Crystal Vision SW222 User manual

Crystal Vision Ltd., Lion Technology Park, Station Road East, Whittlesford, Cambridge, CB22 4WL, England.
E-mail: [email protected] Website: www.crystalvision.tv Tel: [phone] Fax: [phone]
SW222
SDI 2 x 2 switch

SW222 User Manual V1.4 Crystal Vision
110/01/07
Contents
1 Introduction 2
2 Operation 4
Control modes 5
Auto switching on missing input 6
Frame-synchronised or immediate switching 6
Status switching 6
2.1 Using control modes 7
Independent channel selection 7
Alternate channel selection 10
3 Installation 13
3.1 Rear modules and signal I/O 13
Indigo 4, 2, 1 and Desktop box rear connectors 13
Rear module connections with RM01 13
Rear module connections with RM02 14
Rear module connections with RM18 15
Rear module connections with RM38 15
3.2 GPI connections 17
Indigo 1 and Indigo DT Desktop box GPI connections 20
3.3 DVB/SDI configuration 20
4 Problem solving 21
5 Specification 23
Revision 4 Rear module connection table corrected 10/01/07

Crystal Vision Introduction
2
1 Introduction
The SW222 is a 10-bit 2x2 Serial Digital switch. Each of two serial digital inputs can be
switched to either or both of two outputs. Switching can be controlled separately or
together, either from the board or from remote inputs.
Equalise
and reclock
Serial
2 x 2
Switch
SDI/ASI A2
6 x GPI
ASI/SDI
I/P 1
Input monitor
and timing
generator
ASI/SDI
I/P 2 Equalise
and reclock
Control
Logic
Board ed
g
e
piano switches
and LEDs
SDI/ASI A1
A O/P
B O/P
SDI A4
SDI A3
SDI/ASI B2
SDI/ASI B1
SDI B4
SDI B3
3rd & 4th out
p
uts
re
q
uire s
p
ecial connector
SW222 SDI 2 x 2 Switch
The unit can be configured to switch automatically on input failure if required. Local and
remote indications of input status and switch selection are provided. The unit can
automatically detect the video standard and switch at the appropriate point in the frame-
blanking period or, in some modes, switch immediately upon remote command.
When used with the RM38 rear connector module relay bypass is available. This rear
module will switch input 1 to output 1 and input 2 to output 2 on complete frame power
failure or if the SW222 should be removed from the frame.
The main features are as follows:
•SDI or DVB-ASI 2 x 2 switching
•Up to 4 reclocked outputs of both switched signals
•Independent or opposite paired outputs (1>A, 2>B or 1>B, 2>A)
•Switch immediately or in vertical blanking
•Error indication of missing input signal
•Flexible yet simple remote control and/or board edge control
•Status via GPIs and/or board edge LEDs
•Relay bypass available when used with the RM38 rear connector module

Crystal Vision Introduction
3
Default outputs are two pairs of reclocked DVB-ASI complaint serial digital. Additional
four serial digital outputs are available depending on which rear modules are fitted. The
extra outputs are not DVB-ASI complaint.
It is very compact with 6 modules fitting in a 1U frame and 12 modules in a 2U frame and
24 in a 4U frame. The unit plugs into the front of the rack frame, and the universal
connection system allows a mixture of Crystal Vision modules to be used in the 1U/2U
and 4U frames.
Typical applications:
•Emergency SDI or DVB-ASI transmission bypass switcher – with preview
output
•automated n x 2 redundancy changeover switch
•Automatic fail safe switch
•Simple 2x2 manual changeover selector
Both local and remote control and tally indication is provided, making the unit ideal for
use from the critical-paths of complex automated multi-channel systems to the smallest
edit suite.
Note. for relay bypass operation a minor modification to the SW222 board may be
necessary depending on PCB issue. See Chapter 3 Installation.

