CrimeStopper RS1-G4 Cool Start User manual

RS1-G4
ONEBUTTONREMOTESTART SYSTEM
OPERATINGINSTRUCTIONS
CONGRATULATIONS on your choiceofaCoolStart™RemoteEngine Starter and Keyless EntrywithDP
TechnologybyCrimestopperSecurityProductsInc. Thisbookletcontainstheinformationnecessaryforoperating
your system. If anyquestionsarise, contact your installation dealer or Crimestopper SecurityProductsInc.
*IMPORTANTINFORMATION:Primaryand Optional Features
-PRIMARY: Theseare featuresthatmustbe connected inorder for the systemtooperateproperlyi.e. Remote
Start connections, Flashing lights, and BrakeReset. For programming, the programbutton must be installed.
-OPTIONAL: Thesefeaturesaretobeconnectedonlyifdesiredoragreeduponbythecustomerandtheinstalling
dealer i.e.Door Locks,Horn-Honk,Anti-Grind,etc.Thesefeaturesmayalsorequire additionalpartsand/or labor
fees.Consultwithyour installer beforehand tobe sure ofwhatisgoing tobe installed withyour particular system.
CRIMESTOPPERSECURITYPRODUCTS, INC.
1770 S. TAPO STREET, SIMIVALLEY, CA. 93063
REV A07.2013
ThisdevicecomplieswithFCC Rulespart15.Operation is
subjecttothe following twoconditions: 1)Thisdevicemaynot
causeinterference,and (2)thisdevicemustacceptany
interferencethatmaybe received,including interferencethat
maycauseundesired operation.The manufacturerisnot
responsibleforanyradioorTVinterferencecaused by
unauthorized modification tothisequipment. Suchmodification
couldvoidthe user'sauthoritytooperatethe equipment.

2
TABLEOF CONTENTS
Operation Cautions&Warnings…….……………..….…………………………………….…………….….…………2
Using the RemoteTransmitter………………………………………………………………………….………....…….3
StatusLED……………………………………………………………………………………………….……….……….4
RemoteEngine Control…………….…..……………………………………………………………….…….……….4-7
Turbo Timer Mode……………………………….……………………………………...……………….……………..…8
ManualTransmission Mode……………………………….……………………………………...…………………..…9
Convenienceand SafetyFeatures……………………………….………………………………….…...………..10-11
Transmitter Programming….…………….…………………………………………….……………….…………....…12
NoFactoryKeyless Entryafter RemoteStart…………..…………………………………………………………….13
RemoteStart Diagnostics……………………………………………………………………………………………….13
BatteryReplacement.…………………………………….………………...……………………..…………….………14
2-WayDataPort…………………………………………………………………………………………………………15
OPERATIONCAUTIONS&WARNINGS
CRIMESTOPPERSECURITYPRODUCTS,INC. and its VENDORS shall notbe liablefor anyaccidentresulting
fromthe useofthisequipment. Thissystemisdesigned tobe professionallyinstalled intoacarorvehicleinwhich
all items,suchasparking brakeand all associated components,door switches,transmission shift linkage,throttle
linkage, and all engine safetyfeatures, are inperfect working condition.
ITISABSOLUTELYTHEOWNER’SSOLERESPONSIBILITYTO: A)Understand the operation ofthissystem
and itssafetyfeatures.B)Check for proper operation ofthe systemprior toaccepting deliveryofthe vehiclefrom
the installation facility.C)Check and maintainthe condition ofthe vehicleand all itemsrelativetothe proper
operation ofthissystemand itssafetyfeatures.D)Always leavethe doorsand windowsclosed and locked to
protect against accidentsand theft.
DONOTremote startthevehicleinaclosedgarage. Makesure thatthe garage door isopen or there is
adequateventilation.Failure toobservethisrulecouldresultininjuryordeath frompoisonousCarbonMonoxide
fumes.

