CTC Union EcoPart i600M Manual

Important!
• Read carefully before use,
keep for future reference.
• Translation of the original
instructions.
Installation and Maintenance Manual
CTC EcoPart i600M
Modulating ground source heat pump
Modell i608M / i612M / i616M
400V 3N~
162 605 20-4 CR00685 2023-06-07

Table of contents
1. Important to remember! ....................................................5
1.1 Transportation................................................................................5
1.2 Positioning.......................................................................................5
1.3 Recycling..........................................................................................5
1.4 After commissioning .....................................................................5
2. Safety instructions...............................................................6
3. Your home's heating installation.......................................7
4. Checklist..............................................................................11
5. Technical data.....................................................................12
5.1 Component location cooling module......................................14
6. Design..................................................................................15
6.1 Measurements..............................................................................16
6.2 Refrigerant system ......................................................................17
6.3 Delivery includes ..........................................................................17
7. Pipe installation .................................................................18
7.1 Detaching the front.....................................................................18
7.2 Pipe connections, heating medium side ................................18
8. Connecting the brine system ...........................................22
8.1 Connections ..................................................................................22
8.2 Brine system schematic diagram.............................................25
9. Electrical installation .........................................................29
9.1 Electrical installation 400V 3N~.................................................29
10. Communication..................................................................30
10.1 Deneandaddressheatpumpsinthecaseofseries
connection.....................................................................................31
11. Wiring diagram .................................................................33
11.1 Cooling module............................................................................33
11.2 Connection table for electrical components,
cooling module.............................................................................34
11.3 Wiring diagram Relay card /1....................................................35
11.4 Wiring diagram Relay card /2....................................................36
11.5 Wiring diagram Extension card /3............................................37
11.6 Wiring diagram Relay card /4....................................................38
11.7 Connection table for electrical components,
relay card and terminal board...................................................39
11.8 Resistances for sensors..............................................................42
12. First start ............................................................................43
13. Operation and Maintenance ............................................44
13.1 Periodic maintenance .................................................................44
14. Troubleshooting/Appropriate measures ........................44
14.1 Air problems..................................................................................44
14.2 Alarm ..............................................................................................44
15. System.................................................................................45
15.1 Heating circuit ..............................................................................45
15.2 DHW................................................................................................48
15.3 Additional heat .............................................................................48
15.4 Solar panels* ................................................................................49
15.5 Recharging bedrock/ground*...................................................50
15.6 Cooling*.........................................................................................51
15.7 Pool*...............................................................................................51
15.8 Active cooling* .............................................................................52
16. Detailed menu descriptions .............................................57
16.1 Start menu.....................................................................................57
16.2 Installation wizard........................................................................58
16.3 Heating/Cooling ...........................................................................59
16.4 DHW................................................................................................63
16.5 Ventilation......................................................................................64
16.6 Weekly program...........................................................................65
16.7 Operation data .............................................................................67
16.8 Display............................................................................................80
16.9 Settings ..........................................................................................82
16.10 Dene .......................................................................................... 109
16.11 Service ......................................................................................... 126
17. Parameter list...................................................................132
18. Operation and Maintenance ..........................................134
19. Troubleshooting/Appropriate measures ......................135
19.1 Information messages............................................................. 137
19.2 Alarm messages........................................................................ 138
19.3 Critical alarms - Risk of freezing............................................. 140
20. Pipe installation ...............................................................142
20.1 System Type 1*.......................................................................... 142
20.2 System Types 2 and 3*............................................................ 147
20.3 System Types 4 and 5*............................................................ 154
20.4 System Type 6*.......................................................................... 162
21. Valves.................................................................................169
21.1 Three-way mixing valve ........................................................... 170
21.2 3-way valves ............................................................................... 171
21.3 Bivalent mixing valve................................................................ 172
22. Electrical installation terminal blocks ...........................173
22.1 High voltage............................................................................... 173
22.2 Communication between CTC EcoPart i600M and
EcoAir / EcoPart......................................................................... 173
22.3 Protection – low voltage (sensor) .......................................... 180
22.4 Install Ethernet cable ............................................................... 184
22.5 Remote - Screen Mirroring ..................................................... 185
22.6 myUplink - App .......................................................................... 185

3
16260542-1
!
1. Disconnect the cooling module’s power
cable connector and hoses.
2. Attach the two carrying handles to the
bottom edge of the cooling module.
3. Remove the cooling module xing screws. 4. To pull out the cooling module, rst lift the
module slightly upwards using the carrying
handles.
5. Lift the cooling module using the carrying
handles and shoulder straps.
6. Lift the cooling module into the product
using the carrying handles and shoulder
straps. Remove the carrying handles and
reconnect the power cable, hoses and
screws.
Removing the cooling module
• Any work on the product’s cooling system should be carried out by authorised personnel only.
• Close the safety switch before doing any work on the product.

