VDTU2-B110
VDSL2 LAN E x t e nd e r

2
Copyright by CTC UNION Communications Inc., all right reserved
The information in this document has been checked carefully and is believed to be correct as
of the date of publication. CTC UNION Communications Inc. reserves the right to make
changes in the product of specification, or both, presented in this publication at any time
without notice. CTC UNION Communications assumes no responsibility or liability arising from
the specification listed herein. CTC UNION Communications make no representations that the
use of its products in the manner described in this publication will not infringe on existing or
future patents, trademark, copyright, or rights of third parties. Implication or other under any
patent or patent rights of CTC UNION Communications Ins. grants no license.
All other trademarks and registered trademarks are the property of their respective holders.
CTC Union Technologies Co., Ltd.
Far Eastern Vienna Technology Center (Neihu Technology Park)
8F, No. 60, Zhouzi St.
Neihu, Taipei, 114
Taiwan
Phone: [phone]
FAX: [phone]
User Manual
Version 2.00 March 2013
This document is the current official release manual. Please check CTC Union's website for any
updated manual or contact us by E-mail at [email protected]om. Please address any comments for
improving this manual or to point out omissions or errors to [e-mail]. Thank you.

3
Table of Contents
Chapter 1 Introduction ..............................................................................................................................4
1.1 Features ........................................................................................................................................................ 4
1.2 Specification.................................................................................................................................................. 5
1.3 Applications................................................................................................................................................... 6
Chapter 2 Hardware Installation................................................................................................................7
2.1 Front Panel.................................................................................................................................................... 7
2.2 Rear Panel ................................................................................................................................................... 10
2.3 Installation .................................................................................................................................................. 11
Appendix I................................................................................................................................................12
Appendix II...............................................................................................................................................14

4
Chapter 1 Introduction
100M VDSL2Ethernet Extender is a high-speed Ethernet Extender with one Ethernet port (RJ-45 connector) and
one VDSL port (RJ-45 connector). It is a bridge mode modem, well accommodating VDSL2 (Very-high-data-rate
Digital Subscriber Loop) technology to extend Ethernet service over single-pair phone line. It is compliant to
ITU-T G.993.2 standard and supports VDSL2 30a profile that features 100Mbps of symmetric data rate over the
existing copper wires. Supporting both symmetric and asymmetric transmission, it can reach up to 100/100 Mbps
bandwidth (line rate) within 300M or 10/10 Mbps (line rate) for 1 Km long range connections. By providing
ultra-high speed, the VDSL2 100M Ethernet Extender makes your telephone line achieve its best performance
than before. It has the advantage of minimum installation time (simply as plug-n-play) and minimum expense by
allowing video streaming and data to share the same telephone pair without interference.
100M VDSL2 Ethernet Extender delivers everything needed to quickly deploy a high-speed IP-based network
for providing high-speed Internet access, video-on demand services and voice services. The resulting compact,
cost-effective form factor offers Systems Integrators, small business owners an attractive Long Reach Ethernet
solution.
1.1 Features
Cost effective bridge function to connect two Ethernet LAN
Support flow control on Fast Ethernet port via PAUSE frame or Back Pressure
IEEE 802.1Q VLAN tag transparent
Easy installation via simple plug-and-play
Selectable CPE and CO mode via DIP switch:
Two working modes are built in the same unit, which keep the flexibility of installation and easy
provision of service but lower inventory of service provider
Selectable VDSL2 profile mode (17a or 30a):
Support up to VDSL2 30a profile to ensure high data rate.
Selectable target band plan:
Symmetric: Support the band plan G.997 and provide the symmetric transmission on both downstream
and upstream.
Asymmetric: Provides highest line rate in short range in asymmetric mode.
Selectable target SNR margin
Compatible with the 724M/708M DSLAM & third party DSLAM.
Compatible with the 2U 19-inch, 17-slot chassis.

5
1.2 Specification
4-position DIP Switch
Selectable CO or CPE mode
Selectable 30a or 17a (VDSL2 Profile)
Selectable Band plan (Symmetric orAsymmetric)
Selectable target SNR margin (6dB or 9dB)
LED:
LAN: ACT/LNK,10/100Mpbs, Half/Full Duplex
VDSL: Power On/Off, CO/CPE, Idle/Trained/Link
Performance* (AWG24 Wire)
Downstream/ Upstream
17a Profile
600M
42/46 Mbps
1000M
18/13 Mbps
1500M
12/3 Mbps
2000M
5/2 Mbps
30a Profile
600M
40/45 Mbps
900M
22/19 Mbps
1200M
16/7 Mbps
1800M
8/2 Mbps
2100M
5/2 Mbps
*The above performance data is for reference only, the actual data rate may vary depending on the quality of the copper wire and
environmental factors.
LAN Interface:
RJ-45 connector
Complying with IEEE
802.3/802.3u/802.3x
10/100 Base-TAuto-Negotiation,
Auto-MDI/MDI-X.
VDSL Interface:
RJ-45 connector
DMT Encoding
Complying with ITU-T
G993.1/993.2/G.997.1
On-board surge protection
Regulatory Compliance
CE
FCC Part 15 Class B
EN60950
Power supply:
DC single 12 Volt over 2.0 mm DC jack;
4.2 Watt maximum.
Dimension: 73.4mm x 96.2mm x 22.8mm
Temperature: 0°C ~45°C
Humidity: 0%~95%RH (non-condensing)

