MODULE OWNERS MANUAL
Power
Processing
Modules
About Power Processing Modules
The rear panel of the CK family Power Processing amplifiers provides three bays (Input, Network
and Power/Output) configured to accept interchangeable plug-in modules.Your amplifier may have
been factory-configured with some of the optional modules. The back page of this manual contains
an overview chart of all currently available Power Processing modules.
“CC-” Modules fit into the Power/Output or Input module bays. These basic analog modules are
non-programmable and non-NexSys®compatible; only the Sequential Turn-On/Off (STO) function
can be controlled (through hardwiring).
“NC-” Modules can be controlled, programmed and/or monitored via the hand-held N-Coder, N-
Coder/PC software or over the NexSys network. Except for the STO feature, NC Modules are “tam-
per-proof” in that there are no user-accessible setup controls.
Programming NC Input Processing Modules
NC Input Processing modules can be programmed in OR out of the amplifier.
Programming with the N-Coder
Connected to an Input Processing module’s data port via the supplied RJ14-RJ14 cable, N-Coder
automatically identifies module type and displays only the parameters available for that module.
Users can then adjust parameters, audition the results, then store new settings in the module’s non-
volatile memory, or inside the N-Coder for later reference. Modules need not be powered, or even
installed in the amplifier for programming; N-Coder provides the necessary power. Parameters can
also be created ahead of time without any modules attached, stored in the N-Coder, then downloaded
into the module’s memory later. Except for DSP modules, all NC Input Processing modules can be
programmed from an N-Coder.
Programming with N-Coder/PC software
N-Coder/PC Software, a Windows®-based program that configures all Input Processor NC modules,
will run on any PC with Windows ‘95 or 3.1. The computer’s parallel (printer) port is used with a
DB25 to RJ-14 adapter and cable (both supplied) that connects to the Input Processor NC module.
Programming with Octopus
Crest Audio’s LCP-AC8 “Octopus” is a one rack space, Locally Controlled Processor that adds
‘Snapshot’ capability to the CK family of Power Processing amplifiers. Octopus is compatible with
all NC Input Processing modules, and can activate functions including sequential power control,
level attenuation, analog EQ, crossovers, and all DSP parameters. The Octopus may be integrated
with third-party RS-232C system controllers.
Programming with NexSys
Using the appropriate NC Network module, NC Input and Power/Output modules can be controlled,
programmed and/or monitored remotely through the use of NexSys. NexSys is Crest Audio’s hard-
ware and software package that offers network connection of Crest Audio amplifiers and associated
devices, along with diagnostic facilities.

Input Processing Module Connections
The CK family of amplifiers come standard with a CC-IPB Input module. Barrier strip input con-
nectors and removable individual channel rotary attenuators are provided. All Input modules have
an internal voltage gain/input sensitivity jumper that is factory-set for X40 gain.
Input barrier strip lug / gauge information
Input barrier strips have a 0.325" (8.3mm) center and 0.270" (6.9mm) lug space. For connecting to
the input barrier strips, a wire gauge between 14 AWG (2.5mm2) & 24 AWG (0.25mm2), and spade
lugs (Panduit Part No. PNF 18-6LF-C or equivalent) are recommended.
Balanced vs. unbalanced inputs
Barrier strip inputs are ready to accept balanced sig-
nals. For use with an unbalanced source, tie the
inverting (minus) input to ground by installing a
jumper across the appropriate barrier strip terminals.
If the inverting input is left floating, a 6 dB loss in
gain will result.
AES/EBU Input
This XLR jack accepts a standard AES/EBU XLR
plug.
Daisy chaining
Some Input Processing modules have daisy-chained outputs, located on barrier strip terminals.
NC-AES and NC-DSP-D modules have balanced daisy chain outputs.
NC-DSP-A and NC-SEQ modules have unbalanced daisy chain outputs.
NC-MCO and NC-MEQ modules have unbalanced mono HP/LP daisy chain outputs.
The NC-SCO module has unbalanced stereo HP/LP daisy chain outputs.
NC-IPE page input & enable connections
Get information from engineering
Input Processing Module Attenuators
Operation
Channel attenuators (A&B) are used to control signal level. Ideally, the amplifier should be operat-
ed with the controls at 0dB attenuation. When the amplifier is being used in bridged mono mode,
both attenuators must at the same level.
Knob Removal
The attenuator knobs can be removed and replaced with blanking plugs.
The procedure for attenuator knob removal is as follows:
1. With an X-Acto or similar knife, pop off the grey key cap of the attenuator knob. This will reveal
the inside nut.
2. Using needle nose pliers or appropriate size nut driver, loosen and remove the inside nut.
3. Slide the attenuator knob off the shaft.
4. Insert a regular screwdriver in the slotted end of the shaft, and adjust attenuation to desired level.
5. Blanking plugs may now be inserted in the attenuator holes.
Input Barrier Strip
Level
B
Level
A
Input A Input B
++–
–
78
9
5
2
0
1
346
10
78
9
5
2
0
1
346
10
Model
CC-IPB
SEE INSTRUCTION MANUAL
Input Level
Attenuators