Crystal Vision Operation
4
2 Operation
The hinged front panel of the case reveals user control of the card, and also LED
indication of input status and switch routing. The 8-way piano switch allows the operating
modes, switching options and status options to be selected.
1 2 3 4 5 6 7 8
1 IN
2 IN
625
525
A1
A2
B1
B2 PSU
MODE AUTO ST
LOCAL IMM
SW222
The SW222 front edge view
Lever Function Up Down
1-3 MODE Select control mode (see next table)
4A OUT Input 1 (mode dependant) Input 2 (mode dependant)
5B OUT Input 1 (mode dependant) Input 2 (mode dependant)
6AUTO Automatically switches away from
missing input
Forces outputs to set inputs.
7IMMEDIATE Switches in next frame blanking Switches immediately upon remote
control (mode dependant)
8STATUS Dual input/output on 4 GPI lines Input only on 4 GPI lines (mode
dependant)
8-Way DIL switch functions
LED Colour Meaning when lit
1 IN Green (top) Valid serial digital input detected input 1.
2 IN Green (bottom) Valid serial digital input detected input 2.
625 Yellow (top) 625-line input detected input 1.
525 Yellow (bottom) 525-line input detected input 1.
A1 Yellow (top) Input 1 routed to Output A
A2 Yellow (bottom) Input 2 routed to Output A
B1 Yellow (top) Input 1 routed to Output B
B2 Yellow (bottom) Input 2 routed to Output B
PSU Green Power supply voltage present.
LED assignments

Crystal Vision Operation
5
Control modes
To provide maximum flexibility a number of different controls options are available.
Piano switches 1-3 chose the control option as follows: -
Function Mode 123
Both channels selected by a single local
piano switch
O UpUpUp
Each channel selected by separate local
piano switches
I UpUpDown
Both channels toggled by repeated action of
a single remote momentary switch
O Up Down Up
Each channel toggled by repeated action of
separate remote momentary switches
I Up Down Down
Both channels selected by most recent of two
remote momentary switches
O Down Up Up
Each channel selected by most recent of two
remote momentary switches
I Down Up Down
Both channels selected by a single remote
toggle switch
O Down Down Up
Each channel selected by separate remote
toggle switches
I Down Down Down
MODE Description
IA/B output channels controlled independently
OA/B output channels always on opposite selection
The control modes are discussed in more detail in the next section ‘Using control modes’.

Crystal Vision Operation
6
Auto switching on missing input
If piano switch 6 (AUTO) is up, outputs A and B will automatically switch away from a
missing input. The status outputs (‘a’ to ‘d’, depending on control mode) will indicate the
actual status of the routing. If the missing input returns, the SW222 will revert to the
selected routing.
If piano switch 6 (AUTO) is down, outputs A and B will maintain their selected routing
irrespective of input conditions.
Frame-synchronised or immediate switching
After receiving a control signal, the SW222 will, by default, change routing at the
appropriate point in the next frame-blanking period. In some modes it is possible to
disable this feature so that the routing changes within a few microseconds of the control
signal. This simplifies use with sources of timed control signals such as mixers.
If piano switch 7 (IMMEDIATE) is down, routing will change within a few microseconds
of the control signal. This facility is only available when the routing is controlled by
remote toggle switches (not on momentary control). If piano switch 7 is up, routing will
change during the next frame-blanking period.
Status switching
In some modes the GPI lines are bi-directional – they are used both as control inputs and
status outputs. If piano switch 8 (STATUS) is down, the status outputs will be disabled in
these modes. This simplifies use where multiple SW222s are controlled by one set of
remote controller. In the corresponding control mode, if piano switch 8 is up, the GPI
lines will be bi-directional.