4
16260556-1
Congratulations on your new product!
The complete heat pump for rock, ground or lake
The CTC EcoPart i600M is a modulating heat pump which
takes heat from bedrock, ground or watercourses, and
delivers it to the house’s existing heating circuit.
The CTC EcoPart i600M has a built-in, energy-ecient (A
rated) circulation pump for connection to the ground/
bedrock circuit, i.e. the cold side. This can be connected to
either the left, right or back of the heat pump, whichever
suits you best.
The CTC EcoPart i600M has a control system that:
• monitors all heat pump functions.
• allows for individual settings.
• Displays desired values, such as temperatures,
operation times, energy consumption and fault
signals
• facilitates the setting of values and
troubleshooting in a simple and well-structured
way.
Easily accessible electrical components and cooling
modules, along with effective troubleshooting functions
in the control program, make the CTC EcoPart i600M easy
to service.
To make installation easier, especially when replacing an
existing heat pump, the product is equipped with a 3-way
valve and double primary ow pipes for heating and hot
water respectively.
The CTC EcoPart i600M is available in three versions:
CTC EcoPart i608M, CTC EcoPart i612M and CTC EcoPart
i616M.
If the CTC Expansion accessory has been installed,
additional functions can be dened. These functions are
marked with an (*) in this Installation and Maintenance
Manual.
!NB: This installation manual contains
information about technical data,
operation, installation, etc. Local
regulations or country-specic regulations
must be taken into account.

5
16260543-1
1. Important to remember!
Check the following points in particular at the time of delivery and installation:
1.1 Transportation
• Transport the heat pump to the installation
location before removing the packaging. Move
the product using one of the following means:
•Forklift
•Lifting band around the pallet. NB: Can only be
used with the packaging on.
• The heat pump must be transported and stored
upright.
1.2 Positioning
• Remove the packaging and check before
installation that the product has not been
damaged in transit. Report any transport
damage to the carrier.
• Place the product on a solid foundation,
preferably concrete.
If the heat pump needs to be placed on a soft
carpet, base plates must be placed under the
adjustable feet.
• Remember to leave an access and service area of
at least 1 metre in front of the heat pump.
• The heat pump must not be placed below oor
level.
1.3 Recycling
• The packaging must be deposited at a recycling
station or with the installation engineer for
correct waste management.
• Obsolete products must be disposed of
correctly and transported to a waste station or
distributor/retailer offering this service.
Do not discard the product with household
waste. It is imperative that the product’s
refrigerant, compressor oil and electric/
electronic components are disposed of correctly.
1.4 After commissioning
• The installation engineer advises the property
owner on the design and servicing of the system.
• The installation engineer lls in a checklist
and contact information – the customer and
installation engineer sign the list, which the
customer keeps.
• Register the product for warranty and insurance
via the website
https://www.ctc-heating.com/customer-
service#warranty-registration
For your own reference
Fill in the information below. It may come in useful if anything should happen.
Product: Serial number:
Installer: Name:
Date: Tel. no.:
Electrical installer: Name:
Date: Tel. no.:
No liability is accepted for any misprints. We reserve the right to make design changes.
When contacting CTC, always mention the
following:
• Serial number
• Model/Size
• Fault message shown in the display
• Phone number !Information in this type of box
[!] is particularly important for
correctly installing and using
the product.
iInformation in this type of box
[i] is intended to help ensure
that the product functions
optimally.

