Cross 2017-74 User manual

Instruction Manual Model 2017-74
Up/Downconverter
October 2010 Rev. B
MENU
EXECUTE
MODEL 2017
CROSS TECHNOLOGIES INC.
U F=6850.000 G=+10
D F=4600.000 G=+30
MUTE
UPCONVERTERDOWNCONVERTER
REMOTEALARM POWER ALARM
UP/DOWNCONVERTER
Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc., but may be
reproduced or duplicated without the prior permission of Cross Technologies, Inc. for purposes of operating
the equipment.
When ordering parts from Cross Technologies, Inc., be sure to include the equipment model number,
equipment serial number, and a description of the part.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]

Instruction Manual
MODEL 2017-74 Up/Downconverter
TABLE OF CONTENTS PAGE
Warranty 2
1.0 General 3
1.1 Equipment Description 3
1.2 Technical Characteristics 4
1.3 Monitor & Control Interface 5
1.4 Use Information 8
2.0 Installation 9
2.1 Mechanical 9
2.2 Rear I/O’s 10
2.3 Front Panel Controls, Indicators 11
2.4 Operation 12
2.5 Menu Settings 13
WARRANTY - The following warranty applies to all Cross Technologies, Inc. products.
All Cross Technologies, Inc. products are warranted against defective materials and
workmanship for a period of one year after shipment to customer. Cross Technologies, Inc.’s
obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s option,
replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall not be
liable for any special, indirect, or consequential damages. This warranty does not cover parts
or equipment which have been subject to misuse, negligence, or accident by the customer
during use. All shipping costs for warranty repairs will be prepaid by the customer. There
are not other warranties, express or implied, except as stated herein.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
2017-74 Manual, Rev. B Page 2 10/27/10

Model 2017-74 Up/Downconverter
1.0 General
1.1 Equipment Description
The 2017-74 C-band Up/Downconverter converts 70 MHz to 6.7 - 7.025 GHz (Up) and 4.5 - 4.8 GHz to 70
MHz (Down) in 0.125 MHz steps with low group delay and flat frequency response. A common synthesized
local oscillator (LO) provides frequency selection for the Up and Down converter simultaneously. Multi-
function push button switches select the RF frequency, gain, and other parameters. Front panel LEDs provide
indication of DC power (green), PLL alarm for up and downconverters (red), remote operation (yellow), and
Upconverter mute (yellow). Gain can be manually controlled over a 0 to +30 dB range for the upconverter and
over a +30 to +50 dB range for the downconverter as adjusted by the front panel multi-function push-button
switches. Remote operation allows selection of frequency and gain. Parameter selection and frequency and gain
settings appear on the LCD display. Connectors are BNC female for IF and the optional external reference input
and output, and N female for RF. A high stability (±0.01ppm) option is also available. It is powered by a 100-
240 ± 10% VAC power supply and housed in a 1.75” X 19” X 16” 1RU chassis.
MENU
EXECUTE
MODEL 2017
CROSS TECHNOLOGIES INC.
U F=6850.000 G=+10
D F=4600.000 G=+30
MUTE
UPCONVERTERDOWNCONVERTER
REMOTEALARM POWER ALARM
UP/DOWNCONVERTER
FRONT PANEL
AC UPCONVERTER
GND
DOWNCONVERTER
J4J3J18
10 MHZ REF 10 MHZ IF IN
EXT REF
J1
IF OUT OUTPUT INPUT
J10
AND
MONITOR
CONTROL
15 234 6789
RF OUT
RF IN
J5J2
REAR PANEL
Figure 1.1 Front and Rear Panels
70
MHz
OUT
4.5
to
4.8
GHz
IN
CONTROLLER U F=6850.000 G=+10
D F=4600.000 G=+30
70
MHz
IN
6.7
to
7.025
GHz
OUT
REF REF
REF
TO UP
VCOS
var
atten EXT
10MHz*
*OPTIONAL
var
atten var atten
INT
10MHz
Figure 1.2 Block Diagram
2017-74 Manual, Rev. B Page 3 10/27/10

