CrimeStopper Cool Start RS7-G5 FM User manual

RS1-G5, RS3-G5, RS4-G5
RS4-G5FM (1-WaySystem)
RS7-G5FM (2-WayPaging System)
REMOTESTARTSYSTEM
OPERATINGINSTRUCTIONS
CONGRATULATIONS on your choiceofaCoolStart™RemoteEngine Starter and Keyless EntrywithDP
TechnologybyCrimestopperSecurityProductsInc. Thisbookletcontainstheinformationnecessaryforoperating
your system. If anyquestionsarise, contact your installation dealer or Crimestopper SecurityProductsInc.
TheRS1-G5, RS3-G5&RS4-G5systemcomes with(2)1-way AMremotes
TheRS4-G5FMsystemcomes with(2)1-way FMremotes.
TheRS7-G5FMsystemcomes witha2-Way LCD Pagerand a1-Way FMremote.
OPTIONALFeatures are tobe connected onlyifdesired or agreed upon bythe customer and the installingdealer
i.e.Door Locks,TrunkPop,DomeLightIllumination,Horn-Honk,Anti-Grind,etc.Thesefeaturesmayalsorequire
additionalpartsand/or labor fees.Consultwithyour installer beforehand tobe sure ofwhatisgoing tobe installed
withyour particular system.
CRIMESTOPPERSECURITYPRODUCTS, INC.
1770 S. TAPO STREET, SIMIVALLEY, CA. 93063
REV 07-2014
ThisdevicecomplieswithFCC Rulespart15.Operation is
subjecttothe following twoconditions: 1)Thisdevicemaynot
causeinterference,and (2)thisdevicemustacceptany
interferencethatmaybe received,including interferencethat
maycauseundesired operation.The manufacturerisnot
responsibleforanyradioorTVinterferencecaused by
unauthorized modification tothisequipment. Suchmodification
couldvoidthe user'sauthoritytooperatethe equipment.

2
TABLEOF CONTENTS
Operation Cautions&Warnings…….……………..….………………………………….…………….….…………2
Using theRemote Control (1, 4and 5button)….……………….……………………….………....………….....3-4
Using the2-Way Pager……………………………………………….……………………….………....…………...5-6
Setting theClock and BeeporVibrate Selection…………………………………………………….……….….6-7
StatusLED………………………………………………………………………………………………..……….….……8
Remote EngineControl…………….…..……………………………………………………………….…….…..…8-11
Turbo TimerMode……………………………….……………………………………...……………….…………..….12
Manual Transmission Mode……………………………….……………………………………...…………………..13
Convenience and Safety Features……………………………….………………………………….…...……....14-15
TransmitterProgramming….…………….…………………………………………….……………….…………16-17
2VehicleOperation.…………………………………….………………...…………………………………….………18
NoFactoryKeyless EntryafterRemote Start…………..………………………………………………………….19
Remote StartDiagnostics……………………………………………………………………………………………..19
2-Way Data Portand SmartPhoneData Port………………………………………………………………………20
Remote BatteryReplacement(1, 4and 5button remote)……...…………………..…………….………….21-23
OPERATIONCAUTIONS&WARNINGS
CRIMESTOPPERSECURITYPRODUCTS,INC. and its VENDORS shall notbe liablefor anyaccidentresulting
fromthe useofthisequipment. Thissystemisdesigned tobe professionallyinstalled intoacarorvehicleinwhich
all items,suchasparking brakeand all associated components,door switches,transmission shift linkage,throttle
linkage, and all engine safetyfeatures, are inperfect working condition.
ITISABSOLUTELYTHEOWNER’SSOLERESPONSIBILITYTO: A)Understand the operation ofthissystem
and itssafetyfeatures.B)Check for proper operation ofthe systemprior toaccepting deliveryofthe vehiclefrom
the installation facility.C)Check and maintainthe condition ofthe vehicleand all itemsrelativetothe proper
operation ofthissystemand itssafetyfeatures.D)Always leavethe doorsand windowsclosed and locked to
protect against accidentsand theft.
DONOTremote startthevehicleinaclosedgarage. Makesure thatthe garage door isopen or there is
adequateventilation.Failure toobservethisrulecouldresultininjuryordeath frompoisonousCarbonMonoxide
fumes

