Crowcon Clip SGD User manual

User manual
M07716
Issue 1
October 2017
Clip SGD
Portable single Gas Detector

⚠WARNING
•฀฀฀Clip฀SGD฀is฀a฀hazardous฀area฀certied฀gas฀detector฀and฀as฀such฀must฀be฀operated฀and฀maintained฀in฀strict฀accordance฀with฀the฀instructions,฀warnings฀and฀label฀information฀included฀in฀the฀manual.฀•฀฀฀Before฀operating฀this฀device,฀please฀read฀carefully฀and฀understand฀all฀instructions฀in฀the฀manual.•฀฀฀Understand฀the฀screen฀display฀and฀alarm฀warnings฀prior฀to฀use.•฀฀฀Before฀use,฀please฀check฀the฀activation฀date,฀and฀if฀the฀activation฀date฀has฀expired฀please฀do฀not฀use฀the฀device.฀•฀฀฀Before฀use฀ensure฀that฀the฀device฀is฀in฀good฀condition฀and฀the฀enclosure,฀the฀display฀window,฀alarm฀LED฀windows฀and฀sounder฀aperture฀are฀undamaged฀and฀clear฀from฀contaminants.฀•฀฀฀Before฀use฀perform฀the฀self-test฀of฀the฀LED’s,฀sounder฀and฀vibrator.•฀฀฀Bump฀test฀the฀device฀regularly฀by฀applying฀a฀gas฀concentration฀exceeding฀the฀alarm฀set฀point.฀It฀is฀recommended฀that฀a฀bump฀test฀is฀performed฀at฀least฀every฀90฀days.•฀฀฀For฀the฀O2฀detector฀perform฀a฀calibration฀every฀30฀days฀in฀a฀fresh฀air฀environment.•฀฀฀If฀the฀device฀fails฀a฀bump฀test,฀calibration฀or฀self-test฀please฀do฀not฀use฀the฀device.฀•฀฀฀Do฀not฀disassemble฀or฀substitute฀components,฀or฀operate฀beyond฀the฀intended฀range฀of฀use฀as฀this฀may฀impair฀intrinsic฀safety,฀invalidate฀safety฀certication฀and฀will฀void฀the฀warranty.•฀฀฀Do฀not฀attempt฀to฀replace฀the฀battery฀or฀sensor฀as฀the฀Clip฀SGD฀is฀designed฀to฀be฀maintenance฀free฀and฀disposable.฀Changing฀the฀battery฀or฀sensor฀may฀impair฀intrinsic฀safety,฀invalidate฀safety฀certication฀and฀will฀void฀the฀warranty.•฀฀฀Use฀IR฀communications฀only฀in฀a฀safe฀area฀that฀is฀free฀from฀hazardous฀gases•฀฀฀To฀prevent฀the฀generation฀of฀static฀electricity฀do฀not฀clean฀or฀rub฀the฀LCD฀screen฀of฀the฀device฀with฀a฀dry฀cloth฀or฀hands฀in฀a฀hazardous฀area฀environment฀•฀฀฀Perform฀cleaning฀and฀maintenance฀of฀the฀device฀in฀a฀safe฀area฀only฀that฀is฀free฀from฀hazardous฀gases.•฀฀The฀Clip฀SGD฀is฀shipped฀with฀default฀alarm฀level฀settings.฀It฀is฀the฀users฀responsibility฀to฀ensure฀the฀alarm฀level฀settings฀are฀appropriate฀for฀the฀specic฀application;฀these฀can฀be฀changed฀as฀required฀via฀the฀IR_฀Link฀_PC฀Software.•฀฀฀Gas฀concentration฀measurements฀by฀the฀sensor฀can฀vary฀based฀on฀the฀environment฀(temperature,฀pressure฀and฀humidity).฀Therefore฀calibration฀of฀Clip฀SGD฀should฀be฀performed฀in฀the฀same฀(or฀similar)฀environment฀of฀the฀device’s฀actual฀use.•฀฀฀Severe฀vibration฀or฀shock฀to฀the฀device฀may฀cause฀a฀sudden฀gas฀reading฀change.฀Please฀use฀Clip฀SGD฀after฀the฀value฀of฀gas฀concentration฀has฀stabilized.•฀฀฀Excessive฀shock฀to฀Clip฀SGD฀can฀cause฀the฀device฀and/or฀sensor฀to฀malfunction.•฀฀฀If฀the฀temperature฀changes฀sharply฀during฀use฀of฀the฀device฀(for฀example฀moving฀from฀indoors฀to฀outdoors),฀the฀value฀of฀the฀measured฀gas฀concentration฀can฀suddenly฀change.฀Please฀use฀the฀Clip฀SGD฀after฀the฀gas฀concentration฀value฀has฀stabilized.•฀฀฀The฀device฀is฀intended฀for฀use฀in฀normal฀atmospheric฀conditions,฀pressure฀80฀kPa฀(0.8฀bar)฀to฀110฀kPa฀(1.1฀bar);฀and฀air฀with฀normal฀oxygen฀content,฀typically฀21฀%฀v/v฀(volume/volume).

