CTC Union EcoLogic S EcoAir Manual

Providing sustainable energy solutions worldwide
162 605 06-2 2021-03-26
Important!
• Read carefully before use, keep for future reference.
• Translation of the original instructions.
Installation and Maintenance Manual
CTCEcoLogic S

162 605 06-2 2021-03-26
Installation and Maintenance Manual
CTCEcoLogic S

4CTC EcoLogic S
Table of Contents
Important to remember! ______________________________________________ 6
Safety instructions _______________________________________________________ 7
1. Design ____________________________________________________________________ 8
1.1 Display unit________________________________________________________8
1.2 Technical data____________________________________________________8
1.3 Scope of delivery _______________________________________________9
2. EcoLogicS areas of use_____________________________________ 10
2.1 Heating systems with/without 3-way valve __________10
2.2 Heat pump for Property Control (BMS) _______________12
3. Detailed menu descriptions _______________________________ 13
3.1 Start menu ______________________________________________________13
Installer ___________________________________________________________________15
3.2 Display____________________________________________________________ 16
3.3 Settings __________________________________________________________18
3.4 Define _____________________________________________________________23
3.5 Service____________________________________________________________24
4. Parameter list ______________________________________________________ 27
5. Electrical installation___________________________________________ 28
5.1 Power supply __________________________________________________ 28
5.2 Communication between EcoLogic and EcoAir/
EcoPart___________________________________________________________ 28
5.3 Outdoor sensor B15 (EcoPart)___________________________ 28
5.4 Thermostat control K26 / control signal external
3-way valve _____________________________________________________28
5.5 Connecting to terminal block and circuit board A5__
29
5.6 Connecting a separate communication cable______ 29
5.7 Connecting control card EcoAir/EcoPart_____________ 30
6. Installation Communication _______________________________ 31
6.1 CTC Remote - Screen Mirroring_________________________ 32
6.2 MyUplink - App________________________________________________32
7. First start______________________________________________________________ 33
7.1 Before first start _______________________________________________33
7.2 First start_________________________________________________________33
8. Operation and Maintenance ______________________________ 34
9. Troubleshooting/
Appropriate measures ________________________________________ 34
9.1 Information messages ______________________________________ 36
9.2 Alarm messages ______________________________________________36
10. Appendix______________________________________________________________ 39
10.1 Types of Operation with CTC EcoEl V2 _______________ 39

5CTC EcoLogic S
You have just purchased a CTC EcoLogic S. Save this
manual containing the installation and maintenance
instructions. You will be able to enjoy the benefits of
your CTCEcoLogicS for many years, and this manual
provides all the information you will need.
CTC EcoLogicS has a control system that:
• allows supplementary heat pumps to be added to
existing systems.
• monitors and controls your heat pump.
• allows for individual settings.
• displays desired values, for instance, temperature
and operating status.
• allows settings to be made in a simple and
structured manner.
Congratulations on your new product!
Thanks to the flexible set-up with clear and simple
options for settings, CTC EcoLogicS is the perfect
solution for adding heat pumps to existing systems.
CTCEcoLogicS is fully equipped for connection with
the CTC EcoAir outdoor air heat pump or CTC EcoPart
ground source heat pump.

6CTC EcoLogic S
Important to remember!
Check the following points in particular at the time of delivery and installation:
• Remove the packaging and check that the product (electrical
connection box and display) has not been damaged in transit. Report
any transport damage directly to the carrier.
• Check for missing parts.
• The product must not be installed where the ambient temperature is
higher than 60°C.
• CTC EcoAir/EcoPart must have software version HP control card
2020-11-01 or later. If the software version is older than this, contact
your installer for information on how to update the software.
• Register your product for warranty and insurance via the website
https://www.ctc-heating.com/customer-service#warranty-registration
No liability is accepted for any misprints. We reserve the right to make design changes.
For your own reference
Fill in the information below. It may come in useful if anything should happen.
Product: Serial number:
Installer: Name:
Date: Tel. no.:
Electrical installer: Name:
Date: Tel. no.:
!
If these instructions
are not followed
during the installation,
operation and
maintenance of the
system, Enertech’s
liability under the
applicable warranty
terms is not binding.
!Information in
this type of box
[!] is particularly
important for
correctly installing
and using the
product.
iInformation in this
type of box [i] is
intended to help
ensure that the
product functions
optimally.

