Croydex AP5400 H Series User manual

AP5400##H
INCLUSIVE SHOWER CHAIR
ALL PRODUCT DIMENSIONS DETAILED IN THIS INSTALLATION AND MAINTENANCE
MANUAL ARE APPROXIMATE
ALL ILLUSTRATIONS OF THE PRODUCT ARE FOR REFERENCE ONLY. COMPONENTS
SUPPLIED WITH INDIVIDUAL PRODUCTS MAY DIFFER
CONTACT DETAILS
UK: Croydex, Central Way, Andover, Hampshire,
SP10 5AW, UK
EU: MIL, Unit 8 Purcellsinch Ind Est, Dublin Road,
Kilkenny, R95 HP71, Ireland
Tel: [phone]
Email: [e-mail]
www.croydex.com
- Always follow the instructions provided to ensure that your product is assembled and fitted safely, and
retains its high quality finish.
- Before attempting to fit or use this product, ensure that it can be properly installed in the desired
location.
ALWAYS RETAIN THIS MANUAL FOR FUTURE REFERENCE
SAFETY & PRODUCT CARE
1. DO NOT use power tools to assemble this product.
2. DO NOT exceed the maximum user weight indicated in the fitting instructions.
3. ALWAYS check the legs are level and locked in place and the arm rests and back rests are secure.
4. Only use on surfaces free from obstacles.
5. ALWAYS assemble in accordance with the instructions provided.
6. ALWAYS make sure all four feet are in contact with the supporting surface at all times.
7. DO NOT modify the shower chair and its components in any way.
8. DO NOT use the shower chair if damaged or altered in any way.
9. REMOVE the shower chair after use.
10. DO NOT stand or kneel on the shower chair.
11. DO NOT use abrasive or chemical cleaners as these may damage the product.
12. ALWAYS clean the product regularly with a soft damp cloth to retain the best quality finish.
S&H 086 R021
ALWAYS CHECK THE PACKAGING FOR FIXINGS AND PARTS BEFORE THROWING
AWAY AND RECYCLING.
ENSURE YOU HAVE ALL THE FIXINGS AND PARTS BEFORE ATTEMPTING TO
ASSEMBLE OR FIT THIS PRODUCT.

2.Firmly press all four adjustable legs into the bottom of the seat, ensuring that the adjustment
holes are facing inwards and the fixing holes on the
legs are aligned with the fixing holes in the seat. (See
fig. 2) Note: Ensure the thicker end of the leg is
slotted into the seat to ensure the fixing holes line
up and there is no movement.
1.Check all components are in the packaging. (See fig. 1)
INSTALLATION
S&H 086 R02
x1 Seat
x4 Adjustable Leg
x2 Bracket
x2 Arm Rest
x1 Back Rest
x2 Back Post
x2 Arm Rest screw
x4 Seat Plugs x4 Feet
Fig. 2
2
Fig. 1
5mm Hex Key
x4 Hex Socket
Screw
FIXING PACK
x4 Hex Socket
Screw
AB
3.Press the seat plugs into the fixing holes to secure the adjustable legs to the seat. (See fig. 3) Note:
Ensure the seat plugs are aligned and orientated
correctly.
Fig. 3

S&H 086 R02
6.Position the back posts over the screw holes in the back rest. Insert 4x screws 'B' and tighten with the
5mm Hex Key to secure in place. (See fig.6) DO NOT
OVER-TIGHTEN. Note: Ensure both back posts are
secured facing inwards.
Fig. 6
5mm
5.The height of the chair can be adjusted by depressing the locking button on each leg then
sliding the thinner leg section up or down. Ensure that
the locking button is relocated into one of the holes
and check that the adjustable leg is locked in place
before use . (See fig. 5) YOU MUST ensure that all
legs are fully secured and are at the same height
before use.
Fig. 5
4.Firmly press the feet onto the bottom of each adjustable leg. Ensure the feet are angled
outwards. (See fig. 4)
Fig. 4
3
7.To secure the back posts to the bottom of the chair first ensure the back rest is positioned against the
shortest side of the seat when viewed from above.
Then line up the fixing holes in the bottom of the seat
with the fixing holes in the back post. Insert 4x screws
'A' and use the 5mm Hex Key to tighten and secure the
back rest in place. (See fig. 7) DO NOT OVER-TIGHTEN.
Fig. 7
5mm
Fig. 5
Fig. 6
Fig. 6
Fig. 6

Fig. 10
10.The chair is fully assembled and ready to be used. (See fig. 10) Note: Ensure you have read
the safety and product care section before use.
Fig. 9
9.To secure the arm rest in position, insert the two tabs on the bracket through the slots in
the arm rest. Push the bracket down fully and insert
arm rest screw. Turn clockwise to secure the arm
rest in place. Repeat this for the other arm rest.
(See fig. 9)
8.Slot both arm rests into the sides of the chair. (See fig. 8)
Fig. 8
4 S&H 086 R02
9.a 9.b
9.c 9.d
MAX USER
WEIGHT:
175KG
386IB
