SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Model 682A14 & 682A15 4-20mA Din Rail ICP®Signal
Conditioner
Operating Guide with Enclosed Warranty Information
3425 Walden Avenue, Depew, New York 14043-2495
Phone [phone]
Fax [phone]
Toll Free Line 1-800-959-4IMI
MANUAL NUMBER: 72514
MANUAL REVISION: NR
ECN NUMBER: 50075
nbn Austria GmbH

PAGE 2
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Table of Contents
Introduction ...................................................................................................................... Page 3
Block Diagram ........................................................................................................... Page 3
General Features ........................................................................................................................................... Page 4
Installation and Wiring ..................................................................................................... Page 5
Configuring the 682A14 & 682A15 .................................................................................. Page 9
ESD Sensitivity............................................................................................................... Page 10
Warranty/Servicing
Warranty, Service & Return Procedure .......................................................................... Page 11
Customer Service........................................................................................................... Page 12

PAGE 3
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Introduction
Models 682A14 & 682A15 are 4-20mA din rail signal conditionersdesigned to interface with a 100 mV/g ICP®
accelerometer.
The signal is integrated, filtered and scaled. The 4-20mA output signal is proportional to overall velocity with a
measurement range of 0-1ips rms when using the 682A15 and ips peak when using the 682A14.
Block Diagram

PAGE 4
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
General Features
x External transmitters, signal conditioners and ICP® power supplies can be eliminated by direct connection
of the sensor to the din rail signal conditioner.
x24Vdc unregulated/20Vdc regulated (field-selectable), 4mA excitation to power sensor.
xCurrent (4-20mA) output signal for long-term process monitoring.
xAnalog output (raw vibration) signal for conducting frequency analysis and machinery diagnostics.
xLED indicators for power and sensor fault.
xRemovable terminal blocks for easy wiring.
x35mm (1.38in) din rail mount configuration.
xSpace-saving 22.5mm (0.9in.) wide design.

PAGE 5
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Installation and Wiring
Installation
Models 682A14 & 682A15 are designed to be mounted on a 35mm din rail. Do not install in a harsh area where it
can be exposed to cleaning fluids or machine oils. IMI Sensors recommends mounting models 682A14 & 682A15
in a NEMA 4 enclosure, such as Model 682A00, to protect the electronics from contamination.
Dimension Drawing

PAGE 6
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Connector and Pinout Diagram
Models 682A14 & 682A15 use plug-in type screw terminal connectors for all input and output connections. This
easy-to-assemble connection method allows devices to be exchanged easily and the electrical connection to be
visibly isolated.
Strip off 8mm of insulation from the connection wire ends. Using a flat head screwdriver, remove the terminal
block from the enclosure. Loosen the screw, insert the wire connection and tighten the screw. Do not exceed a
torque of 0.5 N-m. Re-install the terminal block.
Pin Location Diagram
WARNING
AC and DC input signals and power supply voltages could be hazardous.
DO NOT connect live wires to screw terminal plugs.
DO NOT insert, remove, or handle screw terminal plugs with live wires connected.

PAGE 7
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Pin Descriptions:
DC Power – Pins 5 and 6:
Pin 5 + Power
Pin 6 - Power (Common)
ICP® Sensor Input – Pins 1, 2 and 3:
Pin 1 + ICP® Sensor Input
Pin 2 - ICP® Sensor Input
Pin 3 Shield
Analog (Raw Vibration) Output –Pins 2 and 4 or BNC Jack:
Pin 2 - Raw Vibration
Pin 4 + Raw Vibration
Current (4 to 20mA) Output –Pins 7 and 8:
Pin 7 + 4 to 20 mA Vibration
Pin 8 - 4 to 20 mA Vibration
Notes:
xPin 3 is tied to the grounding tab on the back of the enclosure.
xLand the accelerometer cable’s shield on Pin 3.

PAGE 8
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Typical Wiring Diagram
To maintain conformance, Earth Ground, power supply common, input shields and
output shields must be connected together.

