Owner's Manual
1/3-Sheet
Pad Sander
Model No.
172.11625
CAUTION: Read, understand and follow
all Safety Rules and Operating Instructions
in this manual before using th=s product.
,SAFETY
,OPERATION
,MAINTENANCE
,ESPA_OL
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.

Warranty. .................................................... Page 2
Safety Instructions ..................................... Pages 3-8
Safety Symbols .......................................... Page 8
Description ................................................. Pages 9-10
Assembly. ................................................... Pages 10-14
Operation ................................................... Pages 15-18
Maintenance .............................................. .Pages 18-19
Accessories ................................................ Page 19
Repair Parts & Phone Numbers ................. Pages 20-22
FULL ONE YEAR WARRANTY ON CRAFTSMAN
1/3-SHEET PAD SANDER
If this CRAFTSMAN 1/3-Sheet Pad Sander fails to give complete
satisfaction within one year from the date of purchase, RETURN IT TO
THE NEAREST SEARS STORE INTHE UNITED STATES, and Sears
will replace it, free of charge.
If this CRAFTSMAN lt3-Sheet Pad Sander is used for commercial
or rental purposes, this warranty applies for only 90 days from the date
of purchase.
This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
Sears, Roebuck and Co., Dept. 817 WA, Hoffman Estates, IL 60179
SAVE THESE INSTRUCTIONS]
READ ALL INSTRUCTIONS!

IZ_ WARNING: BE SURE to read and understand all instructions, I
Failure to follow all instructions listed below may result in electric I
shock, fire and/or serious personal injury.
WORK AREA SAFETY
1. ALWAYS keep your work area clean and well lit. Cluttered benches and
dark areas invite accidents.
2. DO NOT operate power tools tn explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
3. ALWAYS keep bystanders, children, and visitors away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
1. Double insulated tools are equipped with a polarized plug (one blade
is wider than the other.) This plug will fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician to install a polarized outlet.
DO NOT change the plug in any way.
2. Double insulation [] eliminates the need for the three wire grounded power
cord and grounded power supply system. Applicable only to Class II
(double insulated) tools.
3. Before plugging in the tool, BE SURE that the outlet voltage supplied is
within the voltage marked on the tool's data plate. DO NOT use "AC only"
rated tools with a DC power supply.
4. ALWAYS avoid body contact with grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock ifyour body is grounded.
5. If operating the power tool In damp locations is unavoidable, ALWAYS
use a Ground Fault Circuit Interrupter to supply power to your tool.
ALWAYS wear electrician's rubber gloves and footwear in
damp conditions.
6. DO NOT expose power tools to rain or wet conditions. Water entering
apower too! will increase the risk of electric shock.
7. DO NOT abuse the cord. NEVER use the cord to carry the tools or pull
the plug from the outlet. Keep cord away from heat, oil, sharp edges
or moving parts. Replace damaged cords immediately. Damaged cords
increase the risk of electric shook.
8. When operating a power tool outside, ALWAYS use an outdoor
extension cord marked "W-A" or "W'. These cords are rated for outdoor
use and reduce the risk of electric shook.