7CTC EcoLogic S
Turn off the power with an omnipolar switch before doing any work on the product.
The product must be connected to protective earth.
The product is classified as IPX1. The product must not be rinsed with water.
When handling the product with a hoist ring or similar device, make sure that the
lifting equipment, eyebolts and other parts are not damaged. Never stand under the
hoisted product.
Never jeopardise safety by removing bolted covers, hoods or similar.
Any work on the product’s cooling system should be carried out by authorised
personnel only.
The product’s electrical systems should only be installed and serviced by a qualified
electrician.
-If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
Safety valve check:
-Safety valve for boiler/system to be checked regularly.
The product must not be started if it is not filled with water; instructions are in the
“Pipe installation” section.
WARNING: Do not switch on the product if there is a possibility that the water in the
heater is frozen.
This device can be used by children from the age of eight years and above and by
people with reduced physical, sensory or mental ability or lack of experience or
knowledge if they have been taught, either with supervision or with the instructions
provided, how to use the device safely and understand the risks involved. Children
should not play with the device. Cleaning and maintenance should not be carried
out by children without supervision.
If these instructions are not followed when installing, operating and maintaining the
system, Enertech’s commitment under the applicable warranty terms is not binding.
Safety instructions

DCB
A
E
8CTC EcoLogic S
1. Design
A USB port
B Power supply display unit/internal communication
C Network connection (Ethernet)
D BMS connection
E Display unit
CTC no. EcoLogic S (EcoAir / EcoPart) 6212576 / 6212593
Supply 24V DC
Outdoor sensor (CTC EcoPart) 2.2 kΩ
Display
Memory
Backup batteries
Clock
4.3 inch colour touchscreen
retains memory during power failure
not required
controlled in real-time
Weight (packaged weight) 0.8 (1) kg
Display dimensions (depth x width x height) 28 x 159 x 160 mm
Enclosure class (IP) IP X1
1.1 Display unit
1.2 Technical data

H
J
GE
F
I
9CTC EcoLogic S
1.3 Scope of delivery
The figure below shows the main components in the EcoLogic delivery.
F Communication cable display unit – heat pump
G Outdoor sensor (applies to connection to heat pump, model CTC EcoPart)
H Installation and Maintenance Manual
I Display unit bracket
J Ferrite

G11
10 CTC EcoLogic S
2. EcoLogicS areas of use
2.1 Heating systems with/without 3-way valve
System description
Thanks to the settings options in EcoLogicS, operation of the heat pump can be adapted to
the existing boiler’s conditions and settings.
The control of the existing heating system manages the distribution of heat and hot water in the
same way as before.
Conditions
The installation must be adapted on a case-by-case basis depending on the conditions of the
existing heating system. It is important that installation is carried out in full accordance with the
respective product’s installation instructions. Refer to the relevant heat pump manual for details
about electrical installation, flow requirements, volume requirements, temperature requirements
and more. In some cases, the existing boiler’s settings may need to be adapted to enable heat
pump installation.
The heat pump’s operating parameters must be adjusted in relation to the existing heating
system setting. The main principle is that EcoLogic S should be the primary heat producer and
receive the start signal before the boiler.
The settings must be adjusted to minimise the need for additional energy. This is done by
setting the heat pump’s heat curve a few degrees higher than the existing boiler’s heat curve.
To optimise the heating circuit, these settings should be subsequently fine-tuned for optimal
functionality under different operating conditions.
Note that EcoLogicS and the heat pump should be considered supplementary to the existing
heating system in terms of safety functions such as additional heat and backup heating
thermostat. These functions will be retained in the existing heating system.
2.1.1 Heat pump for existing heating system (without 3-way
valve)
System description
This type of connection allows a ground source or air/water heat pump to be added to the
existing heating system consisting of, for example, heat pump (exhaust air, ground source),
electric boiler, wood boiler, oil boiler or pellet boiler.
Conditions
The heat pump must be installed, in terms of flow, before the existing heating system.
Preferably by interrupting the return flow from the heating circuit.
Figure: Example of system solution with
heating system without 3-way valve