Input Processing Modules - Internal Options
Input sensitivity/voltage gain jumper
Input modules have user-settable jumpers to configure Input Gain/Sensitivity. These internal
jumpers (two for CC-IPB, three for all input NC modules), labeled “W1 W2 W3”, are used to set
the overall gain of the amplifier.
The 3 positions (shown at left) allow
the amplifier to be set for constant gain
of X20 (26 dB), X40 (32 dB), OR con-
stant sensitivity for full output (.775V)
at 0 dBu input. The standard factory
setting is for X40 (32dB). All jumpers
must be set to the same position as
shown.
To change jumper settings, the Input
module must first be removed from the
amplifier.
Warning! Amplifier must
be removed from AC
mains supply before this
operation is undertaken!
The diagram at left shows the location
of these jumpers on the CC-IPB mod-
ule. The diagram at the lower right
shows the location of the jumpers on
the NC-IPN module.
NexSys/N-Coder jumper
All NC Modules have internal jumpers used to set the module for operation with NexSys or N-
Coder. These jumpers are labeled “W4 W5” on the Input module circuit board.
The “NC-NXS” jumper position
allows operation with NexSys,
while the “NCODE” jumper posi-
tion permits the Input module to be programmed through N-Coder or N-Coder/PC software when
the amplifier is off.
Note: Factory setting is the ‘NexSys’ position. If NexSys, N-Coder, or N-Coder/PC software is not
being used, jumper position will have no effect upon the operation of the amplifier.
+26dB
0dBu Sen
+32dB
W2 W1 W3
W4W5
N-CODE
NC-NXS
CREST AUDIO
26C2797-02
Input Gain/Sensitivity Jumpers
Nexsys / N-Coder Jumpers
N-Coder Setup NexSys Setup
N-CODE
NC-NXS N-CODE
NC-NXS
CREST AUDIO
26C2197-02
Input Gain/Sensitivity Jumpers
W1
+26dB
W2 A
B
0dBu IN
+32dB
+26dB
0dBu
+32dB
+26dB
0dBu
+32dB
+26dB
0dBu
+32dB
+26dB
0dBu
+32dB
.775V / 0 dBu (For Full Power) X20 (+26 dB)
Channel A Jumper
Channel B Jumper
NexSys Indicator Jumper (NC-IPN Only)
X40 (+32dB) Standard Factory Setting
+26dB
0dBu
+32dB +26dB
0dBu
+32dB

Swapping out Modules
Only jumper setting changes or module upgrades require modules to be removed from the amplifi-
er. Contact Crest Audio Customer Service for full details on module removal. The ‘General Module
Setup’ diagram indicates the general setup of the rear panel module/bay configuration.
Required Tools
A Phillips screw driver. Should the
module jumpers need to be changed
or removed, a pair of long nose or
needle nose pliers is also useful.
Precautions
Amplifier is shown with the top
cut away for clarity only. Dangerous
voltages exist inside, and only a Crest
Audio-certified service technician
should remove the top cover!
Removable modules contain static-
sensitive devices; handle modules at
static-safe work stations! The amplifi-
er MUST be switched off and the
mains plug removed from the supply
before module removal operation is
undertaken.
Removing or Replacing an Input Module.
Remove the four #8 3/8" Phillips pan head sheet
metal screws that secure the module to the chas-
sis. The module is connected electrically to the
amplifier via multi-pin ribbon cables. Unplugging
the module from the ribbon cable connectors
frees the module for removal. To insert the same
or another module, simply reverse this procedure,
making sure that any ribbon cable connectors are
properly and securely seated. Note: The amplifier
must not be operated without an Input module in
place.
Removing or Replacing a Network Module.
This process is the same as that for removing/replacing an
Input module. Be aware, though, that if an NC-NXS
Network module is being removed or replaced, four multi-
pin ribbon cables will need to be disconnected. Note:
Standard CK family amplifiers come with a blank panel
installed in the Network bay. The amplifier must not be oper-
ated without a Network module or blank panel in place.
DO NOT attempt to replace or remove a Power/Output Module.This module can only
be serviced by a Crest Audio certified service technician. Please consult your deal-
er, Crest Audio representative, or Crest Audio Customer Service for assistance.
User-inflicted damage to this module will invalidate your warranty.
Model
NC-NXS
Hi
Data
Lo
Network Address
0
8
1
9
2
A
3
B
4
C
5
D
6
E
7
F
0
8
1
9
2
A
3
B
4
C
5
D
6
E
7
F
Model
Name
CKS 100
CKS 200
CKS 400
CKS 800
CKS 800-2
CKS 1200-2
CKS 1600-2
Output Power
@8Ω/Ch.
50W
100W
200W
400W
400W
600W
800W
