Craftsman 315.268192 Quick setup guide

CRAFTSMAN
4 X 24 in.
DOUBLE INSULATED
BELT SANDER
MODEL NO. 315.268192
REPAIR SHEET

CRAFTSMAN BELT SANDER – MODEL NUMBERS 315.268192
2
SEE NOTE
10
11
1
12
9
8
7
5
6
6
4
13
14
3
2
15

PARTS LIST
** Available From Div. 98 – Source 980.0
*** Complete assortment available at your Nearest Sears Retail Store
CRAFTSMAN BELT SANDER – MODEL NUMBERS 315.268192
3
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 940051014 Logo Label...........................................................................................................................................1
2 *** Sanding Belt........................................................................................................................................1
3 940045031 Data Label ...........................................................................................................................................1
4 300027071 Dust Bag..............................................................................................................................................1
5 301041001 Wear Plate ...........................................................................................................................................1
6 660327002 Screw (8-32 x 1/2 in. Pan Hd.) **STD510805......................................................................................5
7 590546001 Belt Cover............................................................................................................................................1
8 511973001 Belt ......................................................................................................................................................1
9 660106002 Lock Nut (8-32)....................................................................................................................................1
10 680335009 Washer (4.0 x 10.0 x .08).....................................................................................................................1
11 680335011 Washer (6.3 x 18.3 x 0.5).....................................................................................................................1
12 680335010 Washer (5.0 x 13.0 x 1.0).....................................................................................................................1
13 690725001 Compression Spring............................................................................................................................1
14 300898002 Tracking Knob Assembly.....................................................................................................................1
15 591624001 Vacuum Adaptor..................................................................................................................................1
987000065 Operator’s Manual
9-30-09
(REV:01)
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
BELT SANDER or when ordering repair parts.
NOTE : The assembly shown represents an important part of the double insulated system. To avoid the possibility of alteration or damage to the System,
service should be performed by your nearest Sears repair center. Contact your nearest Sears retail store for service center information.

234
6
6
15
6
7
13
12
14
1
20
19 23
25 26
31
32 618
1
17
42
43
41
40
44
45
39
37
36
34
35
33
15 16
18 21 22 46
17
24
47
2728 30
5
29
38
SECTION “A”
CRAFTSMAN BELT SANDER – MODEL NUMBERS 315.268192
4
8
1
9
10 11

KEY PART
NO. NUMBER DESCRIPTION QTY.
PARTS LIST FOR SECTION A
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
BELT SANDER or when ordering repair parts.
1 660327002 Screw (8-32 X 1/2 in. Pan Hd.) **STD510805......11
2 200273004 Gear Box Cover Assembly ....................................1
3 900729001 Seal........................................................................1
4 300897001 Rear Roller Shaft Assembly...................................1
5 660299005 Screw (M5 x 11 mm)..............................................4
6 6620803 Screw (M4 x 22 mm Pan Hd.)................................9
7 300764004 Main Housing Assembly ........................................1
8 690715002 Wear Strip ..............................................................1
9 660366001 Screw (M4 x 12.5 mm Flat Hd.) .............................2
10 6939601 Retaining Ring .......................................................1
11 632450004 Yoke w/Shaft (S45C)..............................................1
12 630438002 Spring Plate ...........................................................1
13 620233001 Front Roller Shaft...................................................1
14 300432006 Front Roller Assembly............................................1
15 590547007 Rotor Sit Cover ......................................................1
16 590539001 Fan Box Cover.......................................................1
17 200042012 Housing Assembly.................................................1
18 6620805 Screw (M4 x16 mm Pan Hd.).................................7
19 660013005 Shoulder Screw .....................................................1
20 590541001 Release Lever ........................................................1
21 512010001 Brush Holder Cap ..................................................2
22 301036001 Brush Assembly.....................................................2
23 690761001 Torsion Spring........................................................1
24 300998003 Armature Assembly................................................1
25 640755004 Glamor Plate..........................................................1
26 300777003 Rear Roller Assembly ............................................1
27 660299006 Screw (M5 x 44 mm Pan Hd.)................................2
28 6611303 Screw (M2.5 x 8 mm Pan Hd.)...............................1
29 550339001 Rubber Plug...........................................................1
30 660568001 T-8 Socket Set (M3.5 x 1.27) .................................2
31 660106004 Lock Nut (M10) ......................................................1
32 660299004 Screw (M5 x 18 mm)..............................................1
33 640585001 Driven Pulley..........................................................1
34 730356007 Power Cord............................................................1
35 610326001 Drive Pulley............................................................1
36 280013041 Circuit Board Assembly .........................................1
37 590274004 Bend Relief ............................................................1
38 400873003 Dial.........................................................................1
39 760314005 Switch....................................................................1
40 6627201 Screw (M4 x 14 mm Pan Hd.)................................2
41 5950101 Cord Clamp ...........................................................1
42 511184001 Dust Guide Plate....................................................1
43 660008003 Screw (M3 x 14 mm)..............................................2
44 690715003 Wear Strip Plate .....................................................1
45 660279003 Screw (M4 x 11 mm)..............................................2
46 301035001 Brush Holder..........................................................2
47 740524001 Field .......................................................................1
KEY PART
NO. NUMBER DESCRIPTION QTY.
** AVAILABLE FROM DIV. 98 – SOURCE 980.0
SECTION “A” REPRESENTS AN IMPORTANT PART OF THE DOUBLE INSULATED SYSTEM OF THIS TOOL. ANY REPAIR TO THIS TOOL REQUIRES
DIELECTRIC TESTING TO INSURE CUSTOMER SAFETY AND TO COMPLY WITH COMPANY REQUIREMENTS.
CRAFTSMAN BELT SANDER – MODEL NUMBERS 315.268192
5

WHITE
VARIABLE SPEED CB
SWITCH
BLACK
RED
WHITE
BLACK
BLUE
BLUE WHITE
BROWN
BLACK
WHITE
BLUE
SOFT START CB
CIRCUIT BOARD
CRAFTSMAN BELT SANDER – MODEL NUMBERS 315.268192
6
WIRING DIAGRAM