3
USINGTHEREMOTECONTROL
RS1-G5 RS3-G5
RS1-G5: The transmitter supplied withthissystemisasinglebutton remotecontrol.
RS3-G5: The transmitter supplied withthissystemhas4verticalbuttons–Lock,Unlock,VehicleSelectandStart.
Toeliminatethe possibilityofaccidentallystarting the vehicle,there are (3) choicesfor button press selection.
Option #6 will allowyou tochange whether the RemoteStarter isactivated bya:
1.DoublePress –2pressesof Start button.
2.*Single½second press (Default).
3.Press and HoldStart button 2seconds.
*Default=1singlepress Start*
Please consultyourinstallertochangeprogrammableoptions
VEH

4
USINGTHE5BUTTONREMOTECONTROL
VEH
UNLOCK
START
DISARM/
ARM/
LOCK
TRUNK
VEHICLE
SELECT
REMOTEVALET =LOCK +UNLOCK (4seconds)
Option 27 has3choicesfor RemoteValet.
1.DoublePress.
2.4Second Press (Default).
3.OFF (no RemoteValet).
NOTE:TheVEHbutton canbeusedtokeepremote control fromaccidentallyoperating yourvehicle..
FM1-WAY
VEH1=Green LED
VEH2=Red LED
AUXOutputsthru Data
AUX1=Trunk+Lock
AUX2=Trunk+Unlock
AUX3=Trunk+Start
AUX4=Lock +Start
(Requires CanbusData Module)
AM1-WAY
VEH1=BlueLED
VEH2=Red LED

5
USINGTHE2-WAYPAGERTRANSMITTER
POWEROFF FUNCTION
Toturn Power ON, press and holdunlockbutton 2seconds.
Toturn Power OFF, press and holdunlockbutton 5seconds.
ValetMode
BatteryLife
SensorWarning
SensorTrigger
TransmitSignal
TrunkOpen
RemoteStarted
Hood Open
DoorOpen
Lock/Unlock
(Arm/Disarm)
Ignition ON
Silentnobeeps
CLOCK/
LCD SCREENICONS
(Small Hammer)
(BigHammer)
Note:
SomeIconsontheLCD displayonlyfunction
ontheComboAlarmwithRemoteStart
LOCK/ARM UNLOCK/ DISARM
(Tools)
RunCountDown
USBCharger
SIDEBUTTONS
TRUNK
VEHICLE
REMOTE
(UnderSideCover)
START
SELECT
RELEASE
AUXOutputsthru Data
AUX1=Trunk+Lock
AUX2=Trunk+Unlock
AUX3=Trunk+Start
AUX4=Lock +Start
Thisremotecan controlup to4AUX
functionsthru datadepending on the
vehicleand datamodule. Thisistypically
used for operating left and right sliding
doors. (Requires CanbusData Module)

6
USINGTHE2-WAYPAGERTRANSMITTER
The 2-WayLCD Pager remotetransceiver isused tosend and receiveinformation fromthe vehicle. The
ControlModuletransmitsHigh FrequencyFMsignalsfromthe vehicletoyour pager over long distances. Your
range will varydepending on location, terrain, and localRFnoise/interference. Thissystemisnot guaranteed to
page you if you are behind concretewalls, underground, inalarge structure, or inan area withhigh levelsof
electronicinterference. Handlethe pager/remotewithcare. The LCD displayand/or the electronics maybe
damaged if subjected toabuse.
BATTERYCHARGING
The2-WayLCDremotehasabatterychargeindicatorontoprightcornerofdisplay.Thebatteryvoltageaffectsthe
distanceoftheremotecontrol.ThesystemcomeswithastandardMiniUSBchargingcablethatplugsintotheside
of remotecontrol. Toaccess toUSB plug, slide the cover tothe left shownbelow.
SETTINGTHECLOCK (2-WAY- LCD REMOTE)
1.Press VEHButton on the side of the remotecontrol5times.
2.The remotewill beep and the AMorPM displaywill beginflashing.
3.Press the TrunkButton togo tothe next item –AM-PM-Hour-Minutes.
4.Press the Lock Button to Increase time.
5.Press the Unlock Button to decrease time.
6.Press the Start Button to DisableorEnableBeepand Vibration. See next page.
7.Press the VEHButton to Save and ExitSetup orwait 8seconds, the LCD light will turnoff.
USBCharging Port