3
USINGTHEREMOTETRANSMITTER
REMOTESTARTBUTTONPRESS SELECTION(Option #6):
The transmitter supplied withthissystemisasinglebutton remotecontrol.
Toeliminatethe possibilityofaccidentallystarting the vehicle,there are (3) optionsforbuttonpressselection.This
option will allowyou tochange whether the RemoteStarter isactivated bya:
1.DoubleButton –2presses.
2.*Single½second press (Default).
3.Press and Hold2seconds.
*Default=1singlepress*
Please consultyourinstallertochangeprogrammableoptions

4
STATUSLED
VEHICLESTATUSLED:UsedforRemote StartDiagnostics –page13 (Install optional)
The optionalLEDwill remainsolidwhen the systemisinValet Servicemode. The remotestart function WILL
NOToperatewhen inValet Mode. See page #10 for Valet Mode.
REMOTEENGINECONTROL
REMOTEENGINESTARTING -SUCCESSFULSTART:
1) Press the remotestart button for at least 1/2second (*default). Parking lightsflashonce, return solid,and the
Ignition/Acc circuitsturn on.
2) After afewsecondsthe Starter Motor engages.The parking lightsand Acc circuitswill turn off whilecranking.
3) Engine Startsand Runs. Parking Lightsand Acc turnsbackon, and the doorslock.
4) Engine will remainrunning for programmed run timeuntil resetwithBrakepedal.Ifneeded,the engine can be
turned off withremotetransmitter bypressing and releasing the Start button.
AFTER
IGN
4
STARTER
THEN
FLASH1X
SOLID
SOLID
SEC.

5
REMOTEENGINECONTROL
REMOTEENGINESTARTING -UNSUCCESSFULSTART
Inthe eventthatthe engine doesnotstarton the firstattempt, the systemshutsdownfor afewsecondsand then
attemptstorestartthe engine a2nd and 3rd time.Forhardstartingengines,theunitwillallowastartercranktimeof
upto4secondsmaximum.Thisshouldprovideamplecrankingtimefordifficultstarts,butislimitedto4secondsto
helpprevent damage tothe starter fromover cranking.
1) If engine startson 2nd or 3rd attempt, see steps3&4of "SuccessfulStart"on page 4.
2) IfThird attemptfailstostartengine,the systemwill turn off and doorswill remainlocked.NOFURTHER
ATTEMPTSWILL BE MADEAUTOMATICALLY
TURNING OFF AREMOTESTARTEDENGINE:
1) Engine isrunning inRemoteStart (Parking lightsON).
2) Press and releasethe remotestart button or doublepress (If option #6 ison).
3) Engine &parking lightsOFF, Doorsre-lock.
ENTERING YOUR REMOTESTARTEDVEHICLE:
1) Withengine running, unlocksystemwithremote(If equipped) or open door withkey.
2) Enter vehicleand be carefulnot tostep on brakepedal!(RemoteStart Reset)
3) Turn Ignition toON/RUN position, then press brakepedaltoreset the RemoteStarter &Shift out of park.
4) Remotestarter will resetinstantlywhen the brakeispressed.Parking lightswill turn off and the ignition keyis
nowcontrolling your vehicle.
REMOTESTART RUN TIMERESET:Requires 3or4button remote
The RemoteStart Run Timeisadjustablefrom5to30 minutes(option #20). Somelocalcitieshavearun time
limit for unattended vehicle. You can nowreset the engine-run timer toallowfor more running timeafter remote
start hasalreadyoccurred using the remotecontrol. After asuccessfulremotestart, press boththe Lock&
Unlockbuttonstogether for at least 2seconds(requires3or 4button remote). The parking lightswill flash3
timesand internalengine timer will reset backtozero minutes.

6
REMOTEENGINECONTROL
IDLEDOWNMODE:
Thismodeallowstheunittotakeoveroperationoftheparkedvehiclewhiletheignitionkeyisremovedandyouexit
the vehicle.The vehiclewill remainrunning for the programmedtimeoruntilcanceled.TheRunTimechoicesare:
10, 20, 30 minutesor InfinityRun. Default=20 minutes
Examples:
•You pull up toaconveniencestore for aquick stop,"IdleDown"mode keepsengine running when you exitthe
vehicle, (withkeys inhand). When you return, turn ignition ON, step on brakeand driveaway.
IDLEDOWNMODE-EXITING THEVEHICLE:
1) Withvehicleengine running withkey, press the RemoteStart button for at least one second or twiceif set for
Doublepress.
2) Parking Lightswill turn ON.
3) Doorswill unlock, or if brakepedalisbeing depressed, doorswill unlockwhen it isreleased.
4) Turn OFF Ignition and removekey. Engine shouldremainrunning.
5) Engine will remainrunning for programmed run timeor until you return (whichever comesfirst).
IGN
SOLID
OFF
UNLOCK
IDLEDOWNINFINITYRUN MODE:
IdleDowncanbeprogrammedforINFINITYRUN.ThisallowsthevehicleenginetoremainrunningINDEFINITELY
withouttheignitionkeyintheswitch.Theparkinglightscontinuouslyflashinthismode.Thismodecanbebeneficial
tolawenforcement or commercialtrucksthat need toremainrunning unattended for long periodsof time.

