INSTRUCTION MANUAL
INDUSTRIAL BLENDER - TI6AL-160001-A1
IMPORTANT SAFEGUARDS
When using electrical appliances, basics safety precautions should always be
observed including the following:
-Before connecting your blender check if voltage of your power system
corresponds to the same specified on the appliance.
-To protect against risk of electrical shock, do not put cord, plug, base or
motor in water or other liquids.
-Never connect two or more appliances in the same plug.
-When not in use, unplug the blender.
-Avoid starting blender
-Avoid contact with moving parts because blades are sharp. "Handle
carefully".
-Keep hands and utensils out of container while blending to prevent the
possibility of severe personal injury and or damage to blender.Aplastic
spatula may be used but must be used only when blender is "NOT
RUNNING".
-Only remove the container when blender "COMPLETELY STOPPED".
-
INSTRUCTIONS FOR USE
-Blender control is made by two bottons: * White button (on/off)
* Red button (pulse)
-It is recommended to cut food in small pieces and maintain food below frieze
height to avoid spilling.
-To start blender place small quantity of food before connecting it, and afterwards
complete container placing food through service lid.
-For mixed dry ingredient use the pulse button first.
-When blender is running do not remove the lid.
-If blender action stops, turn blender off. Remove lid and use a plastic spatula
to push mixture toward blades. Replace lid and continue.
CLEANING PROCEDURE
-Clean container (cup) with liquid soap and water filling to half capacity.
-Turn on blender for some seconds.
-Turn off blender, empty the container and rinse it.
-Unplug blender clean body and external cup with a wet cloth.
-Do not use harsh detergent or chemical products for cleaning.
-To disassemble see Fig1
TI6AL-160001-A1
6AL6AL
6AL6AL
CROYDON
CROYDON
CROYDONMAQ INDUSTRIAL LTDA.
Estrada São Lourenço, 891 - Capivari - Duque de Caxias.
RJ - Brasil - CEP 25243-150 Fax: [phone]
Phone: [phone]
e-mail: [email protected]

Polyurethane Ring
Shaft Adapter
Retainer
(1/4) Screw
Washer
Body Cover
Screw
Switches’ Plate
60 HZ Motor
Washer
Body
Rubber Foot
Washer
Rivet
Cord Connection
Switch (on/off)
Wire Connection
Switch (pulse)
Service Lid
Lid (4l/6l)
Lid Seal (4l/6l)
Knife's Nut (Hex-3/8”)
Knife
Bushings (Chuck)
Rubber Ring
Container (6l)
Container's Base
Chuck Nut
Shaft
Retainer
Washer
Washer
Screw
Cord Retainer
Screw Ground
INDUSTRIAL BLENDER 6 LITERS
INDUSTRIAL BLENDER 6 LITERS
item code description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
37.023-3
37.044-3
37.063-3
343
589
37.043-3
552
37.025-3
37.304-3
641
37.042-3
3.000-3
647
680
14.094-3
37.041-3
37.091-3
37.072-3
37.031-3
37.051-3
37.707-3
37.033-3
37.908-3
37.083-3
37.062-3
37.320-3
37.078-3
37.058-3
37.079-3
9.410-3
643
594
534
9.413-3
----------
TI6AL
Technical Data
Power (HP) ½
Amperage (A) 7
Speed (rpm) 3465
Capacity (l) 6
Weight (Kg/lbs) 15/33
Dimension WxHxD (cm) 22x62x22
22
324
25
1
33 2
30
4
5
6
8
9
17
16
18
10
31
32
11
15 34
12
13
14
19
26
27
28
29
7
20
21
23
Wiring Diagram
35
Knife's Disassemble Procedure
Lock the shaft 29
with the special tool
and turn the nut 22
using the standard
tool (Hex.3/8”).
Remove the nut and
all the movable pieces
will be free.
22
29
standard
tool
special
tool
FIG1
It proceed to
reassemble in inverse
sequence.
L1
L2
G
OFF
ON PULSE
110V
1234
Voltage (V) 110
