Crivit 290935 User manual

IAN 290935IAN 290935
ELECTRONIC DARTBOARD
ELEKTRONIK-DART
Spiel- und Bedienungsanleitung
ELECTRONIC DARTBOARD
Playing and user instructions
ELEKTRONIKUS DARTS TÁBLA
Játékszabály és használati útmutató
ELEKTRONICKÉ ŠIPKY
Návod ke hře a obsluze
ELEKTRONSKI PIKADO
Navodila za igranje in uporabo
ELEKTRONICKÉ ŠÍPKY
Návod na hru a obsuhu
GB Instructions and Safety Notice Page 8
HU Használati és biztonsági tudnivalók 22. Oldal
SI Navodila za uporabo in varnostni napotki Strani 37
CZ Pokyny k používání a bezpečnostní upozornění Stránky 51
SK Pokyny na obsluhu a bezpečnostné pokyny Stranu 65
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 79
Before reading, fold out the illustration page and get to know all of the functions of your unit.
Elolvasás előtt hajtsa ki az oldalt az ábrákkal és ezt követően ismerkedjen meg a készülék valamennyi
funkciójával.
Preden začnete brati, odprite stran s slikami in se seznanite z vsemi funkcijami naprave.
Před čtením si nejdříve vyklopte stránku s obrázky a seznamte se se všemi funkcemi přístroje.
Skôr než začnete návod čítať, si ho otvorte na strane s obrázkami a oboznámte sa so všetkými
funkciami prístroja.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit
allen Funktionen des Artikels vertraut.
DELTA-SPORT HANDELSKONTOR GMBH
Wragekamp 6 • DE-22397 Hamburg
GERMANY
09/2017
Delta-Sport-Nr.: DS-1532

B C
Tip Grip Shaft Flight
Hegy Test Szár Toll
Konica Držalo Glavni Del Krilce
Špička Držátko Stopka Křídlo
Hrot Násadka Telo Letka
Spitze Griff Schaft Flügel
D
A

5

6
Scope of Delivery .............................. 8
Technical data .................................... 8
Intended use ...................................... 8
Safety instructions ......................... 8 - 9
Safety instructions power adapter ..... 9
Assembly instructions ........................ 9
Assembly of the dartboard ................................ 9
Assembly of the darts ......................................... 9
Name and function of parts ............. 10
Operation of the dartboard ....... 10 - 12
Switching on and off ........................................ 10
Function keys .............................................. 10 - 11
Game selection and list of the
difficulty levels (Table 1) .................................. 12
Game rules ...................................... 13
Games ....................................... 13 - 20
Troubleshooting ......................... 20 - 21
Maintenance, care, storage ............. 21
Disposal .......................................... 21
Notes on the guarantee
and service handling ........................ 21
Contents/Tartalomjegyzék/Kazalo/Obsah
A csomag tartalma ............................22
Műszaki adatok ................................22
Rendeltetésszerű használat ...............22
Biztonsági tudnivalók ................. 22 - 23
Biztonsági tudnivalók hálózati
adapter .............................................23
Szerelési útmutató .............................23
A dart tábla felszerelése ....................................23
A dartok felszerelése ..........................................23
A részek megnevezése és funkciója ...24
A dart tábla használata .............. 24 - 26
Be- kikapcsolás....................................................24
Funkciós gombok ........................................24 - 25
Játék kiválasztása és a nehézségi fokozatok
listája (1. táblázat) ..............................................26
A játék menete ..................................27
Játékok ...................................... 27 - 34
Hibakeresés ......................................35
Karbantartás, ápolás, tárolás ...........35
Hulladékkezelés ................................36
A garanciával és a szerviz lebon-
yolításával kapcsolatos útmutató ......36
Obsah dodávky ................................ 51
Technické údaje ................................. 51
Použití k určenému účelu ................... 51
Bezpečnostní upozornění ............51 - 52
Bezpečnostní upozornění k síťovému
adaptéru ...........................................52
Návod k montáži...............................52
Montáž terče .......................................................52
Montáž šipek ......................................................52
Popis a funkce jednotlivých dílů .........53
Obsluha terče ............................. 53 - 55
Zapnutí a vypnutí ................................................53
Funkční tlačítka ............................................53 - 54
Volba hry a listina stupňů obtížnosti
(tabulka 1) ..........................................................55
Průběh hry ........................................56
Hry ............................................. 56 - 63
Hledání chyby ...................................63
Údržba, ošetřování a uchováváni ......64
Pokyny k likvidaci .............................64
Pokyny k záruce a průběhu služby ....64
Obseg dobave ................................... 37
Tehnični podatki ................................37
Predvidena uporaba .........................37
Varnostni napotki ........................37 - 38
Varnostni napotki mrežni
napajalnik .........................................38
Navodila za montažo ........................38
Montaža tarče za pikado ..................................38
Sestavitev puščic za pikado ..............................38
Oznaka in funkcija delov ...................39
Upravljanje s tarčo .....................39 - 41
Vklop/izklop .......................................................39
Funkcijske tipke............................................39 - 40
Izbira igre in seznam težavnostnih
stopenj (tabela 1) ............................................... 41
Potek igre .........................................42
Igre ............................................ 42 - 48
Iskanje napake..................................49
Vzdrževanje, nega, shranjevanje ......49
Napotki za odstranitev .....................50
Napotki za garancijo in izvajanje
servisne storitve ................................50