6
1.3 Applications
LAN Extender Application

7
Chapter 2 Hardware Installation
This chapter shows the front panel and how to install the hardware.
2.1 Front Panel
Front panel can be separated into five parts from left to right:
(1) DIP switch
(2) RJ-45 connector for Ethernet
(3) LEDs for Ethernet
(4) LEDs for VDSL
(5) RJ-45 connector for VDSL

8
1. The RJ-45 is designed to connect to the Local Network with the Unshielded Twisted Pair (UTP) cable. The
LEDs on top of RJ-45 connector show the status below:
2.
LEDs for LAN
 blinking
On
 Off
Activity
Link UP
Link UP
100Mbps
10Mbps
Full Duplex
Half Duplex
LED
Color
Status
Descriptions
PWR(Power LED)
Green
On
Lights to indicate that the VDSL2 bridge had power
Green
Off
The device is not ready or has malfunctioned.
LNK(Ethernet LED)
Green
On
The device has good Ethernet connection.
Green
Blinking
The device is sending or receiving data.
Green
Off
The LAN not connected.
LNK RT(VDSL Link)
Green
On
RT mode.
Green
Blinking
Handshaking/Transmit & Received data
Green
Off
The device not ready.
FUL 100(LAN Link)
Green
On
The device is link on 100M Full duplex and ready.
Green
Blinking
The device is sending or receiving data.
Green
Off
The device is link on 10M Full duplex and ready.

9
3. The following table describes the DIP Switches’ setting.
Pin 1
Pin 2
Pin 3
Pin 4
Side
Channel
Rate Limit
SNR
Off
OT
30a
Symmetric
9dB
On
RT
17a
Asymmetric
6dB
Pin 1: OT, RT switch
OT: LAN Extender acts as Central Office (CO) side.
RT: LAN Extender acts as Customer Premise Equipment (CPE) side.
Pin 2: Impulse noise protection
30a: High Speed Mode. Provides communication protection for up to 250ms impulse
noise with latency less than 6 ms.
17a: Long Reach Mode. Direct data transmission with latency less than 1 ms.
Pin 3: Band Plan
Symmetric: Support the band plan G.997 and provide the symmetric transmission on
both downstream and upstream.
Asymmetric: Provides highest line rate in short range in asymmetric mode.
Pin 4: General protection
9dB: Better channel noise protection with SNR up to 9 dB
6dB: Original channel noise protection with 6 dB SNR.

10
4. The following table describes the LEDs’ function of the product.
LEDs for VDSL
 blinking
On
 Off
Device Power ON
Device Power OFF
CPE-mode
CO-mode
Slow: Idle
Fast: Training
Linked
Off line
2.2 Rear Panel
The DC Jack on the rear panel can be connected to power supply adaptor with the DC input.

11
2.3 Installation
Please see the illustration below

12
Appendix I
Connector Architecture
Ethernet Port Connector (RJ-45)
The Ethernet Port interface is an 8 position Modular Jack. The table below displays the pin out assignments.
Pin Number
Assignment (MDI-X)
Figure
1
RX+; Receive data +
1 8
1 8
F r o n t V i e w
Top V i e w
2
RX-; Receive data -
3
TX+; Transmit data +
4
Not used
5
Not used
6
TX-; Transmit Data -
7
Not used
8
Not used

13
VDSL Interface Pin Assignments (RJ-45)
The VDSL interface is standard eight-pin modular jack. The table below displays the pin out
assignments.
Pin Number
Desc r i p t io n
F ig u r e
1
Not used
1 8
1 8
F r o n t V i e w
Top V i e w
2
Not used
3
Not used
4
ANALOG Input/Output
5
ANALOG Input/Output
6
Not used
7
Not used
8
Not used

VDSLLAN
Extender User Manual V200
14
Appendix II
Chassis Accessory
There is also the Chassis solution for application on the rack in CO side. The major
feature of the Chassis is listed below:
• 2U, 19”, 17-Slot rack
• Support 17-slot in one unit
• Power Input: AC: 100 ~240V or DC48: 36 ~ 60V
• Cross flow cooling fan built-in
• 100M units are hot swappable
Specifications
Power Input: AC : 100 ~240V or DC48 : 36 ~ 60V
Power Consumption: >60W
Dimensions: 76 X 212 X 88 mm (D x W x H )
Weight: 7.9Kg
Temperature: 0 ~ 50°C (Operating), -10 ~ 70°C (Storage)
Humidity: 10 ~ 90% non-condensing
Certification; CE, FCC, RoHS Compliant
MTBF: 65,000 hrs
