CTC Union EOC-10 User manual

Ethernet Over Coaxical Cable
Quick Start Guide
8/2008
Ver. 1.0
Table of Contents
Installation Instructions
EOC-10 Non-Managed Stand-Alone
Ethernet Extender over Coaxial Cable
Introduction
Features
Specifications
Installation
Connections
Application Notes
CE Notice
------- 1
------- 2
------- 3
------- 5
------- 5
------- 6
------- 7
Features
 High-Speed 160Mbps communications link over existing Coaxial Cable,
Symmetrical on EoCNA.
 160Mbps@ up to 800 meters (2,624feet), reach down to 4Mbps@ about
1.2Km (4,000feet).
 Operates transparently to higher layer protocols such as TCP/IP.
 Auto-MDIX and Auto-negotiation 10Base-T or 100Base-TX and Full or
Half-Duplex on the Ethernet port.
 Plug and Play design for simple installation, no configuration or
switch setting.
 Status LEDs for simple monitoring of the device and connection status.
Introduction
The EOC-10 is point-to-point EoCNA (Ethernet over Coax Network)
solution that efficiently extends 10/100 Ethernet circuits to over 800
meters (2,624feet) at up to160Mbps using existing coaxial cable.
The EOC-10 will allow Ethernet connectivity in existing facilities
without pulling extra cable. This is perfect solution for home Ethernet
or anywhere coaxial cable already exists. Installation is easy, just
connect a coaxial cable between the “trunk” connections of two EOC-10.
The EOC-10 uses coaxial cable to extend Ethernet connectivity over
existing CCD/CATV cable.
---------1---------

TRUNK DC 5VCATV LAN
PWR Link/ActSyncMode
COAX
LAN
Link/Act
EOC-10
Front Panel of EOC-10
Rear Panel of EOC-10
LED Indicators
EoCNA
Connection CATV Connection Fast Ethernet Connection DC Jack
Specifications
 Network Standards
ITU G.9954，Ethernet Over Coaxial Network (EoCNA)
IEEE802.3 10BASE-T, 10Mbit/s
IEEE802.3u 100BASE-TX, 100Mbit/s, Auto-negotiation
IEEE802.3x Full Duplex and Flow Control
 Protocol:
Transparent to higher layer protocols
 Connectors
Fast Ethernet：One RJ45 Connector
Coax：Two F-Type Female Coax Connectors,
One for EoCNA, the other for TV
 Transmission Power and Spectrum
0 +/-0.5 dBm
12-28 MHZ
 Transmission Speed and Distance
Up to 160Mbps@800 meters
Up to 4000 Feet (-176dBm/Hz Noise Floor)
 Fast Ethernet Interface
10/100 Mbps
MDI/MDI-X Auto Crossover
Priority Base on IEEE802.1p and TCP/UDP port
---------3------------------2---------

Connection
The following example illustrates the connection scheme when connecting
a remote LAN to the central IP network via coaxial cable.
Installation
Connect the Ethernet cable to RJ-45 LAN port. Follow the connection
examples below. Install the EOC modem with the DC power adapter
provided (+5VDC) and connect the adapter to an AC outlet. The EOC-10
modem will sense whether to operate in Half Duplex mode and Link
status will be indicated on the LED.
Specifications (continued)
 Indicators
“Power” LED
EoCNA Link/Act, SyncMode LED
LAN Link/Act LED
 Environmental Conditions
Operating Temperature: 0oC ~ 55oC (32oF~ 131oF)
Storage Temperature: -10oC ~ 65oC (14oF~ 149oF)
Operating Humidity: 10% ~ 90% Non-condensing
 Power Requirement
External Power Supply: 5V DC
Power Consumption: < 3.25 Watts
 Physical Dimension
155mm(W) x 83mm(D) x 30mm(H)
Unit Weight: 300g
 Emissions Compliance
FCC part 15 Class B, CE EN55022/EN55024
CATV
10/100 Fast Ethernet Switch
TV
DC Power DC Power
IP NetworkIP Network
LAN DC 5V
LAN DC 5VTrunk CATV Trunk CATV
Coax
---------5---------
---------4---------

Application Notes
 Extend LAN connectivity to a remote site or between buildings.
 Connect Ethernet in different rooms over existing home coaxial
infrastructure.
 Connect new controller technology on the factory floor using existing
coaxial cable.
 Extend Ethernet connectivity from a backbone network to an isolated
location via coaxial cable.
 Transmit video and traffic controller information over existing coaxial
cable.
Local Side
LAN DC 5V
10/100 Fast Ethernet Switch
Remote Side
LAN DC 5V
10/100 Fast Ethernet Swtich
Remote Side
LAN DC 5V
Splitter
Splitter
CATV
10/100 Fast Ethernet Switch
Trunk CATV
Trunk CATV
Trunk CATV
Figure: EOC-10 Application
CE NOTICE
Marking by the symbol CE indicates compliance of this equipment to the EMC directive of the
European Community.
Such marking is indicative that this equipment meets or exceeds the following technical standards:
EN 55022:1994/A1:1995/A2:1997 Class A and EN61000-3-2:1995, EN61000-3-3:1995 and EN50082-1:1997