⚠CAUTION
•฀฀฀This฀device฀is฀not฀a฀measurement฀device,฀but฀a฀gas฀detector.฀•฀฀฀Clean฀detectors฀with฀a฀soft฀cloth฀and฀do฀not฀use฀chemical฀substances฀for฀cleaning.฀•฀฀฀To฀ensure฀a฀24฀months฀battery฀life฀is฀attained฀it฀is฀important฀to฀avoid฀the฀following฀activities฀as฀this฀will฀deplete฀the฀battery฀lifetime฀to฀less฀than฀24฀months.1. Allowing the detector to be in gas alarm frequently or for prolonged periods
(Normal Alarm Use: No more than 4 minutes alarm time per day)
2. Operating the detector user button frequently.
3. Connecting the detector with the Clip SGD IR Link frequently, except for regular bump
testing.
•฀฀฀View฀a฀serial฀number฀on฀the฀label฀at฀the฀back฀side฀of฀the฀device.฀(ex,฀20170101)1. The serial number indicates below.
ex)฀SG฀01฀01฀001฀2017(Year)฀01(Months)฀฀01(Day)฀001(Manufacture฀Order)

Table of Contents
1.฀Diagram฀and฀LCD฀...............................................6
2.฀Activation฀...........................................................73.฀Mode฀..................................................................83.1฀Gas฀Measurement฀Mode฀...........................83.2฀Display฀Devise฀Settings฀..............................83.3฀Alarms฀and฀Alerts฀......................................84.฀Event฀Log฀.........................................................115.฀Calibration฀........................................................125.1฀Fresh฀Air฀Calibration฀................................125.2฀Standard฀Gas฀Calibration฀........................135.3฀Return฀to฀Gas฀Measurement฀Mode฀.........146.฀Specification฀.....................................................157.฀Self฀Test฀and฀Bump฀Test฀....................................167.1฀Self฀test฀...................................................167.2฀Bump฀Test฀...............................................168.฀Certificates฀.......................................................18Appendix฀1฀Clip฀SGD฀Docking฀Station฀฀...................19Appendix฀2฀IR฀Link฀User฀Guide฀...............................26
Limited฀Warranty฀....................................................29

6
Clip SGD
1. Diagram and LCD 1.฀IR฀Port2.฀LCD฀display3.฀Alarm฀LED4.฀Buzzer5.฀Button6.฀Gas฀sensor7.฀Gas฀TypeLCD display symbols
ALARM Alarm฀conditionMMonths฀remaining฀1Low฀alarm฀DDays฀remaining฀
2
High฀alarm฀TTime฀remaining฀(hours)vTest฀success
MAX
Maximum฀peak฀valuexTest฀failure
MN
I
Minimum฀peak฀valueFresh฀air฀calibration
LEL
PPM
VOL
%
%
Measurement฀UnitStandard฀gas฀calibrationLow฀battery฀life฀(Less฀than฀30฀days)1
2
4
5
6
7
3
3
3
MAX
LEL
PPM
VOL
%
%
MN
I
ALARM 1V
M
D
T
X
2