ELECTRICAL SAFETY cont.
NOTE: The extension cord must have adequate wire size AWG (American
Wire Gauge) for safe, efficient use, Smaller gauge wires have greater
capacity (16 gauge wire has more capacity than I8 gauge wire).
Minimum Gauge for Extention Cords (AWG)
Volts
120V
240v
Ampere Rating
More than 0
Not more than 6
More than 6
Not more than 10
More than 10
Not more than 12
More than 10
Not more than 16
Total Cord Length of Cord in Feet
0-25
0-5O
AWG
18
18
16
14
26 - 50
51 - 100
16
16
16
12
51 -100 101 -150
101-200 201-300
16 14
14 12
14 12
Not Recommended
PERSONAL SAFETY
1, ALWAYS stay alert, watch what you are doing and use common sense
when operating a power tool. DO NOT use tool while tired or under the
influence of drugs, alcohol or medication. Amoment of inattention while
operating power tools may result in serious personal injury.
2. ALWAYS dress properly. DO NOT wear loose clothing or jewelry, Pull
back long hair. Keep your hair, clothing and gloves away from moving
parts. Loose clothing, jewelry or long hair can be caught in moving parts.
3. ALWAYS avoid accidental starting. BE SURE switch is in the "Off"
position before plugging in. Carrying tools with your finger on the switch
or plugging in tools that have the switch in the "On" position invitesaccidents.
4. ALWAYS remove adjusting keys or wrenches before turning the tool
on. Awrench or akey that is left attached to a rotating part of the tool
may result in personal injury.
5. DO NOT overreach. ALWAYS keep proper footing and balance at all
times. Proper footing and balance enables better control of the too! in
unexpected situations.
6. ALWAYS use safety equipment. ALWAYS wear eye protection. Dust
mask, non-skid safety shoes, hard hat, or hearing protection must be used
for appropriate conditions
4

TOOL USE AND CARE SAFETY
1. ALWAYS use clamps or other practical ways to secure and support
the workpiece to a stable platform. Holding the work by hand or against
your body is unstable and may lead to loss of control.
2. DO NOT force the tool. Use the correct tool for your application. The
correct toolwill do the job better and safer at the rate for which itis designed.
3. DO NOT use the tool if the switch does not turn it "On" or "Off".
Any tool that cannot be controlled with the switch is dangerous and
must be repaired.
4. ALWAYS disconnect the plug from the power source before making
any adjustments, changing accessories or storing the tool. Such
preventive safety measures reduce the risk of starting the tool accidentally.
5, ALWAYS store idle tools out of the reach of children and other
untrained persons. Tools are dangerous in the hands of untrained users.
6. ALWAYS maintain tools with care, Keep cutting tools sharp and clean.
Properly maintained tools with sharp cutting edges are less likely to bind
and are easier to control
7. ALWAYS check for misalignment or binding of moving parts, breakage
of parts, and any other condition that may affect the tool's operation.
If damaged, have the tool serviced before using. Many accidents are
caused by poorly maintained tools.
IZ_WARNING: USE OF ACCESSORIES THAT ARE NOT RECOMMENDED I
I
FOR USE WITH THIS TOOL MAY CREATE A HAZARDOUS CONDITION, I
8. ALWAYS use only accessories that are recommended for this tool,
Accessories that may be suitable for one tool can become hazardous
when used on another tool.
SERVICE SAFETY
1. Tool service MUST BE performed only by Sears or other qualified
repair personnel. Service or maintenance performed by unqualified
personnel could result in a risk of injury.
2.When servicing a tool, ALWAYS use only Identical replacement parts.
Follow instructions in the Maintenance Section of this manual.
Use of unauthorized parts or failure to follow Maintenance Instructions may
create a risk of electric shock or injury.
5

SAFETY RULES FOR SANDERS
1. NEVER use this or any power sander for wet sanding or liquid
polishing. Failure to follow this rule will increase the risk of electrical shock
ADDITIONAL RULES FOR SAFE OPERATION
Z_WARNING: BE SURE to read and understand all instructions.
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious personal injury.
1. Know your power tool. Read operator's manual carefully. Learn the
applications and limitations, as well as the specific potential hazards I
related to this tool. Following this rule will reduce the risk of electric shock,
fire or serious injury,
2. ALWAYS wear safety glasses or eye shields when using this sander.
Everyday eyeglasses have only impact-resistant lenses; they are
NOT safety glasses. Following this rule will reduce the risk of serious
personal injury.
3. ALWAYS protect your lungs.Wear a face mask or dust mask if the
operation is dusty. Following this rule will reduce the risk of serious
personal injury.
4. ALWAYS protect your hearing, Wear hearing protection during
extended periods of operation. Following this rule will reduce the
risk of serious personal injury.
5. ALWAYS inspect the tool cords periodically and if damaged have them
repaired at your nearest Sears Service Center or other qualified
Service Facility. ALWAYS be aware of the cord location. Following
this rule will reduce the risk of electric shock or fire.
6. ALWAYS check for damaged parts. Before further use of the tool, a
guard or other part that is damaged should be carefully checked to
determine if it will operate properly and perform its intended function.
Check for misalignment or binding of moving parts, breakage of parts,
and any other condition that may affect the tool's operation. A guard
or other part that Is damaged, should be properly repaired or replaced
at an qualified Service Center. Following this rule will reduce the risk of
electric shock, fire or serious injury.
7. DO NOT abuse the cord. NEVER use the cord to carry the tools or pull
the plug from the outlet. Keep cord away from heat, oil, sharp edges or
moving parts. Replace damaged cords immediately. Damaged cords
increase the risk of electric shock. Following this rule will reduce the risk of
electric shock or fire.
6

