Craftsman 486.24331 User manual

PRINTED IN U.S.A.
Owner's Manual
Model No. 486.24331
32" SPIKER SPREADER
FORM NO. 48070 (REV. 5/20/08)
®
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
www.sears.com/craftsman
CAUTION:
Before using this product, read
this manual and follow all Safety
Rules and Operating Instructions.
• Safety
• Assembly
• Operation
• Maintenance
• Parts
STOP
DO NOT RETURN TO STORE
For Missing Parts or Assembly
Questions Call 1-866-576-8388

2
TABLE OF CONTENTS
SAFETY RULES..........................................................3
FULL SIZE HARDWARE CHART................................ 4
CARTON CONTENTS................................................. 5
ASSEMBLY..................................................................5
OPERATION.............................................................. 12
MAINTENANCE ........................................................13
STORAGE .................................................................13
REPAIR PARTS ILLUSTRATION.............................. 14
REPAIR PARTS LIST.................................................15
PARTS ORDERING/SERVICE .....................Back Page
MODEL NUMBER: 486.24331
SERIAL NUMBER: __________________
DATE OF PURCHASE: __________________
The model number and serial numbers will be found on a
decal attached to the hitch tube.
You should record both the serial number and the date of
purchase and keep in a safe place for future reference.
WARRANTY
ONE YEAR FULL WARRANTY
When operated and maintained according to the instructions supplied with it, if this Spiker Spreader fails due to a defect in
material or workmanship within one year from the date of purchase, call 1-800-4-MY-HOME® to arrange for free repair (or
replacement if repair proves impossible).
If this product is used for commercial or rental purposes, this warranty applies for only 90 days from the date of purchase.
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
Sears, Roebuck and Co., D817WA, Hoffman Estates, IL 60179

3
SAFETY
Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment.
Exercise caution at all times, when using power equipment.
• Read this owner's manual before attempting to
assemble or operate the spiker/spreader.
• Read the towing vehicle owner's manual and know
how to operate the tractor before using the
spiker/spreader attachment.
• Do not allow anyone to ride on or sit on the
spiker/spreader.
• Never allow children to operate the tractor or
spiker/spreader attachment.
• Do not allow adults to operate the tractor or
spiker/spreader without proper instructions.
• Read the chemical label for instructions and
cautions for handling and applying chemicals.
• Wear eye and hand protection when handling and
using lawn chemicals.
• Always begin with the transmission in rst (low) gear
and gradually increase speed as conditions permit.
Maximum towing speed - 10 M.P.H.
• Do not drive too close to a creek or ditch and be alert
for holes and other hazards which could cause you to
loose control of the tractor and spiker/spreader.
• Before operating the vehicle on any grade (hill) refer
to the safety rules in the vehicle owner's manual
concerning safe operation on slopes. Stay off steep
slopes!
• Follow maintenance and lubrication instructions as
outlined in this manual.
Look for this symbol to point out important safety precautions.It means — Attention!! Become
alert!! Your safety is involved.

4
HARDWARE PACKAGE CONTENTS
ABC D E F
K
L
M
GH I
J
SHOWN FULL SIZE
O
P
Q
NOT SHOWN FULL SIZE
N
T
U
S
W
X
FF
DD
GG
BB
CC
EE
AA
Z
Y
HH
II
R
V
REF. QTY. DESCRIPTION
A 2 Hex Bolt, 1/2" x 4"
B 3 Hex Bolt, 5/16" x 2-1/4"
C 2 Hex Bolt, 5/16" x 2"
D 2 Hex Bolt, 5/16" x 1-3/4"
E 2 Hex Bolt, 5/16" x 1-1/2"
F 1 Hex Bolt, 5/16" x 1"
G 1 Hex Bolt, 1/4" x 1 1/4"
H 1 Hex Bolt, 1/4" x 3/4"
I 1 Carriage Bolt. 5/16" x 1-3/4"
J 2 Self-Tapping Screw
K 6 Nylock Hex Nut, 1/4"
L 10 Nylock Hex Nut, 5/16"
M 2 Jam Hex Nut, 1/2"
N 2 Nylock Jam Hex Nut, 1/2"
O 2 Flat Washer, 1/4"
P 2 Nylon Washer, 21/64"
Q 4 Flat Washer, 5/16"
R 4 Flat Washer, 1/2"
REF. QTY. DESCRIPTION
S 10 Flat Washer, 5/8"
T 3 Cotter Pin, 1/8" x 1-1/2"
U 1 Cotter Pin, 3/32" x 3/4"
V 1 Hair Cotter Pin, 1/8"
W 1 Chain with Connector
X 13 Flanged Bearing
Y 1 Compression Spring
Z 1 1/4" Thick Spacer
AA 2 Short Spacer Tube
BB 5 Long Spacer Tube
CC 1 Flow Control Link
DD 1 Ferrule
EE 1 Control Lever Grip
FF 1 Height Adjustment Grip
GG 1 Plastic Wing Nut
HH 1 Flat Head Hitch Pin, 3/8"
II 1 Flow Plate Spring