7
Obsah/Inhaltsverzeichnis
Obsah balenia ...................................65
Technické údaje .................................65
Použitie podľa predpisov ..................65
Bezpečnostné pokyny ................ 65 - 66
Bezpečnostné pokyny pre sieťový
adaptér ............................................66
Návod na montáž .............................66
Montáž terča .....................................................66
Montáž šípiek .....................................................66
Označenie a funkcia častí ..................67
Obsluha terča .............................67 - 69
Zapnutie a vypnutie ............................................67
Tlačidlá funkcií ............................................67 - 68
Voľba hry a zoznam stupňov obtiažností
(tabuľka č. 1) ......................................................69
Priebeh hry .......................................70
Hry ............................................. 70 - 77
Vyhľadávanie chýb .................... 77 - 78
Údržba, ošetrovanie, skladovanie .... 78
Pokyny k likvidácii ............................78
Pokyny k záruke a priebehu servisu .78
Lieferumfang ................................... 79
Technische Daten ............................. 79
Bestimmungsgemäße Verwendung . 79
Sicherheitshinweise ................... 79 - 80
Sicherheitshinweise Netzadapter .... 80
Montageanleitung ........................... 80
Montage des Dartboards ................................ 80
Montage der Darts ........................................... 80
Bezeichnung und Funktion der Teile . 81
Bedienung des Dartboards ........ 81 - 83
Ein- / Ausschalten ............................................. 81
Funktionstasten .......................................... 81 - 82
Spielauswahl und Liste der
Spieloptionen (Tabelle 1) ................................ 83
Spielablauf ...................................... 84
Spiele ........................................ 84 - 92
Fehlersuche ..................................... 92
Wartung, Pflege, Aufbewahrung ..... 93
Hinweise zur Entsorgung ................. 93
Hinweise zur Garantie
und Serviceabwicklung ................... 93