7
Clip SGD
2. Activation
Only activate in a safe environment.฀Press฀the฀button฀for฀3฀secs;฀gas฀type฀and฀rmware฀version฀(e.g.฀v2.2)฀will฀be฀displayed.฀Following฀the฀10฀secs฀countdown,฀the฀device฀will฀be฀fully฀activated,฀the฀V฀icon฀will฀ash฀on฀the฀display฀screen฀and฀the฀device฀will฀be฀in฀Gas฀Measurement฀mode.After฀turning฀on฀the฀device,฀the฀remaining฀life฀is฀displayed;฀23฀months฀originally.฀After฀the฀remaining฀life฀reaches฀1฀month,฀30฀days฀remaining฀is฀displayed.฀When฀1฀day฀is฀left,฀24฀hours(T)฀remaining฀is฀displayed.⚠CAUTION
Before฀use,฀check฀the฀activate฀by฀date฀on฀the฀box.฀If฀the฀activation฀date฀is฀past,฀do฀not฀activate฀the฀device.Shelf฀Life฀within฀6฀months฀from฀manufacture.V
%
D
X
MAX
LEL
PPM
VOL
%
%
MN
I
ALARM 1V
M
D
T
X
2
%
T
⚠CAUTION
Appropriate฀calibration฀of฀the฀device฀is฀required฀prior฀to฀operation.฀Always฀ensure฀that฀the฀device฀responds฀correctly฀to฀the฀relevant฀gas.฀Verify฀that฀foreign฀materials฀that฀could฀interfere฀with฀the฀detection฀of฀gas฀are฀not฀blocking฀the฀sensor.In฀the฀event฀that฀activation฀of฀the฀device฀fails,฀the฀฀X฀฀icon฀will฀appear฀on฀the฀display฀and฀Gas฀Measurement฀mode฀will฀not฀be฀entered.฀In฀this฀case,฀perform฀calibration฀or฀contact฀authorized฀reseller฀or฀Crowcon฀Detection฀Instruments฀customer฀support฀at฀+44฀(0)฀1235฀557711฀for฀repair/return฀information.

8
Clip SGD
3. Mode
3.1 Gas Measurement Mode
Following฀activation฀the฀device฀will฀operate฀in฀Gas฀Measurement฀Mode.฀The฀remaining฀sensor฀life฀(default฀setting)฀or฀gas฀concentration฀(congurable฀option)฀will฀be฀displayed฀on฀the฀screen.฀Oxygen฀concentration฀is฀displayed฀in฀percent฀by฀volume฀(%Vol)฀and฀toxic฀concentration฀is฀displayed฀in฀parts฀per฀million฀(PPM).3.2 Display Device Settings
In฀Gas฀Measurement฀Mode฀to฀view฀the฀device฀settings฀press฀the฀button฀to฀cycle฀through฀the฀settings.฀The฀settings฀will฀be฀displayed฀in฀the฀following฀order฀upon฀each฀button฀press.฀VOL
%
VOL
%
MN
I
MAX
VOL
%
MAX
VOL
%
MN
I
Detection฀mode฀฀฀฀฀฀฀฀Min฀level฀seen฀(only฀for฀oxygen)Max฀level฀seenClear฀min/max฀levelsM
VOL
%
1
VOL
%
2
V
VOL
%
Remaining฀life฀(T,฀D,฀M)1st฀alarm฀set฀point2nd฀alarm฀set฀pointFirmware฀versionCalibration฀concentrationAt฀the฀last฀step฀the฀device฀will฀return฀to฀Gas฀Measurement฀Mode.3.3 Alarms and Alerts
When฀a฀gas฀concentration฀exceeds฀the฀congured฀alarm฀set฀points,฀1฀or฀
2
฀will฀be฀displayed฀on฀the฀screen,฀the฀device฀will฀vibrate,฀alarm฀LEDs฀will฀ash,฀and฀the฀buzzer฀will฀sound.฀The฀alarms฀will฀stop฀when฀the฀device฀is฀moved฀to฀a฀clean฀air฀environment.฀
%
M

