CSL CS1520 User manual

QUICK GUIDE &
INSTRUCTION MANUAL
Grade 2 Boxed Power Supply
0.5 Amp

At CSL we give you the right tools for
maximum support and minimum hassle.
It’s service that’s built around you.
csl-group.com/installer
INSTALLING
CONFIDENCE
24/7 HELP DESK LIVE CHAT TRAINING VIDEOS COVERAGE MAPS APPS
CSL10709_PSI_Back_Cover_Ad_AW.indd 1 28/08/2018 10:12

3
This product is suitable for use in systems designed to comply with PD6662:2010, EN50131-6
Grade 2 and Environmental Class 2. It is a Type A power supply. Rated Output = 0.5 Amp
INSTALLATION
Mount the metal enclosure onto the wall.
Connect the Live, Neutral and Earth terminals to the un-switched fused spur.
Connect the 0V, tamper and fault outputs to the control panel as appropriate (see control panel
manual for details).
Connect the 12V power output to the system.
Ensure that the tamper switch is connected to the PCB.
Fit the battery.
Switch on the AC supply and confirm that the ‘EPS’ and ‘APS’ LEDs are on.
1.
2.
3.
4.
5.
6.
7.
12 V - BAT 1 +
LEN
A/T PSU FLT PSU FLT EPS F LT
TAMP
AC FUSE
TAMPER
CONNECTOR
AC SUPPLY
CONNECTORS
FOR REMOTE
LEDS
FAULT
OUTPUTS
TAMPER
OUTPUTS
12v POWER
OUTPUT
BATTERY
CONNECTORS
‘12V OK’ LED
FAULT
LEDs

4
EXTERNAL POWER SUPPLY (EPS) (AC SUPPLY)
The power supply has a three way terminal block for Live, Neutral and Earth connections, and is
protected by a 20mm anti-surge fuse rated at 230V, 315mA. A replacement fuse MUST be the same
type and rating.
Mains Earth is connected to the power supply screening and metal enclosure; but is isolated from the
0V output.
TAMPER OUTPUT
This voltage free output is connected to the Tamper Connector. These terminals will be shorted when
the tamper switch is closed.
FAULT OUTPUTS
Two voltage free fault outputs and LEDs are provided to monitor for External Power Supply (EPS) fault
and Auxiliary Power Supply (APS) fault:
Both Relay contacts open and all LEDs out = total power down.
12V POWER OUTPUT
Terminal blocks are provided to connect to the system. The “Rated Output” current is the maximum
that can be drawn from the PSU’s ‘Power Output’ terminals. This is shown in the ‘Rated Output’
section.
The ‘12V OK’ LED indicates that 12V is available from these terminal blocks.
AUXILLARY POWER SUPPLY (APS) (BATTERIES)
One battery connector is provided marked BATT1.
A battery MUST be fitted to the BATT1 connector.
This power supply is compatible with a 7Ah or 8Ah Sealed Lead Acid Gel battery.
EPS FAULT (MAINS) APS FAULT (BATTERY)
Green LED goes out and Relay
contacts open if:
Green LED goes out and Relay
contacts open if:
AC power fault Battery voltage lower than 10.8V
Unit powered down Unit powered down
Thermal shutdown

BATTERY PROTECTION
The battery and electronic circuitry are protected against reverse polarity connection by a self
resetting electronic fuse. The battery is also protected against deep discharge, which will be invoked
when the battery terminal voltage has dropped to 10.8V.
MAINTENANCE
This unit is to be used by service personnel only. There are no user serviceable parts.
No maintenance is required other then routine periodic testing, calibration check and replacement of
the standby battery.
Reference should be made to the battery manufacturer’s documentation to determine typical /
expected battery life with a view to periodic replacement of the battery.
PSU RATING
Power supplies conforming to the new European Standards (ENs) are specified dierently from older
designs. The “Rated Output” current is the maximum that can be drawn from the PSU:
a) With a mains supply and a flat standby battery (that is being recharged), and...
b) With no mains supply (battery only).
The Rated Output is shown in the ‘Rated Output’ section.
RATED OUTPUT
If the Rated Output is exceded then the Power Supply will no longer meet security Grade 2
APS PD6662-2004
GRADE 2 RATED OUTPUT
EN50131-1-2004
GRADE 2 RATED OUTPUT
1 x 7 Ah battery 0.5 Amps for 12 hours 0.5 Amps for 12 hours
1 x 8 Ah battery 0.5 Amps for 12 hours 0.5 Amps for 12 hours
5

SPECIFICATIONS
Product Number CS1520
Applicable Standards Type A, Security Grade 2, Environmental Class 2
AC Input Voltage 230v +10% -15%, 50Hz ± 15%
Output Voltage 13.7v ± 0.1V
Output Ripple < 50mV (0.4% @ 13.6V)
Rated Output See Rated Output table
APS Battery Type 1 x 7Ah or 1 x 8Ah lead acid gel
APS Recharge <24 hours
Operating temp -10oC to +4oC
Case Size 265 x 320 x 100mm
Weight 3.2 Kg
SUPPORT
For more information on this and other products please contact CSL Technical Support:
UK Tel: [phone]
Ireland Tel: [phone]
Email: [email protected]
Hours: 08.30 to 18.00 weekdays, 10.00 to 16.00 Saturday
Visit www.csl-group.com for the latest copies of all manuals.