6
16260544-1
2. Safety instructions
Turn off the power with an omnipolar switch before doing any work on the
product.
The product must be connected to protective earth.
The product is classied as IPX1. The product must not be rinsed with water.
When handling the product with a hoist ring or similar device, make sure that
the lifting equipment, eyebolts and other parts are not damaged. Never stand
under the hoisted product.
Never jeopardise safety by removing bolted covers, hoods or similar.
Any work on the product’s cooling system should be carried out by authorised
personnel only.
Installation and connection in the product must be carried out by a
authorised electrician. All piping must be installed according to the applicable
requirements.
Service of the product’s electrical system must only be carried out by a
qualied electrician in compliance with the specic requirements of the
national standard for electrical safety.
Replacement of damaged supply cable, must be carried out by the
manufacturer or qualied service engineer to avoid risk.
Safety valve check:
-Safety valve for boiler/system to be checked regularly.
The product must not be started if it is not lled with water; instructions are in
the “Pipe installation” section.
WARNING: Do not switch on the product if there is a possibility that the water
in the heater is frozen.
This device can be used by children from the age of eight years and above and
by people with reduced physical, sensory or mental ability or lack of experience
or knowledge if they have been taught, either with supervision or with the
instructions provided, how to use the device safely and understand the risks
involved. Children should not play with the device. Cleaning and maintenance
should not be carried out by children without supervision.
If these instructions are not followed when installing, operating and
maintaining the system, Enertech’s commitment under the applicable
warranty terms is not binding.

7
16260545-1
T °C
3. Your home's heating installation
The House Heating Curve
The heating curve is the central part of the product’s
control system. It is the heating curve which determines
the compensated ow temperature requirements for your
property dependent upon the outdoor temperatures. It
is important that the heating curve is correctly adjusted,
so that you achieve the best operation and economy
possible.
One property requires a radiator temperature of 30 °C
when the outdoor temperature is 0 °C, whilst a different
property requires 40 °C. The difference between different
properties is determined by the radiator surface area, the
number of radiators and how well insulated the house is.
Part of the ”Installer/Settings/Heating Circuit/Heating Circuit 1” menu.
iFor more information on how to set the
heating curve, see section ”Heating curve”
in chapter ” Settings / Heating circuit”.
Menu: ”Installer / Settings / Heating Circuit / Heating Circuit 1/Heating
curve/Fine adjustment".
Menu: ”Installer / Settings / Heating Circuit / Heating Circuit 1/Heating
curve". Active curve: #1.
Adjusting the heating curve
In the ”Heating curve” menu under ”Settings/Heating
circuit”, you can ne adjust the values of the heating
curve for the primary ow temperature in relation to
the outdoor temperature in the graph, as well as set the
values for curve inclination and curve adjustment for the
heating circuit.
See section ”Heating curve” in chapter ”Settings/
Heating circuit” for detailed information.
Ask your installer to help you set these values.
It is extremely important to set the heating curve and, in
some cases, unfortunately, this process may take several
weeks. The best way of doing this, upon the initial start-
up, is to select operation without any room sensor. The
system then operates using the outdoor temperature
reading and the property’s heating curve only.
During the adjustment period it is important
that:
• the night reduction function is not selected.
• all thermostat valves on the radiators be fully
opened. (This is to nd the lowest curve for the
most economical use of the heat pump).
• the outdoor temperature is not higher than
+5 °C.
• the radiator system is operational and correctly
adjusted between different circuits.

8
Adjusting the heating curve
The method described below can be used to adjust the
heating curve correctly.
Adjustment if it is too cold indoors:
• If the outdoor temperature is lower than 0 degrees:
Increase the Inclination value by a couple of degrees.
Wait 24 hours to see if any further adjustment is
required.
• If the outdoor temperature is higher than 0 degrees:
Increase the Adjustment value by a couple of
degrees. Wait 24 hours to see if any further
adjustment is required.
Adjustment if it is too warm indoors:
• If the outdoor temperature is lower than 0 degrees:
Decrease the Inclination value by a couple of
degrees.
Wait 24 hours to see if any further adjustment is
required.
• If the outdoor temperature is higher than 0 degrees:
Decrease the Adjustment value by a couple of
degrees.
Wait 24 hours to see if any further adjustment is
required.
iThe set heating curve always takes priority. The room sensor can only increase or decrease the heat
beyond the set heating curve to a certain extent. Where operating without a room sensor, the selected
heating curve determines the ow temperature supplied to the radiators.
Appropriate Default Values
During installation you can seldom achieve a precise
setting for the heating curve instantly. In this case, the
values given below may provide a good starting point.
Radiators with small heat-emission surfaces require a
higher primary ow temperature. You can adjust the
gradient (heating curve gradient) for your heating system
under the "Installer / Settings / Radiator system" menu.
Recommended values are:
Floor heating only: Inclination 35
Low temperature system: Inclination 40
(well insulated houses)
Normal temperature system: Inclination 50
(factory setting)
High temperature system: Inclination 60
(older houses, small radiators, poorly insulated)