Crystal Vision Operation
7
2.1 Using control modes
Independent channel selection
The four independent operational modes their switching options and GPI assignments are
as follows:
1 2 3
Each channel selected by separate local piano switches
Lever Function Up Down
4A OUT Input 1 Input 2
5B OUT Input 1 Input 2
7IMMEDIATE Switches in next frame blanking Switches in next frame blanking
Use levers 4,5 and 7 to set switching options
GPIs When open (+5V) When grounded
‘a’ Not used Not used
‘b’ Status - Input 1 routed to Output A Status - Input 2 routed to Output A
‘c’ Not used Not used
‘d’ Status - Input 1 routed to Output B Status - Input 2 routed to Output B
‘e’ Status - Input 1 absent. Status - Input 1 present.
‘f’ Status - Input 2 absent. Status - Input 2 present.
GPI assignments for current mode
1 2 3
Each channel selected by separate remote toggle switches
Lever Function Up Down
4A OUT Input 1 Input 2
5B OUT Input 1 Input 2
7IMMEDIATE Switches in next frame blanking Switches immediately upon remote
control
Use levers 4,5 and 7 to set switching options

Crystal Vision Operation
8
GPIs When open (+5V) When grounded
‘a’ Control - Route Input 2 to Output A Control - Route Input 1 to Output A
‘b’ Status - Input 1 routed to Output A Status - Input 2 routed to Output A
‘c’ Control - Route Input 2 to Output B Control - Route Input 1 to Output B
‘d’ Status - Input 1 routed to Output B Status - Input 2 routed to Output B
‘e’ Status - Input 1 absent. Status - Input 1 present.
‘f’ Status - Input 2 absent. Status - Input 2 present.
GPI assignments for current mode
1 2 3
Each channel selected by two remote momentary switches
Lever Function Up Down
4A OUT Input 1 Input 2
5B OUT Input 1 Input 2
7IMMEDIATE Switches in next frame blanking Switches in next frame blanking
8STATUS Dual control/status on GPI lines ‘a’ to ‘d’ Control only on GPI lines ‘a’ to ‘d’
Use levers 4,5,7 and 8 to set switching options
Piano switches 4 & 5 as shown above determine power-up routing. Subsequently, each
input will be selected (during frame blanking) each time the corresponding momentary
switch is closed and released. With piano switch 8 down, indicator outputs are disabled to
allow the remote controls of a number of SW222s to be connected in parallel.
GPIs When open (+5V) When grounded
‘a’ Status - Input 2 routed to Output A. Status - Input 1 routed to Output A. Control (momentary
action) – Route Input 1 to Output A.
‘b’ Status - Input 1 routed to Output A. Status - Input 2 routed to Output A. Control (momentary
action) – Route Input 2 to Output A.
‘c’ Status - Input 2 routed to Output B. Status - Input 1 routed to Output B. Control (momentary
action) – Route Input 1 to Output B.
‘d’ Status - Input 1 routed to Output B. Status - Input 2 routed to Output B. Control (momentary
action) – Route Input 2 to Output B.
‘e’ Status - Input 1 absent. Status - Input 1 present.
‘f’ Status - Input 2 absent. Status - Input 2 present.
GPI assignments – Status enabled (piano switch 8 up)

Crystal Vision Operation
9
GPIs When open (+5V) When grounded
‘a’ Not used. Control (momentary action) – Route Input 1 to Output A.
‘b’ Not used. Control (momentary action) – Route Input 2 to Output A.
‘c’ Not used. Control (momentary action) – Route Input 1 to Output B.
‘d’ Not used. Control (momentary action) – Route Input 2 to Output B.
‘e’ Status - Input 1 absent. Status - Input 1 present.
‘f’ Status - Input 2 absent. Status - Input 2 present.
GPI assignments – Status disabled (piano switch 8 down)
1 2 3
Each channel toggled by separate remote momentary switches
Lever Function Up Down
4A OUT Input 1 Input 2
5B OUT Input 1 Input 2
7IMMEDIATE Switches in next frame blanking Switches in next frame blanking
Use levers 4,5 and 7 to set switching options
Piano switches 4 & 5 as shown above determine power-up routing. Subsequently, each
input will be selected (during frame blanking) each time the corresponding momentary
switch is closed and released.
GPIs When open (+5V) When grounded
‘a’ Status - Input 2 routed to Output A. Control (momentary action) – toggle routing to Output A.
‘b’ Status - Input 1 routed to Output A. Status - Input 2 routed to Output A.
‘c’ Status - Input 2 routed to Output B. Control (momentary action) – toggle routing to Output B.
‘d’ Status - Input 1 routed to Output B. Status - Input 2 routed to Output B.
‘e’ Status - Input 1 absent. Status - Input 1 present.
‘f’ Status - Input 2 absent. Status - Input 2 present.
GPI assignments

