CSI W6881 User manual

ECONOMY LED LIGHT PACK
Instruction Manual
PART#W6881
ECONOMY WIRING KIT FOR PART#W6881
SOLD SEPARETLY - PART#W4803

INSTALLATION INSTRUCTIONS:
1. Find a suitable mounting location that will allow for running wires and mounting the LED light(s). Lay out and mark where
the mounting holes will be positioned. Drill appropriate-sized hole(s) for the mounting hardware. Before starting to drill
hole(s), check behind locations to insure nothing will be damaged while drilling light mounting holes.
2. Mount the lights with the provided hardware, being sure not to over tighten the hardware (you will adjust them in Step 7).
3. Route the lighting side of the wiring harness from the battery to the light(s) in a safe, secure manner. Connect the harness
 tothelight(s).Besuretoavoidheatsourcesandanymovingpartswhilerunningyourwires.Prolongedchangofthe
wires may lead to a short in the circuit. Following the vehicle manufacturer’s wiring harness is a safe path to follow.
4. Continue to route the switch portion of the harness to the desired location of the switch. The switch may need to be un
plugged from the harness to make routing of the harness easier. Drill an appropriate-sized hole for the switch. Connect
the wires to the switch and mount the switch.
5. Connect the black (ground) wire w/the large ring
terminal from the harness to the negative battery
terminal. Connect the red (power) wire w/the large
ring terminal from the harness to the positive
battery terminal.
6. Secure the relay to a suitable location and test the
lights to make sure the circuit works.
7. Finally, aim the lights in the desired direction
and tighten all the mounting hardware.
POWERING UP LED LIGHTS:
Whenrstpoweringupthelightstheywillcyclethrough
the colors and then turn to a solid white light.
CHANGING THE LIGHT MODES USING THE SWITCH:
With each toggle of the power switch the light will change
modes.
MODE 1: Bright solid white
MODE 2: Flashing bright white
MODE 3: Solid amber
MODE 4: Flashing amber
LED LIGHT SPECIFICATIONS:
DIMENSIONS 3.25”W x 3H x 3.25D
VOLTAGE 9 - 32V DC
LUMENS 1455 LM
LED QTY 16
AMP DRAW 1.0A@12V
POWER
CONSUMPTION 16W
3” 3.25”
3.25”
3.75”
