustration.
Ground/di/TingPin
Inspect the p!ug and cord before
each use. Do not use if there are
signs of damage.
If these grounding instructions
are not completely understood,
or if in doubt as to whether
the compressor is properly
grounded, have the installation
checked by a qualified
electrician.
SHOCK, IMPROPER GROUNDING
CAN RESULT IN ELECTRICAL
SHOCK,
Do not modify the plug provided, If
it does not fit the available outlet,
a correct outmet should be installed
by a qualified electrician,
Repairs to the cord set or plug
MUST be made by a qualified
electrician,
11-ENG A09706

Extension Cords
Using extension cords is not
recommended. The use of extension
cords will cause voltage to drop
resulting in power loss to the motor
and overheating.
instead of using an extension cord,
increase the working reach of the
air hose by attaching another length
of hose to its end. Attach additional
lengths of hose as needed.
if an extension cord must be used,
be sure it is:
a 3-wire extension cord that has
a 3-blade grounding plug, and a
3-slot receptacle that will accept
the ptug on the product
in good condition
no longer than 50 feet
12 gauge (AWG) or larger. (Wire
size increases as gauge number
decreases. 10 AWG and 8 AWG
may also be used. DO NOT USE
14 OR 16 AWG.)
Voltage and Circuit Protection
Refer to the specification chart for the
voltage and minimum branch circuit
requirements.
air compressors can be operated
on a 15 amp circuit if the following
conditions are met,
1. Voltage suppIy to circuit must
comply with the National
Electrical Code.
2. Circuit is not used to supply any
other electrica! needs.
3. Extension cords comply with
specifications.
4. Circuit is equipped with a
15 amp circuit breaker or 15
amp time delay fuse. NOTE: If
compressor is connected to a
circuit protected by fuses, use
only time delay fuses. Time delay
fuses should be marked "D" in
Canada and "T" in the US.
If any of the above conditions
cannot be met, or if operation of
the compressor repeatedly causes
interruption of the power, it may be
necessary to operate it from a 20
amp circuit. It is not necessary to
change the cord set.
A09706 12-ENG

Know *four Air Compressor
READ THiS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING
YOUR UNIT. Compare the illustrations with your unit to familiarize yourself with
the Iocation of various controls and adjustments. Save this manual for future
reference.
On/Auto/Off Pressure
Switch
Safety Valve
Out(et
Pressure Gauge
Description of Operation
Become famiIiar with these controls
before operating the unit.
On/Auto/Off Switch: Turn this switch
"On/Auto" to provide automatic
power to the pressure switch and
"Off" to remove power at the end of
each use.
Pressure Switch: The pressure
switch automaticaily starts the
motor when the air tank pressure
drops below the factory set "cut-in"
pressure, it stops the motor when the
air tank pressure reaches the factory
set "cut-out" pressure.
Safety Vamve: if the pressure switch
does not shut off the air compressor
at its "cut-out" pressure setting, the
safety valve wiII protect against high
pressure by "popping out" at its
factory set pressure (slightly higher
than the pressure switch "cut-out"
setting).
Outlet Pressure Gauge: The outlet
pressure gauge indicates the air
pressure available at the outtet side
of the regulator. This pressure is
controlIed by the reguIator and is
always less than or equal to the tank
pressure.
Tank Pressure Gauge: The tank
pressure gauge indicates the reserve
air pressure in the tank.
Regulator: Controls the air pressure
shown on the outlet pressure
gauge. PuII the knob out and turn
clockwise to increase pressure
and counterc!ockwise to decrease
pressure. When the desired pressure
is reached push knob in to lock in
place.
UniversaB Quick-Connect Body:
The universa! quick-connect body
accepts the three most popular styles
of quick-connect plugs- industrial,
automotive (Tru-fiate), and ARC. One
hand push-to-connect operation
makes connections simple and easy.
13-ENG A09706