Crystal Vision Operation
10
Alternate channel selection
The four ‘opposite selection’ or ‘alternate’ operational modes, their switching options and
GPI assignments are as follows:
1 2 3
Both channels selected by a single local piano switch
Lever Function Up Down
4A OUT Input 1 routed to Output A
Input 2 routed to Output B
Input 2 routed to Output A
Input 1 routed to Output B
5B OUT Not used Not used
7IMMEDIATE Switches in next frame blanking Switches in next frame blanking
Use levers 4,5 and 7 to set switching options
Piano switches 4 & 5 as shown above determine power-up routing. Subsequently, each
input will be selected (during frame blanking) each time the corresponding momentary
switch is closed and released.
GPIs When open (+5V) When grounded
‘a’ Not used. Not used.
‘b’ Not used. Not used.
‘c’ Status - Input 1 routed to Output A.
Status - Input 2 routed to Output B.
Status – Input 2 routed to Output A.
Status – Input 1 routed to Output B.
‘d’ Status – Input 2 routed to Output A.
Status - Input 1 routed to Output B.
Status - Input 1 routed to Output A.
Status – Input 2 routed to Output B.
‘e’ Status - Input 1 absent. Status - Input 1 present.
‘f’ Status - Input 2 absent. Status - Input 2 present.
GPI assignments for current mode
1 2 3
Both channels selected by a single remote toggle switch
Lever Function Up Down
4A OUT Not used. Not used.
5B OUT Not used. Not used.
7IMMEDIATE Switches in next frame blanking Switches immediately upon remote
control
Use levers 4,5 and 7 to set switching options

Crystal Vision Operation
11
GPIs When open (+5V) When grounded
‘a’ Control - Input 2 routed to Output A.
Control - Input 1 routed to Output B.
Control - Input 1 routed to Output A.
Control - Input 2 routed to Output B.
‘b’ Not used. Not used.
‘c’ Status - Input 1 routed to Output A.
Status – Input 2 routed to Output B.
Status - Input 2 routed to Output A.
Status – Input 1 routed to Output B.
‘d’ Status - Input 2 routed to Output A.
Status – Input 1 routed to Output B.
Status - Input 1 routed to Output A.
Status – Input 2 routed to Output B.
‘e’ Status - Input 1 absent. Status - Input 1 present.
‘f’ Status - Input 2 absent. Status - Input 2 present.
GPI assignments
1 2 3
Both channels selected by two remote momentary switches
Lever Function Up Down
4A OUT Input 1 routed to Output A
Input 2 routed to Output B
Input 2 routed to Output A
Input 1 routed to Output B
5B OUT Not used. Not used.
7IMMEDIATE Switches in next frame blanking Switches in next frame blanking
Use levers 4,5 and 7 to set switching options
Power-up routing is determined by piano switch 4 as shown above. Subsequently, each
input will be selected (during frame blanking) each time the corresponding momentary
switch is closed and released.
GPIs When open (+5V) When grounded
‘a’ No Change Control (momentary action) – Input 1 routed to Output A,
Input 2 routed to Output B.
‘b’ No Change Control (momentary action) – Input 2 routed to Output A,
Input 1 routed to Output B.
‘c’ Status - Input 1 routed to Output A.
Status – Input 2 routed to Output B.
Status - Input 2 routed to Output A.
Status – Input 1 routed to Output B.
‘d’ Status - Input 2 routed to Output A.
Status – Input 1 routed to Output B.
Status - Input 1 routed to Output A.
Status – Input 2 routed to Output B.
‘e’ Status - Input 1 absent. Status - Input 1 present.
‘f’ Status - Input 2 absent. Status - Input 2 present.
GPI assignments

