Installation- and Maintenance Manual
CTC EcoAir 510M
Modulating air/water heat pump
400 V 3N~
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE

Installation and Maintenance Manual
CTC EcoAir 510M
Modulating air/water heat pump
400 V 3N~

4CTC EcoAir 510M 400V 3N~
No liability is accepted for any misprints. We reserve the right to make design changes.
Quick reference
Fill in the information below. It may come in useful if anything should happen.
Product: Manufacturing number:
Installer: Name:
Date: Tel. no.:
Electrical installer: Name:
Date: Tel. no.:
Table of Contents
Checklist _____________________________________________________________________ 7
1. Technical data______________________________________________________ 8
1.1 Sound pressure data________________________________________ 8
1.2 Dimensional drawing ________________________________________ 9
1.3 Refrigerant system _________________________________________ 10
1.4 Operating range ____________________________________________ 10
1.5 Component location_______________________________________ 12
2. Important to remember! ____________________________________ 14
2.1 Transportation _______________________________________________ 14
2.2 Positioning____________________________________________________ 14
2.3 Recycling _____________________________________________________ 14
2.4 After commissioning_______________________________________ 14
3. Installation__________________________________________________________ 15
3.1 Delivery includes____________________________________________ 15
3.2 Placement of the heat pump____________________________ 16
3.3 Preparation and drainage _______________________________ 17
3.4 Condensation water _______________________________________ 18
4. Pipe installation _________________________________________________ 19
4.1 Pipe connection ____________________________________________ 19
4.2 Example of connection to CTC EcoZenith i350 L 20
4.3 Circulating pump – heat carrier ________________________ 21
4.4 Pressure differential diagram CTC EcoAir 510M__ 21
5. Electrical installation _________________________________________ 22
5.1 General ________________________________________________________ 22
5.1.1 Electrical installation 400 V 3N~ ___________________ 22
5.1.2 Communication connections________________________ 22
5.1.3 Compressor heater_____________________________________ 22
5.1.4 Termination with a heat pump_______________________ 22
5.2 Wiring diagram 400 V 3N~ (A4)________________________ 23
5.3 Wiring diagram 400 V 3N~ (A3)________________________ 24
5.4 Parts list _______________________________________________________ 26
5.5 Sensor Data__________________________________________________ 27
6. First start____________________________________________________________ 28
7. Operation and Maintenance______________________________ 29
8. Troubleshooting/appropriate measures ___________ 31

5
CTC EcoAir 510M 400V 3N~
Safety instructions
!Information in this type of box [!] is particularly important for correctly installing and
using the product.
Turn off the power with an omnipolar switch before doing any work on the
product.
The product must be connected to protective earth.
The product is classified as IPX4.
When handling the product with a hoist ring or similar device, make sure that
the lifting equipment, eyebolts and other parts are not damaged. Never stand
under the hoisted product.
Never jeopardise safety by removing bolted covers, hoods or similar.
Any work on the product’s cooling system should be carried out by authorised
personnel only.
The product’s electrical systems should only be installed and serviced by a
qualified electrician.
The product must not be started if it is not filled with water; instructions are in
the “Pipe installation” section.
WARNING: Do not switch on the product if there is a possibility that the water in
the heater is frozen.
This device can be used by children from the age of three years and above and
by people with reduced physical, sensory or mental ability or lack of experience
or knowledge if they have been taught, either with supervision or with the
instructions provided, how to use the device safely and understand the risks
involved. Children should not play with the device. Cleaning and maintenance
should not be carried out by children without supervision.
If these instructions are not followed when installing, operating and maintaining
the system, Enertech’s commitment under the applicable warranty terms is not
binding.

6CTC EcoAir 510M 400V 3N~
General Information
The Complete System
CTC EcoAir 510M
CTC EcoAir 510M is a modulating air source heat pump
that takes heat from the outside air and supplies it to the
existing heating system in the house. The heat pump
works with outdoor temperatures down to -22°C.
The CTC EcoAir 510M has been designed to operate
with high efficiency and low noise levels. The heat pump
has integrated hot gas defrosting which keeps the
evaporator coil free from ice to maintain high efficiency.
Control
CTCEcoAir520M is controlled by these products.
• CTCEcoZenithi250
• CTCEcoZenithi350
• CTC EcoVent i 350 F
Ecodesign information relating to the current
combination (current package) can be downloaded from
www.ctc.se/ecodesign. Energy labelling stickers can
also be printed from here.