8 GB
Congratulations on purchasing this
high-quality product. Be sure to familiarise
yourself with the assembly instructions prior
to use.
Please take the time to carefully
read through the following playing
and user instructions and safety
notes.
Only use the product as described and for
the intended use. Please retain these instruc-
tions for future reference and ensure that
they are passed on to any third party.
Scope of Delivery
1 x playing and user instructions
1 x electronic dartboard
12 x shafts (3 each in blue, green, red,
and black)
12 x grip
12 x flights (3 each in blue/white,
green/white, red/white, and
black/white)
112 x soft tips (tip)
1 x power adapter
4 x screws & wall plug
1 x scratch line
1 x drilling template
Technical data
Electronic Dartboard
Model: DS-1532
Dimensions:
approx. 420 x 517 x 26mm (W x H x D)
Power rating: 9V DC 300mA
= Safety class III
Power adapter
Model: EU: ASSA105E-090030
Model: UK: ASSA105B-090030
Input: 100-240 V – 50/60 Hz 0,35 A
Output: 9V 300mA
= Safety class II
Date of manufacture (month/year):
09/2017
Intended use
This dartboard product is a sports item and
is not suitable for children under 14-years-
old! The item contains small parts which
could be swallowed by children and, as
sports equipment, it requires pin-point accu-
racy and concentration, as well as a high
level of motor skills.
The item has been designed for private use
indoors, and is not intended for commercial
use or for use outdoors. This item is to be
used exclusively with darts fitted with soft
tips. If used with darts fitted with steel tips
this will cause irreparable damage. Remove
the protective film from the dartboard.
Safety instructions
Danger of injury!
• This item is not suitable for use by people
(including children) with limited physical,
sensory or mental abilities or with a lack
of experience and/or a lack of know-
ledge, unless they are supervised by a
person responsible for their safety, or
receive instruction from a responsible
person on how to use the apparatus.
• Children should be supervised to ensure
that they do not play with the item.
• Do not throw or aim the darts at people
or animals.
• When in use make sure that the dart-
board is positioned or arranged in such
a way, that as far as possible, people will
not wander between the dartboard and
the player.
• Do not attach the dartboard to a door!
•Do not use metal tips!

9GB
• The external connection cable from this
transformer cannot be substituted; if the
cable is damaged, the transformer will
have to be scrapped.
Assembly instructions
Assembly of the dartboard
(Illustration B, C)
1. Select a suitable position with approx.
3m free space around it.
2. The ‘scratch line’ must be at a distance of
2.37m from the dartboard. Fix the dart
board to the wall so that the centre of the
Bullseye is at a height of 1.73m above
the ground.
3. Using the enclosed drilling template,
mark the respective drill holes with a
pencil. The markings “+”indicate the
direction to mount the dartboard in. The
markings “O” indicate openings on the
dartboard for permanent wall mounting.
Mount the dartboard using either the
mounting device (3 screws) or permanent
wall mounting (4 screws). The cross at
the centre of the drill template indicates
the position of the bullseye on the dart
board. Then mount the dartboard using
the included screws and wall plugs.
Assembly of the darts
(Illustration D)
Screw the tip and shaft together as indica-
ted into the grip and insert the unfolded
flight into the cross-slots.
Avoiding material damage!
• Use exclusively proper original replace-
ment tips, in order to avoid the darts
ricocheting off the dartboard. We strongly
recommend you do not use long tips for
electronic dartboards. They quickly buck-
le and easily break (Removing broken-off
tips from the dartboard – Trouble-
shooting, page 20 - 21).
• Do not allow the item to be exposed to
extreme weather conditions and tempera-
tures.
• Protect the item from moisture and damp-
ness. The electronics could be damaged.
Safety instructions power
adapter
ATTENTION
Important information for use of the
adapter!
Note: The device gets warm during
normal use.
• Only use the adapter in connection with
the Dartboard DS-1532.
• Only use the supplied adapter!
• Only use original spare parts in the event
of a defect!
• First unplug the adapter from the wall
socket before disconnecting the adapter
from the dartboard.
• The adapter is suitable for indoor use
only. Keep away from moisture.
• If the housing or the power lead of the
device is damaged, discontinue using the
adapter.
• Disconnect the device from the mains if
not used over a longer period of time.
• The mains output line is not allowed to be
short-circuited.