7
REMOTEBEEP &VIBRATESELECTION
The LCD pager remoteBEEPS and VIBRATES when it receivesasignalfromthe vehicle. The Beepsand
Vibration are selectable(on/off). Toenter programmode,
1.Press VEHButton on the side of the remotecontrol5times.
2.The remotewill beep and the AMorPM displaywill beginflashing.
3.Press the Start button tochoosethe mode of “Beep ON/OFF &VibrateON/OFF”.
4.Press the VEHButton to Save and ExitSetup orwait 8seconds, the LCD light will turnoff.
Mode 1: Beep ON&VibrateON. RemoteStart Run TimeReminder Beep ON&VibrateON.
Mode 2: Beep ON&VibrateOFF. RemoteStart Run TimeReminder Beep ON&VibrateOFF.
Mode 3: Beep OFF &VibrateON. RemoteStart Run TimeReminder Beep OFF &VibrateON.
Mode 4: Beep OFF &VibrateOFF. RemoteStart Run TimeReminder Beep OFF &VibrateOFF.
Mode 5: Beep ON&VibrateOFF. RemoteStart Run TimeReminder Beep OFF &VibrateOFF.
Mode 6: Beep OFF &VibrateON. RemoteStart Run TimeReminder Beep OFF &VibrateOFF.

8
STATUSLED
LEDOperation:(Optional, requires Installation ofLED)
LEDwill flashwhen locking your doorswithremote.
LEDwill remainsolidinValet ServiceMode.
REMOTEENGINECONTROL
REMOTESTARTButton Press Selection (Option #6):
Toeliminatethe possibilityofaccidentallystarting the vehicle,there are (3) optionsforbuttonpressselection.This
option allowsyou tochange whether the Remotestarter isactivated bya:
4.Doublebutton -½second presses.
5.*Single½second press (Default).
6.Press and Hold2seconds.
*Default=1singlepress*
REMOTEENGINESTARTING -SUCCESSFULSTART:
1) Press the remotestart button for at least 1/2second (*default). Parking lightsflashonce, return solid,and the
Ignition/Acc circuitsturn on.
2) After afewsecondsthe Starter Motor engages.The parking lightsand Acc circuitswill turn off whilecranking.
3) Engine Startsand Runs. Parking Lightsand Acc turnsbackon, and the doorslock.
4) Engine will remainrunning for programmed run timeuntil resetwithBrakepedal.Ifneeded,the engine can be
turned off withremotetransmitter bypressing and releasing the Start button.
Note:Whenthevehicleremote starts, the2-WayPagerwill displaytheenginerun inplace oftheClock.
AFTER
IGN
3
STARTER
THEN
FLASH1X
SOLID
SOLID
SEC.
PRESS START

9
REMOTEENGINECONTROL
REMOTEENGINESTARTING -UNSUCCESSFULSTART
Inthe eventthatthe engine doesnotstarton the firstattempt, the systemshutsdownfor afewseconds,then
attemptstorestartthe engine a2nd and 3rd time.Forhardstartingengines,theunitwillallowastartercranktimeof
upto4secondsmaximum.Thisshouldprovideamplecrankingtimefordifficultstarts,butislimitedto4secondsto
helpprevent damage tothe starter fromover cranking.
1) If engine startson 2nd or 3rd attempt, see steps4&5of "SuccessfulStart"on page 7.
2) IfThird attemptfailstostartengine,the systemwill turn off and doorswill remainlocked.NOFURTHER
ATTEMPTSWILL BE MADEAUTOMATICALLY
TURNING OFF AREMOTESTARTEDENGINE:
1) Engine isrunning inRemoteStart (Parking lightsON).
2) Press and releasethe remotestart button or doublepress (If option #6 ison).
3) Engine &parking lightsOFF, Doorsre-lock/re-arm.
ENTERING YOUR REMOTESTARTEDVEHICLE:
1) Withengine running, Unlocksystemwithremote(If equipped) or open door withkey.
2) Enter vehicleand be carefulnot tostep on brakepedal!(RemoteStart Reset)
3) Turn Ignition toON/RUN position, then press brakepedaltoreset the RemoteStarter &Shift out of park.
4) Remotestarter will resetinstantlywhen the brakeispressed.Parking lightswill turn off and the ignition keyis
nowcontrolling your vehicle.
REMOTESTART RUN TIMERESET:
The RemoteStart Run Timeisadjustablefrom5to30 minutes(option #20). Somelocalcities
havearun timelimit for unattended vehicle. You can nowreset the engine-run timer toallowfor more running
timeafter remotestart hasalreadyoccurred using the remotecontrol. After asuccessfulremotestart, press
boththe Lock&Unlockbuttonstogether for at least 2seconds. The parking lightswill flash3timesand
internalengine timer will reset backtozero minutes.
LOCK withREMOTESTARTand AfterREMOTESTARTABORT:
Option#8controlswhetherthesystemwillautomaticallylockduringandafteraremoteStartabortortime-out.This
feature can be turned OFF. The default isLockwithRemoteStart.