ADDITIONAL RULES FOR SAFE OPERATION CONT.
8. ALWAYS make sure that your extension cord is in good condition.
When using an extension cord be sure to use one that is heavy enough
to carry the current that your tool will draw. A wire gauge size (A.W.G,)
of at least 16 is recommended for an extension 100 feet or less in
length, Using an extension cord that is over 100 feet in length is not
recommended, If in doubt, use the next heavier gauge. Smaller gauge
wires, have greater capacity (16 gauge wire has more capacity than
18 gauge wire), An undersized cord will cause a drop in line voltage,
resulting in loss of power and overheating.
9, ALWAYS inspect and remove all nails from lumber before sanding.
Following this rule will reduce the risk of serious personal injury.
10. DO NOT use the tool while tired or under the influence of drugs,
alcohol or any medication. Following this rule will reduce the risk of
electric shock, fire or serious personal injury.
11. SAVE THESE INSTRUCTIONS. Refer to them frequently and use them
to instruct others who may use this tool. If someone borrows this tool,
make sure they have these instructions also.
Z_WARNING: Some dust particles created by power sanding,
sawing, grinding, drilling and other construction jobs contain
chemicals known to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints.
•Crystalline silica from bricks and cement and other masonry products.
•Arsenic and chromium from chemically treated lumber.
Your risk from these exposures varies, depending upon how often you do
this type of work. To reduce your exposure to these chemicals:
• Work in a well-ventilated area.
• Work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.

ADDITIONAL RULES FOR SAFE OPERATION CONT.
Z_ WARNING: The operation of any sander can
result in foreign objects being thrown into your eyes,
which can result in severe eye damage. Before
beginning power tool operation, ALWAYS wear
safety goggles or safety glasses with side shield
and a full face shield when needed, We recommend
a Wide Vision Safety Mask for use over eyeglasses
or standard safety glasses with side shield, available
at Sears Retail Stores.
The label of your tool may include the following symbols:
V........................................................... Volts
A ........................................................... Amps
Hz ......................................................... Hertz
W.......................................................... Watts
rain ....................................................... Minutes
....................................................... Alternating current
........................................................ .Direct current
Hz ......................................................... Frequency
no ........................................................ .No-load speed
[] ......................................................... Class II Construction
,.Jmln ................................................... Revolutions or Strokes per minute
OPM ...................................................... Obits Per Minute
,_ ......................................................... Indicates Danger, Warning or
Caution. It means attention!
Your safety is involved.
IMPORTANT! READ ALL INSTRUCTIONSI
8