10 GB
Function keys (Illustration A)
GAME
Press this button to choose a game.
On the left results display the game displa-
yed (G01-27, see table 1, page 12); on the
right results display the first option of the
game is displayed.
OPTION
Press this key to select various options within
a game (see table 1, page 12).
PLAYER / SCORE
Press the PLAYER/SCORE button in order to
select the number of players before starting
to play.
Press the PLAYER/SCORE button during a
game to display the points for all players.
Press 1x to show players 1 and 2
Press 2x to show players 3 and 4
Press 3x to show players 5 and 6
Press 4x to show players 7 and 8
Press 5x to show players 9 and 10
Press 6x to show players 11 and 12
Press 7x to show players 13 and 14
Press 8x to show players 15 and 16
The number of players will be displayed
on the scoreboard using the corresponding
lights.
HANDICAP
Press the HANDICAP button in order to
select different levels of difficulty / options
for different players before start of play.
Example:
You wish to play the game G01 with 3
players (all with different handicaps).
Press the GAME button until the game G01
is displayed to the left of the results display.
Select 2 fellow players by pressing the
PLAYER/SCORE button once.
Select 3 fellow players by pressing the
PLAYER/SCORE button twice.
Name and function of parts
(Illustration A, C)
1 Single: Score as indicated
2 Double: Number of points x 2
3 Triple: Number of points x 3
4 Bullseye: Outer ring is worth 25 points;
the inner ring is worth 50 points
5 Catcher: Edge throw, no point
6 Function keys (see chapter Function
keys, page 54 - 55)
7 Results display: Shows in rotation the
target / information, hit, total points
result, and which player‘s turn it is
8 Dart indicator: Shows how many throws
(darts) the player still has left
9 Scoreboard
10 Display for Double In (DI),
Double Out (DO) and for the
game Count Down
11 Plug for power adapter
12 Dart holder
13 Bracket
14 Drill holes
Operation of the dartboard
Switching on and off
The article is provided with an automatic
shut off.
To switch on the article connect the power
adapter to the socket and the dartboard.
If the article is not used for longer than 10
minutes, the display and systems switch off
automatically (standby mode). When the
power adapter is plugged in, the article
“remembers” the last score. Pressing any
button will switch the article on again.
Remove the plug to shutdown the article
completely.

11GB
Press the HANDICAP button twice to set
the handicap for player 3 from 101 to 301.
Then press the PLAYER/SCORE button
14 times in order to get to the setting for
player 1 (players 4-16 are skipped). Press
the HANDICAP button once in order to
set the handicap for player 1 from 101 to
201. Press the PLAYER/SCORE button once
in order to select player 2 and press the
HANDICAP button 5 times in order to set
the handicap for player 2 from 101 to 601.
Press the PLAYER/SCORE button once in
order to go back to player 3.
Press the START/NEXT button in order to
begin the game.
ELIMINATE / TEAM
Press the ELIMINATE/TEAM button in
order to set team play before beginning the
game (2 against 2, 3 against 3, 4 against
4, 5 against 5, 6 against 6, 7 against 7, 8
against 8).
If this button is pressed during a game then
the last throw by one player is eliminated.
CYBER MATCH
Press this button to play a game against a
virtual opponent. By repeatedly pressing
the button adjust the skill level of your virtu-
al opponent (C1 = hardest opponent -
C5 = easiest opponent).
DOUBLE
Press this key to enable the function Double
In or Double Out for game G01.
Press 1x: Double In
(red light on the left scoreboard, 10)
Press 2x: Double Out
(red light on the left scoreboard, 10)
Press 3x: with Double In, Double Out
(two red lights on the left scoreboard, 10)
Press 4x: without double In, double Out
(no red lights)
START / NEXT
Press this button to start a game or to move
to the next player during a game.
SOUND / VOLUME
Default setting: SOUND/VOLUME level 3.
Press the SOUND/VOLUME button in
order to choose between 7 volume levels or
to switch the sound off.
The SOUND/VOLUME level is shown on
the display.
MISS
Press this button to reduce the number of
the remaining darts, when the dartboard is
missed.

12 GB
Game selection and list of the difficulty levels (Table 1)