Crystal Vision Operation
12
1 2 3
Both channels toggled by single remote momentary switch
Lever Function Up Down
4A OUT Input 1 routed to Output A
Input 2 routed to Output B
Input 2 routed to Output A
Input 1 routed to Output B
5B OUT Not used. Not used.
7IMMEDIATE Switches in next frame blanking Switches in next frame blanking
Use levers 4,5 and 7 to set switching options
Power-up routing is determined by piano switch 4 as shown above. Subsequently, each
input will be selected (during frame blanking) each time the corresponding momentary
switch is closed and released.
GPIs When open (+5V) When grounded
‘a’ No Change Control (momentary action) – toggle routing to Output A
and Output B.
‘b’ Not Used Not used.
‘c’ Status - Input 1 routed to Output A.
Status – Input 2 routed to Output B.
Status - Input 2 routed to Output A.
Status – Input 1 routed to Output B.
‘d’ Status - Input 2 routed to Output A.
Status – Input 1 routed to Output B.
Status - Input 1 routed to Output A.
Status – Input 2 routed to Output B.
‘e’ Status - Input 1 absent. Status - Input 1 present.
‘f’ Status - Input 2 absent. Status - Input 2 present.
GPI assignments

Crystal Vision Installation
13
3 Installation
The SW222 2x2 switch single height module fits into all Crystal Vision rack frames. All
modules can be plugged in and removed while the frame is powered without damage.
3.1 Rear modules and signal I/O
Indigo 4, 2, 1 and Desktop box rear connectors
The Indigo 4 frame can accommodate up to 24 SW222 cards. The Indigo 2 frame takes up
to 12 cards, six cards will fit in the Indigo 1 frame and 2 will fit in the Indigo DT Desktop
box.
The available rear connectors are as follows:
There are four types of rear connector available for the FR2AV and Indigo frame. This
provides system flexibility by allowing a mix between access to all connections and
maximum module packing density. Relay bypass is available with the RM38
Rear module connections with RM01
FR2AV, FR1AV & DTBAV rear connectors Description
RM01 (ZLA00075
artwork)
•24 cards per Indigo 4,
12 cards per Indigo 2, 6
per Indigo 1 & 2 per
Indigo DT
•All frame slots can be
used
BNC Description
SDI(B2) OUT Reclocked ASI-compliant Serial Digital Output (channel 2).
SDI(1) IN Serial Digital Input channel 1.
SDI(A1) OUT Reclocked ASI-compliant Serial Digital Output (channel 1).
SDI(A2) OUT Reclocked ASI-compliant Serial Digital Output (channel 1).
SDI(B1) OUT Reclocked ASI-compliant Serial Digital Output (channel 2).
SDI(2) IN Serial Digital Input channel 2.