7
REMOTEENGINECONTROL
SELECTABLEHOURLYCOLD-STARTMODE(1-4 HOURS)
Thismode allowsthe vehicletobe programmed toself-startevery1,2,3or 4hoursand run for the programmed
run time. Thiscan be helpfulduring extremelycoldconditionswhere engine fluidfreeze-up isaconcern.
TIMEDSELF-STARTMODE–Requires Valet Button Installed
1) Engine shouldbe running withthe Key.Press the RemoteStartbutton for atleast1second.Lightswill turn on
signaling the remotestart hasturned on and doorswill unlock.
2) Within10 secondspress and releasethe valet/programbutton oncefor eachhourlyincrement(1 time=1hour,
2X=2hours, 3X=every3hours, 4X=every4hours).
3) Parking Lightswill turn ONwhen the button ispressed and flashoncefor eachconsecutivebutton press.
4) Turn Ignition switchOFF, removekeyand exit the vehicle. Engine shouldremainrunning.
5) Onceoutside the vehicle,press and releasethe remotestartbutton toturn off engine.The parking lightswill
flashthe number of timesindicating the hourlyincrement for confirmation. The vehiclewill startbyitselfatthe
selected hourlyincrement until driven withkeyor started viathe remotecontrol.
IGN
SOLID
OFF
UNLOCK
PRESS1 -4X
WITHIN 10 SEC.
LIGHTSFLASH
foreachpress
ENGINETURNSOFF
FLASHHourIncrement
RESETTING TIMEDSELF-STARTMODE:
Toreset the timed self-start mode, start vehicleusing the ignition keyor the remotecontrol.

8
TURBOTIMERMODE(OPTION#22)
The optionalTurbo Timer mode allowsthe CoolStart systemtokeep aTurbo or Turbo Dieselvehiclerunning
for 1, 3or 5minutes[selectively] after you removethe keyand exit the vehicle. Thisishandyfor turbo cool-
downwithout the need for expensiveturbo timers. The Default=OFF.
To Activate Turbo Timer:
Withthe engine running bykey, press Remote StartButton withbrake pedal depressed. Asyou releasethe
brakepedal, the Parking Lightsand StatusLEDwill blinkthe number of minutesfor the Turbo Timer setting.
The doorsunlockafter confirmation.
REMOVE KEY
FLASH 1-5X
EXITVEH.
PRESS
AND HOLD
BRAKE
RUNNING RELEASE
BRAKE
LIGHTS
RUNNING
REMAIN
1-5 MIN.

9
MANUAL TRANSMISSIONMODE(Option 11)
MANUALTRANSMISSIONEXITPROCEDURE(Option #11-1, 11-3 and 11-4)
ThissystemfeaturesaManualTransmission Mode. When exiting the vehicle, there isasafetycheckout
procedure required for the manualtransmission mode towork. There are 3choicesof operation,
1. Option 11-1: Withengine running and vehicleinneutral,setparking brake,then press “KEY” Icon on
transmitter.The remotestarter will turn on and takeover operation ofthe vehicle.Press “KEY”Icon after
closing last door tofinishexit procedure.
2. Option 11-3: Withengine running and vehicleinneutral, set parking brake. The remotestarter will turn on
and takeover operation of the vehicle. Press “KEY”Icon after closing last door tofinishexit procedure.
3.Option 11-4: Withengine running and vehicleinneutral,setparking brake.The RemoteStarter will turn on
and takeover operationofthevehicle.RemoveKeyandexitvehicle.Whenthelastdoorofvehicleisclosed,
the engine will turn off in2secondsand set up ManualTransmission Mode.
Option 8 can be used toprogramlockwithremotestart abort.
TURBO TIMERinManual Transmission Mode:Requires 3or4button remote
For Turbo Timer,Press brakepedalbefore setting parking brakeor pressing RemoteStartbutton (requiresTurbo
TimerOption#22).TheenginewillremainrunningfortheTurboTimersetting(1,3or5minutes).RemoteStartwill
notworkafter turbo timer expiresusing aone button remote.ToRemoteStartafter Turbo Timer requiresa3or 4
button remotetolockthe doorsafter exiting vehicle.The 3or 4button remotescan be added tothe systemalong
withthe 1button remote. Consult your dealer.
CONVENIENCEAND SAFETYFEATURES
KEYLESS ENTRY(PowerDoorLocks, mayrequireData Module-Optional)
Option 23 Unlock on StartButton
The doorswill automaticallylockwithremotestart (Programoption #8). Thiskeepsyour vehiclesecure when it
isremotestarted. After the vehicleisremotestarted, the systemcan be programmed toremotelyunlockthe
doorswithamomentarypress of the start button (option #23). Vehiclestaysremotestarted and doorsunlock.
Thisisveryconvenient asmanyfactorykeyless entriesdon’t function withthe ignition on.