Before attempting to use any tool, be sure to familiarize yourself with
an the operating features and safety instructions.
Z_ WARNING: IF ANY PARTS ARE MISSING, DO NOT OPERATE
YOUR SANDER UNTIL THE MISSING PARTS ARE REPLACED.
FAILURE TO FOLLOW THIS RULE COULD RESULT IN SERIOUS
PERSONAL INJURY.
Z_ WARNING: DO NOT let familiarity with your sander make you
careless. Remember that acareless fraction of a second is sufficient
to cause severe injury.
KNOWYOUR SANDER (SEE FIG.l)
This sander is ideal for sanding with fine, medium and coarse grit sand paper.
It will give you a fine, scratch-free finish when you use itto sand with the grain
on all wood surfaces. It can also be used to sand flush to corners.
Trigger Switch
The sander trigger switch is located under the rear handle. To turn the sander
"ON", simply squeeze the trigger switch.To turn the sander "OFF", release the
trigger switch. This sander also has a Lock-On Button on the side of the rear
handle for continuous sanding operations. To activate the Lock-On feature,
simply squeeze the trigger switch to turn sander "ON" and push in the
Lock-On Button. To deactivate lock-on feature, simply release trigger switch.
Dust Collection
Your sander includes adust bag assembly that is designed to help remove
accumulated dust from the sanding area.
g

Electrical Connection
Your sander has a precision-buiR electric motor and it should only be
connected to a 120-volt, 60-Hz. power supply (normal household current).
DO NOT operate on direct current (DC). This large voltage drop will cause a
loss of power that will overheat the motor. Ifyour sander does not operate
when plugged into an outlet, check the power supply.
No-load Speed
Rating
Input
Orbit Diameter
Paper Size
Paper Type
11,000 OPM (Orbits Per Minute)
120 Volts, 60 Hz AC
1.5 Amps
1/16 in.
1/3 Sheet
Non-Adhesive Sandpaper & Adhesive Sandpaper
Z_ WARNING: Your sander should NEVER be connected tothe
power source when you are assembling parts, making adjustments,
installing or removing sandpaper, cleaning or when it is not in use.
Disconnecting the sander will prevent accidental starting, that could
cause serious personal injury.
INSTALLING THE SANDPAPER (See Figs. 2 & 3)
This sander has a cushion that allows you to use: either non-adhesive
sandpaper, pressure-sensitive sandpaper or adhesive-backed sandpaper.
The non-adhesive sandpaper clamps to the platen. Adhesive-backed
sandpaper sticks to the cushion.
NOTE: This sander has dust collection, so we recommend that you use
sandpaper with pre-punched holes that will line up with the holes in the cushion.
Installing Non-Adhesive Sandpaper (See Fig, 2 on next page)
ALWAYS inspect the sandpaper before installing. DO NOT use
if broken or defective.
1. Unplug the sander.
IZ_ WARNING: Failure to unplug the sander could result in accidental
starting causing possible serious personal injury. I
10

Installing Non-Adhesive Sandpaper cont. (see Fig.2)
2. Remove dust bag assembly,
3. If replacing sandpaper, remove old sandpaper.
4. To remove old sandpaper, raise the levers on each side of the sander
to release the paper clamps holding the sandpaper. Then remove old sandpaper.
5. Insert the end of the new sandpaper approximately 1/2-inch
under the front paper clamp,
6. Lift up the lever on the left side of the sander and lock it into the slot on the
platen. Apply downward pressure to tighten sandpaper to the platen.
7. Wrap remaining sandpaper around the cushion and insert the loose end of
the sandpaper under the rear paper clamp. Fit the sandpaper against the
cushion as tightly as possible.
8. Lift up the lever on the right side of the sander and lock it into
the slot on the platen.
9. Replace the dust bag assembly.
Installing Adhesive-Backed Sandpaper (See Fig. 3 on next page)
ALWAYS inspect the sandpaper before installing. DO NOT use
ifbroken or defective.
1, Unplugthe sander.
IZ_ WARNING: Failure to unplug the sander could result in accidental
starting causing possible serious personal injury.
2, If replacing adhesive-backed sandpaper, remove old sandpaper by peeling
it off the cushion.
3. If replacing non-adhesive sandpaper, release paper clamp by lifting up on
each lever.Then remove sandpaper.
I
11

