Crate&Barrel WINGBACK HUBBARD User manual

1
A
B
C
Please note: actual product may look different
than illustration.
ITEM DESCRIPTION
Headboard
Headboard Leg
Wing
QTY
1
2
2
QUESTIONS? CALL 1.800.542.7553
(H1) x 4 — 5/8" x 5/16" bolt
(H2) x 20 — 1 1/4" washer
(H3) x 4 — 1" x 1/4" bolt
(H4) x 4 — 1/4" nuts
Components
WINGBACK
HUBBARD HEADBOARD ASSEMBLY
HARDWARE
(H5) x 8 — 2" x 5/16" bolt
Please note: you will need a at head screwdriver and a wrench to asseble
your headboard.
A
C
B

2
Attach (C) wing to (A) headboard using (H5)
bolts and (H2) washer. Tighten using at head
screwdriver.
Please note: Make sure the top of the (A) head-
board is level with the top of the (C) wings before
tightening.
1.1
Step 1
QUESTIONS? CALL 1.800.542.7553
WINGBACK
HUBBARD HEADBOARD ASSEMBLY

3
QUESTIONS? CALL 1.800.542.7553
WINGBACK
HUBBARD HEADBOARD ASSEMBLY
Attach (B) headboard legs to (A) headboard using
(H1) bolts and (H2) washers. Tighten with a at
head screwdriver.
Please note: Make sure the (B) headboard legs are
ush with the ground before tightening.
2.2
Insert (B) headboard leg through hole of (A)
headboard and align the slots with the holes.
2.1
Step 2

4
QUESTIONS? CALL 1.800.542.7553
WINGBACK
HUBBARD HEADBOARD ASSEMBLY
Attach assembled headboard to your bed frame
using (H3) bolts, (H2) washers and (H4) nuts.
Tighten with a at head screwdriver and wrench.
If you are assembling a complete upholstered bed,
attach (C) headboard wings to upholstered bed
frame using (H5) bolts and (H2) washers. If you
are assembling a headboard only, ignore this step.
3.1
3.2 (OPTIONAL)
Step 3
C
B

5
Skyline Furniture Inc. guarantees its
upholstered furniture against defects in
construction for a period of one (1) year. When a struc-
tural defect is brought to our attention, we will repair
or replace it at our option at no charge to the customer
(inculdes parts and labor, not transportation costs).
Fabric wearability for upholstered furniture is not
covered by the warranty. Vacuum for regular cleaning.
Please dispose of plastic bag(s) and carton(s)
responsibly.
Skyline Furniture Inc. garantiza sus muebles tapiza-
dos contra defectos en construccion por un periodo
de un (1) ano. Cuando un problema de estructura es
traido a nuestra atencion, nosotros repararemos o
remplazaremos sin ningun cargo a nuestro cliente
(incluye partes y trabajo, no costo en transportacion).
Descoloramiento del material de muebles tapizados
no es cubierto por la garantia. Regularmente puede
aspirar.
Por favor tirar bolsa(s) y caja(s)
responsablemente.
Skyline Furniture Inc. garantiza sus muebles tapiza-
dos contra defectos en construccion por un periodo
de un (1) ano. Cuando un problema de estructura es
traido a nuestra atencion, nosotros repararemos o
remplazaremos sin ningun cargo a nuestro cliente
(incluye partes y trabajo, no costo en transportacion).
Descoloramiento del material de muebles tapizados
no es cubierto por la garantia. Regularmente puede
aspirar.
Por favor tirar bolsa(s) y caja(s)
responsablemente.
LIMITED WARRANTY
LIMITE DE GARANTIA
GARANTIE LIMITÉE
Warranty
QUESTIONS? CALL 1.800.542.7553
WINGBACK
HUBBARD HEADBOARD ASSEMBLY