10
CONVENIENCEAND SAFETYFEATURES
AUTO LOCK / UNLOCK (Option #2)
TheAutoLockfeaturecontrolswhetherthedoorswillautomaticallylock/unlockonyourvehiclewhendrivingorwith
turning the Ignition ON/OFF.Ifthe AutoLockfeature isturned on,and your systemisin“Tach” mode,then the
doorsshouldautomaticallylockasthe engine RPM’sincrease(driving).Ifthe AutoLockfeature isturned on,and
your systemisin“SmartTachless”mode,then the doorswill lockafewsecondsafter the Ignition isturned on.
When the AutoLockfeature isturned on, the systemwill alwaysunlockthe doorswhen the Ignition isturned off.
Withthisfeature turned OFF,the systemwill notautomaticallylockor unlockthe vehicle.See your installer for
programming information on thisfeature.
HORN CHIRPS (Option #7&16)
Ifvehiclehornsareconnectedtothesystem,theywillprovideaudibleconfirmationchirpsforremotestart.Thechirp
sound can be programmed fromshorttolong toadjustfor differentsounding horns.Note:Horn honk/chirp feature
mayrequire extra labor and/or partstoinstall.
Option 7=ChirpswithRemoteStart On/Off.
Option 16 =Short, mediumor long Chirp Pulse(15, 20 or 40 milliseconds).
VALETMODE(Requires Installation ofValet Switch)
Before servicing your vehicleor handing the keysover toaValetwerecommend putting the unitintoValetMode.
The remotestartfunction WILL NOToperatewhen inValetMode.Toenter Valetmode,turn the keytothe ON
position, press and holdProgram/Valet switchfor 5-6 seconds. The LEDwill turn on solidwhen the systemisin
Valet Mode. Toexit Valet Mode, performthisprocedure again.
ANTI-GRIND (Optional, relaynotincluded)
ThisOptionalfeature preventsthe user fromaccidentallygrinding the starter ifthe Ignition keyisturned too far to
the startposition whileengine isalreadyrunning fromthe remotestarter.The Anti-Grind requiresthe useofan
externalrelay.

11
CONVENIENCEAND SAFETYFEATURES
HOODOPENSAFETY(Requires hood pinswitch)
Preventsthe engine frombeing RemoteStarted when hood isopen.Eliminatesriskofinjurytosomeone working
under the hood ofthe vehiclewithaproperlyworking hood pininstalled.IfRemoteStartbutton ispressed withthe
hood open,the lightswill flashtwiceand the unit will not attempt astart. The systemwill abort RemoteStart any
timethe hood isopened. See RemoteStart Diagnostics on page 13.
BRAKEPEDALRESET:
Preventsstarting or shutsoff aremotestarted vehiclewhen thiscircuitisactive.Preventsunauthorized driving of
vehicle.Thiscircuitshutsthe systemdownimmediatelywhen brakepedalispressed.Turn the ignition keytothe
“ON”position before the brakepedalispressed.
OEMALARMINTERFACE(Mayrequireoptional DatabusModule)
Thisfeature isdesigned toDisarmandRe-armFactoryequippedsecuritysystemsinconjunctionwithremotestart
and keyless entry(if needed for your vehicle). Thisfeature will maintainthe originalintegrityand securityofyour
vehicle’sfactoryequippedsystemsbefore,during,orafterremotestart.SomevehiclesrequireanoptionalDatabus
moduletooperateafactoryalarmor keyless entry.
LOCK withREMOTESTARTand AfterREMOTESTARTABORT:
Option #8controlswhether the systemwill automaticallylockduring and after aremoteStartabortor time-out.
There are 4choicesfor thisoption:
1.OFF
2.Lock withRemote StartOnly-Default.
3.LockwithRemoteStart and LockwithRemoteStart Abort.
4.LockwithRemoteStart Abort only.
NOTE: When changing, charging, or jumpstarting the vehicle’sbatterywerecommend removing the mainpower
fuseslocated on the heavy gauge REDwiresnear the remotestart module.