9
Examples of Heating Curves
You can see in the diagram below how the heating curve
changes with different Inclination settings. The gradient
of the curve shows the temperatures that the radiators
require at different outdoor temperatures.
Primary Flow Temperature
Primary Flow Temperature
Primary Flow Temperature
Outside Temperature
Outside Temperature

Outside Temperature
Adjustment
The curve can be parallel displaced (adjusted) by the
desired number of degrees to adapt to different systems/
houses.
An example
Inclination 60 °C
Adjustment 0 °C
In this example, the maximum outgoing primary ow
temperature is set at 55 °C.
The minimum permitted primary ow temperature is
27 °C (e.g. summer-time basement heating or the oor
circuits in a bathroom).




iIf the values set are too low, this may mean that the desired room temperature is not being reached.
You then need to adjust the heating curve, as necessary, following the method shown above.

Curve Inclination
The inclination value which is set is the primary ow
temperature when the outside temperature is –15 °C.

10
ºC
ºC
Summer season
All properties have internal heat gains (lamps, oven,
body heat, etc.), which means that the heating can be
switched off when the outdoor temperature is lower than
the desired room temperature. The better insulated the
house is, the earlier the heating from the heat pump can
be switched off.
The example shows the product set at the default value of
18°C. This value, "Heating off, outside", can be changed
in the "Installer / Settings / Heat circuit" menu.
In systems with a radiator pump, the radiator pump
stops when the heat is switched off. The heating starts up
automatically when it is required again.
See chapter ”Settings/Heating circuit” for information on
setting the heating mode.
Outside Temperature

Primary Flow Temperature Heating
switched off
Heating up
Part of the ”Installer/Settings/Heating Circuit/Heating Circuit 1” menu.

11
16260546-1
4. Checklist
The checklist must always be completed by the installation engineer
• If service is needed, you may be required to provide this document.
• Installation must always be carried out according to the installation and maintenance
instructions.
• Installation must always be carried out in a professional manner.
Following installation, the unit must be inspected and functional checks performed as
indicated below:
Pipe installation
Heat pump lled, positioned and adjusted in the correct manner according to the instructions.
The heat pump is positioned so that it can be serviced.
Capacity of the charge/radiator pump (depending on type of system) for the ow required.
Open radiator valves (depending on type of system) and other relevant valves.
Tightness test.
Bleed the system.
Check proper operation of the requisite safety valves.
Requisite waste pipes connected to the oor drain (depending on type of system).
Electrical installation
Power switch.
Correct tight wiring.
Requisite sensors tted.
Accessories.
Customer information (adapted to the relevant installation)
Start-up with customer/installer.
Menus/controls for selected system.
Installation and maintenance manual supplied to the customer.
Check and lling, heating circuit.
Information on ne adjustments.
Alarm information.
Functional test of safety valves tted.
Review warranty terms and conditions with the customer.
Register your Installation certicate at ctc-heating.com.
Information on fault reporting procedures.
___________________________________________________________ ______________________________________________________________
Date/Customer Date/Installer