9
Clip SGD
The฀table฀below฀shows฀the฀‘alarms’฀and฀‘alerts’฀that฀may฀be฀shown฀on฀the฀display฀during฀operation.฀AlarmAlarm฀StandardShown฀on฀LCD฀DisplayAlarm฀and฀Vibration฀DisplayLow฀AlarmExceeds฀1st฀Alarm฀set฀point1฀icon฀&฀concentrationBuzzer,฀LEDVibrationHigh฀AlarmExceeds฀2nd฀Alarm฀set฀point2฀icon฀&฀concentrationBuzzer,฀LEDVibrationRemaining฀lifeBelow฀30฀days฀icon฀Lifetime฀expiration฀Past฀24฀monthsService฀life฀is฀over฀(Replace฀with฀a฀new฀Clip฀SGD)Test฀failureFailure฀of฀sensor฀test฀/฀calibrationDisplay฀฀X฀฀icon฀with฀beepingBattery฀testLow฀powerBump฀testBump฀test฀periodVX Press฀the฀push฀button฀to฀turn฀off฀the฀alarmCalibrationCalibration฀periodPress฀the฀push฀button฀to฀turn฀off฀the฀alarm⚠CAUTION
Default฀alarm฀set฀points฀are฀based฀on฀common฀international฀standards.฀It฀is฀user฀responsibility฀to฀ensure฀the฀congured฀alarm฀set฀points฀are฀in฀accordance฀with฀local฀regulations฀and฀site฀procedures.฀

10
Clip SGD
Default Alarm Set Point
Gas Type CO H2S O2
Part
Number CL-C-25CL-C-30CL-C-35CL-H-2CL-H-5CL-H-10CL-O-19CL-O-19.5Lower
Alarm Level 25ppm30ppm35ppm2ppm5ppm10ppm19%19.5%Upper
Alarm Level 50ppm100ppm50ppm5ppm10ppm15ppm23.5%23.5%

11
Clip SGD
4. Event Log
The฀last฀30฀events฀are฀stored฀on฀a฀device.฀Once฀30฀events฀are฀stored,฀the฀log฀events฀are฀removed฀automatically฀in฀the฀order฀starting฀at฀Event฀1.฀The฀stored฀log฀events฀can฀be฀downloaded฀using฀the฀฀IR฀Link฀or฀the฀Docking฀Station฀(refer฀to฀Appendix฀1฀and฀2).฀Each฀alarm฀event฀records฀the฀following:฀•฀฀Alarm฀type฀(1st฀or฀2nd)•฀฀Alarm฀concentration฀in฀ppm฀or฀%•฀฀Peak฀concentrationEvent log

12
Clip SGD
5. Calibration
5.1 Fresh Air Calibration
To฀perform฀a฀Fresh฀Air฀Calibration฀press฀the฀button฀to฀navigate฀to฀Calibration฀Mode,฀the฀calibration฀icon฀will฀be฀displayed฀on฀the฀screen฀฀.•฀฀Press฀and฀hold฀the฀button฀for฀5฀seconds,฀‘CAL’฀and฀the฀fresh฀air฀calibration฀icon฀will฀be฀seen฀on฀the฀screen฀.฀•฀฀Press฀and฀hold฀the฀button฀for฀3฀seconds฀to฀initiate฀the฀Fresh฀Air฀Calibration.฀When฀the฀calibration฀begins,฀a฀countdown฀(starting฀at฀10)฀will฀be฀displayed฀on฀the฀screen.฀VOL
%
V
%
Press฀ESC฀to฀show฀Gas฀Measuremnt฀mode.Once฀completed,฀V฀icon฀will฀appear฀on฀the฀LCD.
%
Fresh Air Calibration
Standard Gas Calibration
⚠CAUTION
For฀O2฀units฀only.฀Initial฀calibration฀is฀performed฀on฀all฀devices฀prior฀to฀shipment.฀Once฀received,฀calibration฀should฀be฀performed฀monthly฀(or฀quarterly)฀depending฀on฀frequency฀of฀use.฀⚠CAUTION
Calibration฀should฀be฀performed฀in฀a฀fresh-air฀environment฀that฀is฀free฀from฀the฀inuence฀of฀other฀gases฀(calibration฀is฀assumed฀to฀be฀performed฀in฀an฀environment฀with฀a฀concentration฀of฀20.9%฀oxygen).฀It฀is฀also฀recommended฀that฀calibration฀should฀not฀be฀performed฀in฀a฀conned฀space.