10
REMOTEENGINECONTROL
IDLEDOWNMODE:
Thismodeallowstheunittotakeoveroperationoftheparkedvehiclewhiletheignitionkeyisremovedandyouexit
the vehicle.The vehiclewill remainrunning for the programmedtimeoruntilcanceled.TheRunTimechoicesare:
10, 20, 30 minutesor InfinityRun. Default=20 minutes
Examples:
•You pull up toaconveniencestore for aquick stop,“IdleDown”mode keepsengine running when you exitthe
vehicle,(withkeysinhand)remotelockdoors.Whenyoureturn,unlock,turnignitionONanddriveaway.NOTE:
If lock button ispressed twicein“IdleDown”mode, the remotestart will abort.
IDLEDOWNMODE-EXITING THEVEHICLE:
1) Withvehicleengine running withkey, press the RemoteStart button for at least one second or twiceif set for
Doublepress.
2) Parking Lightswill turn ON.
3) Doorswill unlock, or if brakepedalisbeing depressed, doorswill unlockwhen it isreleased.
4) Turn OFF Ignition and removekey. Engine shouldremainrunning.
5) Exit vehicleand remotelockdoorsif desired. Locking doorsa2nd timeabortsremotestart.
6) Engine will remainrunning for programmed run timeor until you return (whichever comesfirst).
IGN
SOLID
OFF
UNLOCK
PRESSSTART
IDLEDOWNINFINITYRUN MODE:
IdleDowncanbeprogrammedforINFINITYRUN.ThisallowsthevehicleenginetoremainrunningINDEFINITELY
withouttheignitionkeyintheswitch.Theparkinglightscontinuouslyflashinthismode.Thismodecanbebeneficial
tolawenforcement or commercialtrucksthat need toremainrunning unattended for long periodsof time.

11
REMOTEENGINECONTROL
SELECTABLEHOURLYCOLD-STARTMODE(1-4 HOURS)
Thismode allowsthe vehicletobe programmed toself-startevery1,2,3or 4hoursand run for the programmed
run time. Thiscan be helpfulduring extremelycoldconditionswhere engine fluidfreeze-up isaconcern.
TIMEDSELF-STARTMODE–Exiting theVehicle:
1) Engine shouldbe running withthe Key.Press the RemoteStartbutton for atleast1second.Lightswill turn on
signaling the remotestart hasturned on and doorswill unlock.
2) Within10 secondspress and releasethe valet/programbutton oncefor eachhourlyincrement(1 time=1hour,
2X=2hours, 3X=every3hours, 4X=every4hours).
3) Parking Lightswill turn ONwhen the button ispressed and flashoncefor eachconsecutivebutton press.
4) Turn Ignition switchOFF, removekeyand exit the vehicle. Engine shouldremainrunning.
5) Onceoutside the vehicle,press and releasethe remotestartbutton toturn off engine.The parking lightswill
flashthe number of timesindicating the hourlyincrement for confirmation. The vehiclewill startbyitselfatthe
selected hourlyincrement until driven withkeyor started viathe remotecontrol.
IGN
SOLID
OFF
UNLOCK
PRESS1 -4X
WITHIN 10 SEC.
LIGHTSFLASH
foreachpress
ENGINETURNSOFF
FLASHHourIncrement
RESETTING TIMEDSELF-STARTMODE:
Toreset the timed self-start mode, start vehicleusing the ignition keyor the remotecontrol.