PAGE 9
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Configuring the 682A14 & 682A15
Sensor Power Jumper Configuration:
Regulated 20Vdc/4mA Power
(Factory Default)
Unregulated 24Vdc/4mA Power
(Constant Current Diode is internal to Model 682A14 & 682A15.)

PAGE 10
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Warning 1 –ESD sensitivity
The power supply/signal conditioner should not be opened by anyone other than qualified service
personnel. This product is intended for use by qualified personnel who recognize shock hazards and are familiar
with the safety precautions required to avoid injury.
Warning 2 –ESD sensitivity
This equipment is designed with user safety in mind; however, the protection provided by the equipment may be
impaired if the equipment is used in a manner not specified by PCB Piezotronics, Inc.
Caution 1 –ESD sensitivity
Cables can kill your equipment. High voltage electrostatic discharge (ESD) can damage electrical devices.
Similar to a capacitor, a cable can hold a charge caused by triboelectric transfer, such as that which occurs in the
following:
 Laying on and moving across a rug,
 Any movement through air,
 The action of rolling out a cable, and/or
 Contact with a non-grounded person.
The PCB solution for product safety:
 Connect the cables only with the AC power off.
 Temporarily “short” the end of the cable before attaching it to any signal input or output.
Caution 2 –ESD sensitivity
ESD considerations should be made prior to performing any internal adjustments on the equipment. Any
piece of electronic equipment is vulnerable to ESD when opened for adjustments. Internal adjustments should

PAGE 11
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
therefore be done ONLY at an ESD-safe work area. Many products have ESD protection, but the level of
protection may be exceeded by extremely high voltage.
Warranty
IMI instrumentation is warranted against defective material and workmanship for 1 year unless otherwise
expressly specified. Damage to instruments caused by incorrect power or misapplication, is not covered by
warranty. If there are any questions regarding power, intended application, or general usage, please consult with
your local sales contact or distributor. Batteries and other expendable hardware items are not covered by
warranty.
Service
Because of the sophisticated nature of IMI instrumentation, field repair is typically NOT recommended and may
void any warranty. If factory service is required, return the instrumentation according to the “Return Procedure”
stated below. A repair and/or replacement quotation will be provided prior to servicing at no charge. Before
returning the unit, please consult a factory IMI applications engineer concerning the situation as certain problems
can often be corrected with simple on-site procedures.
Return procedure
To expedite returned instrumentation, contact a factory IMI applications engineer for a RETURN MATERIAL
AUTHORIZATION (RMA) NUMBER. Please have information available such as model and serial number. Also,
to insure efficient service, provide a written description of the symptoms and problems with the equipment to a
local sales representative or distributor, or contact IMI if none are located in your area.
Customers outside the U.S. should consult their local IMI distributor for information on returning equipment. For
exceptions, please contact the International Sales department at IMI to request shipping instructions and an RMA.
For assistance, please call [phone], or fax us at [phone]. You may also receive assistance via e-
mail at [e-mail] or visit our web site at www.pcb.com.

PAGE 12
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Customer Service
IMI, a division of PCB Piezotronics, guarantees Total Customer Satisfaction. If, at any time, for any reason, you
are not completely satisfied with any IMI product, IMI will repair, replace, or exchange it at no charge. You may
also choose, within the warranty period, to have your purchase price refunded.
IMI offers to all customers, at no charge, 24-hour phone support. This service makes product or application
support available to our customers, day or night, seven days a week. When unforeseen problems or emergency
situations arise, call the IMI Hot Line at [phone], and an application specialist will assist you.
3425 Walden Avenue, Depew, NY 14043-2495
Phone: [phone]
x USA Fax: [phone] x INTL Fax: [phone]
ICP®is a registered trademark of PCB Group, Incorporated,
which uniquely identifies PCB sensors that incorporate built-in microelectronics.
[e-mail] | www.nbn.atTel. [phone] | Fax [phone]Riesstraße 146, 8010 Graz
nbn Austria GmbH
Aufgrund laufenderWeiterentwicklungen sind Änderungen der Spezikationen vorbehalten. Alle Angaben vorbehaltlich Satz- und Druckfehler. v200427