Brain Valve: The drain valve is
located at the base of the air tank
and is used to drain condensation at
the end of each use.
Oooling System (not shown}: This
compressor contains an advanced
design cooling system. At the heart of
this cooling system is an engineered
fan. It is perfectly normal for this fan
to blow air through the vent holes
in large amounts. You know that the
cooling system is working when air is
being expelled.
Air Oompressor Pump (not shown):
Compresses air into the air tank,
Working air is not available until the
compressor has raised the air tank
pressure above that required at the
air outlet.
Oheck Vamve: When the air
compressor is operating, the check
valve is "open", allowing compressed
air to enter the air tank. When the
air compressor reaches "cut-out"
pressure, the check valve "closes",
allowing air pressure to remain inside
the air tank.
How to Use Your Unit
Bow to Stop:
1. Set the On/Auto/Off lever to
"Off"a
Break-in Procedure
Risk of Unsafe
Operation, Serious
damage may result if the following
breakqn instructions are not
cmosemyfollowed°
This procedure is required before the
air compressor is put into service and
when the check valve or a complete
compressor pump has been replaced.
1. Make sure the On/Auto/Off lever
is in the "Off" position.
NOTE: Pull coupler back until it clicks
to prevent air from escaping through
the quick connect.
2. Plug the power cord into the
correct branch circuit receptacle.
(Refer to "Voltage and Circuit
Protection" paragraph in the
"Installation" section of this
manua!.)
3. Open the drain valve fully
(counter-clockwise) to permit
air to escape and prevent air
pressure build up in the air tank
during the break-in period.
4. Move the On/Auto/Off lever
to "On/Auto" position. The
compressor will start.
5. Run the compressor for 15
minutes. Make sure the drain
valve is open and there is
minimal air pressure build-up in
tank.
6. After 15 minutes, close the drain
valve (clockwise). The air receiver
wil! filI to "cut-out" pressure and
the motor will stop.
The compressor is now ready for use.
A09706 14-ENG

Before Each Start-Up:
1. Place On/Auto/Off lever to "Off"
and close air regulator.
2. Pu!I regulator knob out, turn
counterclockwise until it stops,
Push knob in to lock in place,
3. Attach hose and accessories,
NOTE: The hose or accessory
wilI require a quick connect plug
if the air outlet is equipped with a
quick connect socket,
Risk of Bursting,
Too much air
pressure causes a hazardous
risk of bursting, Check the
manufacturer's maximum pressure
rating for air tooms and accessories,
The regumator outlet pressure
must never exceed the maximum
pressure rating,
Bow to Start:
1. Turn the On/Auto/Off lever
to "On/Auto" and allow tank
pressure to build. Motor will
stop when tank pressure reaches
"cut-out" pressure.
2. PulI the regulator knob out
and turn clockwise to increase
pressure. When the desired
pressure is reached push knob in
to Iock in place.
The compressor is ready for use.
15-ENG A09706

Customer Responsibilities
3heck Safety Valve
Drain Tank
Before
each
Jse
@
Daily
or after
each
use
O
cycles automatically when power
is on. When servicing, you may
be exposed to voltage sources,
compressed air, or moving parts.
Before servicing unit unpBug or
disconnect emectricaB suppmy to the
air compressor, b_eed tank of pres-
sure, and allow the air compressor
to cool
NOTE: See "Operation" section for
the location of controls.
To Check Safety Valve
To Drain Tank
1. Set the On/Auto/Off lever to "Off"
and unplug unit.
2. Pull the regulator knob out and
turn counterclockwise to set the
outlet pressure to zero.
3. Remove the air toot or accessory.
4. Pull ring on safety valve allowing
air to bleed from the tank until
tank pressure is approximately
20 psi. Release safety valve ring.
5. Drain water from air tank by
opening drain valve (counter-
clockwise) on bottom of tank.
does not work properly, over_
pressurization may occur, causing
air tank rupture or an expBosion.
1. Before starting compressor, putl
the ring on the safety vane to
make sure that the safety valve
operates freely. If the valve
is stuck or does not operate
smoothly, it must be repiaced
with the same type of vane.
condense in the air tank. mfnot
drained, water will corrode and
weaken the air tank causing a risk
of air tank rupture.
6. After the water has been drained,
close the drain vane (clockwise).
The air compressor can now be
stored.
NOTE: If drain valve is plugged,
release alI air pressure. The valve
can then be removed, cleaned, the
reinstalled.
A09706 16-ENG

ALL MAINTENANCE AND REPAIR
OPERATIONS NOT LISTED MUST
BE PERFORMED BY TRAINED
SERVICE TECHNICIAN,
cycles automaBcaHy when power
is on, When servicing, you may
be exposed to voltage sources,
compressed air, or moving parts,
Before servicing unit unplug or
disconnect emectricaB supply to the
air compressor, b_eed tank of pres-
sure, and allow the air compressor
to cool
To Replace or Clean Check
Valve
1. Release all air )ressure from air
tank. See "To Drain Tank" in the
"Maintenance" section.
2. Set the On/Auto/Off lever to "Off"
and unplug unit.
3. Loosen the nut on the outlet tube
and move the outlet tube to the
side.
4.
5.
Unscrew the check valve (turn
counterclockwise) using a socket
wrench.
Using a screwdriver, carefully
push the valve disc up and
down. NOTE: The valve disc
should move freely up and down
on a spring which holds the valve
disc in the closed position; if
not the check valve needs to be
cleaned or replaced.
position
nothing is
visible.
mnclosed position
disc is visible.
6. Apply sealant to the check valve
threads. Reinstall the check valve
(turn clockwise).
7. Replace the outlet tube and
tighten the nut.
8. Perform the Break-in Procedure.
See "Break-in Procedure" in the
"Operation" section.
17-ENG A09706