13
Clip SGD
%
X
%
XIf฀calibration฀fails,฀X฀icon฀will฀appear฀on฀the฀display.฀If฀this฀continues,฀please฀contact฀the฀sales฀representative฀or฀Crowcon฀customer฀support.5.2 Standard Gas Calibration
To฀perform฀a฀Standard฀Gas฀Calibration,฀using฀the฀supplied฀calibration฀cap฀connect฀the฀appropriate฀gas฀cylinder฀to฀the฀device.•฀฀Press฀the฀button฀to฀navigate฀to฀Calibration฀Mode,฀the฀calibration฀icon฀will฀be฀shown,฀.฀•฀฀Press฀and฀hold฀the฀button฀for฀5฀seconds,฀‘CAL’฀and฀the฀fresh฀air฀calibration฀icon฀will฀be฀displayed฀on฀the฀screen,฀.฀•฀฀Press฀the฀button฀once฀until฀the฀calibration฀icon฀is฀shown,฀.฀•฀฀Press฀and฀hold฀the฀button฀for฀3฀seconds฀to฀initiate฀the฀Standard฀Calibration.฀When฀the฀calibration฀begins,฀a฀countdown฀(60฀seconds฀or฀more฀depending฀on฀the฀gas฀type)฀will฀appear฀on฀the฀screen.฀
%
VOL
%
VOL
%
V
%
V
%
Once฀completed,฀V฀icon฀will฀appear฀for฀several฀seconds฀on฀the฀display.฀The฀device฀will฀then฀return฀to฀Gas฀Measurement฀mode.
%
X
%
XIf฀calibration฀fails,฀X฀icon฀will฀appear฀on฀the฀display.฀If฀this฀continues,฀please฀contact฀the฀authorised฀reseller฀or฀the฀Crowcon฀customer฀support฀team.

14
Clip SGD
5.3 Return to Gas Measurement Mode
To฀return฀to฀Gas฀Measurement฀Mode฀from฀Calibration฀Mode,฀press฀the฀button฀to฀cycle฀through฀the฀Fresh฀Air฀Calibration฀฀and฀Standard฀Calibration฀฀screens฀until฀‘ESC’฀is฀shown฀on฀the฀display.Whilst฀‘ESC’฀is฀shown฀on฀the฀display฀press฀and฀hold฀the฀button฀for฀3฀seconds,฀the฀device฀will฀return฀to฀the฀Gas฀Measurement฀screen.VOL
%
%
Calibration concentration.
Gas O2CO H2S
Concentration 18%Vol100ppm25ppm

15
Clip SGD
6. Specification
Model Clip฀SGDMeasure Gas O2COH2SSensor range 0-30%Vol0-300ppm0-100ppmSensor Type ElectrochemicalMeasurement Diffusion฀typeDisplay LCD฀displayAudible 90dB฀at฀10cmWarning Lamp Red฀Flashing฀LEDs฀(Light-Emitting฀Diode)Vibration Vibration฀AlarmBattery Manufacture:฀Vitzrocell฀/฀P/N:฀SB-AA02(P)฀/฀System:฀Lithium฀Primary฀BatteryNominal฀voltage:฀3.6V฀/฀Nominal฀capacity:฀1.2AhTemperature &
Humidity -40°C฀to฀+50°C฀(for฀Toxic)฀/฀-35°C฀to฀+50°C฀(for฀O2)5%฀to฀95%฀RH฀(non-condensing)Ingress protection IP65฀and฀IP67Case Rubber฀EnclosureAccessories Calibration฀cap,฀manual,฀calibration฀and฀test฀certicateOption IR฀Link,฀Docking฀StationSize & Weight Size:฀54mm(W)฀x฀91mm(H)฀x฀32mm(D)Weight:฀93g฀(Toxic),฀104g฀(O2)฀(Battery,฀clip฀included)Operating Life 24฀months,฀based฀on฀4฀minutes฀of฀alarm฀per฀day฀(>2900฀Alarm฀minutes)Event Log Recent฀30฀alarmsApproval See฀Certication฀on฀฀page฀16