Crystal Vision Installation
14
Rear module connections with RM02
FR2AV rear connector Description
RM02 (ZLA00128 artwork)
•18 cards per Indigo 4 frame
•3 modules per rear
connector
•9 connections available
•Card 1 fits in slots 1, 5 and
9
•Card 2 fits in slots 2, 6 and
10
•Card 3 fits in slots 4, 8 and
12
•No card fits in 3, 7 or 11
BNC Card 1 Description
ASerial Digital Input channel 1.
BReclocked ASI-compliant Serial Digital Output (channel 1).
CReclocked ASI-compliant Serial Digital Output (channel 1).
DReclocked Serial Digital Output (channel 1).
EReclocked Serial Digital Output (channel 2).
FReclocked ASI-compliant Serial Digital Output (channel 2).
GReclocked Serial Digital Output (channel 2).
HReclocked ASI-compliant Serial Digital Output (channel 2).
ISerial Digital Input channel 2.
BNC Card 2 Description
ASerial Digital Input channel 1.
BReclocked ASI-compliant Serial Digital Output (channel 1).
CReclocked ASI-compliant Serial Digital Output (channel 1).
DReclocked Serial Digital Output (channel 1).
EReclocked Serial Digital Output (channel 2).
FReclocked ASI-compliant Serial Digital Output (channel 2).
GReclocked Serial Digital Output (channel 2).
HSerial Digital Input channel 2.
IReclocked ASI-compliant Serial Digital Output (channel 2).
BNC Card 3 Description
ASerial Digital Input channel 1.
BReclocked ASI-compliant Serial Digital Output (channel 1).
CReclocked ASI-compliant Serial Digital Output (channel 1).
DReclocked Serial Digital Output (channel 1).
EReclocked Serial Digital Output (channel 2).
FReclocked ASI-compliant Serial Digital Output (channel 2).
GReclocked Serial Digital Output (channel 2).
HReclocked ASI-compliant Serial Digital Output (channel 2).
ISerial Digital Input channel 2.

Crystal Vision Installation
15
Rear module connections with RM18
FR2AV, FR1AV & DTBAV rear connectors Description
RM18 (ZLA00174 artwork)
•12 cards per Indigo 4 frame,
6 per Indigo 2, 3 per Indigo
1 & 1 per Indigo DT
•1 module per rear connector
•10 connections available
•Card fits in upper slot
•No card fits in lower slot
BNC Description
N/C No connection
SDI IN 1 Serial Digital Input channel 1.
SDI OUT A (1) Reclocked ASI-compliant Serial Digital Output (channel 1).
SDI OUT B (3) Reclocked Serial Digital Output (channel 2).
SDI IN 2 Serial Digital Input channel 2.
SDI OUT B (4) Reclocked ASI-compliant Serial Digital Output (channel 2).
N/C No connection
SDI OUT A (2) Reclocked ASI-compliant Serial Digital Output (channel 1).
SDI OUT A (3) Reclocked Serial Digital Output (channel 1).
SDI OUT B (1) Reclocked Serial Digital Output (channel 2).
SDI OUT A (4) Reclocked Serial Digital Output (channel 1).
SDI OUT B (2) Reclocked ASI-compliant Serial Digital Output (channel 2).
Rear module connections with RM38
The RM38 has the addition of bypass relays fitted to loop the input programme to the
outputs should there be a catastrophic frame supply/mains failure or SW222 card
removal.
Indigo & FR-AV rear connectors Description
RM38
•24 cards per Indigo 4,
12 cards per Indigo 2, 6
per Indigo 1 & 2 per
Indigo DT
•All frame slots can be
used
3

Crystal Vision Installation
16
BNC Description
SDI IN 1 Serial Digital Input channel 1.
SDI OUT A1 Reclocked ASI-compliant Serial Digital Output (channel 1). (SDI IN 1
loop on fail)
SDI OUT A2 Reclocked ASI-compliant Serial Digital Output (channel 1).
SDI OUT B2 Reclocked ASI-compliant Serial Digital Output (channel 2).
SDI OUT B1 Reclocked ASI-compliant Serial Digital Output (channel 2). (SDI IN 2
loop on fail)
SDI IN 2 Serial Digital Input channel 2.
SW222 modification information for using the RM38
SW222 PCB Issue number
Issue 2 No modification required
Issue 3 No modification required
Issue 4 No modification required
Issue 5 Connect as 1R wire ended resistor between PL1 pin A24 and C104 +5v end
Issue 6 Mod level 1-5. Connect as 1R wire ended resistor between PL1 pin A24 and C104
+5v end
Issue 6 Mod level 6 and above no modification required
Modification for RM38 relay bypass operation