Installing Adhesive-Backed Sandpaper cont. (See Fig. 3)
4, Place levers back in locked position (see Steps 6 and 8 on Installing
Non-Adhesive Sandpaper).
NOTE: ALWAYS be sure that both levers are in the locked position before
starting sander.
5. CAREFULLY peel adhesive backing from the new 1/3-sheet sandpaper,
6. Place sandpaper in position. ALWAYS make sure that the front edge of
the sandpaper is carefully aligned with the front edge of the cushion.
Then carefully press the sticky side of the sandpaper onto the cushion.
NOTE: The sandpaper MUST be aligned with the front edge of the cushion
in order for the sander to properly function when flush sanding.
NOTE: We recommend that you clean the cushion occasionally by brushing
it gently with a small brush. Dust build-up on the cushion will cause the
sandpaper to not stick properly,
ATTACHING DUST BAG ASSEMBLY (See Fig. 4)
I _ WARNING: To prevent the possibility of sanding dust or other
foreign objects being thrown into your face or eyes NEVER try to
operate your sander without the dust bag assembly properly installed.
Sanding dust or foreign objects thrown into your face or eyes could result
in serious personal injury.
1. Unplug the sander.
IZ_ WARNING: Failure to unplug the sander could result in accidental
starting causing possible serious personal injury. I
12

ATTACHING DUST BAG ASSEMBLY cont. (See Fig. 4)
2. Insert dust bag adapter into dust exhaust hole (see Fig. 4).
3. Push in adapter until the raised edges on the top and bottom of the adapter
snap into the grooves in the dust exhaust hole.
4. Your sander is now ready to use.
NOTE: For more efficient operation, we recommend that you empty the dust
bag when it is no more than half full. This will allow the air to flow through the
bag better. ALWAYS empty and clean the dust bag thoroughly when you've
finished sanding and before you store the sander.
Fig 4_
......
TO REMOVE AND EMPTY DUST BAG (See Fig. 5)
1. Unplug the sander.
I Z_ WARNING: Failure to unplug the sander could result in accidental
starting causing possible serious personal injury.
2. Remove dust bag assembly from sander by firmly holding the adapter
and pulling straight out.
3. Remove dust bag from adapter (see Fig. 5).
4. Shake dust bag to empty.
5. Place dust bag back onto the adapter.
6. Attach dust bag assembly back onto sander,
I
13

ATTACHING THE VACUUM HOSE ADAPTER (See Fig, 6)
Your sander includes a vacuum hose adapter that easily attaches to the
sander. The adapter allows you to hook your sander up to your shop vac
(sold separately),
I. Unplug the sander.
I/_ WARNING: Failure to unplug the sander could result in accidental Istarting causing possible serious personal injury.
2. Remove dust bag assembly from the sander by firmly holding the adapter
and pulling it straight out.
3. Insert vacuum hose adapter into the dust exhaust hole.
4. Push in adapter until the raised edges on the top and bottom of the
adapter snap into the grooves in the dust exhaust hole.
5. Firmly attach the vacuum hose adapter to your vacuum hose.
6. Attach vacuum hose to vac.
Fig 6
Dust Exhaust Hole
""" acuum
e Adapter
14

Z_ WARNING: ALWAYS wear safety goggles
or safety glasses with side shield and a full face
shield when operating your sander. Failure to do so
could result in foreign objects being thrown into your
eyes, resulting in possible serious injury.If the sanding
operation is dusty, also wear a face or dust mask.
APPLICATIONS
Only use your sander for the applications listed below.
1, Sanding wood surfaces with various grits of sandpaper,
2. Removing rust from steel surfaces with special sandpaper.
Z_ CAUTION: ALWAYS be careful not to let your hand cover the
air vents.
i
1. ALWAYS clamp or otherwise secure the workpiece to prevent it from
moving under your sander.
I Z_ WARNING: Unsecured work could be thrown towards the
operator causing injury.
2. ALWAYS hold your sander in front and away from you, keeping it clear
of the workpiece.
3. Start the sander by squeezing the trigger switch and then let the motor
come up to maximum speed.
4. Gradually lower the sander onto the workpiece with a slight forward
movement. (See Fig. 7.)
5. Move it slowly, using forward and backward strokes.
I
t5