5
ASSEMBLY
CARTON CONTENTS
1. Chain Cover
2. Flow Control Lever
3. Center Brace
4. Hopper Assembly
5. Hitch Tube (2)
6. Lift Handle
7. Spike Disk (7)
8. Drive Disk Assembly (2)
9. Wheel (2)
10. Transport Tube Assembly
11. Hitch Bracket (2)
12. Spiker Shaft Assembly
1
23
8
12
10
9
4
6
7
5
11

6
FIGURE 1
HITCH TUBE
5/16" FLAT
WASHER
5/16" 1-1/2"
HEX BOLT
5/16" NYLOCK HEX NUT
• Assemble the grip onto the lift handle. See gure 2.
• On the right side, insert a 5/16" x 1-3/4" hex bolt
through a 5/16" at washer and then through the
rear hole in the hopper and the hitch tube. Assemble
the transport tube and then the lift handle onto the
bolt and secure with a 5/16" nylock hex nut. Do not
tighten yet. See gure 2.
• Assemble a 5/16" x 1" hex bolt and 5/16" nylock hex
nut to the bottom hole in the transport tube assembly
and the lift handle. Do not tighten yet. See gure 2.
5/16"FLAT
WASHER
5/16" x 1-3/4"
HEX BOLT
GRIP
LIFT
HANDLE
TRANSPORT TUBE
5/16" NYLOCK
HEX NUT
5/16" x 1"
HEX BOLT
FIGURE 2
FIGURE 3
5/16" x 1-3/4"
HEX BOLT
5/16"FLAT
WASHER 5/16" NYLOCK
HEX NUT
• On the left side, insert a 5/16" x 1-3/4" hex bolt
through a 5/16" at washer and then through the rear
hole in the hopper and the hitch tube. Assemble the
transport tube onto the bolt and secure it with a 5/16"
nylock hex nut. Do not tighten yet. See gure 3.
TOOLS REQUIRED FOR ASSEMBLY
(2) 7/16" Wrenches
(2) 1/2" Wrenches
(2) 3/4" or Adjustable Wrenches
(1) Screwdriver
(1) Pliers
• Remove all parts and hardware packages from the
carton. Lay out all parts and hardware and identify
using the illustrations on pages 3 and 4.
• Attach a hitch tube to the front hole in the right
hand side of the hopper using a 5/16" x 1-1/2" hex
bolt, a 5/16" at washer and a 5/16" nylock hex nut.
Assemble the bolt and washer from inside the hopper.
Do not tighten yet. See gure 1.
• Repeat on the left hand side of the hopper.