12
16260547-1
EP i608M EP i612M EP i616M
CTC nr. 588601001 588601002 588601003
400V, 3N~, 50Hz
kW 3.1 5.34 7.0
kW 10.5 15.7 17.1
A 4.82 8.9 11.7
A 15.2 22.7 24.7
kW 2.1 / 2.1 / 5.8 / 5.8 / 5.8 0.3 / 0.9 / 2.1 / 7.2 / 9 - / 0.3 / 0.9 / 2.1 / 9
A 16 25 25
A 10
A 4
A 2.3 2.3 1.8
kW 0.3-5.8 0.3-9.0 0.3-9.0
IP X1
HP Keymark Certificate 012-C700085 012-C700087 012-C700088
EP i608M EP i612M EP i616M
°C 100
°C 65
l/s 0.12 0.20 0.27
l/s 0.29 0.26 0.52
kPa 47 52 58
EP i608M EP i612M EP i616M
@B0/W35 | B5/W35 | B10/W35 kW 6.08 I 7.10 I 8.10 10.52 I 12.26 I 13.95
@B0/W35 | B5/W35 | B10/W35 kW 1.27 I 1.26 I 1.26 2.34 I 2.42 I 2.56
COP 1) @B0/W35 | B5/W35 | B10/W35 - 4.78 I 5.62 I 6.45 4.50 I 5.07 I 5.46
Electrical data
Rated electrical data
Rated power cooling module
Rated power input
Rated current cooling module
Rated current
Max immersion heater output
@ fuse size 10 / 13 / 16 / 20 / 25 A
Group fuse
Total max load relay card*
Max load relay output
Max. start current
Output range immersion heater (min-max)
Ingress Protection (IP)
Heating system
Max. temperature (TS)
Max. operating temperature condenser
Flow qw min. B0/W35, ∆t = 15K @max rps
Flow qw nominal B0/W35, ∆t = 5K
Max ext available pressure head, nom flow
Pressure drop See diagram in chapter "Pipe installation".
Operational data for heat pump
Heating capacity 1)
Power input 1)
1) EN14511:2018, nominal value.
*Note! Observe the maximum group fuse size for the product.
5. Technical data

13
EP i600M
mm 28
mm 28
mm 28
mm 28
EP i608M EP i612M EP i616M
kg 2.4 2.4 2.2
ton 4.258 4.258 3.903
MPa 3.1
kg 230 / 207 230 / 207 233 / 210
mm 673 x 596 x 1632
mm 1700
dB(A) 34 / 34 39 / 41 42 / 42
dB(A) 29 34 37
EP i608M EP i612M EP i616M
l 4.1
°C -5 / +20
bar 0.2/3.0
l/s 0.205 0.27 0.42
l/s 0.39 0.32 0.58
kPa 113 113 116
Other data
Refrigerant quantity (R407C, fluorinated greenhouse
gases GWP 1774)
CO2equivalent
Interrupt value switch HT
Weight with / without packaging
Dimensions (Depth x Width x Height)
Required ceiling height
Sound power (LWA) acc. to EN 12102 @B0, W35/55
Noise pressure (LPA)1m B0/W35 (EN ISO 11203)
Brine system
Water volume (V)
Brine system min/max temp (TS)
Brine system min/max pressure (PS)
Flow qc minimum B0/W35, ∆t = 6K
Flow qc nominal B0/W35, ∆t = 3K
Pump capacity See diagram in chapter "Pipe installation".
Ext available pump pressure nominal flow
No annual leakage control of the refrigerant is required.
Pipe connections
Brine circuit, ext. diam. Cu piping (flexible hose)
Heating medium, ext. diam. Cu piping
Hot water supply, ext. diam.
Cold water supply, ext. diam.

14
23
23
1
1
4
5
7
810
9
12
11
18
22
32
6
13
14
15
16
17
19
21
20
24
5.1 Component location cooling module
1. Compressor
2. Evaporator
3. Condenser
4. Drying lter
5. Expansion valve
6. High pressure switch
7. High pressure sensor
8. Low pressure sensor
9. Drain valve
cold side/Brine
10. Drain valve
warm side/Water
11. Brine pump
12. Charge pump
13. Brine in
Ø28 mm (from rock)
14. Brine out
Ø28 mm (to rock)
15. Heat carrier out
(ow line) Ø22
16. Heat carrier in
(return line) Ø22
17. Discharge sensor
18. Brine sensor in
19. Brine sensor out
20. Suction gas sensor
21. Sensor WP In
22. Sensor WP Out
23. AC-chokes (x3)
24. Sensor, AC choke temp

15
16260548-1
Primary ow,
hot water
Return ow,
heating system
Primary ow,
heating system
Return ow,
hot water
Junction box (A5)
cooling module
Charge pump (G11)
Pump for the hot side
(concealed, placed
behind the junction
box).
Automatic circuit
breakers (F1/F3)
Junction box (A2)
Flow heater
With an electric
heater for additional
heat.
3-way valve
Flow conditioner.
Display unit (A1)
Brine pump (G20)
Brine connections
The brine is connected to
the collector here.
6. Design
The picture below shows the fundamental construction of the heat pump.
Max. thermostat (F10)
Filter ball valve
Connections,
heating medium