16
Clip SGD
7. Self Test and Bump Test
7.1 Self Test
The฀Clip฀SGD฀provides฀a฀Self฀Test฀function.The฀default฀interval฀of฀the฀Self฀Test฀reminder฀is฀20hrs.Use฀the฀IR฀Link฀or฀Docking฀Station฀to฀congure฀the฀interval฀between฀1hr฀and฀20hrs,฀or฀set฀to฀“off”.฀When฀the฀congured฀Self฀Test฀is฀due,฀“STS”฀will฀ash฀on฀the฀screen฀(the฀message฀will฀continue฀to฀ash฀until฀the฀user฀performs฀a฀successful฀Self฀Test).฀MAX
LEL
PPM
VOL
%
%
MN
I
ALARM 1V
M
D
T
X
2
PPM
1
PPM
2
•฀฀Press฀the฀button฀to฀initiate฀the฀Self฀Test฀function.The฀device฀will฀perform฀a฀self฀test฀by฀operating฀the฀buzzer,฀LED’s,฀vibrator฀and฀LCD.฀It฀will฀also฀show฀the฀congured฀low฀and฀high฀alarm฀set฀points฀on฀the฀display.฀After฀the฀test฀is฀completed,฀“END”฀will฀be฀displayed฀on฀the฀screen.฀(The฀user฀is฀required฀to฀check฀that฀the฀items฀operated฀in฀the฀self฀test,฀performed฀as฀expected).฀7.2 Bump Test
The฀device฀can฀be฀congured฀to฀provide฀an฀on฀screen฀Bump฀Test฀reminder.The฀default฀setting฀for฀the฀Bump฀Test฀reminder฀is฀“off”,฀no฀Bump฀Test฀reminder฀will฀be฀displayed.If฀a฀Bump฀Test฀reminder฀interval฀is฀required฀it฀can฀be฀congured฀using฀the฀IR฀Link฀or฀Docking฀Station.฀The฀interval฀can฀be฀congured฀from฀1฀day฀to฀365฀days.When฀congured฀and฀a฀Bump฀Test฀is฀due,฀the฀“bts”฀message฀be฀displayed฀and฀will฀ash฀on฀the฀screen.

17
Clip SGD
ALARM 1V
2
VOL
%
ALARM 1
2
VOL
%
ALARM 1
2
VOL
%
•฀฀Press฀and฀hold฀the฀button฀for฀3฀seconds,฀and฀the฀“tst”฀message฀will฀be฀displayed฀for฀45฀seconds฀(to฀cancel,฀press฀the฀button฀for฀one฀second).฀•฀฀Apply฀the฀gas฀using฀the฀calibration฀cap฀and฀gas฀tube฀within฀the฀45฀second฀period.฀If฀a฀Bump฀Test฀is฀not฀undertaken฀within฀this฀period฀the฀“bts”฀message฀will฀ash฀until฀a฀successful฀test฀is฀conducted.After฀the฀selected฀gas฀is฀applied฀and฀if฀the฀test฀is฀successful,฀the฀“SUC”฀message฀with฀the฀฀V฀฀icon฀will฀be฀displayed฀for฀3฀seconds฀then฀immediately฀return฀to฀Gas฀Measurement฀Mode.฀The฀calibration฀cap฀and฀gas฀tube฀can฀then฀be฀removed.If฀the฀test฀fails,฀the฀“FA”฀message฀with฀X฀icon฀will฀be฀displayed฀and฀“bts”฀message฀will฀ash฀until฀a฀successful฀test฀is฀conducted.X