To Replace Regulator
1. Release all air pressure from air
tank. See "To Drain Tank" in the
"Maintenance" section.
2. Reiease all air pressure from air
tank. See "To Drain Tank" in the
"Maintenance" section.
3. Using an adjustable wrench
remove the gauges and quick
connect from the regulator.
4. Remove the regulator.
5. Apply pipe sealant tape to the
nipple on the standpipe.
6. Assemble the regulator and
orient as shown.
NOTE: Arrow indicates flow of
air. Make sure it is pointing in the
direction of air flow.
7.
8.
Reappiy pipe sealant to gauges
and quick connect.
Reassemble gauges and quick
connect. Orient gauges to read
correctly. Tighten quick connect
with wrench.
Before you store the air compressor,
make sure you do the following:
1. Review the "Maintenance"
section on the preceding
pages and perform scheduled
maintenance as necessary.
2. Set the On/Auto/Off lever to "Off"
and unplug unit.
3. Turn the regulator
counterclockwise and set the
outlet pressure to zero.
4. Remove the air tooi or accessory.
5. Puff ring on safety valve alIowing
air to bteed from the tank untiI
tank pressure is approximately
20 psi. Release safety valve ring.
6. Drain water from air tank by
opening drain valve on bottom of
tank.
Risk of Bursting,
Water will
condense in the air tank, if not
drained, water will corrode and
weaken the air tank causing a risk
of air tank rupture,
7. After the water has been drained,
close the drain or drain valve.
NOTE: if drain valve is plugged,
release a!l air pressure. The valve
can then be removed, cieaned, then
reinstalled.
8. Protect the eiectrica! cord and
air hose from damage (such as
being stepped on or run over).
Wind them loosely around
the compressor handle. (if so
equipped).
9. Store the air compressor in a
clean and dry location.
A09706 18-ENG

iiiiii e iii,
_Risk of Unsafe Operation, Unit cyctes automatically when
power is on, When servicing, you may be exposed to
voBtage sources, compressed air, or moving parts, Before servicing unit
unplug or disconnect electrical supply to the air compressor, bmeedtank of
pressure, and allow the air compressor to cool,
PROBLEM
Excessive tank
pressure - safety
valve pops off,
Air leaks at
fittings,
Air leaks in air
tank or at air
tank welds=
Air leaks
between head
and valve plate,
Air leak from
safety vane,
CAUSE
Pressure switch does
not shut off motor when
compressor reaches "cut-
out" pressure=
Pressure switch "cut-out"
too high,
Tube fittings are not tight
enough,
Defective air tank,
Leaking seal
Possible defect in safety
valve,
Possible defect in safety
valve,
Knocking Noise=
CORRECTION
Move On/Auto/Off lever to
the "Off" position, if the
outfit does not shut off
contact a Trained Service
Technician=
Contact a Trained Service
Technician,
Tighten fittings where air
can be heard escaping,
Check fittings with soapy
water solution= Do Not
_hten,
Air tank must be replaced=
Do not repair the leak=
Risk of
Bursting,
Do not drill into, weld or
otherwise modify air tank
or it will weaken, The tank
can rupture or expmode,
Contact a Trained Service
Technician,
Operate safety valve
manually by pulling on ring.
If valve still leaks, it should
be replaced=
Operate safety vane
manualIy by pulling on ring=
If valve still leaks, it should
be replaced=
19= ENG A09706

PROBLEM
Pressure reading
on the regulated
pressure gauge
drops when an
accessory is
used.
Compressor is
not supplying
enough air
to operate
accessories.
Regulator knob
has continuous
air leak.
Regulator will
not shut off air
outlet.
CAUSE
it is normaJ for "some"
Dressure drop to occur
Prolonged excessive use of
air.
Compressor is not large
enough for air requirement.
Hole in hose.
Check valve restricted.
Air leaks.
Damaged regulator.
Damaged regulator.
CORRECTION
if there is an excessive
amount of pressure drop
when the accessory is used,
adjust the regulator following
the instructions in the
"Description of Operation"
paragraph in the "Operation"
section.
NOTE: Adjust the regulated
)ressure under flow
conditions (while accessory is
Decrease amount of air
usage.
Check the accessory
air requirement, if it is
higher than the SCFM or
)ressure supplied by your
air compressor, you need a
larger compressor.
Check and replace if
required.
Remove and cban, or
replace.
Tighten fittings.
Replace.
Replace.
A09706 20-ENG