7
FIGURE 4
• Fasten the hitch tubes together using three 5/16" x
2-1/4" hex bolts and 5/16" nylock hex nuts. Do not
tighten yet. See gure 4.
FIGURE 5
5/16" x 2-1/4"
HEX BOLT (3)
5/16" NYLOCK
HEX NUT (3)
5/16" x 2"
HEX BOLT (2)
HITCH PIN
HAIR COTTER
PIN (1/8")
5/16" NYLOCK
HEX NUT (2)
• Assemble a 1/2" at washer, a wheel, another 1/2" at
washer and then a 1/2" jam nut onto a 1/2" x 4" hex
bolt. Tighten the nut nger tight and then back off 1/4
to 1/2 turn. See gure 6.
• Assemble the bolt and wheel to the transport tube
using a 1/2" nylock hex jam nut. Tighten the nut but
don't collapse the tube. See gure 6. FIGURE 7
FIGURE 6
1/2" HEX
JAM NUT
TRANSPORT
TUBE
1/2" x 4"
HEX BOLT
1/2" NYLOCK
HEX JAM NUT
1/2" FLAT
WASHER
• Screw a 1/4" nylock hex nut all the way onto the ow
control link. Assemble the ferrule onto the link and
then start a 1/4" nylock hex nut one or two turns onto
the link. See gure 7.
• Assemble the ferrule into the hole at the end of the
ow control lever using a 1/4" nylock hex nut. Tighten
the nut, leaving it loose enough that the ferrule can
pivot freely. See gure 7.
• Assemble the grip onto the end of the ow control
lever. See gure 7.
FLOW
CONTROL
LINK
FERRULE
GRIP
FLOW
CONTROL
LEVER
1/4" NYLOCK
HEX NUT
1/4" NYLOCK
HEX NUT
1/4" NYLOCK
HEX NUT
• Assemble the hitch brackets to the hitch tubes using
two 5/16" x 2" hex bolts and 5/16" nylock hex nuts. Do
not tighten. See gure 5.
• Assemble the hitch pin through the hitch brackets and
secure with the hair cotter pin. See gure 5.
IMPORTANT: Do not collapse the at ends of the hitch
tubes when tightening the bolts in the next step.
• Tighten, but do not overtighten the two 5/16" x
1-1/2" hex bolts assembled in gure 1.
Tighten, but do not overtighten the two 5/16" x
1-3/4" hex bolts assembled in gures 2 and 3. The lift
handle must be able to pivot.
Tighten the hex bolts assembled in gure 4 and 5.
• If the wheel does not spin freely, back off the nylock
jam nut and then the plain jam nut 1/4 to 1/2 turn each.
• Assemble a wheel to the other side. See gure 6.

8
FIGURE 9
FIGURE 8
• Insert the 5/16" x 1-3/4" carriage bolt up through the
slot and secure it with a nylon washer and the plastic
wing nut. See gure 9.
• Move the lift handle into the locked position as shown
in gure 9 and then tip the spreader back to rest on
the wheels and the rear of the hopper.
1/4" x 3/4"
HEX BOLT
1/4" FLAT
WASHER
CENTER
BRACE
1/4" x 1-1/4"
HEX BOLT
1/4" FLAT
WASHER
1/4" HEX
LOCK NUT
1/4" NYLOCK
HEX NUT
PLASTIC WING NUT NYLON
WASHER
5/16" x 1-3/4"
CARRIAGE BOLT
LOCKED POSITION
• Place the ow control lever into the slot in the hopper.
See gure 8.
• Place the center brace into the hopper. Insert the 1/4"
x 1-1/4" hex bolt through the center brace and the
front of the hopper. Assemble a 1/4" at washer, the
ow control lever and a 1/4" nylock hex nut onto the
bolt. Do not tighten yet. See gure 8.
• Insert the 1/4" x 3/4" hex bolt through the center
brace and the rear of the hopper. Assemble a 1/4" at
washer and 1/4" nylock hex nut onto the bolt. Tighten
both the front and rear bolts. See gure 8.
FIGURE 10
EXTENSION
SPRING
NYLON
WASHER
3/32" x 3/4"
COTTER PIN
FLOW
CONTROL
LEVER
FLOW CONTROL LINK
FEED PLATE
1/4" NYLOCK
HEX NUT
1/4" NYLOCK
HEX NUT
1/4" NYLOCK
HEX NUT
• Move the ow control lever as far as it will go to the
"OFF" position. Push the feed plate back as far as it
will go to the closed position. See gure 10.
• Place a nylon washer onto the bent end of the ow
control link and then insert the link into the feed plate
bracket. Secure it with a 3/32" x 3/4" cotter pin. See
gure 10.
• Tighten the lower 1/4" nylock hex nut until it touches
the bottom of the ferrule, then tighten the upper 1/4"
nylock hex nut until it is snug against the top of the
ferrule. See gure 10.
• Hook the open end of the spring into the feed plate.
Place the closed end of the spring onto the end of the
hex bolt in the ow control lever. Secure it with a 1/4"
nylock hex nut. See gure 10.
• Open and close the feed plate using the ow control
lever. Check to make sure the feed plate is closed
completely when the lever is in the "OFF" position.
If the feed plate does not close completely, adjust
the 1/4" nylock hex nuts on the ow control link. See
gure 10.

