CSL CS1510 User manual

QUICK GUIDE &
INSTRUCTION MANUAL
DigiAir PSU

CSL - the trusted choice
Complete Connectivity Solutions
www.csldual.com ©CSL DualCom Limited @CSLDualCom
IFSEC ad 2017 CSL full page v20.indd 1 30/05/2017 11:00

INSTALLATION
Refer to the DigiAir Quick Guide for triggering and Dial Capture connections.
3
Control Panel (CIE)
Comms
Fault
Mains
EPS
Fault
- + AC FLT TAMP
MAINS
DATA
INPUTS
NO
COM FAULT
SUPPLY
NC
-
+
Battery
APS
Fault TAMP
DigiAir
PSU Board
QUICK GUIDE
Figure 1 - Power, Tamper and Fault Wiring between the CIE, PSU and DigiAir (3 fault inputs in panel).

4
Where the CS1510 will be used with small CIE, the CIE is unlikely to have 3 separate fault inputs. This diagram
shows how to wire all of the PSU & DigiAir fault outputs (Mains, Battery & DigiAir) to one panel fault input. Refer
to the DigiAir Quick Guide for triggering and Dial Capture connections.
Control Panel (CIE)
FAULT
- + AC FLT TAMP
MAINS
DATA
INPUTS
NO
COM FAULT
SUPPLY
NC
-
+
TAMP
DigiAir
PSU Board
Mains failure and mains restore (on the AC FLT output) will be reported by the PSU to the CIE in less than
10 secs. Note that Mains failure reporting (by the CIE) to the ARC may be delayed for up to 1 hour EN50131
standard. Refer to the CIE manual for its programming/setup details.
When the wiring between the PSU, CIE and DigiAir is completed, plug the battery into the BAT connector on
the PSU board and connect mains power to the L, N & E terminals.
Figure 2 - Power, Tamper and Fault Wiring between the CIE, PSU and DigiAir (1 fault input in panel).

5
LED INDICATIONS
LED Label LED STATUS
ON Flashing OFF
Red FLT LED
Battery disconnected
Battery charge fail
Over voltage output
Low voltage output
- No faults
Green OK LED Battery power OK
Mains power OK
Battery power
OK but no mains
power
No battery power
and no mains power
INSTALLATION
The CS1510 is a compact type A Power Supply (PSU) with battery back-up that is designed to house and power
a DigiAir, and to be mounted with its associated Control Panel (CIE). The CS1510 Power Supply is suitable for
use in systems installed to conform to PD 6662:2010 at Grade 1 & 2, and environmental class 1 & 2.
The CSL5652/5653 is the PSU with a DigiAir already fitted with its power wiring connected. The CS1510 is the
same PSU but is supplied without a DigiAir.
This PSU is designed to supply power to a DigiAir only. Do not use the PSU to supply power to a DigiAir AND
other equipment.
When fitting a DigiAir into the PSU ensures that the DigiAir’s break-o mounting lugs are removed.
Ensure that the PSU’s + and - 12 volt output is connected to the DigiAir’s + and - supply input.
The ‘normally closed’ PSU outputs must be wired to the CIE inputs so that CIE setting may be inhibited by:
• TAMPterminals  
• Atamperfault(i.e.thePSUlidisremoved)
• ACFLTterminals  
• Primepower(mains,EPS)fault
• FLTterminals  
• Alternatepower(battery,APS)lowvoltageorfailure
• COM&NCterminalsonDigiAir
• DigiAir(ATS)pathorcommunicationsfault.
Do not run wiring under the PSU board.

SPECIFICATIONS
Manufacturer CSL
Part Numbers
CS1510 - PSU (PSU only)
CS5652 - PSU + DigiAir UDL UK/Ire
CS5653 - PSU + DigiAir UDL EU
CS0710 - Replacement battery
Installation Standard
This PSU is designed to meet the requirements of:
EN50131-1:2006 + A1:2009, Grade 1 & 2
EN50131-6:1998
EN50131-10:2014
EN50136-2:2013, SP1 & SP2
EN50136:1998 Grade 2 ATS2 = D2, M2, T2, S0, I0
EN50136:1998 Grade 2 ATS3 = D2, M2, T2, S1, I1 PD6662:2010
PD6662 IA 1501:2015
EMC standard EN 61000-6-3
EN 50130-4:2011
Electrical safety st’d EN 60065:2014 or EN62368-1:2014
PSU Type Type A (EN50131-6:1998)
Environmental Class 1 & 2, Indoor Heated & Indoor General
Temperature Range -10 to +40 Centigrade
Humidity Less than 75%, non-condensing
Mains supply 230v +/- 10% AC, 50Hz +/- 5Hz
Max output current No more than 1.00A may be continuously drawn from the PSU
Output ripple At the max output current and 90% mains supply, max ripple = 50mV
Low Voltage fault The FLT output will activate when the output voltage is below 9.60 volts
AC FLT output Normally closed (no mains fault), clean contacts. 60 volts, 100mA max
FLT output Normally closed (no battery fault), clean contacts. 60 volts, 100mA max
TAMP output Normally closed (with lid fitted), clean contacts. 60 volts, 500mA max
SUPPORT
For more information on PSU for DigiAir or other DualCom products please contact CSL
Technical Support:
UK Tel: [phone]
Ireland Tel: [phone]
Email: [email protected]
Hours: 08.30 to 18.00 weekdays, 10.00 to 16.00 Saturday
Visit www.csldual.com for the latest copies of all manuals.
© Copyright CSL DualCom LimitedCSL572V1 16022016