7
CTC EcoAir 510M 400V 3N~
General Information
Checklist
The check list must be completed by the installer.
• If service is needed, you may be required to provide this document.
• Installation must always be done according to the installation and maintenance instructions
• Installation must always be carried out in a professional manner
Following installation, the unit must be inspected and functional checks performed as
indicated below:
Pipe installation
Heat pump filled, positioned and adjusted in the correct manner according to the instructions.
The heat pump should be positioned so that it can be serviced
Capacity of the charge/radiator pump (depending on type of system) for the flow required.
Open radiator valves (depending on type of system) and other relevant valves.
Tightness test
Bleed the system
Check proper operation of the requisite safety valves
Action taken to deal with condensation water
Electrical installation
Power switch
Correct tight wiring
Requisite sensors fitted
Heat pump activated and started
Accessories
Information for the customer (adapted to current installation)
Start-up with customer/installer
Menus/controls for selected system
Installation and maintenance manual supplied to the customer
Check and filling, heating system
Information on fine adjustments
Alarm information
Functional test of safety valves fitted
Information on procedures for fault registration
______________________________________ ______________________________________
Date / Customer Date / Installer

8CTC EcoAir 510M 400V 3N~
CTC EcoAir 510M 53.5 dB(A) 30-33 dB(A) 24-27 dB(A)
CTC EcoAir 510M
400V 3N~ 50Hz
kW 0.47 / 2.28
kW 2.5 / 6.33
COP 1) 5.31 / 2.78
A 8.5
A 2.7 A
L 1.9
kg 2.2
ton 3.903
bar 31
bar 2.5
mm 545 x 1245 x 1080
Inverter scroll / PVE FV50S
m3/h 3800
rpm
W 73
kg 126
dB(A) 55.9/53.5
IPX4
Electrical data
Input power 1)
Output power 1)
Rated current 2)
Max start current
Water volume
Refrigerant quantity (R407C, fluorinated
greenhouse gases GWP 1774)
CO2 equivalent
High pressure switch
Max. operating pressure water (PS)
Dimensions (D x W x H)
Compressor / Oil type
Air flow 100%
Fan speed Modulating
Fan, max power
Weight
Sound power 3)
IP class
1) At 35°C water temperature. +7 @ 20 rps / -7 °C @ 90 rps. According to EN 14511.
2) At 120 rps (from factory max 90 rps). Incl. Grundfos UPM GEO 25-85 charge pump.
3) Sound power level in accordance with EN12102/ISO3741 at test conditions A7 W47/55 and A7 W30/35
No annual leakage control of the refrigerant is required
Sound power Sound pressure 5 m * Sound pressure 10 m *
1. Technical data
!Note: In case of deviations, the product's data plate
applies. When servicing always check the product's
data plate for correct refrigerant quantity.
* The sound specified should be regarded as an indication since the level
is affected by the compressor’s and the fan’s speed, as well as the
surroundings. The upper value corresponds to 100% reflecting ground and
walls (smooth concrete).
1.1 Sound pressure data

9
CTC EcoAir 510M 400V 3N~
1.2 Dimensional drawing
CTC EcoAir 510M
A 486
B 1155
C 1245
D 188
E 1080
F 308
G 476
H 451
I Ø28
J 85
K 530
L 10
42
A
B
C
D
E
H
L
GF
J
I
K
Top view
L
L
Bottom view

10 CTC EcoAir 510M 400V 3N~
1.3 Refrigerant system
1. Fan
2. Evaporator
3. Air
4. Defrosting sensor (B16)
5. Suctiongassensor (B22)
6. Low pressure sensor (B101)
7. Compressor
8. Hot gas sensor (B21)
9. High pressure switch
10. High pressure sensor (B100)
11. 4-way valve
12. Condenser
13. Primary flow sensor (B1)
14. Return sensor (B7)
15. Drying filter
16. Schrader
17. Expansion valve
Heating mode
Defrosting mode
TCE
16
16
1 2
3
17 15
14
13
6
5
7
12
4
9 10
11
8
Refrigerant system CTC EcoAir 510M
1.4 Operating range
The control system for the CTC EcoAir 510M monitors and ensures that the
product is working within its operating range.
Primary flow Cº
Outside temperature Cº
50
20
60
70
40
30
-25 +25 +35+15+5-5-15