12
TURBOTIMERMODE(OPTION#22)
The optionalTurbo Timer mode allowsthe CoolStart systemtokeep aTurbo or Turbo Dieselvehiclerunning
for 1, 3or 5minutes[selectively] after you removethe keyand exit the vehicle. Thisishandyfor turbo cool-
downwithout the need for expensiveturbo timers. The Default=OFF.
To Activate Turbo Timer:
Withthe engine running bykey, press Remote StartButton withbrake pedal depressed. Asyou releasethe
brakepedal, the Parking Lightsand StatusLEDwill blinkthe number of minutesfor the Turbo Timer setting.
The doorsunlockafter confirmation.
REMOVE KEY
FLASH 1-5X
EXIT VEH.
PRESS
AND HOLD
BRAKE
RUNNING RELEASE
BRAKE
LIGHTS
RUNNING
REMAIN
1-5 MIN.
PRESSSTART

13
MANUAL TRANSMISSIONMODE(Option 11)
MANUALTRANSMISSIONEXITPROCEDURE(Option #11-1, 11-3 &11-4)
ThissystemfeaturesaManualTransmission Mode. When exiting the vehicle, there issafetycheckout
procedure required for the manualtransmission mode towork. There are 3choicesof operation,
1. Option 11-1: Withengine running and vehicleinneutral,setparking brake,then press “KEY” Icon on
transmitter.The remotestarter will turn on and takeover operation ofthe vehicle.Press lockbutton after
closing last door tofinishexit procedure (sameassteps a, b, cand d below).
2. Option 11-3: Withenginerunningandvehicleinneutral,setparkingbrake,theremotestarterwillturnonand
takeover operation of the vehicle.
a. Removekey,exitvehicle(remotestarter unitmust“SEE”door opened,then closed withengine
running).
b. Press Lockbutton within10 secondsofclosing door to“ArmwithIdleDown” (engine staysrunning).
Press Locka2nd timetocancel“IdleDown” (engine turnsoff)and setup ManualTransmission Mode.
c. PressLockbuttonafter10secondstoArmsystem,lockthedoorsandshutdowntheengine.Fromthis
point, you can remotestart the engine unless adoor isopened.
d. Press the RemoteStartButton after closing door tosetupManualTransmissionModewithoutArming
AlarmSystem.
3.Option 11-4: Withenginerunningandvehicleinneutral,setparkingbrake,theremotestarterwillturnonand
takeover operation ofthe vehicle.RemoveKeyand exitvehicle.When the lastdoor ofvehicleisclosed,the
engine will turn off in2secondsand setup ManualTransmission Mode. You can armthe alarmsystemto
lockdoorsand protect vehicle.
TURBO TIMERinManual Transmission Mode:
ForTurboTimer,pressbrakepedalbeforesettingparkingbrake,thenpresstheRemoteStartIcon(requiresTurbo
Timer Option #22).After exiting vehicle,press lockbutton tosetManualTransmission Mode.The engine will
remainrunningfortheTurboTimersetting(1,3or5minutes).Turbotimerdoesnotworkwithoption11-4selected
REMOTEPANIC(Optional, hornmust beconnected)
For personalsafetythisunitnowincludesapanicfeature.Tosoundthevehiclecarhorn,presstheLockButtonon
the remotefor more than 2seconds.The vehiclehorn will honkalong withflashing parking lampsfor 1minute.
Reset RemotePanicbypressing either the lockor unlockbutton.