11CTC EcoLogic S
2.1.2 Heat pump for existing heating system (with 3-way valve
solution)
System description
This type of connection allows a ground source or air/water heat pump to be added to the existing heating
system consisting of, for example, heat pump (exhaust air, ground source), electric boiler, wood boiler, oil
boiler or pellet boiler, with 3-way valve control for DHW production.
Conditions
The heat pump must be installed, in terms of flow, before the existing heating system. Preferably by
interrupting the return flow from the heating circuit. In cases where the 3-way valve is located outside the
heating system, the heat pump must be installed before the 3-way valve.
When the 3-way valve switches to DHW, EcoLogic is signalled to activate a fixed setpoint so that the heat
pump can also be used for hot water production.
2.1.3 Replacing a heat pump connected to CTC EcoEl
System description
For installations where the existing heat pump is connected to the CTC EcoEl V1/V2/V3 electric boiler and
the heat pump needs to be replaced.
Conditions
The existing heat pump will be replaced by the new heat pump. The electric boiler power output is limited
in order to minimise the need for additional energy. To optimise the heating circuit, the heat pump settings
should be subsequently fine-tuned for optimal functionality under different operating conditions.
To disconnect the existing heat pump and convert the electric boiler in order to limit the power output,
refer to Appendix "Types of Operation with CTC EcoEl V2".
Figure: Example of system solution with
heating system with 3-way valve solution
Figure: Examples of system solution
connected to older heating system,
e.g. CTC EcoEl

12 CTC EcoLogic S
2.2 Heat pump for Property Control (BMS)
EcoLogic SCTC Heat Pump
System description
For installations where the heat pump must interact with a property control.
Conditions
EcoLogic S is connected to a local network and control signals to the heat pump are sent
via the BMS interface from the existing property control.
Refer to the "Detailed Menu Descriptions" chapter for information on how to define the
Modbus TCP protocol and the digital BMS input, as well as apply settings for heating and
DHW systems.
Existing property
control
Figure: Example showing heat pump
installed in a system with property control
(BMS).
Router

13CTC EcoLogic S
Control system
EcoLogic S Display
Outside temperature Measured temperature, outdoor sensor.
Brine temperature
Current temperature (2°C) of the brine from the collector in the
liquid/water heat pump and return temperature (-1°C) of the brine
back into the collector hose.
External buffer tank Current primary flow temperature (42 °C) to the tank is shown on
the left. Current return temperature (34 °C) is shown below.
Heat pump, air/water The air/water heat pump is connected to the circuit. The in and
out temperatures of the heat pump are shown on the right.
Heat pump, liquid/water
The liquid/water heat pump is connected to the circuit. The in and
out temperatures of the heat pump are shown on the right at the
buffer tank.
3. Detailed menu descriptions
3.1 Start menu
The system start menu displays an overview of the current operation data.
Depending on which system is defined, the following
symbols may appear on the start menu:
Main menu. Connected heat pump: CTCEcoAir (air/water HP). Main menu. Connected heat pump: CTCEcoAir (liquid/water
HP).

14 CTC EcoLogic S
3.1.1 Control unit EcoLogic S
Menu: "Control unit EcoLogic S".
Click the display symbol in the start menu to view CTC
EcoLogic operation data.
Status HC/Off
Displays the system status.
Primary flow °C 42 (48)
Shows the temperature out to the buffer tank as well as
the setpoint in brackets.
3.1.2 Stored oper. data
Menu: "Control unit / Stored oper. data".
This menu shows cumulative operation values.
The operation values shown in the menu screenshots
are only examples. The historical operational info
presented varies depending on the language choice.
Total operation time h 3,500
Shows the total time the product has been powered.
Operation time /24 h:m 07:26
Shows total operating time during the last 24 hours.
Starts /24 h 15
Shows the number of starts in the last 24 hours.
Total operation time h 1500
Displays the total operating time of the compressor.