SANDING TIPS
1. DO NOT force the sander. The weight of the sander supplies adequate
pressure. Let the sander and the sandpaper do the work.
A. Applying additional pressure will only slow the motor, wear the
sandpaper out faster and reduce sander speed.
B. Excessive pressure will overload the motor and cause possible damage
to the sander from the motor overheating.
C. Excessive pressure will also result in inferior work.
2. Any existing finish or resin on wood may soften from the heat of the friction,
3. DO NOT sand in one spot for too long a time because the the sander's
rapid action may remove too much material and make the surface uneven.
SELECTING THE RIGHT SANDPAPER
NOTE:This sander has dust collection, so we recommend that you use
sandpaper with pre-punched holes that will line up with the holes in the cushion.
Selecting the correct grit and type of sandpaper is an extremely important
decision that will allow you to achieve the best quality sanding finish,
1. Aluminum oxide, silicon carbide and other synthetic abrasives are best for
power sanding.
2. Natural abrasives such as flint and garnet are too soft for economical
use in power sanding.
3. Coarse grit will remove the most material and finer grit will give you the
best finish in all sanding operations.
4. The condition of the surface to be sanded will determine which grit will
do the job.
5. If the surface is rough:
A, Start with a coarse grit and sand until the surface is uniform.
B, Then use medium to remove any scratches left by the coarse grit.
C. Then use a finer grit for finishing the surface.
NOTE: ALWAYS continue sanding with each grit until the surface is uniform,
NOTE: DO NOT use the sander without sandpaper.
This will damage the cushion.
IZ_ WARNING: DO NOT wear loose clothing or jewelry when operating I
sander, They could get caught in moving parts, causing serious injury. I
Keep head away from sander and sanding area. Hair could be drawn into
sander, causing serious injury.
16

ORBITAL MOTION (See Fig. 8)
As shown in Figure 8, the orbit of the sander is 1/16-inch in diameter so the
sandpaper moves in tiny circles at high speed.
This orbital action duplicates a "hand sanding" motion for more aggressive
sanding as you push the sander forward. This powerful orbital action is ideal
for heavy-duty sanding applications, such as:
1. Removing old finishes
2. Smoothing rough wood
3. Sanding stock down to required dimensions
4. Finishing surfaces that are to be painted
FLUSH SANDING (See Fig. 9)
Your sander will allow you to flush sand corners. You can use the front and
sides or your sander for flush sanding. DO NOT use the rear of the sander
for flush sanding.
ALWAYS remove the sander from the workpiece before turning it off.
17

REMOVE PRESSURE-SENSITIVE SANDPAPER BEFORE STORAGE
DO NOT store your sander with pressure-sensitive sandpaper still attached.
The heat generated by sanding causes the pressure-sensitive adhesive to
flow and form a tight bond between the cushion and the sandpaper.
ALWAYS remove the sandpaper soon after you have finished sanding to avoid
adhesive set up. When sandpaper is left on the cushion for an extended
period of time after use, the adhesive will set up and make the sandpaper
difficult to remove.
The sandpaper may tear when removing it. If this happens it makes itdifficult
to clean the cushion for the next piece of sandpaper,
NOTE: If you do forget to remove the sandpaper after sanding, run your
sander for a few minutes to soften the adhesive backing before you try
to remove the sandpaper
GENERAL
Z_, WARNIN G: To avoid accidents, ALWAYS disconnect the toolfrom
the power source BEFORE cleaning or performing any maintenance.
IZ_ WARNING: When servicing a tool, ALWAYS use only identical
replacement parts. Use of any other parts may create arisk of electric
shock or injury and cause product damage,
All parts represent an important part of the double insulation system and
should be serviced only at a Sears Service Center.
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible
to damage from various types of commercial solvents and may be damaged
by their use. Use clean cloths to remove dirt, carbon dust, etc.
Z_ WARNING: DO NOT at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc. to come in contact with plasticparts.
They contain chemicals that can damage, weaken or destroy plastic.
It is a known fact that electric tools are subject to accelerated wear and
possible premature failure when they are used to work on fiber glass boats
and sports cars, wallboard, spackling compounds or plaster. The chips and
grindings from these materials are highly abrasive to electrical tool parts,
such as bearings, brushes, commutators, etc. Consequently, it is not
recommended that this tool be used for extended work on any fiber glass
material, wallboard, spackling compound, or plaster. During any use on these
materials, it is extremely important that the tool is cleaned frequently by
blowing with an air jet.
I
18

