Craftsman 24597 User manual

1
Front Bumper
Part No. 24597
INSTALLATION
1. Attach bumper (A, Figure 2) to frame (B) securing
with 5/16-18 x 7/8 capscrews (C) and 5/16-18 flange
lock nuts (D).
Figure 1. Contents
Figure 2. Bumper Installation (Footrest and Spindles
Ghosted for Clarity)
A. Bumper
B. Frame
C. Capscrews, 5/16-18 x 7/8
D. Nut, Flange Lock, 5/16-18
Kit Contents:
Ref Part No. Qty. Description
1 1727006 1 Bumper Assembly
2 1927557 4 Nut, Flange Lock, 5/16-18
3 1923325 4 Capscrew, Hex, 5/16-18 x 7/8
A
1
Before beginning any service work turn off the
PTO, set the parking brake, turn off the ignition,
remove the key, and disconnect the spark plug
wire(s).
WARNING
3
2
Installation Instructions
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
Visit our Craftsman website: www.sears.com/craftsman TP 200-4056-04-AT-C
1726916-04
C
C
D
D
B
Note: Lift front of bumper up while tightening hardware to
prevent wheels from contacting bumper.
For ZTS 7500 or ZT 7000
(Items 27768, 27770, 27772 or 27774)