1.2 Technical Characteristics
TABLE 1.0 Equipment Specifications*
--------UPCONVERTER--------
Input Characteristics (IF)
Impedance/Return Loss 75 /18 dB
Frequency 70 ± 18 MHZ
Input Level -40 to -10 dBm
Output Characteristics (RF)
Impedance/Return Loss 50 /14 dB
Frequency 6.7 to 7.025 GHz
Output level -20 to 0 dBm
Output 1 dB compression +10 dBm
Channel Characteristics
Gain range (adjustable) 0 dB to +30 dB
Frequency Sense Non-inverting
--------UP AND DOWNCONVERTER--------
Channel Characteristics
Frequency Response ±1.5 dB, in band; ± 0.5 dB, 36 MHz BW
Spurious Response <-50 dBC in band
Group Delay (max) 0.015 ns/MHz2parabolic; 0.05 ns/MHz linear; 1 ns ripple
Synthesizer Characteristics
Frequency Accuracy ± 0.01 ppm max over temp internal reference
Frequency Step 1 MHz (125 kHz Frequency Steps (option X)
10 MHz Level (In/Out) +3 dBm ± 3 dB (option -E)
-100-90-80-70-60
1MHz100kHz10kHz1kHz100 Hz
dBC/Hz
Phase Noise
@
Fre
q
Controls, Indicators
Frequency Selection direct readout LCD; manual or remote selection
Gain Selection direct readout LCD; manual or remote selection
Power Green LED
Down/Up Alarm Red LEDs
Up Mute Yellow LED
Remote Yellow LED; RS232C, 9600 baud (RS485, option -Q)
Other
RF Connectors Type N (female), (see Table 2.2 for connector options)
IF Connectors BNC (female), (see Table 2.2 for connector options)
10 MHz Connectors BNC (female), 50/75(option -E)
Alarm/Remote Connector DB9 (female), NO or NC contact closure on Alarm
Size 19”1RU standard chassis, 1.75”H X 16.0”D
Power 100 - 240 ±10% VAC, 47-63 Hz, 45 watts max
Options
E External 10 MHz Reference with RF insertion
O Frequency Reference Offset Adjust
L LNB Voltage, +24VDC, 0.4 amps
V SSPB Voltage, +24VDC, 2.5 amps
Q RS485 Remote Interface
T PCB Temperature Sensor
W8 Ethernet M&C Remote Interface with Web Browser
W18 Ethernet M&C Remote Interface with Web Browser & SNMP
X 125 kHz Frequency Steps
X1 100 kHz Frequency steps
Connectors/Impedance See Table 2.2, Page 10
*+10˚C to +40˚C; Specifications subject to change without notice
2017-74 Manual, Rev. B Page 4 10/27/10
--------DOWNCONVERTER--------
Input Characteristics (RF)
Impedance/Return Loss 50 /14 dB
Frequency 4.5 to 4.8 GHz
Noise Figure (max) 15 dB @ max gain
Input Level -60 to -30 dBm
Input 1 dB compression -10 dBm @ min gain
Output Characteristics (IF)
Impedance/Return Loss 75 /18 dB
Frequency 70 ± 18 MHz
Output level range -10 to 0 dBm
Output 1 dB compression +10 dBm
Channel Characteristics
Gain range (adjustable) +30 dB to +50 dB
Image rejection > 50 dB, min
Freq Sense (selectable) Non-inverting

1.3 Monitor and Control Interface
A) Remote serial interface
Protocol: RS-232C, 9600 baud rate, no parity, 8 data bits, 1 start bit, and 1 stop bit.
(RS-232C, RS-422, or RS-485 - option -Q)
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
Female DB-9
PC Com Port Male DB-9
2015/16/17 M&CPort
M&C Cable Diagram - Cross Technologies Frequency Converters
Connector: Rear panel, DB-9 female
J10 Pinouts
Pinouts (RS-232C/422/485)
Pin Function
1Rx-
2 Rx+ (RS-232C)
3 Tx+ (RS-232C)
4Tx-
5GND
6 Alarm Relay: Common
7 Alarm Relay: Normally Open
8NotUsed
9 Alarm Relay: Normally Closed
2017-74 Manual, Rev. B Page 5 10/27/10