http://ctc0040/main.htm”
15CTC EcoLogic S
Installer
This menu contains four sub-menus:
"Display", "Settings", "Define" and "Service".
Menu: "Installer".
Menu: "Installer / System information". To access this menu,
click the "i" button in the lower right corner of the "Installer"
menu.
For "System Information", click the "i" button in the
lower right corner of the screen in the "Installer" menu.
This displays the product serial number, MAC address,
and application and bootloader versions. Click "Legal
Information" to view information regarding third-party
licences.
Use a phone or tablet to scan the QR code, or enter the
address: http://ctcXXXX/main.htm. When your phone/
tablet is connected to your local network, the product
can be used with your device’s touchscreen in the same
way as the product’s screen. Also refer to the "CTC
Remote - Screen Mirroring" chapter

16 CTC EcoLogic S
Menu: "Installer / Display / Language".
3.2 Display
Menu: "Installer / Display".
Menu: "Installer / Display / Time".
Time, language and other screen settings can be carried
out from this menu.
3.2.1 Time
Time and Date
Click on the time symbol.
The menu can also be accessed by clicking the date or
time in the upper right corner of the start screen.
Press "OK" to highlight the first value and use the arrows
to set the time and date.
DST (On, Active)
The left value can be set. "On" means the time is
adjusted according to Summer Time.
The right value is fixed and shows the current status (for
example, "Off" during the winter period). The display
does not need to be connected to power for the values
to be adjusted, since this occurs at the next start-up.
SNTP
Menu option "On" retrieves the current time from the
internet (if online). More settings options can be found
in the "Installer / Settings / Communication / Internet"
menu.
3.2.2 Language
Click a flag to select the language. The language
selected is highlighted with a green square.
To view more language options than those shown in the
menu, scroll down the page, or press the down arrow
key.

17CTC EcoLogic S
3.2.3 Display setup
Sleep delay 120 (Off, 1...360)
Enter the time in minutes before the display enters sleep
mode if not touched. Settings can be applied in 10min.
intervals.
Backlight 80% (10...90)
Set the brightness of the backlit display.
Click sound Yes (Yes/No)
Enable or disable button sounds.
Alarm sound Yes (Yes/No)
Enable or disable alarm sounds.
Time zone, GMT +/- +1 (-12...14)
Set your time zone (relative to GMT).
Lock code 0000
Press "OK" and use the arrows to set a 4-digit lock
code. If a lock code is set, it is shown as four stars.
You will prompted to enter the code when the screen is
restarted.
NB: Make a note of the lock code for your own
reference when you enter it in the menu for the first time.
The serial number of the display (12 digits) can also
be entered to unlock the screen; refer to the chapter
"Installer / System Information" chapter.
The screen can be locked by clicking the product name
in the upper left of the start menu, whereupon you will
prompted to enter the lock code.
A lock code can be deleted by entering "0000" in this
menu instead of the previously specified lock code.
Font size Standard (Small/Standard/Large)
The display’s font size can be changed here.
Menu: "Installer / Display / Display Setup".

18 CTC EcoLogic S
3.3 Settings
3.3.1 Settings Heating Circuit
Menu: "Installer / Settings / Heating Circuit" when controlling
outdoor sensor.
Example
Inclination 50 means that the temperature to the
external heating tank will be 50°C when the outdoor
temperature is -15°C if Adjustment is set to 0. If
Adjustment is set to +5°C, the temperature will
be 55°C instead. For all outdoor temperatures the
inclination is increased by 5°C, i.e. inclination is parallel
displaced by 5°C.
Menu: "Installer / Settings /".
3.3.1.1 Control on outdoor sensor/
inclination
EcoLogic S controls the charging of the external heating
tank based on the set heat curve. The inclination of
the heat curve indicates the temperature to which the
external heating tank must charge at different outdoor
temperatures.
The outdoor sensor used depends on the type of heat
pump connected to the system:
• Liquid/water heat pump (CTC EcoPart): -
packaged outdoor sensor must be installed
(refer to the "Electrical installation/Connecting the
control card EcoAir/EcoPart" chapter)
• Air/water heat pump (CTC EcoAir): -the existing
outdoor sensor of the heat pump is used.
Max primary flow °C 55 (30...80)
Maximum temperature (sensor HPout) permitted out to
the external heating tank.
Min primary flow °C 14 (14...65)
Minimum temperature (sensor HPout) permitted out to
the external heating tank.
Start/stop diff °C 5 (1...30)
This menu is used to set the negative hysteresis before
the heat pump starts charging the external heating
tank after the stop temperature (sensor HPout) has been
reached.
Example: If the stop temperature is 55°C and hysteresis
is set to 5°C in this menu, it means the heat pump will
start charging again when the temperature has dropped
to 50°C.
Inclination °C 50 (25...85)
Inclination indicates the temperature the external heating
tank needs at different outdoor temperatures. More
information about this can be found in the "Your home’s
heating settings" chapter.
The value set in this menu is the outgoing flow
temperature to radiators when the outdoor temperature
is -15°C.