14
CONVENIENCEAND SAFETYFEATURES
KEYLESS ENTRY(PowerDoorLocks, mayrequireData Module-Optional)
Thissystemenablesyou toremotelylockand unlockthe vehicle’sdoors(ifequipped withpower locks)viaremote
controlfor safetyand convenience.Note:Thisfeature mayrequire extra labor and/or partstoinstall.Press the
LockorUnlocktransmitterbuttonasyouleaveorcomenearthevehicle.ParkinglightswillflashonceforLockand
twicefor Unlock.The parking lightswill turn on for 30 secondswithUnlocktoassistinlocating and providing
illuminationnearyourvehiclewhenapproachingatnightforsafety.Theparkinglightalsoturnsoffwithignitionon.If
vehicleisrunning bythe remotestart system, the lightswill flash, but return backtosolid.
AUTO LOCK / UNLOCK (Option #2)
TheAutoLockfeaturecontrolswhetherthedoorswillautomaticallylock/unlockonyourvehiclewhendrivingorwith
turning the Ignition ON/OFF.Ifthe AutoLockfeature isturned on,and your systemisin“Tach” mode,then the
doorsshouldautomaticallylockasthe engine RPM’sincrease(driving).Ifthe AutoLockfeature isturned on,and
your systemisin“SmartTachless”mode,then the doorswill lockafewsecondsafter the Ignition isturned on.
When the AutoLockfeature isturned on, the systemwill alwaysunlockthe doorswhen the Ignition isturned off.
Withthisfeature turned OFF,the systemwill notautomaticallylockor unlockthe vehicle.See your installer for
programming information on thisfeature.
HORN CHIRPS (Option #7, 13 &16)
Ifvehiclehornsare connected tothe system,theywill provide audibleconfirmation chirpsfor lockand unlockand
remotestart.Thechirpsoundcanbeprogrammedfromshorttolongtoadjustfordifferentsoundinghorns.Pressing
theLockorUnlockbutton(Programmableoptionfor1or2Press)willprovideahornchirpforaudibleconfirmation.
The systemcan alsobeprogrammedtoprovide3chirpswhenaremotestartisrequestedusingtheremote.Note:
Horn honk/chirp feature mayrequire extra labor and/or partstoinstall.
Option 7=ChirpswithRemoteStart On/Off.
Option 13 =1or 2button press for Chirp withLock/ Unlock.
Option 16 =Short, mediumor long Chirp Pulse(15, 20 or 40 milliseconds).
OEMALARMINTERFACE(Mayrequireoptional DatabusModule)
Thisfeature isdesigned toDisarmandRe-armFactoryequippedsecuritysystemsinconjunctionwithremotestart
and keyless entry(if needed for your vehicle). Thisfeature will maintainthe originalintegrityand securityofyour
vehicle’sfactoryequippedsystemsbefore,during,orafterremotestart.SomevehiclesrequireanoptionalDatabus
moduletooperateafactoryalarmor keyless entry.

15
CONVENIENCEAND SAFETYFEATURES
REMOTETRUNK RELEASE ORDOMELIGHTILLUMINATION(Option 9)
Thissystemincludesan outputthatcanbeprogrammedtoremotelyreleaseafactoryelectronictrunkorilluminate
the interior lightwhen you unlockyour vehiclefor lighted entryatnight. Ifyou havetheoptionaltrunkpopinstalled,
simplypress and releasethe TrunkButton #3 on the transmitter toremotelyopen trunk.Ifyour systemis
programmedforDomeLightillumination,thenitwillworkautomaticallylightingthedomelightfor30secondswhen
you unlockyour vehicleviathe remote.The domelightwill turn off after 30 seconds,or turning the keyon
(whichever comesfirst).Toeliminatethe possibilityofaccidentallyopening the trunk,there are (3) optionsfor
button press selection. Thisoption will allowyou tochange whether the Trunkreleaseactivatesbya:
1.Doublepress (2 x½second presses).
2.Single½second press. *Default*
3.Press and Hold2seconds. Thisoutput stayson until trunkbutton isreleased.
VALETMODE
Before servicing your vehicleor handing the keysover toaValetwerecommend putting the unitintoValetMode.
The RemoteStart function WILL NOToperatewhen inValet Mode.
1. To Activate Valet ModeManually: TurntheignitiononandpresstheValetbutton[about5-6seconds]until
the LEDturnson solid. Repeat the process toexit VALETmode.
2. To Activate Valet ModewiththeRemote (SelectableOption 27): Default=Press &Hold
Press boththe Lock and Unlock Buttonsand holdtogether for about3-4 (ordoublepress)
secondsuntil 3chirpsare heard (horn mustbe connectedforchirps). Repeatthissteptoexitviatheremote
transmitter.Lock /Unlock and AUXfeatureswill still operateinVALETMode however RemoteStartis
inhibited.
HOODOPENSAFETY(Requires hood pinswitch)
Thispreventsremotestarting engine when hood isopen.Iteliminatesriskofinjurytosomeone working under the
hoodofthevehiclewithaproperlyworkinghoodpininstalled.IfRemoteStartbuttonispressedwiththehoodopen,
the parking lightswill flashtwiceand the unitwill notattemptastart. The systemwill abortRemoteStartanytime
the hood isopened. See RemoteStart Diagnostics on page 19.
BRAKEPEDALRESET:
Preventsremotestarting or turnsoff aremotestarted vehiclewhen the brakepedalispressed.Thisprevents
UnauthorizedDrivingofVehicle.Thiscircuitshutsthesystemdownimmediatelywhenbrakepedalispressed.Turn
the ignition keytothe “ON”position before the brakepedalispressed.