16
1840
694
781
1632
20 (12-47)
559
1578
626
673
517
39,5
596
233
91,5
265
103,5
114
180,5
Erfoderlig reshöjd (vid inskruvade ställfötter): 1700 mm
E
art. nr
Utgåva
Ämnes nr
Ersätter
art. nr
Ersättes av
Grupp
Produkt
Reg. nr
Benämning
Tol.system
Kontr.
Normgr.
Skala
Ritad
Material
Datum
Sign.
Distr till/Antal
Ytjämnhet RA
Godk. prod
Om ej annat angives gäller ovanstående
Denna ritning är Enertech AB's egendom. Den får ej användas till skada för företagets intressen.
Diese Zeichnung ist das Eigentum der Enertech AB und darf nicht zum Scha- den dieser Gesellschaft verwendet werden.
This drawing is the property of Enertech AB and is not to be used against the interest of this com- pany
1:20
EAN
2021-05-06
EcoPart i600M
EPi600M
4588601
Reservdelsstruktur: 586767-072
SJ
blad 4/4
1840
694
781
1632
20 (12-47)
559
1578
626
673
517
39,5
596
233
91,5
265
103,5
114
180,5
Erfoderlig reshöjd (vid inskruvade ställfötter): 1700 mm
E
art. nr
Utgåva
Ämnes nr
Ersätter
art. nr
Ersättes av
Grupp
Produkt
Reg. nr
Benämning
Tol.system
Kontr.
Normgr.
Skala
Ritad
Material
Datum
Sign.
Distr till/Antal
Ytjämnhet RA
Godk. prod
Om ej annat angives gäller ovanstående
Denna ritning är Enertech AB's egendom. Den får ej användas till skada för företagets intressen.
Diese Zeichnung ist das Eigentum der Enertech AB und darf nicht zum Scha- den dieser Gesellschaft verwendet werden.
This drawing is the property of Enertech AB and is not to be used against the interest of this com- pany
1:20
EAN
2021-05-06
EcoPart i600M
EPi600M
4588601
Reservdelsstruktur: 586767-072
SJ
blad 4/4
1840
694
781
1632
20 (12-47)
559
1578
626
673
517
39,5
596
233
91,5
265
103,5
114
180,5
Erfoderlig reshöjd (vid inskruvade ställfötter): 1700 mm
E
art. nr
Utgåva
Ämnes nr
Ersätter
art. nr
Ersättes av
Grupp
Produkt
Reg. nr
Benämning
Tol.system
Kontr.
Normgr.
Skala
Ritad
Material
Datum
Sign.
Distr till/Antal
Ytjämnhet RA
Godk. prod
Om ej annat angives gäller ovanstående
Denna ritning är Enertech AB's egendom. Den får ej användas till skada för företagets intressen.
Diese Zeichnung ist das Eigentum der Enertech AB und darf nicht zum Scha- den dieser Gesellschaft verwendet werden.
This drawing is the property of Enertech AB and is not to be used against the interest of this com- pany
1:20
EAN
2021-05-06
EcoPart i600M
EPi600M
4588601
Reservdelsstruktur: 586767-072
SJ
blad 4/4
6.1 Measurements

17
1 3 24
5
8
6
7
9 10 11
12 13
1514
16
17
1. Brine (heat source)
2. Water
3. Evaporator
4. Condenser
5. Compressor
6. Expansion valve (electronic)
7. Drying lter
8. Refrigerant heat exchanger
9. Low pressure sensor
10. High pressure sensor
11. High pressure switch
12. Temp suction gas
13. Temp hot gas
14. Temp brine
15. Temp water out
16. Temp water in
17. Control expansion valve
6.2 Refrigerant system
6.3 Delivery includes
• 2 x Angle connection 28x28
• Room sensor
• Outdoor sensor
• 3 x 22k sensor, 5 m
• Ethernet cable, 1 m
• RJ45 connection
• Ferrite 25 MHz 141 Ω
• Level vessel, brine**
• Safety valve 1/2" 3 bar, brine system
• 4 x support sleeves
• Filling kit, brine G25**
• Filling kit, brine G32*
• Edge moulding
• Manometer
• Manifold 921-20
• Safety valve 2.5 bar, ext., heating circuit
• 2 x Handles
• Pipe, brine, short
• Pipe, brine, long
* Applies to CTC EcoPart i616M
** Applies to CTC EcoPart i608M and CTC EcoPart i612M