19CTC EcoLogic S
3.3.1.2 Remote control
For external control, the Normally Open (NO) or Normally
Closed (NC) mode is determined first for the external
control signal. This is setting is applied in the "Installer /
Define / Remote Control" menu.
Refer to the "Installer / Define / Remote Control" chapter
for more information on how the remote control function
works.
Ext. control temp °C 30 (30...60)
Select the temperature for the external heating tank for
remote control.
This menu bar is displayed if external control is active
(has been defined).
Ext. control temp DHW °C 30 (30...60)
Select the temperature for the external DHW tank for
remote control.
This menu bar is displayed if external control is active
(has been defined).
Other settings in the menu apply when external control
is not active.
Menu: "Installer / Settings / Heating Circuit" for remote control
of external heating or DHW tank.
Menu: "Installer / Settings / Heating Circuit" for remote control
of external DHW tank.
Adjustment °C 0 (-20...20)
Adjustment means that the temperature level can be
raised or lowered at a specific outdoor temperature.
HP max DHW No (No/Yes)
Specify whether the charging temperature should be
raised to 60°C every fourth time the compressor starts.
HP max DHW can only be selected when external
control is not active.

rps
-25 -20 -15 -10 -5 0 5 10 15 20 25 30
20 CTC EcoLogic S
3.3.2 Settings Heat pump
Compressor Blocked (Permitted/Blocked)
The heat pump is supplied with a blocked compressor.
"Permitted" means that the compressor is allowed to
start.
Stop at outdoor °C -22 (-22...10)
This menu relates to settings for the outdoor
temperature at which the compressor is no longer
permitted to operate. The heat pump starts 2°C above
the set value.
Only applies to air-to-water heat pumps.
Charge pump % 50% (20...100)
The speed of the charge pump is set here.
Refer to the heat pump’s "Installation and Maintenance
Manual" for more information.
Cold temp limit 0 (0...-15)
Temperature limit for "winter power".
When the outdoor temperature is equal or lower (T2),
the compressor speed is adjusted up to speed R2.
Only applies to modulating air-to-water heat pumps.
Max rps 90* (50...120)
The maximum permissible speed of the compressor at
"winter temperature". Sets the compressor’s maximum
speed (R2) at outdoor temperature T2.
Only applies to modulating air-to-water heat pumps.
Warm temp limit 20 (0...20)
Temperature limit for "summer power". When the
outdoor temperature is equal or higher (T1), the
compressor speed is adjusted down to speed R1. The
heat pump starts and stops at the actual value and
setpoint value.
Only applies to modulating air/water heat pumps.
Max rps warm temp 50 (50...120)
The maximum permissible speed of the compressor
at "summer temperature". Sets the compressor’s
maximum speed (R1) at outdoor temperature T1.
Only applies to modulating air/water heat pumps.
Compressor stop at brine °C -5 (-7...10)
Specify the brine temperature at which to stop the
compressor.
Only applies to liquid/water heat pumps.
Outdoor °C
The diagram shows that the compressor speed is controlled
according to the outside temperature.
When the outside temperature is below T2, the compressor
speed adjusts up to R1.
When the outside temperature exceeds T1, the compressor
speed adjusts down to R1.
These temperature and speed limits are set in the menus on
the left.
*The value may vary depending on the heat pump model.
Menu: "Installer / Settings / Heat Pump".