Crystal Vision Installation
17
3.2 GPI connections
Each slot has an associated set of GPI connections for remote control and external status
outputs on the frame rear-panel remote connectors. For convenience, GPI lines are
associated with reference codes ‘a’ to ‘f’ in the connector pin-out tables for each frame.
OPEN (+5V) GROUND
‘a’
‘b’
‘c’
‘d’
Mode dependent
‘e’ Input 1 absent. Input 1 present.
‘f’ Input 2 absent. Input 2 present.
GPI input and outputs assignment is mode dependent – see Operation chapter
GPI input connections have 10k Ω pull-up to +5V. Closed-contact switches or +5V to
+24V logic levels can be used
GPI output connections have 0Ωseries resistors fitted (to drive +5V to +24V bulbs) and
10k Ω pull-up to +5V (to drive a remote input). LEDs can be used by changing the series
resistors to 330 Ω 0805-type. See illustration below.
.
1IN2IN
PL 4
PL 3
SMPTE 259M
DVB-ASI
Use 330 Ohm resistors 0805-type for LEDs.
Factory set.
Do not re-adjust
Change the six resistors arrowed to 330 Ω 0805 type for external status LEDs
TIP:
330Ωresistors may be fitted externally if required

Crystal Vision Installation
18
4U frame GPI connections
GPI lines ‘a’ to ‘f’ of each card connect to one of eight rear remote connectors as follows:
Slot no. ‘a’ pin ‘b’ pin ‘c’ pin ‘d’ pin ‘e’ pin ‘f’ pin
18 (1) 9 (1) 18 (1) 26 (1) 19 (2) 20 (2)
27 (1) 16 (1) 17 (1) 25 (1) 10 (2) 11 (2)
38 (3) 9 (3) 18 (3) 26 (3) 19 (4) 20 (4)
47 (3) 16 (3) 17 (3) 25 (3) 10 (4) 11 (4)
55 (1) 6 (1) 15 (1) 24 (1) 1 (2) 2 (2)
64 (1) 14 (1) 13 (1) 23 (1) 3 (2) 4 (2)
75 (3) 6 (3) 15 (3) 24 (3) 1 (4) 2 (4)
84 (3) 14 (3) 13 (3) 23 (3) 3 (4) 4 (4)
93 (1) 12 (1) 22 (1) 21 (1) 12 (2) 13 (2)
10 10 (1) 11 (1) 19 (1) 20 (1) 21 (2) 22 (2)
11 3 (3) 12 (3) 22 (3) 21 (3) 12 (4) 13 (4)
12 10 (3) 11 (3) 19 (3) 20 (3) 21 (4) 22 (4)
Slot no. ‘a’ pin ‘b’ pin ‘c’ pin ‘d’ pin ‘e’ pin ‘f’ pin
18 (5) 9 (5) 18 (5) 26 (5) 19 (6) 20 (6)
27 (5) 16 (5) 17 (5) 25 (5) 10 (6) 11 (6)
38 (7) 9 (7) 18 (7) 26 (7) 19 (8) 20 (8)
47 (7) 16 (7) 17 (7) 25 (7) 10 (8) 11 (8)
55 (5) 6 (5) 15 (5) 24 (5) 1 (6) 2 (6)
64 (5) 14 (5) 13 (5) 23 (5) 3 (6) 4 (6)
75 (7) 6 (7) 15 (7) 24 (7) 1 (8) 2 (8)
84 (7) 14 (7) 13 (7) 23 (7) 3 (8) 4 (8)
93 (5) 12 (5) 22 (5) 21 (5) 12 (6) 13 (6)
10 10 (5) 11 (5) 19 (5) 20 (5) 21 (6) 22 (6)
11 3 (7) 12 (7) 22 (7) 21 (7) 12 (8) 13 (8)
12 10 (7) 11 (7) 19 (7) 20 (7) 21 (8) 22 (8)
Table shows pin number (Remote number)
Note: Remote 1, Remote 3, Remote 5 and Remote 7 are 26-way high-density D-Type female
sockets. Frame ground is pin 2 and +5V @500mA is pin 1 in each case.
Remote 2, Remote 4, Remote 6 and Remote 8 are 26-way high-density D-Type male plugs
and frame ground is pin 6 in each case and +5V @500mA is pin 15 on Remote 2 and
Remote 6.
Note. The +5V output is protected by self-resetting thermal fuses, which limit the total
output current available from Remotes 1-4 to approximately 1A. Remotes 5-8 are similarly
protected.
UpperLower