16
TRANSMITTERPROGRAMMINGon 1BUTTON
Note: All transmittercodes must belearnedat timeofprogramming!! TheRS1-G5learnsup to4different
transmittercodes.
1.Turn Ignition Keytothe ONposition.
2.Press Programming button 4times, then after afewsecondsthe unit flashesthe parking lights4times.
3.Press the start button of the first transmitter. You shouldget 1light flashconfirming the remoteiscoded,then
press the startbutton ofasecond transmitter,the unitwill flash2timesconfirming the remoteiscoded and so
on.Ifall 4codesare learned, the unit will automaticallyexit code learning mode, otherwiseturn keyoff. See
diagrambelow.
IGN
OFF
WAITFOR
4FLASHES
PRESS 4X's
FLASH2, 3, or 4X's
IGN
OFF
PRESS STARTBUTTON

17
TRANSMITTERPROGRAMMINGon 4&5BUTTON
Note: All transmittercodes must belearnedat timeofprogramming!! TheCoolStartsystemlearnsupto4
differenttransmittercodes.
4.Turn ignition keytothe ONposition.
5.Press Programming button 4times, after afewsecondsthe unit flashesthe parking lights4times.
6.PressLockbuttonofthefirsttransmitter.Youshouldget1lightflashconfirmingtheremoteiscoded,thenpress
Lockbutton ofasecond transmitter,the unitwill flash2timesconfirming the remoteiscoded and soon.Ifall 4
codesare learned,the unitwill automaticallyexitcode learning mode,otherwiseturn keyoff. See diagram
below.
IGN
OFF
WAIT FOR
4FLASHES
PRESS4X's
FLASH2, 3,or4X's
IGN
OFF
COMPLETE
PRESS LOCK

18
2VEHICLEOPERATION
Your remoteshavethe abilitytocontrolasecond vehiclewithaCrimestopper systeminstalled.
Toset up the 2-Vehicleoperation you must first programyour remotestoVehicle#2. Followthe “Transmitter
Programming”steps(Pg. 15) at the second vehicleand learn YOUR remote, along withvehicle#2’sexisting
remotes.
2-VEHCLENOTES:
(1) You do not havetoswitchbetween Vehicle“1”and “2”toget pagesfromeachvehicle. Your remotepager
will receivepagesfrombothcarsregardless of whichvehiclethe pager isset to. The “1”or “2”icon will always
displaywitheachpage indicatewhichvehiclethe page originated from.
(2) All 1-Wayand 2-WayPagersfor thatvehiclemustbe learned atthe timeofprogramming (up to4).When you
programyour remoteatthe second vehicle,thatvehicle’soriginalremotemustalsobeprogrammed.Yourremote
shouldbe set inVehicle“2” and the vehicle’soriginalremoteshouldbe set inVehicle“1”.
VEH1/VEH2
CLOCK SET Push2Seconds
tochangefrom
Vehicle1to2
VEHICLE1=GREENLED
VEHICLE2=REDLED
Push2Seconds
tochangefrom
Vehicle1to2 VEHICLE SELECT
PushVEHButton5
Times tosetClock
VEHICLE1=1-1
VEHICLE2=2-1
1-Way FMREMOTE
LCDREMOTE
VEH
1-Way AM REMOTE
VEHICLE1=BLUELED
VEHICLE2=RED LED
Note:Use canuse Vehicle2Modetoturnoff remote ifthereisno systeminstalledina2nd vehicle.
AMSYSTEMS: Option 27-1 must beselectedfor2-VehicleMode
VEHICLE
ICON