9
FIGURE 11
• Push two ange bearings into each of the drive disk
assemblies. See gure 11.
• Push a ange bearing into each of the seven drive
disks, from the side shown in gure 12.
FIGURE 12
• Press anged bearings into both of the end plates.
See gure 13.
• Place the 1/4" thick spacer onto the spike disk
shaft and then insert the shaft through the anged
bearing in the left hand end plate. See gure 13.
FIGURE 13
SPIKE DISK
LONG SPACER TUBE
• Place a short spacer tube, a drive disk, a 5/8" at
washer, another drive disk and a second 5/8" at
washer onto the shaft. Fit the short spacer tube onto
the anged bearing in the end plate. See gure 14.
FIGURE 14
FIGURE 15
IMPORTANT: When assembling the spike disks, be sure
they face in the direction shown in the instructions.
• Place two spike disks, separated by a long spacer
tube, onto the shaft. Fit the long spacer tube onto the
ends of the anged bearings in the disks. See gure
15.
DRIVE DISKS
5/8" FLAT WASHER
SHORT SPACER
TUBE
FLANGED
BEARING
FLANGED
BEARING
DRIVE DISK
ASSEMBLY
FLANGED
BEARING
SPIKE DISK
FLANGED
BEARING
FLANGED
BEARING
1/4" THICK SPACER
SPIKE DISK SHAFT

10
5/8" FLAT
WASHER
COMPRESSION
SPRING
• Place a 5/8" at washer, the compression spring and
another 5/8" at washer onto the shaft. See gure 16.
SPIKE DISK
LONG SPACER TUBE
• Place two spike disks, separated by a long spacer
tube, onto the shaft. Fit the long spacer tube onto the
ends of the anged bearings in the disks. See gure
17.
FIGURE 16
FIGURE 17
• Place two 5/8" at washers separated by a long
spacer tube onto the shaft. See gure 18.
FIGURE 18
5/8" FLAT WASHER
LONG SPACER TUBE
SPIKE DISK
LONG SPACER TUBE
FIGURE 19
• Place two spike disks, separated by a long spacer
tube, onto the shaft. Fit the long spacer tube onto the
ends of the anged bearings in the disks. See gure
19.

11
• Place two 5/8" at washers separated by a long
spacer tube onto the shaft. See gure 20.
FIGURE 20
SPIKE DISK
SHORT SPACER TUBE
• Place a spike disk and a short spacer tube onto the
shaft. Fit the short spacer tube onto the ends of the
anged bearings in the spike disk and in the end
plate. Push the shaft on through the anged bearing
in the end plate. See gure 21.
5/8" FLAT WASHER
LONG SPACER TUBE
FIGURE 21
FIGURE 23
• Place a 5/8" at washer onto the end of the spike disk
shaft and secure the shaft with a 1/8" x 1-1/2" cotter
pin. See gure 22.
• Fasten the two drive disks to the shaft using two 1/8"
x 1-1/2" cotter pins. See gure 22.
5/8" FLAT
WASHER
1/8" x 1-1/2"
COTTER PIN
DRIVE DISKS
FIGURE 22
• Assemble the chain onto the two sprockets on the
left side of the hopper. Fasten the ends of the chain
together using the connecting link. See gure 23.
• Place the chain cover over the chain and fasten it to
the hopper end plate using two self tapping screws.
See gure 23.
CONNECTING
LINK
CHAIN
SELF
TAPPING
SCREW

12
OPERATION
KNOW YOUR SPIKER SPREADER
Read this owner's manual and safety rules before operating your Spiker Spreader.
Compare the illustration below with your Spiker Spreader to familiarize yourself with the various controls and their
locations.
FLOW CONTROL LEVER Opens and closes the ow
plate at the bottom of the hopper.
LIFT HANDLE Raises the unit for transport or lowers it
for spreading and aerating.
PLASTIC WING NUT Tightens at desired setting to
control how far the ow control lever can open the ow
plate.
HOW TO USE YOUR SPIKER/SPREADER
• Refer to the instruction label on the material package
and to the instruction decal on your spreader to help
determine the proper spreader setting and application
rate. Also see the Setting Chart on page 13 of this
manual for a general range of settings for commonly
used materials.
• Determine the approximate square footage of the
area to be covered and estimate the amount of
fertilizer or seed required.
• Move the spreader to the area where application is to
begin.
FIGURE 24
FLOW CONTROL LEVER
PLASTIC WING NUT
LIFT HANDLE
• Loosen the plastic wing nut and move it to the desired
setting. Retighten the nut. See gure 24.
• Making sure the ow control lever is in the "OFF"
position, ll the hopper, breaking up any lumps.
• Lower the aerator spikes to the operating position.
• Start the spreader in motion and then move the
ow control lever to the "ON" position (against the
plastic wing nut) as you travel across your lawn. The
recommended towing speed is 3 m.p.h.
• Do not make sharp turns with spikes in the ground.
• Raise aerator spikes to transport position when
crossing over concrete or other hard surfaces.
• Do not aerate if the ground is extremely hard or dry.
If ground is too dry, sprinkle or water for one to two
hours prior to use.
• Do not aerate if the ground is too wet (muddy).
IMPORTANT: Always place ow control lever in the
"OFF" position to prevent excess fertilizer from being
released when lling the spreader and when stopping or
turning.
ALIGN AND TIGHTEN WING NUT
AT DESIRED FLOW SETTING
12345
67
89
10 11
12 13
14 15
16 17
18
OFF
0
WING NUT SET AT "5"