18
16260549-1
Ändr. meddel. Datum Nr Ändring Ändr. av Kontr. av
E
art. nr
Utgåva
Ämnes nr
Ersätter
art. nr
Ersättes av
Grupp
Produkt
Reg. nr
Benämning
Tol.system
Kontr.
Normgr.
Skala
Ritad
Material
Datum
Sign.
Distr till/Antal
Ytjämnhet RA
Godk. prod
Om ej annat angives gäller ovanstående
Denna ritning är Enertech AB's egendom. Den får ej användas till skada för företagets intressen.
Diese Zeichnung ist das Eigentum der Enertech AB und darf nicht zum Scha- den dieser Gesellschaft verwendet werden.
This drawing is the property of Enertech AB and is not to be used against the interest of this com- pany
1:20
blad 1/1
7. Pipe installation
The installation must be carried out in accordance with the applicable
standards. The product must be connected to an expansion vessel in
an open or closed system. Do not forget to ush the heating circuit
clean before connecting. Apply all the installation settings based on the
description in the section entitled "First start".
7.1 Detaching the front
In order to adjust the pressure in the expansion vessel and check the pipe
ttings before the rst start, the front needs to be dismantled.
1. Remove magnetic strip.
2. Loosen the two screws securing the front to the top cover.
3., 4. Fold out and lift off the front. Set it to one side.
NOTE! Bear in mind that the cable to the display on the front is sensitive
to damage.
7.2 Pipe connections, heating medium side
Route the pipes so that no other highest point is present where air can
collect and obstruct circulation. If this cannot be done, however, provide
this highest point with an automatic bleeder.
7.2.1 Filling valve, heating circuit
Fit a lling valve between the cold water connection and the heating
circuit’s return ow.
7.2.2 Non return valve
Fit the non-return valve to the incoming cold water connection.
7.2.3 Shut-o valves
It is important to t a shut-off valve to the primary ow.
7.2.4 Safety valve
The heat pump’s safety valve (2.5 bar) for the heating circuit must be tted
in accordance with applicable regulations. Connect the waste pipe to the
waste system directly to the oor drain or, if the distance is more than two
metres, to a funnel. The waste pipe must slope towards the waste system,
be installed frost-free and left open to the atmosphere/without pressure.
7.2.5 Manometer – system pressure
Fit a manometer to the expansion vessel or the heating circuit’s return
line.
1. Magnetic strip
2. Screws x 2
3. Fold out front
4. Lift front up
and out
!NB: The waste pipe must
be tted to the waste
system.
!NB: It is important to t
shut-o valves to both
the primary and return
ows.

19
H
5 0.5 0.8 568
10 1.0 1.3 426
15 1.5 1.8 284
7.2.6 Connection of expansion vessel (accessory)
The heat pump is designed to be tted to an 18 l closed expansion vessel.
Install the expansion vessel
1. Attach the supplied bracket to the rear panel on the inner stand. Push
the bracket down so that it attaches to the stand.
2. Insert the expansion vessel into the bracket so that the vessel’s
connection is free to connect to the expansion hose. To connect the
expansion hose to the product, the plug cone must be removed from
the T-connection on the return line.
3. Place the mounting pad between the expansion vessel and the
junction box.
If you are using an open system, the distance between the expansion vessel
and the highest placed radiator must not be below 2.5 m in order to avoid
introducing oxygen into the system.
If the heat pump is connected together with another heat source, e.g. an
existing boiler, the installations must have separate expansion vessels.
7.2.7 Expansion vessel pre-pressure
The pre-pressure in the expansion tank is calculated according to the
height (H) between the highest-positioned radiator and the expansion
tank. The pre-pressure must be checked/set before the system is lled
with water. The system pressure must be set 0.3 bar higher than the pre-
pressure in the expansion vessel. For example, a pre-pressure of 1.0 bar
(10 mvp) means a maximum permitted height difference of 10 m.
The table assumes the installation of the expansion vessel that is
included in the accessory kit for the heat pump.

manometer.
Maximum
height (H) (m)
Pre-pressure
(bar)
System
pressure
(bar)
Maximum
volume in the
heating circuit
(excl. product)
(L)

20
CTC EcoPart i616M
CTC EcoPart i608/612M
7.2.8 Diagram, circulation pumps (charge pumps) (G11)
