Spider-81 Random Test Quick Start Guide
Start Up
Power button is on the left side of the front panel of the Spider-81.
-Press the power button.
-Use an Ethernet cable to connect the Spider-81 to a PC running the EDM software.
Start EDM Software
-Click on Random to create a new random test.
Spider Configuration
-Click Tools->Spider Configuration
-On the next screen, click Create a new Spider System.
-Select one or more detected Spider module(s) to create a new system.
Create A New Test
-Press New Test button in the upper left to start creating a new test.
-Click on VCS tab to create a VCS test.
-Click on Random to create a random test.
-Select Spider System to be involved in this new test and press Finish to proceed to a new test window.

2370 Owen Street
Santa Clara, CA 95054
www.go-ci.com
Page 2 of 2
Input Channels
-Click Setup->Input Channels to setup input channels.
-All input channels related parameters can be edited at this step.
Measured Signals
-Click Setup->Measured Signals to select signals to be measured
and recorded.
Test Configuration
-Click Config button from the control panel to open a dialogue.
-Click Shaker Parameters to edit shaker parameters.
-Click other tabs to edit additional parameters if necessary.
Run A Test
-Press Run button from the control panel to start the test.
-Click window tabs to switch displayed signals.