18
Clip SGD
8. Certificates
The฀SGD฀Clip฀meets฀the฀following฀certications฀and฀standardsIECEx:Ex฀ia฀IIC฀T4฀Ga➀ ➁ ➂ ➃ ➄ 1:฀Explosion฀protected2:฀Protection฀Concept3:฀Gas฀Group4:฀Temperature฀Classication5:฀Equipment฀protection฀level฀Ex฀ia฀IIC฀T4฀GaClass฀I,฀Zone฀0,฀AEx฀ia฀IIC฀T4฀GaClass฀I,฀Division฀1,฀Groups฀A,฀B,฀C,฀D,฀T4ATEX:฀฀II฀1฀G฀Ex฀ia฀IIC฀T4฀GaKRH฀17฀ATEX฀0013Directive฀2014/34/EUStandardsThe฀electrical฀apparatus฀and฀any฀acceptable฀variations฀to฀it฀specied฀in฀the฀schedule฀of฀this฀certicate฀and฀the฀identied฀documents,฀was฀found฀to฀comply฀with฀the฀following฀standards:IEC฀60079-0:2011฀Ed6IEC฀60079-11:2011฀Ed6UL฀61010-1,Ed.฀3UL฀913,฀Ed.฀8UL฀60079-0,฀Ed.฀6UL฀60079-11,฀Ed.฀6C22.2฀No.฀60079-0:2015C22.2฀No.฀60079-11:2014C22.2฀No.฀61010-1-12:2012EN฀60079-0:2012+A11:2013EN60079-11:2012ComplianceElectromagnetic฀Compatibility฀Directive฀2014/30/EUManufacturing฀Approval:The฀detector฀manufacturer฀is฀certied฀compliant฀with฀ISO฀9001:2000฀provisions

19
Clip SGD
Appendix 1
Clip SGD Docking Station
User Manual
Clip SGD Docking Station Configuration
Users฀can฀change฀settings,฀upgrade฀rmware,฀and฀download฀log฀events฀through฀the฀Docking฀Station฀IR฀link฀(see฀Appendix฀2).฀

20
Clip SGD
Figure 1: Clip SGD Dock PC Application
IR / USB Disk
Chose฀either฀IR฀Link฀or฀USB฀Stick฀to฀transfer฀conguration฀to฀and฀from฀Docking฀Station.•฀฀Click฀‘IR’฀➀฀to฀congure฀Docking฀Station฀via฀the฀Clip฀SGD฀IR฀Link.฀•฀฀Click฀‘USB฀Disk’฀➁฀to฀select฀USB฀Stick฀connected฀to฀PC฀and฀transfer฀conguration฀to฀the฀USB฀Stick฀–฀this฀can฀then฀be฀inserted฀into฀the฀Docking฀Station฀and฀the฀conguration฀uploaded.฀•฀฀Info฀Read/Write:฀Select฀to฀‘Read’฀or฀‘Write’฀conguration฀➂฀to฀Docking฀Station฀via฀IR฀link฀or฀to฀USB฀Stick฀Docking Station
The฀layout฀of฀the฀Clip฀SGD฀Dock฀PC฀Application฀is฀shown฀above฀Figure฀1.•฀฀To฀interact฀with฀Docking฀Station฀via฀the฀Clip฀SGD฀IR฀Link,฀it฀must฀be฀turned฀on.฀•฀฀Ensure฀the฀PC฀has฀the฀Clip฀SGD฀Dock฀PC฀Application฀installed฀and฀connect฀the฀Clip฀SGD฀IR฀Link฀to฀the฀PC.฀•฀฀Place฀the฀topside฀of฀the฀Clip฀SGD฀IR฀Link฀face฀down฀in฀detector฀bay฀labelled฀฀“Unit฀1”.฀N.B.:฀The฀IR฀link฀only฀interacts฀with฀detector฀bay฀labelled฀“Unit฀1”.3
1 2