Crystal Vision Installation
19
GPI lines ‘a’ to ‘f’ of each card connect to one of four rear remote connectors as follows:
Slot no. ‘a’ pin ‘b’ pin ‘c’ pin ‘d’ pin ‘e’ pin ‘f’ pin
18 (1) 9 (1) 18 (1) 26 (1) 19 (2) 20 (2)
27 (1) 16 (1) 17 (1) 25 (1) 10 (2) 11 (2)
38 (3) 9 (3) 18 (3) 26 (3) 19 (4) 20 (4)
47 (3) 16 (3) 17 (3) 25 (3) 10 (4) 11 (4)
55 (1) 6 (1) 15 (1) 24 (1) 1 (2) 2 (2)
64 (1) 14 (1) 13 (1) 23 (1) 3 (2) 4 (2)
75 (3) 6 (3) 15 (3) 24 (3) 1 (4) 2 (4)
84 (3) 14 (3) 13 (3) 23 (3) 3 (4) 4 (4)
93 (1) 12 (1) 22 (1) 21 (1) 12 (2) 13 (2)
10 10 (1) 11 (1) 19 (1) 20 (1) 21 (2) 22 (2)
11 3 (3) 12 (3) 22 (3) 21 (3) 12 (4) 13 (4)
12 10 (3) 11 (3) 19 (3) 20 (3) 21 (4) 22 (4)
Table shows Pin number (Remote number)
Note:
Remote 1 and Remote 3 are 26 way high density ‘D’ type female sockets and frame ground is pin
2 and +5V @500mA is pin 1 in each case.
Remote 2 and Remote 4 are 26 way high density ‘D’ type male plugs and frame ground is pin 6
and +5V @500mA is pin 15 in each case.
2U frame GPI connections
GPI lines ‘a’ to ‘f’ of each card connect to one of four rear remote connectors as follows:
Slot no. ‘a’ pin ‘b’ pin ‘c’ pin ‘d’ pin ‘e’ pin ‘f’ pin
18 (1) 9 (1) 18 (1) 26 (1) 19 (2) 20 (2)
27 (1) 16 (1) 17 (1) 25 (1) 10 (2) 11 (2)
38 (3) 9 (3) 18 (3) 26 (3) 19 (4) 20 (4)
47 (3) 16 (3) 17 (3) 25 (3) 10 (4) 11 (4)
55 (1) 6 (1) 15 (1) 24 (1) 1 (2) 2 (2)
64 (1) 14 (1) 13 (1) 23 (1) 3 (2) 4 (2)
75 (3) 6 (3) 15 (3) 24 (3) 1 (4) 2 (4)
84 (3) 14 (3) 13 (3) 23 (3) 3 (4) 4 (4)
93 (1) 12 (1) 22 (1) 21 (1) 12 (2) 13 (2)
10 10 (1) 11 (1) 19 (1) 20 (1) 21 (2) 22 (2)
11 3 (3) 12 (3) 22 (3) 21 (3) 12 (4) 13 (4)
12 10 (3) 11 (3) 19 (3) 20 (3) 21 (4) 22 (4)
Table shows pin number (remote number)
Note: Remote 1 and Remote 3 are 26-way high-density D-Type female sockets. Frame ground is
pin 2 and +5V @500mA is pin 1 in each case.
Remote 2 and Remote 4 are 26-way high-density D-Type male plugs and frame ground is
pin 6 in each case and +5V @500mA is pin 15 on Remote 2.
Note. The +5V output is protected by self-resetting thermal fuses, which limit the total
output current available from Remotes 1-4 to approximately 1A.