EXTENSION CORDS
The use of any extension cord will cause some loss of power. To keep the
loss at a minimum and to prevent overheating, use an extension cord that is
heavy enough to carry the current that the tool will draw.
A wire gauge (AWG) of at least 16 is recommended for an extension cord
100 feet or less in length. When working outdoors ALWAYS use an extension
cord that is suitable for outdoor use. The cord's jacket will be marked WA.
Z_ CAUTION: Keep extension cords away from the cutting area, and
position the cord so it will not get caught on lumber, tools, etc. during the
cutting operation.
Z_ WARNING: Check extension cords before each use. If damaged,
replace it immediately. NEVER use a tool with a damaged cord because
touching the damaged area could cause electrical shock, resulting in
serious injury.
Extension cords that aresuitablefor usewith yoursander are availableat
'ournearest Sears Store.
WARNING: ALWAYS wear safety goggles or safety glasses with
side shields when using this tool or blowing dust, If operation is dusty,
also wear a dust mask,
LUBRICATION
All of the bearings in this tool are lubricated with a sufficient amount of
high-grade lubricant for the life of the tool under normal operating conditions.
Therefore, no further lubrication is required.
I
I
I
The following recommended accessories are currently available at your
local Sears Store.
NON-LOADING ALUMINUM OXIDE ADHESIVE BACKED
SANDING SHEETS ( 3213 in. x 7 tl8 in.)
Extra Fine, Fine, Medium, Coarse
ALUMINUM OXIDE SANDING SHEETS ( 3213 in, x 9 In.)
Fine, Medium, Coarse
IZ_ WARNING: The use of attachments or accessories that are
not recommended might be dangerous. I
t9

1/3 PAD SANDER- MODEL NUMBER 172.11625
The Model Number will be found on the Nameplate.
Always mention the Model Number when calling about your tool.
No. Part No. Description Quantity
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
SA16.0,00.4-00
STA50.04.02-00
SW50.01.0-00
ST05.03.02-00
STA51.04.00-00
SA16,0.01,2-00
SW50.10.0-00
SA16.2.05-00
SA16.0.04-00
SA16.0.03-00
SAt6.0,05-00
SA16.3.04-00
SW50.12.0-00
SA16,3.05-00
SW59.41.0-00
SA16.4.00-00
SW60.79.0-00
SW60.02.0-00
SW56.16.0-0
SW02.34-00
SA16.0.01.2-00
SW55.58.0-00
SW55.37.0-00
ST08.01.07-00
ST05.01.03-00
SW01.31.25-00
SA16.E04-00
SA16,F,06-00
PCB Assembly
Stator
Ball Bearing
Rubber Bar
Rotator
Left Housing
Ball Bearing
Fan
Foam Ring
Foot
Clamp
Sanding Pad
Ball Bearing
Balance Block
Nut
Gasket Assembly
Washer
Washer
Screw
Switch
Right Housing
Screw
Screw
Cord Clamp
Cord Protector
Plug & Cord
Dust Ba9 Support
Dust Bag
1
1
1
4
1
1
1
1
1
2
2
1
1
1
1
1
4
4
4
1
1
7
2
1
1
1
1
1
SEE BACK PAGE FOR PARTS ORDERING INSTRUCTIONS
20
