croydon TR04 User manual

CROYDON
CROYDON
TR04-25524-700
TR04
TR04
FOOD BLENDER - MODEL: 524-700
IMPORTANT SAFEGUARDS
-When using electrical appliances, basic safety precautions should always be
observed including the following:
-Before connecting your blender check if voltage of your power system
corresponds to the same specified on the appliance.
-To protect against risk of electrical shock, do not put cord, plug, base or
motor in water or other liquids.
-Never connect two or more appliances in the same plug.
-When not in use, unplug the blender.
-Avoid contact with moving parts because blades are sharp. "Handle
carefully".
-Keep hands and utensils out of container while blending to prevent the
possibility of severe personal injury and or damage to blender.Aplastic
spatula may be used but only when blender is "NOT RUNNING".
-Only remove the container when blender "COMPLETELY STOPPED".
-
INSTRUCTIONS FOR USE
-It is recommended to cut food in small pieces and maintain food below 3/4 height
to avoid spilling.
-To start blender, place small quantity of food before connecting it, and afterwards
complete container.
-When blender is running do not remove the lid.
-If blender action stops, turn blender off. Remove lid and use a plastic spatula
to push mixture toward blades. Replace lid and start blender again.
CLEANING PROCEDURE
-Clean container (cup) with liquid soap and water filling to half capacity.
-Turn on blender for some seconds.
-Turn off blender, empty the container and rinse it.
-Unplug blender clean body and external cup with a wet cloth.
-Do not use harsh detergent or chemical products for cleaning.
TR04-25
INSTRUCTION MANUAL
C
R
N
O
O
Y D
The pictures/drawings are illustrations. All data can be changed without notification.
CROYDONMAQ INDUSTRIAL LTDA.
Estrada São Lourenço, 891 - Capivari
Duque de Caxias - RJ / Brasil - CEP 25243-150
Phone: [phone]
e-mail: [email protected] - www.croydon.com.br

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
37.014-3
37.543-3
37.524-3
37.566-3
37.562-3
37.565-3
37.558-3
37.316-3
37.563-3
37.561-3
604
643
3.000-3
4.063-3
381
4.044-3
2.093-3
37.116-3
359
37.325-3
567
37.000-3
37.317-3
534
37.545-3
597
37.510-3
37.584-3
635
642
9.410-3
CROYDON
CROYDON
1
2
4
5
6
7
8
9
10
15
26 25
24
23
21
20
17 19
11
12
18
14
13
12
11
27
27
22
3
16
28
29
30
31
INDUSTRIAL BLENDER 4 LITERS
INDUSTRIAL BLENDER 4 LITERS
Lid
Knife’s Nut
Knife
Retainer
Bushing
Rubber Ring
Container (4 liters)
Container’s Base
Nut
Shaft
Nut (3/16")
Washer (3/16")
Foot
Bottom Cover Plate
Screw 1/4
Base
Power Connection Cord
Switch
Screw 3/16”
Body
Screw (2.9)
Electric Motor
Container’s Support
Screw (1/4")
Shaft Adapter
Washer (1/4")
Friction Washer
Container Assembly
Nut M6
Washer(1/4")
Grease Retainer
Voltage (V)
Power (HP)
Amperage (A)
Speed (rpm)
Capacity (l)
Weight (kg/lbs)
Dimensions W x H x D (cm/in)
220 (50 Hz)
1/2
4.4
3500
4
9.7/21.3
25/9.8 x 65/25.6 x 21/8.3
Technical Data
TR04-25524-700
Wiring Diagram
L1
L2
G
OFF
ON
MOTOR
SWITCH
Item Code Description