12
TRANSMITTERPROGRAMMING
Note: All transmittercodes must belearnedat timeofprogramming!! TheRS1-G4learnsup to4different
transmittercodes.
1.Turn Ignition Keytothe ONposition.
2.Press Programming button 4times, then after afewsecondsthe unit flashesthe parking lights4times.
3.Press the start button of the first transmitter. You shouldget 1light flashconfirming the remoteiscoded,then
press the startbutton ofasecond transmitter,the unitwill flash2timesconfirming the remoteiscoded and so
on.Ifall 4codesare learned, the unit will automaticallyexit code learning mode, otherwiseturn keyoff. See
diagrambelow.
IGN
OFF
WAITFOR
4FLASHES
PRESS 4X's
FLASH2, 3, or 4X's
IGN
OFF
PRESS STARTBUTTON

13
NOFACTORYKEYLESS ENTRYAFTERREMOTESTART
MostnewcarsDoNotallowthefactoryRemoteKeylessEntrytofunctionwiththeIgnitionON.Thismeansyoucan’t
usethe factoryremotetolockor unlockthe doors.After remotestartyou havetousethe keystounlockthe door.
Also,manynewvehiclesunlockthe doorswhendisarmingthefactoryalarm.Thisleavesthedoorsunlockedwhile
RemoteStarted. Toresolvethisproblem,haveyour installer connectthe door lockstothe RemoteStartKeyless
Entry. The RemoteStarter will Re-Lockthe doorsafter remotestarting.
After the vehicleisremotestarted, the systemcan be programmed toremotelyunlockthe doorswitha
momentarypress of the start button (option #23). Toabort remotestart withremotecontrol, press the start
button about 2-3 seconds.
Note: Thereare3Remote StartOptions(see page3).Theoptionsare: 1/2second press (Default),2second
press orDoublebutton press.
REMOTESTART DIAGNOSTICS
Ifthesystemflashes theLEDand Parking Lights onetoseventimes and doesn’tattemptremote.TheLED
will continueflashing theerrorcodeuntil theignition isturnedon, itmeansthefollowing:
1Parking LightFlash(1 LEDFlash)=ProblemwithBrake Switch.
2Parking LightFlashes (2 LEDFlashes) =ProblemwithHood Switch.
3Parking LightFlashes (SolidLED)=Valet Service Mode.
5Parking LightFlashes (5 LEDFlashes) =TachProblemorIgnition OnbeforeRemote Start.
7Parking LightFlashes (7 LEDFlashes) =Manual Transmission Error.
Besure totell your installer the Diagnosticcode when taking vehicleinfor service
SYSTEMISUNSUCCESSFULATREMOTESTARTDURING EXTREMECOLDCONDITIONS:
Pleasebeawarethatduringsub-freezingconditionsyourremotestartermaytakemorethatoneattempttostartorit
maynotsuccessfullystartthe vehicleafter 3attempts.During theseconditionsthe vehiclemaynotproperlystart
even using the key; therefore trying tostart bythe remotewouldalsobe unsuccessful.

14
BATTERYREPLACEMENT
To replace thebattery: Simplyremovethescrewonbackofthetransmitterandslidethecaseapartasshown.
Removethe twoCR-1620 Lithiumbatteriesand replace. Put casebacktogether and tighten screw.

15
2-WayDATAPORT
Somevehiclesrequire aDatabusModuletoBypass the factoryImmobilizer and operatethe keyless entry.
Databusmodulesare used tocommunicatewiththe vehiclescomputer at the OBD2Dataconnector or Canbus
wires. Thisreducesinstallation error. Crimestopper SystemswithDPSerieshaveadirect DataPort Plug-Infor
the Databusbypass module. Thiseliminatesconventionalwiring between the Alarm/RemoteStarter and the
bypass interfacemodule.
Features Include:
•Transponder Immobilizer.
•PassLockImmobilizer.
•O.E.M. AlarmControl.
•R.A.P. Shutdown.
•Power Door Locks.
•PriorityUnlock.
•TrunkRelease.
•Parking Lights.
•CourtesyLights.
•Tachometer.
•Heated Seats.
•Rear Defrost.
•Driver 1and 2Memorypresets.
The actualfeaturescontrolled depend on the vehicleand Databusmodule.

16
www.crimestopper.com
[e-mail]
Phone [phone]
FAX [phone]
©2013 CrimestopperSecurityProducts
ONLINETECHNICALSUPPORT
www.crimestopper.com