13
OPERATING TIPS
• To help prevent granular material from compacting
and clogging the hopper, avoid unnecessary towing
when the hopper ow plates are closed.
• Reduce the ow setting for speeds slower than
3 M.P.H. and increase the setting for higher speeds.
• To avoid misses or striping, overlap the previous
wheel tracks by approximately 5" to 6".
FIGURE 25
MAINTENANCE
Spike points are sharp. Exercise caution
when handling or working near spike disks.
Service Dates
Check for loose fasteners X
Lubrication X
Cleaning X
MAINTENANCE SCHEDULE
Fill in dates as you
complete regular service.
Before each use
After each use
Every year
Before storage
CUSTOMER RESPONSIBILITIES
• Read and follow the maintenance schedule and the maintenance procedures listed in this section.
CHECK FOR LOOSE FASTENERS
•Before each use make a thorough visual check of
the spiker spreader for any bolts and nuts which may
have loosened. Retighten any loose bolts and nuts.
LUBRICATION
•Apply a few drops of oil to wheels and to plastic
bearings in spike disks and at end of spike axle.
• Remove chain cover, clean and oil drive chain.
CLEANING
• Always empty spiker spreader after each use, storing
leftover material in it's original bag.
•Wash the spiker spreader and dry thoroughly after
each use.
• For easiest application, rst apply material across
both ends of the area. Two or three passes on each
end are sufcient. Then apply material back and forth
as shown. Use the end areas for turning around,
shutting off the spreader as you enter the end areas
and turning the spreader on again as your leave the
end areas for your next pass. See gure 25.
• If lawn is odd shaped, spread a border around the
edges and then spread between the border.
•Be careful when spreading around ornamental plants
because weed control chemicals can damage these
plants.
• Empty the spiker spreader, storing leftover material in
it's original bag.
• Apply a light coat of oil on exposed metal to help
prevent rust.
STORAGE
•Wash the spiker spreader and dry thoroughly before
storing.
• Store in a clean, dry area.
Flow Rate Setting
MATERIAL TYPE At 3 M.P.H.
SETTING CHART
Fertilizer Granular / Pelleted 5-6 / 6-7
Grass Seed Fine / Coarse 5-6 / 7-8
3 M.P.H. is equivalent to traveling 100 feet in 23 seconds.

14
PARTS
REPAIR PARTS FOR MODEL 486.24331
A
B
A
C
1
2
3
5
6
10
16
19
10
11 63
12
12
62
13
21
14
13
7
8
8
9
13
17
49
50
51
52
53
54
55
18
28 29
33
35
36
37
38
39
40
41
42
30
31
22
23
25
23
26
27
42
42
43
43 44
44
46
47
48
45
56
57
57
58
59
58
58
15
59
43
34
43
54
43
58
59
F
B
42
32
24
C
20
60
61
4
59
59
59