19
NOFACTORYKEYLESS ENTRYAFTERREMOTESTART
MostnewcarsDoNotallowthefactoryRemoteKeylessEntrytofunctionwiththeIgnitionON.Thismeansyoucan’t
usethe factoryremotetolockor unlockthe doors.After remotestartyou havetousethe keystounlockthe door.
Also,manynewvehiclesunlockthe doorswhendisarmingthefactoryalarm.Thisleavesthedoorsunlockedwhile
RemoteStarted. Toresolvethisproblem,haveyour installer connectthe door lockstothe RemoteStartKeyless
Entry. The RemoteStarter will Re-Lockthe doorsafter remotestarting (programmable).
When you return toaremotestarted vehicle,justpress the Unlockbutton on the remotecontrol.OnRS1-G5,the
Start button can be programmed tounlockthe doors(option 23-1), Consult your installer.
Note: Thereare3Remote StartOptions(see page7).Theoptionsare: 1/2second press (Default),2second
press orDoublebutton press.
REMOTESTART DIAGNOSTICS
Ifthesystemflashes theLEDand Parking Lights onetoseventimes and doesn’tattemptremote start.The
LEDwill continuetoflashtheerrorcodeuntil theignition isturnedon, itmeansthefollowing:
1Parking LightFlash(1 LEDFlash)=ProblemwithBrake Switch.
2Parking LightFlashes (2 LEDFlashes) =ProblemwithHood Switch.
3Parking LightFlashes (SolidLED)=Valet Service Mode.
5Parking LightFlashes (5 LEDFlashes) =Ignition orTachProblem.
7Parking LightFlashes (7 LEDFlashes) =Manual Transmission Error.
Besure totell your installer the Diagnosticcode when taking vehicleinfor service
SYSTEMISUNSUCCESSFULATREMOTESTARTDURING EXTREMECOLDCONDITIONS:
Pleasebeawarethatduringsub-freezingconditionsyourremotestartermaytakemorethatoneattempttostartorit
maynotsuccessfullystartthe vehicleafter 3attempts.During theseconditionsthe vehiclemaynotproperlystart
even using the key; therefore trying tostart bythe remotewouldalsobe unsuccessful.

20
2-WayDATAPORT
Somevehiclesrequire aDatabusModuletoBypass the factoryImmobilizer and operatethe keyless entry
Databusmodulesare used tocommunicatewiththe vehiclescomputer at the OBD2Dataconnector or Canbus
wires. Thisreducesinstallation error. Crimestopper SystemswithDPSerieshaveadirect DataPort Plug-Infor
the Databusbypass module. Thiseliminatesconventionalwiring between the Alarm/RemoteStarter and the
bypass interfacemodule.
Features Include
•Transponder Immobilizer.
•PassLockImmobilizer.
•O.E.M. AlarmControl.
•R.A.P. Shutdown.
•Power Door Locks.
•PriorityUnlock.
•TrunkRelease.
•Sliding Doors.
•Parking Lights.
•CourtesyLights.
•Tachometer.
•Heated Seats.
•Rear Defrost.
•Driver 1and 2Memorypresets.
The actualfeaturescontrolled depend on the vehicleand Databusmodule.
SMART PHONEDATAPORT
ThisunitincludesaSmartPhoneDataPort.Thisisthewhite4pinplugonsideofmodule,seepage25forlocation.
Thisis“Direct DatatoData” Plug-Infor the MS3Smart Phone interfacemodule.Noother wiring isrequired.The
MS3ispurchasedseparately.ThisisanAPPbasedsystemforasmartphonewiththesamefunctionsasanormal
remotecontrol.