15
REPAIR PARTS FOR MODEL 486.24331
REF. PART QTY DESCRIPTION NO. NO.
REF. PART QTY DESCRIPTION NO. NO. 1 47931 1 Hopper 2 24736 1 End plate, Right Hand 3 24735 1 End plate, Left Hand 4 48418 12 Rivet, Pop 5 24747 1 Brace, Center 6 64104 1 Assembly, Agitator Shaft 7 47963 2 Bearing, Hex Flange 8 24739 2 Blade, Agitator 9 47978 10 Screw, Hex Washer Hd, #8-32 10 R19172410 2 Washer, 17/32" x 1-1/2" x 10 Ga. 11 46838 2 Spacer, .8" I.D.x1" O.D. x .50" Lg. 12 R19171616 4 Washer, 17/32" x 1" x 16 Ga. 13 43093 3 Pin, Cotter 1/8" x 1-1/2" 14 45133 1 Spacer, .5" I.D. x 1" O.D. x .59" Lg. 15 23520 1 Spacer, .66" I.D.x1.25" O.D. x .25" 16 47962 1 Spring, Flow Plate 17 64106 1 Assembly, Spiker Shaft 18 64107 1 Assembly, Transport Tube 19 24743 1 Lever, Flow Control 20 63956 2 Drive Disk 21 24332 7 Disk, Spike (7") 22 47953 1 Cover, Chain 23 47944 2 Tube, Hitch 24 24746 1 Lift, Handle 25 47961 2 Wheel, 10" x 1-5/8" 26 24741 1 Plate, Flow 27 23981 2 Bracket, Hitch 28 24539 1 Bracket, Feed Plate 29 728-3001 2 Rivet, Pop 5/32 (Stainless) 30 47960 1 Chain with Connector 31 43848 1 Grip, Control Arm .187" x .75" 32 43943 1 Grip, Height Adjustment 32"/38" 33 47959 1 Link, Flow Control
34 47969 1 Ferrule, 5/16" Thread x 1/4" Hole 35 43224 3 Bolt, Hex 5/16" x 2-1/4" 36 44180 2 Bolt, Hex 5/16" x 2" 37 43085 2 Bolt, Hex 5/16" x 1-1/2" 38 43084 2 Bolt, Hex 5/16" x 1-3/4" 39 43063 1 Bolt, Hex 5/16" x 1" 40 44731 2 Screw, Self Tapping 1/4" x 1" 41 43012 1 Bolt, Hex 1/4-20 x 3/4" 42 47810 10 Nut, Nylock Hex 5/16" 43 47189 6 Nut, Nylock Hex 1/4" 44 43088 2 Washer, Flat 1/4" 45 43081 4 Washer, Flat 5/16" 46 45100 2 Bolt, Hex 1/2" x 4" Full Thread 47 43019 2 Nut, Hex Jam 1/2" 48 48115 2 Nut, Nylock Hex Jam 1/2" 49 43343 1 Pin, Hair Cotter #4 (1/8") 50 44101 1 Pin, Cotter 3/32" x 3/4" 51 47623 1 Pin, Flat Head Hitch, 3/8" Dia. 52 44215 1 Bolt, Carriage 5/16" x 1-3/4" 53 712-0421 1 Nut, Plastic Wing 5/16" 54 1543-69 2 Washer, Nylon 21/64" 55 46524 5 Spacer Tube, Long 56 47777 1 Spring, Compression 57 46497 2 Spacer Tube, Short 58 741-0249 13 Bearing, Flanged PV80 .63 I.D. 59 R19212016 10 Washer, Flat 5/8" (21/32" x 1-1/4") 60 1509-90 1 Bolt, Hex 1/4-20 x 1-1/4" 61 48173 2 Washer, 13/16" x 1-1/2" x 1/16" 62 46557 1 Push Nut, 1/2" 63 44137 5 Washer, Flat .518 x 1 x.02 48070 1 Owner's Manual

® Registered Trademark / TM Trademark / SM Service Mark of Sears Brands, LLC
® Marca Registrada / TM Marca de Fábrica / SM Marca de Servicio de Sears Brands, LLC
MC Marque de commerce / MD Marque déposée de Sears Brands, LLC © Sears Brands, LLC
Get it fixed, at your home or ours!
Your Home
For repair – in your home – of all major brand appliances,
lawn and garden equipment, or heating and cooling systems,
no matter who made it, no matter who sold it!
For the replacement parts, accessories and
owner’s manuals that you need to do-it-yourself.
For Sears professional installation of home appliances
and items like garage door openers and water heaters.
1-800-4-MY-HOME®(1-800-469-4663)
Call anytime, day or night (U.S.A. and Canada)
www.sears.com www.sears.ca
For expert home solutions advice: www.managemyhome.com
Our Home
For repair of carry-in items like vacuums, lawn equipment,
and electronics, call or go on-line for the location of your nearest
Sears Parts & Repair Service Center
1-800-488-1222 (U.S.A.) 1-800-469-4663 (Canada)
Call anytime, day or night
www.sears.com www.sears.ca
To purchase a protection agreement on a product serviced by Sears:
1-800-827-6655 (U.S.A.) 1-800-361-6665 (Canada)
Para pedir servicio de reparación
a domicilio, y para ordenar piezas:
1-888-SU-HOGAR®
(1-888-784-6427)
Au Canada pour service en français:
1-800-LE-FOYERMC
(1-800-533-6937)
www.sears.ca
